4 GLEASON gear cutting machines used machines

CHANGE GEARS

Max. cone distance: 230 mm Number of teeth: 5-150 Diameter of taper hole at large end: 100 mm Taper: 1:19,7 Depth of taper: 150 mm Diameter of hole through spindle: 78 mm Diameter of spindle nose: 140 mm Max. offset above center: 114 mm Max. offset below center: 114 mm Max. distance from machine center to nose of spindle: 343 mm Min. distance from machine center to nose of spindle: 63 mm Cutter speeds: 17-115 rpm Feed (sec/tooth): 9-80 sec Floor space: 1900x2900 mm Net weight: 10750 kg

MAX DIAM 400

MAX DIAM 410

Generating Grinding Machine Grinding Machine Gleason Pfauter G320 CNC + Promot Automation Hersteller [manufacturer]: Gleason Pfauter G320 + with Promot Automation handling unit Type [ type]: G 320 Control unit: Siemens 840 Incl. control panel Baujahr[construction year]: 10/2001 Module [ ]: 0.5-7.0 Min. workpiece diameter [ ]: 10 mm Max. workpiece diameter [ ]: 380 mm Number of teeth [ ]: 10-600 Vertical carriage stroke "Z" [ ]: 200mm Horizontal carriage stroke "X" [ ]: 230mm Tangential carriage stroke (SHIFTING) "Y" [ ]: 135mm Swivel angle clamping head "A" [ ]: +-45° Tailstock tip stroke [ ]: 125mm tangential slide stroke – dressing [ ]: "V" 180mm radial carriage stroke – dressing [ ]: "U" 110mm Rotation speed – grinding wheel in progress [ ]: 3000rpm max - infinitely variable Egg speed - linear axes [ ]: 10000 mm/min Max. table rotation speed [ ]: 240 RP ...

max. machining diameter: 3200 mm max. workpiecediameter: 3200 mm axial slide way: 2200 mm control: Siemens Sinumerik 840 D table diameter: 2500 mm boring diameter: 800 mm max. load: 40.000 kg table rotation speed: 2 U/min grinding head: grinding head - swivable: +45 / - 45 ° turning speed range - grinding wheel: 270 - 2700 U/min tip circle diameter: min. 1500 mm grinding spindel dia.: 100 mm Max. grinding wheel diameter: 450 mm Dressing diameter: min. 250 mm Planing width: min. 80 mm Fast feed speed: axial: 10 m/min Fast feed speed: radial: 3 m/min max. depth of profile: 100 mm tail stock: tailstock travel: 1410 mm total power requirement: 225 kVA weight of the machine ca.: 46 t dimensions of the machine ca.: 14,5 x 9,95 x 6,1 m Gear Profil-Grinding Machine - CNC Control Siemens 840D - Tailstock - Dressing Unit - Oil Mist suction - Coolant The data for this ad was created with Modul ...

max. wheel diameter: 100 mm gear width: 26 mm max. module: 31 min. module: 0,1 Control: Siemens 840 D SL total power requirement: 45 kW weight of the machine ca.: 7 t dimensions of the machine ca.: 4x3x2,5 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ ...

