HECKERT fu used machines

Offer 24303 Specifications: - Table size approx. 630 x 340 mm - Working range of the axes - X (longitudinal) approx. 400 mm - Y ( transverse ) approx. 220 mm - Z (vertical) approx. 400 mm - Max. distance between milling spindle and table surface 400 mm - Tool holder SK 40 - Working spindle speeds adjustable in 16 steps 45 - 2240 rpm - Mot table feeders X ; Y ; Z 6.3 - 1250 mm/min - Drive 400 V / 8.5 kW - Space requirement approx. W 1450 x H 1900 x D 1450 mm - Weight approx. 1600 kg - with: - 3 axis digital display HEIDENHAIN - Vertical milling head can be swivelled - Horizontal spindle counter holder - Machine vise

x-travel: 850 mm y-travel: 270 mm z-travel: 355 mm tool taper: ISO 50 speeds of spindle (left/right): 25-1400 total power requirement: 3,8 kW weight of the machine ca.: 2 t dimensions of the machine ca.: m X-axis travel: 850 mm Y-axis travel: 270 mm Z-axis travel: 355 mm Tool holder: ISO 50 Spindle speed (clockwise / counter-clockwise, infinitely variable): 25 – 1,400 rpm Total power requirement: 3.8 kW Machine weight: approx. 2 t Infinitely variable feed rates on all axes (X, Y and Z) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel:1120 mm y-travel:345 mm z-travel:400 mm total power requirement:14,5 kW weight of the machine ca.:3,85 t dimensions of the machine ca.:3.500 x 2.920 x 2.710 mm table-size:1600 x 400 mm spindle taper:SK 50

Various CNC and conventionally controlled milling machines, make Fritz Heckert, are available. 1) Fritz Heckert FU 315/E, weight: approx. 4000kg. 2) Fritz Heckert FU 315 2/PS, weight: approx. 3900kg. 3) Fritz Heckert FU 315 2/PS, weight: approx. 3900kg. 4) Fritz Heckert FU 315 2/PS, weight: approx. 3900kg. 5) Fritz Heckert FU 315/E, weight: approx. 3200kg. 6) Fritz Heckert FW 400/E, weight: approx. 3700kg. 7) Fritz Heckert FU 315 x 12. 8) Fritz Heckert FU 315, weight: approx. 3100kg. An on-site inspection is possible.

This 4-axis Starrag Heckert CWK500D was manufactured in 2002. It features an impressive X-axis travel of 750 mm, Y-axis travel of 750 mm, and Z-axis travel of 700 mm. The machine includes a robust pallet size of 500 × 500 mm and a maximum pallet load of 500 kg. If you are looking to get high-quality machining capabilities, consider the Starrag Heckert CWK500D horizontal machining centre we have for sale. Contact us for further details.

This 4-axis Starrag Heckert HEC 400 D was manufactured in 2012. It features a maximum spindle speed of 12,000 rpm and a tool magazine capacity of 80 tools, allowing for efficient machining operations. The machine includes two workpiece pallets with a size of 400 × 500 mm. If you are looking to get high-quality machining capabilities, consider the Starrag Heckert HEC 400 D horizontal machining centre we have for sale. Contact us for further details.

These 4-axis Starrag Heckert HEC 500 H/V were manufactured in 2008 and 2009. They features a swivelling head configuration, with an X-axis travel of 800 mm, Y-axis travel of 800 mm, and Z-axis travel of 680 mm. The second machine features a swivelling head configuration, with an X-axis travel of 800 mm, Y-axis travel of 650 mm, and Z-axis travel of 680 mm. The machines include a pallet size of 500 x 500 mm and a maximum load per pallet of 1000 kg. If you are looking to get high-quality machining capabilities, consider these Starrag Heckert HEC 500 H/V horizontal machining centres we have for sale. Contact us for further details.

Vertical -consol milling machine, used    Vertical -milling machine, used Make/make: WMW HECKERT Type/ model: FQS 400 Year built: 1978 Control type / control: conventional   x-way: 1190 mm   y-way: 530 mm z-way: 540 mm Table size/ table: 1600 x 400 mm Spindle power/ spindle power: 11kW Tool holder/tool taper: ISO 50 Speeds/ speeds: 28 - 1400 rpm Feeds: 16- 800 mm/min Total power requirement: 21 kW Machine weight: 4.8 t

Crank press HECKERT PKZ 400.1 built in 1980. Technical data : - maximum pressing force: 400 t - working path - lower position of the slider to the maximum pressing force: 21 mm - maximum drawing depth: 125 mm - pressing force using the maximum drawing depth: 160 Mp - idle speed of the slider: 18 min-1 - maximum number of switchings: 9 min-1 - ram stroke (min-max): 315 mm - slider adjustment: 200 mm - holding force of the drawing device at air pressure: 63 Mp, 5 kp / cm2 - force of the drawing device ejector at air pressure: 10 MP, 7 kp / cm2 - total weight: 38.5 t

