3 HECKERT universal milling machines used machines

New drive shafts for Vertical and Universal Fraeshead FU 400 - FW 400 HECKERT Germany Price 900,-- Euro per square plus VAT

Key data: 850 mm, 270 mm, 355 mm

Table width 315 mm, table length 1250 mm Tool holder SK 50 Speed range 28 - 1400 rpm Feed range 16 - 800 mm/min Travel x=850 mm, y= 270 mm, z=355 mm Connected load 8 kW Incl. Electric clamp horizontal Vertical head in X swivel with manual tightening Dispensing as present, no longer energized

Offer 24303 Specifications: - Table size approx. 630 x 340 mm - Working range of the axes - X (longitudinal) approx. 400 mm - Y ( transverse ) approx. 220 mm - Z (vertical) approx. 400 mm - Max. distance between milling spindle and table surface 400 mm - Tool holder SK 40 - Working spindle speeds adjustable in 16 steps 45 - 2240 rpm - Mot table feeders X ; Y ; Z 6.3 - 1250 mm/min - Drive 400 V / 8.5 kW - Space requirement approx. W 1450 x H 1900 x D 1450 mm - Weight approx. 1600 kg - with: - 3 axis digital display HEIDENHAIN - Vertical milling head can be swivelled - Horizontal spindle counter holder - Machine vise

Key data: 1120 mm, 345 mm, 550 mm

Table width 400 mm, table length 1600 mm Tool holder SK 50 Speed range 28-1400 rpm Feed range 16-800 mm/min Travel x 1120 mm ; y 345 mm; z 550 mm Connected load approx. 14.5 kW Accessories: 2 counter bearings Electric clamp horizontal and vertical spindle Vertical milling head SK50 with snap bearing

Inv. Num. : 8265 Type: FU 400/V/2 Producer: Heckert Generated: Parameters: Work table length: 1600 mm Work table width: 400 mm Maximum vertical spindle speed: 1400 1/min X-axis travel: 1150 mm Y-axis travel: 370 mm Z-axis travel: 430 mm Machine height: 1980 mm Machine length: 2490 mm Machine width: 2270 mm Machine weight: 3850 kg

WMW HECKERT FU450R-51 universal milling machine was built in 2009 in Belarus by Gomel Machine Tool Plant S.M. Kirov.. This extremely versatile, functional and reliable machine is designed for precision machining of workpieces with a maximum weight of 1500 kg. The machining process is performed by a powerful spindle on a large work table. T-slots in the table allow for quick installation of additional tooling such as a vice. The precision and repeatability of the manufactured parts, in turn, is maximised by the design made of the highest quality cast iron, which maintains excellent stability during even the most intensive challenges. All this makes the offered FU450R conventional milling machine an excellent choice for both unit and series production. The WMW HECKERT vertical milling machine weighs 4300 kg. Technical specifications of the WMW HECKERT FU450R-51 milling machine - number ...

Universal milling head, milling holder, milling extension, angle milling head -Manufacturer: WMW HECKERT, milling head from milling machine FSS 315-V -Recording output: SK50 -Recording: Input gear -Milling head: fully pivotable -Stroke: 72 mm -Transport dimensions: 850/650/H520 mm -Weight: 277 kg

Universal milling head, milling adapter, milling extension, angle milling head -Spare part of a: WMW HECKERT milling machine -Number: 1 piece angle milling head -Recording output: SK50 -Recording: input gear -Milling head: completely swiveling -Rezes recording: mm -Pitch circle: mm -Transport dimensions: 750/600/H530 mm -Weight: 296 kg

Speed: 355-1800/min, nominal voltage: 380V, 50Hz, 3 AC, control voltage: 220/24V, protection class: IP54, nominal current: 100A, control: Heidenhain TNC 355, weight: 2.95t, with handwheel, coolant system, hose nozzle, hydraulic/lubrication unit, pressure accumulator/ hydraulic accumulator, solenoid valves, Bosch components and ORSTA directional control valve. An on-site inspection is possible.

x-travel:1120 mm y-travel:370 mm z-travel:410 mm total power requirement:14,5 kW weight of the machine ca.:3850 kg dimensions of the machine ca.:3,5 x 3,5 x 2,2 m Table dimensions:400 x 1600 mm spindle taper ISO:50

x-travel:1120 mm y-travel:345 mm z-travel:400 mm total power requirement:14,5 kW weight of the machine ca.:3,85 t dimensions of the machine ca.:3.500 x 2.920 x 2.710 mm table-size:1600 x 400 mm spindle taper:SK 50