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mm tooth width max.: 58 mm spindle speeds (infinitely variable): 6000 U/min work piece spindle speed: 1200 U/min diameter of tools max.: 230 mm diameter of tools min: 69,85 mm x-axis: 325 mm y-axis: 350 mm z-axis: 470 mm b-axis: + 90,1 / - 1 ° work piece table - Ø: 212,71 mm Control: SIN 840 D SIEMENS total power requirement: 75 kW weight of the machine ca.: 10.000 Kg dimensions of the machine ca.: 6,10 x 4,40 x 3,30 m coolant filtering unit Hoffmann HSF 100 V The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 900 mm y-travel: 300 mm z-travel: 1000 mm control: Siemens Sinumerik 840D max. workpiece diameter: 1600 mm max. module: 20 mm tip circle diameter: 350 mm Milling arbour diameter: 375 mm Total closing value: 80 kVa weight of the machine ca.: 33,5 t dimensions of the machine ca.: 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter nominal: 2400 mm max. workpiece diameter: 2800 mm max. module: 30 mm control: Siemens Sinumerik 840 D dividing plate diameter: 2200 mm table diameter: 2500 mm Table hole Diameter / depth: 800 / 875 mm max. table load: 40000 kg Table rpm: 4,5 min-1 clamping length max.: 375 mm clamping diameter max.: 350 mm cutter diameter max.: 2800 mm Cutter arbor cone: HSK-B160 swivelling range milling head: + 30/-45° Distance Cutter - Workpiece: 615 / 1600 mm weight of the machine ca.: 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction - technical Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mm tooth width max.: 58 mm spindle speeds (infinitely variable): 6000 U/min work piece spindle speed: 1200 U/min diameter of tools max.: 230 mm diameter of tools min: 69,85 mm x-axis: 325 mm y-axis: 350 mm z-axis: 470 mm b-axis: + 90,1 / - 1 ° work piece table - Ø: 212,71 mm Control: SIN 840 D SIEMENS total power requirement: 75 kW weight of the machine ca.: 10.000 Kg dimensions of the machine ca.: 6,10 x 4,40 x 3,30 m Internal probe Renishaw LP2 (axis X2,Y2) Hoffmann coolant filter system HSF 100SE/K (built in 2008) Tank capacity 2500L VT oil mist filter system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cone distance min./max.: 0-108 mm Pitch angle min/max: 5°/84° Control: GE Fanuc Series 0-GC Pitch diameter (1:1 ratio): 152 mm pitch diameter (10:1 ratio): 216 mm Diametral pitch (finest/coarsest): 1.3/8.5 Mod. Face width gear wheel max.: 35 mm Knife spindle - Speed range: 41-121 U/min working spindle speed range: 0-33.33 U/min weight: 9025 kg dimensions of the machine ca.: 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: -Knife -Chip conveyor -Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mm diameter of tools min: 69,85 mm tooth width max.: 58 mm diameter of tools max.: 230 mm x-axis: 325 mm y-axis: 350 mm z-axis: 470 mm work piece table - Ø: 212,71 mm b-axis: + 90,1 / - 1 ° Control: 160 i - MB FANUC total power requirement: 75 kW weight of the machine ca.: 10.000 Kg dimensions of the machine ca.: 6,10 x 4,40 x 3,30 m WAGURI With EWAB robot cell (KUKA robot) without coolant filter system Fire extinguishing system without CO2 bottles Cooling oil return with various pumps / collecting basins Threading device A1/B2 axes with measuring probe Clamping device for a pinion shaft External spindle oil cooler Extraction system pinion shaft The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ratio of transmission: 10:1 min. number of teeth: 3 max. number of teeth: 200 range of tooth size: 20 mm tooth width max.: 58 mm diameter of tools min: 69,85 mm diameter of tools max.: 230 mm x-axis: 325 mm y-axis: 350 mm z-axis: 470 mm work piece table - Ø: 212,71 mm b-axis: + 90,1 / - 1 ° Control: SIN 840 D SIEMENS total power requirement: 75 kW weight of the machine ca.: 10.000 Kg dimensions of the machine ca.: 6,10 x 4,40 x 3,30 m WAGURI with EWAB load cell built in 2012 (Linear loader) no coolant filter system available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 406,4 mm gear width: 66 mm max. module: ca. 12,5 min. module: Control: Zyklengesteuert total power requirement: 21 kW weight of the machine ca.: 12,5 t dimensions of the machine ca.: 3,3 x 2,5 m The GLEASON 641 G-PLETE bevel gear generating machine is a proven and robust solution for the production of spiral bevel gears, hypoid gears, and Zerol bevel gears usingthe well-established Gleason generating method. Designed for reliable and repeatable machining processes, this machine is ideally suited for small to medium batch production in industrial gear manufacturing. The 641 supports both roughing and finishing operations in a single setup (completing process), ensuring consistent gear quality while reducing handling time. Its mechanical generating system with variable roll ratio and plunge feedmechanism allows precise control of the tooth geometry, making it a depend ...

max. wheel diameter: 3000 mm gear width: 1200 mm max. module: 30/40 min. module: 2 table diameter: 2500 mm table load capacity: 400 kN hob dia. - max.: 450 x 500 mm milling spindle speeds: 10 - 165 U/min hob length max.: 500 mm tip circle diameter: 2050 mm tooth helical angle min/max: 0 - 45 ° center distance betw. workpiece-tool min/max.: 150 - 1750 mm milling slide swivelling: 50 Grad distance table / counter stay: 1050 - 2050 mm shifting: 300 mm workpiece weight: 40 t table bore diameter: 800 mm depth of hole: 1100 mm main drive motor: 37 kW min. workpiece diameter: 290 mm min. number of teeth: Wälzfräsen 20 min. number of teeth: Formfräsen 2 taper: MK 100 feeds axial: 1 - 1800 mm/min radial feed: 1 - 500 mm/min feed: Tangential 1 - 450 mm/min rapid traverse: 1875 / 530 / 470 mm/min electrics - voltage/frequency: 380 / 50 V/Hz control: Siemens Sinumerik 3M total power requirement: ...

