HAAS hsz used machines

Flat waffle machine HAAS SWAK 64 Haas/Hebenstreit Price £75,000 Built around 1980 Location Germany Dimensions: -Height: 1500 mm -Height machine head: 2200 mm -Width: 1300 mm -Wide machine head: 1860 mm -Length: 12,000 mm Power supply: -Power: 4 kW -Power: 3x380 V -Number of baking plates: 64 -Engraving: 2.5mm x 0.5mm -Plate size: 460 mm x 290 mm -Leaf thickness: 2.8 mm-3.0 mm -Efficiency: 450-500 kg/8 h -Weight of leaf: 55 g/leaf -Baking time: 2:20 min Machine is sold together with the arc cooler and is currently in storage.

Flaring system for sewage gas combustion - Mint- Manufacturer: Haase Maximum flow rate: 10 m³/h Gas pressure: 15-50 mbar Material: Stainless steel (V4A) Diameter: 150 mm Total height: 4.500 mm Emissions: CO2 and NOx to TA-Luft in the range of 50-100% of the maximum power. Flaring system is unused. Only a test run was conducted so as new and in very good condition! System is still built and can be visited at any time!

Hollow hip machine Haas EWB Price: £25,000 Machines # 3379 Built: 1975 Power: 10 kg/hour Connection power: 2.5 KW Volt 3x 380 Natural gas:? Location: Poland Dimensions -Length: 3.20m Bed: 1.70m -Height: 1.40 m The machine is used to make holhippets between 50 and 220 mm in length. The thickness can be adjusted manually.

Hollow hip machine Haas EWB Price: £25,000 Machines # 3379 Built: 1975 Power: 10 kg/hour Connection power: 2.5 KW Volt 3x 380 Natural gas:? Location: Poland Dimensions -Length: 3.20m Bed: 1.70m -Height: 1.40 m The machine is used to make holhippets between 50 and 220 mm in length. The thickness can be adjusted manually.

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HAAS AUTOMATION Technical data Table length: 1219 mm Table width: 457 mm Table load max.: 794 kg Longitudinal travel (X-axis): 1016 mm Transversal travel (y-axis): 508 mm Vertical travel (z axis): 635 mm Pallets: number: 2 Tool changer: Number of tools: 40 Tool diameter max.: 64 mm Diameter with free adjacent pockets: 127 mm Tool lenght: 330 mm Max. tool-weight: 5.4 kg Time of tool changing: 2.8 sec Distance spindle nose to table: 742 mm Spindle speeds: stepless up to: 12000 rpm Work feed rate: 21.2 m/min Rapid traverse:: 35.6 m/min Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Spindle power: 22.4 kW Machine´s weight about: 6300 kg Various accessories: Coolant system: 208 l Tool setter Renishaw Pallets chanching device:

Haas HTRO D 200 G waffle squirrel Price negotiating matter Built in 2002 Location Poland Product: 110 x 47 mm, 23 ° Dimensions: -Height: -Width: -Length: Energy supply: -Performance: -Power supply: -Gas: Natural gas -Gas consumption: About 25 m ³/h -Number of baking plates: 100 -Number of baking courts per baking plate 2 -Engraving exterior: 6 x 6 mm -Plate size: -Core strength: 1.6 mm Machine is currently in production. Walterwerk/GAM/Haas

Flat waffle machine Haas SWAK 72 including arch cooler Manufacturer: HAAS Model: SWAK 72 Machine No.: 11351 Dimensions baking plate: 460 mm x 290 mm Number of baking plates: 72 Weight Net: 17,000 kg Length: 11,705 mm Height machine head: 2,030 mm Height machine body: 1,600 mm Machine is currently still in production and is sold together with an archcooler. Hebenstreit/Haas/Danger

5-axis cnc machining center Type: UMC-750 Manufacturer: Haas Year: 2022 X: 762 mm Y: 508 mm Z: 508 mm Tool magazine 30+1 positions Spindel taper: ISO 40 The distance between the tip of the spindle and the table (~ max) 610 mm Distance between spindle tip and table (~ min) 102 mm Maximum weight on the table (evenly distributed) 300 kg 25 micron filter Chip conveyor Spindle center cooling pressure 300 psi Wireless tool and workpiece probe Synchronized threading Rotating measuring ruler Machine in good condition, under power. Find more here - / Contact us at -

HAAS SWAK 40 for waffle chopsticks Manufacturer: HAAS Model: SWAK 40 Factory number: 18812 Waffle blade dimensions: 460 mm x 315 mm 40 baking plates - 120 rods per baking plate Dimensions: Net Weight: 10,200 kg Length: 6.665 mm Height machine head: 2,030 mm Height baking machine: 1,290 mm Gas oven HAAS RAISES DISPUTE DANGER