New drive shafts for Vertical and Universal Fraeshead FU 400 - FW 400 HECKERT Germany Price 900,-- Euro per square plus VAT

Code 101237 Description Universal Cylindrical Grinder Make WMW Heckert Model SA 5 U x 630 Serial No. 3115 Year 1981 Grinding length, max. 630 mm Grinding diameter, max. 275 mm Centerheight 140 mm Max. Weight workpiece 125 kg Table tilting angle - 5° till + 11,5° Diam. Grinding wheel 500 mm Width Grinding wheel, max. 100 mm Motorpower grindingwheel 5,5 kW Speeds workpieceholder 31,5 – 710 rpm Total power 12,5 kVA 380 Volts Machine size L x W x H 3,9 x 2,3 x 1,6 meter Weight 4800 kg Accessories coolant with magnetic some tooling Condition Machine is in good condition

Dosing hoppers Manufacturer: HECKERT Type: Dosing bunker specifications: Sliding floor length: approx. 8,500 mm Sliding floor width: approx. 2,700 mm Sliding floor height: approx. 2,360 mm Side wall height: approx. 2,000 mm Capacity: approx. 40 m³ Drive power: to follow!

Ref. -No.: 10357 Manufacturer: STARRAG HECKERT Year of construction: 2007 Type of control: CNC Steuerung Control: Sinumerik 840D Country of origin: Schweiz X-Travel: 1200 mm Y-Travel: 950 mm Z-Travel: 1200 mm Work spindle drive power (25% ED): 67 kW Work spindle torque (25% ED): 1508 Nm Tool Taper: HSK-A100 Workpiece interference circle diameter: 1250 mm Tool Piece Magazine With: 80 Pcs./pcs. Tool changer: Werkzeugkettenmagazin Max. Workpiece height: 1200 mm Feed Speeds X/Y/Z Axis: 60000 mm / min Feed Capacities X/Y/Z: 22/18/22 N Speed range - main spindle: 20 - 6000 RPM Numbers Of Pallets: 2 Max pallet load: 1500 kg Size Of Pallet: 800 x 630 mm pallet change time: 14 s Pallet clamping area (lxw): 800 x 630 mm Weight Of The Machine Ca.: 25 t

Ref. -No.: 10342 Manufacturer: STARRAG HECKERT Year of construction: 2015 Type of control: CNC Control: Fanuc Series 16i Storage location: Halberstadt Country of origin: Schweiz Serial no.: 12217 X-Travel: 1000 mm Y-Travel: 910 mm Z-Travel: 835 mm Distance spindle center - table: 100 mm Table Dimensions (Lengthxwidth): 630 x 800 mm Table Load: 1250 kg Max. Tool Length: 600 mm Max. Tool Diameter: 500 mm Tool Taper: HSK-A 100 Numbers Of Tools In Magazin: 240 Spindle Speed: 20 - 6000 RPM Feed Capacities X/Y/Z: 20.000 N Rapid Traverse: 40 m / min Internal cooling: 30/40/50 bar External cooling: 2 bar

Ref. -No.: 10286 Manufacturer: STARRAG HECKERT Year of construction: 2007 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Country of origin: Schweiz Machine-No.: 24139 X-Travel: 2800 mm Y-Travel: 2100 mm Z-Travel: 1900 mm Table Dimensions (Lengthxwidth): 2 x 1.250 x 1.600 mm Max. Tool Weight: 35 kg Workpiece Diameter At Full Load: 110 mm Tool Piece Magazine With: 60 Pcs./pcs. Tool dimensions (with occupied adjacent spaces): 125 mm Numbers Of Pallets: 2 Operating hours: 26180 H spindle running time: 26180h 43m 46s h/m/s automatic mode: 28559 H on time: 120 H pallet change time: 60 s Further information: internal coolant supply

Key data: 750 mm, 750 mm, 725 mm

GENERAL Project No.: 905674 Quantity: 1 pcs. Manufacturer: HECKERT (STARRAG) Type: HEC 500 D Control: Siemens 840 D solutionline Year of Make: 2011 Condition: Used machine Layers approx.: 2-3 layers DESCRIPTION MILL Travel in X 750 mm Travel in Y 750 mm Travel in Z 725 mm Max. rapid traverse speed in X/Y/Z 100/100/100 m/min Max. acceleration in X/Y/Z 11/14/11 m/s2 Tool holder HSK 63 Max. speed milling spindle 15000 1/min Max. power at ED 10-40/100% 31/– kW Max. torque at ED 10-40/100% 200/– Nm Spindle diameter in the front bearing 75 mm 1 pc. horizontally arranged milling spindle/s Torque support for multi-spindle drill heads Tool magazine 60 stations Max. tool diameter 160 mm Max. tool length 400 mm Max. tool weight 10 kg Chip to chip time 2.7 s Rotary pallet changer 2-fold Pallet size 500×630 mm Max. workpiece weight per pallet 600 kg Rotary  ...