Max working diameter 660,4 mm Module max 16,9 Working width 106,7 mm Min. max no. of teeth 20 - 75 Machine weight 17700 Kg Equipped with Indexing discs Cutter heads Gauge Blade setting device

max. wheel diameter: 1010 mm gear width: 0 mm max. module: min. module: total power requirement: 15 kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: m Max. depth of tooth 10 mm Max. workpiece Ø (for clearance) 1,010 mm Max. external Ø of coupling 610 mm Sliding base withdraw 216 mm Max. distance from grinding wheel to workpiece nose 90 - 430 mm Max. weight of workpiece, including clamp 500 kg No. of teeth 32 to 150 Grinding wheel Ø, approx 152 - 320 mm Grinding wheel speeds, infinitely variable 0 - 3,600 rpm Work spindle bore 60 mm Total electrical load, approx. 15 kW - 380 V - 50 Hz Weight, approx. 9,500 kg Accessories / Special Features * Automatic roughing and finishing process via pre-settable counter and built-in feed cam. * Counter for number of teeth. * Counter for number of dressing cycles. * 2 built-on dressing units with three dressing diamonds for r ...

max. wheel diameter: 215 mm gear width: 40,65 mm max. module: total power requirement: 20 kW weight of the machine ca.: 10 t Max. external Ø of workpiece 215 mm Tooth profile, height x width 16 x 40.65 mm No. of teeth 5 - 200 Max. tooth ratio 1 : 10 Grinding wheel Ø 51 - 190 mm Grinding wheel speeds 1,000 - 6,000 rpm X Axis (horizontal) 152 mm Y Axis (vertical) 178 mm Z Axis (slide base plate) 304 mm Distance from middle of machine to middle of workspindle 115 mm Axial speed 125 mm/sec Workpiece speeds 0 - 30 rpm Workspindle bore, conical 3 29/32 inch Total electrical load 20 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features * FANUC CNC Control, Model 150 MB, for 7 axes, with monitor and direct input. Automatic calculation of all workpiece and grinding parameters. * Extensive coolant equipment with filter system, band filter, etc. * D ...

max. wheel diameter: 762 mm gear width: 116,84 mm max. module: min. module: total power requirement: 145 kW weight of the machine ca.: 27 t dimensions of the machine ca.: 5,5 x 5,3 x 3,4 m With the GLEASON Phoenix® 800HG bevel gear grinding machine, manufacturers of spiral, hypoid, and other bevel gears for large components can significantly increase their productivity. The machine enables faster grinding processes while maintaining the highest accuracy and excellent repeatability. Its extremely robust machine design forms the basis for stable machining processes, even for large workpiece diameters of up to 762 mm. Combined with a powerful FANUC CNC control system, the 800HG offers maximum flexibility for a wide range of gear geometries—from spiral and hypoid bevel gears to special forms. Thanks to its well-thought-out machine concept, the Phoenix® 800HG allows for reduced setup ti ...

max. wheel diameter: 406,4 mm gear width: 66 mm max. module: min. module: module: Control: FANUC Series 150M total power requirement: 61,6 kW weight of the machine ca.: 10 t dimensions of the machine ca.: 5,5x4,6 m The GLEASON Phoenix 400HG is a high-precision CNC bevel gear grinding machine designed for the grinding of spiral, hypoid, and Zerol bevel gears in various operations. The machine is based on a 6-axis design with an additional dressing axis (D-axis) and enables fully interpolated movements between the tool and the workpiece. This allows for both generating and formate processes. The CNC control system synchronizes all movements, resulting in very high profile accuracy, repeatability, and flexibility. • GLEASON PHOENIX 400HG CNC machine with FANUC 150M control system • Gleason HMI – user interface for easy entry of gear parameters and correction values • Automatic dr ...

max. wheel diameter:150 mm gear width:* mm max. module:3,5 min. module:1,25 total power requirement:* kW weight of the machine ca.:6,5 t dimensions of the machine ca.:2,35 x 2,10 x 2,35 m Width of teeth:45 mm boring diameter:100 mm surface area:1300 x 300 mm

max. wheel diameter:275 mm gear width:58 mm max. module:8 min. module:0,5 weight of the machine ca.:10 t max. number of teeth:200 min. number of teeth:5

max. wheel diameter:200 mm gear width:250 mm max. module:3 min. module:0,5 total power requirement:45 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:4,4 x 2,4 x 2,7 m Machine out of prototype production Without automation

max. wheel diameter:200 mm gear width:250 mm max. module:3 min. module:0,5 total power requirement:45 kW weight of the machine ca.:6,5 t dimensions of the machine ca.:4,4 x 2,4 x 2,7 m Machine out of prototype production Without automation