Manufacturer: HAAS Model: VF6 SS Year of Manufacture: 2008 Machine Type : Vertical Machining Center - Control: Haas CNC Axis Travels - X axis: 64 inches (1,625 mm) - Y axis: 32 inches (813 mm) - Z axis: 30 inches (762 mm) Spindle - Spindle speed: 12,000 RPM - Spindle taper: 40 taper (CT40 / BT40) - Spindle type: inline direct-drive, high-efficiency (HE) - Spindle motor: 30 HP Tool Changer - Type: side-mount automatic tool changer (SMTC) - Configuration: high-speed Super Speed ATC Electrical Requirements - Voltage: 360/480V - Phase: 3-phase - Frequency: 50/60 Hz - Full load: 40 amps - Largest load / short circuit: 70 amps - Interrupting capacity: 10,000 amps - Enclosure: NEMA Type 1 - indoor use only Find more here - / Contact us at -

Haas TRO 140G Price: 110,000 € Machine No: 18767 Built: Number of baking tongs 140 , 2 baking places per pliers Upper engraving without Underengraving 5 x 5 mm Rand yes Tool 22°30' Power consumption: approx. 2.5 kw/h Gas consumption: approx. 24 m3/h Location: Germany The machine is used for the production of sweet, twisted squirrels with standard industrial size and flattop. Winders, conveyor belt, ready-to-wearer, metal detector and stacking table are included. The machine is in a well-maintained condition. The machine is currently stored. Haas, GAM, Steinhoff, Walter, Industry

Only 18,600 operating hours, X-axis 630 mm, Y-axis 465 mm, Z-axis 630 mm, C-axis rotation angle 300°, A - Axis SK50 (round axis) , Grinding spindle HSK50, Tool changer 7-fold, Dressing unit with body sound, Clamping equipment according to requirements, Software Horizon as required, Extinguishing system Kraft and Bauer, Coolant plant Turbo Separator, Exhaustlta, Fanuc - robot with 4 cassette racks, Pest handling in the robot cabin, B - Axis (6th axis) for the complete machining of Mold turning cutting plates (circumference, profile and chip surface), Further accessories are possible as required, Financing / rental purchase possible!

For the production of profile and turning plates Control: Siemens 840 D X - Axis 650 mm Y - Axis 400 mm Z - Axis 280 mm A - Axis (sub-machine) 360 ° SK50 C - Axis (round table) 270° Grinding spindle: HSK50 Tool changer: 10-fold magazine plate Coolant system: Turbo Separator Suction: LTA Extinguishing system: Kraft & Bauer Other accessories: Available from the factory Automation: Internal handling for profile plates Software: Custom available Financing / rental purchase possible

For the production of profile and turning plates Control: Siemens 840 D X - Axis 650 mm Y - Axis 400 mm Z - Axis 280 mm A - Axis (sub-machine) 360 ° SK50 C - Axis (round table) 270° Grinding spindle: HSK50 Tool changer: 10-fold magazine plate Coolant system: Turbo Separator Suction: LTA Extinguishing system: Kraft & Bauer Other accessories: Available from the factory Automation: Internal handling for profile plates Software: Custom available Financing / rental purchase possible

For the production of profile and turning plates Control: Siemens 840 D X - Axis 650 mm Y - Axis 400 mm Z - Axis 280 mm A - Axis (sub-machine) 360 ° SK50 C - Axis (round table) 270° Grinding spindle: HSK50 Tool changer: 10-fold magazine plate Coolant system: Turbo Separator Suction: LTA Extinguishing system: Kraft & Bauer Other accessories: Available from the factory Automation: Internal handling for profile plates Software: Custom available Financing / rental purchase possible

For the production of profile and turning plates Control: Siemens 840 D X - Axis 650 mm Y - Axis 400 mm Z - Axis 280 mm A - Axis (sub-machine) 360 ° SK50 C - Axis (round table) 270° Grinding spindle: HSK50 Tool changer: 10-fold magazine plate Coolant system: Turbo Separator Suction: LTA Extinguishing system: Kraft & Bauer Other accessories: Available from the factory Automation: Internal handling for profile plates Software: Custom available Financing / rental purchase possible

Machine Details Warehouse number 1105-03409 Machine Type Machining Center - Vertical Brand MIKRON - HAAS Type VCE 1000 VF 3 Year of construction 1998 Control type CNC Control Haas Storage location FRANCE Country of origin USA Delivery time immediately Freight base EXW (Incoterms 2010) Technical details x-displacement 1016 mm y-way 508 mm z-way 635 mm Control Haas Table clamping surface 1219 X 457 mm Rapid speed 25 m/min Table load 1000 kg Speed range 7500 1/min Drive power - Milling spindle 15 kW Number of tools in the magazine 20 pieces Tool holder SK 40 Information IMMEDIATELY FREE IN GOOD CONDITION UNDER POWER

Type: David Dehairing And Flaming Machine Slaughter performance approx. 40-50 pigs/hour Pigs up to approx. 270 kg Machine body in hot-dip galvanized or stainless steel design Built-in control cabinet Roller equipped with 36 special clubs Electrical power: 5.5kW Installation dimensions of the machine in cm: Width: 240 Lenght: 340 Height: 250 Delivery time: after advanced payment, the machine is generally refurbished and ready for delivery