FZWD 160x1600/1 Sabo Basis 160 Facing & Centering Machine WMW HECKERT Workpiece dia 20-160 mm Length 130-1600 mm Max. Diameter of Milling Cutter 200 mm Facing Spindle's Speeds 112-280 rpm Spindle's Speeds 560-1400 rpm Adjustable feed rate range 15 – 800 mm / min. Spindle ISO 50 Rapid traverse 6000 mm Max. stroke 230 mm Max. Depth of 6 mm Tool holder 4 - 20 mm Max. Feed path 60 mm Total connected load 20 kW Weight 4.5 t

Inv. Num. : 8265 Type: FU 400/V/2 Producer: Heckert Generated: Parameters: Work table length: 1600 mm Work table width: 400 mm Maximum vertical spindle speed: 1400 1/min X-axis travel: 1150 mm Y-axis travel: 370 mm Z-axis travel: 430 mm Machine height: 1980 mm Machine length: 2490 mm Machine width: 2270 mm Machine weight: 3850 kg

BAZ Heckert H55 (4 axle) BJ 2019

Inv. Num. : 8589 Type: CWK 400D Dynamic Producer: Heckert Created: 2002 Parameters: Control system: Siemens Sinumerik 840D Work table length: 400 mm Work table width: 400 mm Maximum table load (uniform): 400 kg Spindle drive power: 19 kW Number of axes: 4 pieces Tool magazine: 120 pieces Minimum spindle speed: 50 1/min Maximum spindle speed: 15000 1/min X-axis travel: 650 mm Y-axis travel: 650 mm Travel travel Z-axis: 650 mm Cone: HSK A63 Max. tool length: 350 mm Max. tool weight: 10 kg Machine height: 2600 mm Machine length: 8500 mm Machine width: 4500 mm Machine weight: 12000 kg Equipment: 2 pallets 4th axis – rotary table Chip conveyor KNOLL 450 K – 1/250 Emulsion Filtration KNOLL 210/1350 Oil mist extraction

Heckert CWK 400 Built in 1995 Control Siemens 840 Travel X/Y/Z 650/650/680 mm Spindle speed up to 10,000 rpm HSK 40 Tool Changer Rotary table 400 x 500 mm, Conveyor Weight 12.5 t.

Heckert ZFWVG 250 x 2000 Thread Milling and Spline Hobbing Machine. Max. workpiece diameter 250 mm Workpiece diameter over bed 500 mm Center height over bed 260 mm Threading/hobbing length 2000 mm Min/Max. module 2/18 Workpiece spindle bore 102 mm Bore of the collets 100 mm Tailstock quill stroke 100 mm Speed 45 – 560 rpm Lead of leadscrew 1,2 '' links / left mm Workpiece turning speeds 0,0032-2,65 U/min Rolling feed 0,027-5,66 mm/WU Longitudinal hob feeds 0,3-198 mm/min Main drive 4 kW Feed motor 25 NM Coolant pump 0,09 kW Lubrication pump 0,37 kW Total power requirement 9,5 kW Dimensions 3700x2400x1600 mm Total weight 5200 kg Accessories; -heavy duty head -standard head -steady rest -flange -change gears full set

HECKERT ZFWVG 250 x 1250 Thread Milling and Spline Hobbing Machine Max. workpiece diameter 250 mm Workpiece diameter over bed 500 mm Center height over bed 260 mm Threading/hobbing length 1250 mm Min/Max. module 2/18 Workpiece spindle bore 102 mm Bore of the collets 100 mm Tailstock quill stroke 100 mm Speed 45 – 560 rpm Lead of leadscrew 1,2 '' links / left mm Workpiece turning speeds 0,0032-2,65 U/min Rolling feed 0,027-5,66 mm/WU Longitudinal hob feeds 0,3-198 mm/min Main drive 4 kW Feed motor 25 NM Coolant pump 0,09 kW Lubrication pump 0,37 kW Total power requirement 9,5 kW Weight of the machine ca. 3,40 t Accessories; -heavy duty head -standard head -steady rest -change gears set -centers and arbors -spindle spare -counter weight Will be re-paint in original brown colour.

BAZ Heckert CWK 800 BJ 1999

Quick clamping device, hydraulic clamping device, electro-hydraulic clamping device, -Manufacturer: WMW HECKERT, clamping device from milling machine FSS 315-V -Type: FHKN 3311 -Motor: VEM 0.12 kW -Dimensions: 440/150 / H220 mm -Weight: 24 kg