Ref. -No.: 10286 Manufacturer: STARRAG HECKERT Year of construction: 2007 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Country of origin: Schweiz Machine-No.: 24139 X-Travel: 2800 mm Y-Travel: 2100 mm Z-Travel: 1900 mm Table Dimensions (Lengthxwidth): 2 x 1.250 x 1.600 mm Max. Tool Weight: 35 kg Workpiece Diameter At Full Load: 110 mm Tool Piece Magazine With: 60 Pcs./pcs. Tool dimensions (with occupied adjacent spaces): 125 mm Numbers Of Pallets: 2 Operating hours: 26180 H spindle running time: 26180h 43m 46s h/m/s automatic mode: 28559 H on time: 120 H pallet change time: 60 s Further information: internal coolant supply

Vertical -consol milling machine, used    Vertical -milling machine, used Make/make: WMW HECKERT Type/ model: FQS 400 Year built: 1978 Control type / control: conventional   x-way: 1190 mm   y-way: 530 mm z-way: 540 mm Table size/ table: 1600 x 400 mm Spindle power/ spindle power: 11kW Tool holder/tool taper: ISO 50 Speeds/ speeds: 28 - 1400 rpm Feeds: 16- 800 mm/min Total power requirement: 21 kW Machine weight: 4.8 t

Key data: 1120 mm, 345 mm, 400 mm

Table width 400 mm, table length 1600 mm Tool holder SK 50 Speed range 28-1400 1/min Travel X/Y/Z 1120/345/400 mm Feed range X/Y 16 - 800 mm/min, Z 5 - 250 mm/min Rapid traverse Milling head swivel range +/- 45°, quill stroke 90 mm Connected load approx. 14 kW Incl. coolant device Electric tensioner, bracket cover

max. workpiece diameter: 500 mm threading length: 1250 mm max. module: 10 min. module: 1 workpiece dia. over saddle: 250 mm spindle bore of workspindle: 102 mm quill stroke: 100 mm workpiece turning speeds: 0,0032 - 2,6 U/min feeds - rolls: 0,027 - 5,66 mm/WU feeds - longitudinal: 0,3 - 198 mm/min main drive: 4 kW swivel angle for work spindle: 90/120 ° diameter of hob: 150 mm milling width: 100 mm hob turning speeds: 45 - 560/900 U/min total power requirement: 9,5 kW weight of the machine ca.: 4,2 t Machine equiped with: - Heavy Duty Hob Head ApFw - change gears - Milling Head ApFF - Single Indexing Device ETE - Bush Rest - Coolant Tank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 850 mm y-travel: 270 mm z-travel: 355 mm tool taper: ISO 50 speeds of spindle (left/right): 25-1400 total power requirement: 3,8 kW weight of the machine ca.: 2 t dimensions of the machine ca.: m - feeds all axis 10 - 630 mm/min / 250 mm/min The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1190 mm y-travel: 530 mm z-travel: 540 mm table-size: 1600 x 400 mm spindle drive: 11 kW tool taper: ISO 50 turning speeds: 28-1400 U/min feeds: 16-800 mm/U total power requirement: 21 kW weight of the machine ca.: 4,8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. workpiece diameter: 500 mm threading length: 5000 mm max. module: 10 min. module: 2 workpiece dia. over saddle: 250 mm center height over bed: 260 mm workpiece dia. over bed: 500 mm workpiece spindle bore: 102 mm thread pitch: 1 - 800 mm speed of workpiece (milling): 0,0034 - 2,65 U/min feeds - longitudinal: 0,256 - 195 mm/min feeds - rolls: 0,0256 - 5,17 mm/WU hob turning speeds: 45 - 900 U/min electrics - voltage/frequency: 380 / 50 V/Hz total power requirement: 8,5 kW weight of the machine ca.: 6,6 t dimensions of the machine ca.: 7,0 x 1,7 x 1,6 m Thread-, Worm-,gear shafts- and Spline Milling Machine with : equipped with: - Thread Milling Head ApGs - Counter Stay - 1 Bush Rest - 2 Steadies - Cabinet with change Gears The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Heckert CWK 400 Built in 1995 Control Siemens 840 Travel X/Y/Z 650/650/680 mm Spindle speed up to 10,000 rpm HSK 40 Tool Changer Rotary table 400 x 500 mm, Conveyor Weight 12.5 t.