Machine Details Warehouse number 1105-03446 Machine type machining center - Horizontal Haas brand Type HCE 400 P Year of construction 2000 Control type CNC Haas control system Storage location FRANCE Country of origin Japan Delivery time by arrangement Freight base EXW (Incoterms 2000) Price Technical details x-displacement 560 mm y-way 635 mm z-path 560 mm Haas control system Pallet size 400x400 mm Table load 400 kg Spindle motor 22 kW Spindle speed 8100 1/min Rapid speed 36 m/min Pallet changer type 2-fold rotation Table indexing 360000° ° Tool magazine: 30 x BT 40 Total power requirement 54 kVA Machine weight approx. 8 t Space requirement approx. 2.8 x 5.5 m Accessories Conveyor Information Still very precise horizontal center full B AXIS 30X BT 40 TOOL CHANGER CNC HAAS 2 PALLETS 400 X 400 MM

Machine Details Warehouse number 1105-03536 Machine type CNC lathe - inclined bed machine Haas brand Type SL 20 THE Year of construction 2006 Control type CNC Control Haas Storage location HAGUENAU Country of origin Delivery time immediately Freight base from location Technical details Turning diameter 584 mm Turning length 533 mm Control Haas Chuck diameter 210 mm Passage 51 mm Circulation diameter 584 mm Speed 4000 rpm Power 407 Nm Power 15 KW Tool changer 12 COMPARTMENT Gear levels 0 Total power requirement 25 kW Machine weight approx. 5 t Space requirement approx. 3.3 X 2 X 1.9 H m Information CNC HAAS LINING SLIDE 210 MM+ TAILSTOCK SPAENEFOEDERER

BRAND: HAAS YEAR: 2018 MODEL: UMC 750 SS PRODUCTION HOURS: 456 APPLICATION TYPE: MILLING LOCATION: SLOVENIA MACHINE TYPE: MACHINING CENTERS (VERTICAL) AVAILABILITY: IMMEDIATELY Technical Information CONTROL UNIT BRAND: HAAS MAIN DRIVE SPINDLE SPEED RANGE: 15000 1/MIN Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - WIRELESS INTUITIVE PROBING SYSTEM - AUXILIARY COOLANT FILTER - THROUGH-SPINDLE COOLANT - THROUGH-SPINDLE AIR - BELT-TYPE CHIP CONVEYOR UMC - PROGRAMMABLE COOLANT NOZZLE - STANDARD PROGRAM MEMORY, 1 GB - DYNAMIC WORK OFFSETS AND TOOL CENTER POINT CONTROL - EARLY POWER-FAILURE DETECTION MODULE - ETHERNET INTERFACE QUALITATIVE MACHINE BENEFITS: - REMOTE MONITORING - SECOND HOME POSITION - HIGH-SPEED MACHINING HSM - MEDIA DISPLAY M-CODE; M130 - RIGID TAPPING - PRODUCT OPTIONS - TOP COVER FOR UMC SERIES - CT-STYLE T ...

From September 2022 immediately available newly overhauled Multigrind HT retrofit machine prepared for resharpening hobs / worm gear cutters / pushers and cutting rotor Control: Siemens 840 D X - axis 650 mm Y - axis 400 mm Z - axis 280 mm A - axis (dividing apparatus) 360 ° SK50 C - axis (rotary table) 270 ° X3 - axle with tailstock Grinding spindle: HSK50 Dressing unit Tool changer: 10-fold magazine plate Coolant system: Turbo Separator Suction: LTA Extinguishing system Other accessories: Available ex works Software: Customer-specific delivery Financing / hire purchase possible.

Control: Siemens 840 D X - axis 540 mm Y - axis 300 mm Z - axis 300 mm A - Axis (dividing apparatus) 360° C - Axis (rotary table) 255° Grinding spindle: HSK50 Tool changer: 4-fold Other accessories: Factory available Software: Customer-specific factory delivery Suction LTA Coolant system Turbo Separator Extinguishing system

Pig dehairing machine Haas Delivery time: 30 days after advanced payment

BRAND: HAAS YEAR: 2012 MODEL: VF-3YT APPLICATION TYPE: MILLING LOCATION: POLAND MACHINE TYPE: MACHINING CENTERS (VERTICAL) AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MEASUREMENTS WIDTH: 3960 MM MEASUREMENTS DEPTH: 2590 MM MEASUREMENTS HEIGHT: 3230 MM MACHINE WEIGHT: 6350 KG CONTROL UNIT BRAND: HAAS MAIN DRIVE SPINDLE SPEED RANGE: 8100 1/MIN NUMBER OF AXIS: 3 MOVEMENT X-AXIS MOVEMENT: 1016 MM Y-AXIS MOVEMENT: 660 MM Z-AXIS MOVEMENT: 635 MM TABLE OUTER LENGTH: 1372 MM OUTER WIDTH: 635 MM TABLE LOAD: 1588 KG TOOLS MAX WEIGHT: 5.4 KG MAX TOOL DIAMETER: 89 MM MEDIA MAIN ELECTRONIC CONNECTION: 360-480V / 50-60HZ Additional Equipment - NO TOOLING INCLUDED IN THE OFFER Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - TOOL CHANGER: CAROUSEL TYPE - ATC: 20 PCS - SPINDLE TAPER: BT40 - MAX. TOOL DIA ...