Various CNC and conventionally controlled milling machines, make Fritz Heckert, are available. 1) Fritz Heckert FU 315/E, weight: approx. 4000kg. 2) Fritz Heckert FU 315 2/PS, weight: approx. 3900kg. 3) Fritz Heckert FU 315 2/PS, weight: approx. 3900kg. 4) Fritz Heckert FU 315 2/PS, weight: approx. 3900kg. 5) Fritz Heckert FU 315/E, weight: approx. 3200kg. 6) Fritz Heckert FW 400/E, weight: approx. 3700kg. 7) Fritz Heckert FU 315 x 12. 8) Fritz Heckert FU 315, weight: approx. 3100kg. An on-site inspection is possible.

CONTROLS   conventional BASIC DESIGN   basic design: cross bed WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 1120 mm   Y-axis travel: 350 mm   Z-axis travel: 400 mm   distance spindle nose - table surface (max.): 420 mm TABLE   table surface (left-right): 1600 mm   table surface (front-back): 400 mm   workpiece load (max): 1500 kg SPINDLE / HEAD   spindle type: tilting head   - mode of operation: manual   - mode of operation: manual   spindle revolutions (max): 28 /min   number of gears: 1400   tool fixture: ISO SK 40 AXIS DRIVES   feed velocity (min): 16 mm/min   feed velocity (max): 800 mm/min ELECTRICAL SPECIFICATIONS   total power consumption: 14.5 kW DIMENSIONS / WEIGHTS   space requirements -left/right-: 2700 mm   space requirements -front/back-: 2350 mm   total height: 2150 mm   total wei ...

x-travel:1190 mm total power requirement:25 kW feeds::3 - 2000 mm/min weight of the machine ca.:4,3 t table-size:1600 x 400, 5 Spannbacken mm dimensions of the machine ca.:4000 x 3600 x 2200 mm speeds:45 - 1800 U/min y-travel:530 mm z-travel:540 mm tool taper:ISO 50 control cabinet:940 kg

Code 101237 Description Universal Cylindrical Grinder Make WMW Heckert Model SA 5 U x 630 Serial No. 3115 Year 1981 Grinding length, max. 630 mm Grinding diameter, max. 275 mm Centerheight 140 mm Max. Weight workpiece 125 kg Table tilting angle - 5° till + 11,5° Diam. Grinding wheel 500 mm Width Grinding wheel, max. 100 mm Motorpower grindingwheel 5,5 kW Speeds workpieceholder 31,5 – 710 rpm Total power 12,5 kVA 380 Volts Machine size L x W x H 3,9 x 2,3 x 1,6 meter Weight 4800 kg Accessories coolant with magnetic some tooling Condition Machine is in good condition

Bohrleistung in Stahl (-Ø: 45 mm throat: 1250 mm workpiece height max.: 1100 mm swival range +/-: 360 ° height adjustment: 745 mm base plate surface area: 1450 x 920 mm Bohrspindel-Ø/ Aufnahme: 90 mm / MK 5 bore spindle stroke: 355 mm max. torque on the spindle: 250 Nm feed power: 14000 N turning speed range: 20 - 1200 U/min feed range: 0,063 - 0,63 mm/U power capacity: 3,7 kW weight of the machine ca.: 3,0 t dimensions of the machine ca.: 2,1 x 0,9 x 3,3 m • cube table 650 x 650 x 500 mm, • coolant device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 4000 mm grinding width: 1450 mm workpiece height: 1250 mm column daylight: 1500 mm Passage height: 1420 mm table surface area: 4240x1250 mm T-slot - distance: 160 mm T-slot - width: 28H12 mm T-slots: 10 workpiece weight: 20.000 kg table speed -stepless-: 1-50 m/min grinding motor: 22 kW turning speeds: 960 U/min total power requirement: 125 kW weight of the machine ca.: 67 t dimensions of the machine ca.: 13,2x7,8x5,1 m Peripheral grinding support: 960 rpm, 22 kW Universal grinding support: 7 kW, 500-2900 rpm Dressing device The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are inter ...
