3 HURCO cnc milling centers used machines

Sell our old vertical milling machining center as a spare parts dispenser, unfortunately I can not say what the machine has exactly, I only know that the control unit is defective

Hurco VMX 24, YOC 2003 Travel X/Y/Z: 610mm/508mm/610mm Rapid traverse X/Y/Z: 35m/35m/30m Feed: 7600mm/min Table dimensions X/Y: 760mm/510mm Max. table load: 700kg Tool holder: SK40 Tool Positions: 24 Spindle speed: 10000rpm Power: 7.5kW Dimensions approx. 2200mm/2400mm/2500mm Weight: approx. 5000kg Control: Ultimax 4 (Documentation available)

We offer the following machine directly on behalf of the owner. It was delivered in 2026, but due to a change in demand, it will not be used. The machine is in its original packaging and unused. 5 - Axis CNC Portal Milling Machine, New Make : HURCO Type : DCX 32-5 Si Year of manufacture : 2025, Delivery 3 / 2026 Control: MAX 5, 2 screens TRAVELS X-axis: 3,200 Y-axis: 2,100 Z-axis: 900 mm B-axis: +100°/-110° C-axis: ±360° TABLE Table size: 3,000 × 1,700 Table load: 11,000 kg Distance between portal stand: 2,130 mm Distance spindle nose to table: 66 – 966 mm SPINDLE / HEAD Clevis CYTEC Tool holder: HSK63-A Max. speed: 18,000 rpm Power : 63 kW Max. torque: 106 Nm Rapid traverse: 15/15/10 m/min Tool Changer / ATC : 60 - speed EQUIPMENT : - IKZ internal cooling by spindle 40 bar - KNOLL belt filter system - KNOLL chip conveyor - Di ...

Key data: 316 mm, 340 mm

CNC LATHE FOR GENERAL PURPOSE TURNING

Inv. Num. : 5552 Type: BMC 24 SSM Producer: HURCO Created: 2004 Parameters: Control system: ULTIMAX Work table length: 760 mm Work table width: 400 mm Spindle drive power: 7.5 kW Tool magazine: 24 pieces Speed: 80-8000 1/min Travel X-axis: 610 mm Travel Y-axis: 405 mm Travel Z-axis: 505 mm Cone: SK40 Machine height: 2650 mm Machine length: 2140 mm Machine width: 2100 mm Machine weight: 4200 kg

Key data: 1020 mm, 510 mm, 610 mm

Inv. Num. : 6222 Type: BMC 4020 Producer: HURCO Created: 2000 Parameters: Control system: UNIMAX Operating hours: 59,600 h Work table length: 1220 mm Work table width: 510 mm Minimum vertical spindle speed: 80 1/min Maximum vertical spindle speed: 8000 1/min X-axis travel: 1020 mm Y-axis travel: 510 mm Z-axis travel: 610 mm Spindle power: 15 kW Maximum tool weight: 682 kg Max. tool weight: 7 kg Machine height: 2670 mm Machine length: 3350 mm Machine width: 2320 mm Machine weight: 5600 kg Equipment: Tool clamping 2015: Spindle change

Key data: 1625 mm, 860 mm, 760 mm

Control Ultimax 4 Travel X/Y/Z: 1625/860/760 mm Speed 8000 min-1 Tool magazine for 40 Wkz., SK 40 IKZ Conveyor

Control Ultimax 4 Travel X/Y/Z 760 x 510 x 610 mm Table size 1020 x 510 mm Speed 12,500 min-1 Tool magazine for 24 Wkz., SK 40

Control Ultimax 3-4 2 color screens (text + graphics) Travel X/Y/Z 1020/510/610 mm Speed 8000 1/min Tool magazine for 24 Wkz. SK 40 DCF Software

Control Winmax Travel X/Y/Z 2135 x 865 x 762 mm Spindle speed 12,000 min-1 Tool magazine for 40 Wkz., SK 40 Handwheel Ultimotion IKZ 40bar Probes Renishaw Conveyor

Winmax V10 X-axis: 1,067 mm Y-axis: 610 mm Iebtfb Tswt N Tgepmsic Z-axis: 610 mm Table size: 1,270 × 610 mm Tool holder: SK40 (DIN 69871) Max. speed: 12,000 rpm⁻¹ Drive power (S1/S6): approx. 15 / 22 kW IKZ (internal cooling) 20 bar Separate coolant tank with paper belt filter Rapid traverse X/Y/Z: 35 m/min (X/Y), 30 m/min (Z) Capacity: 30 tools (optionally 40) Changeover time: Tool-to-tool approx. 2 s Max. tool diameter: 80 mm (next to free space: up to 125 mm) Max. tool length: 300 mm Max. tool weight: 7 kg Machine weight: approx. 6,900 kg Space requirement (W × D × H): approx. 4,600 × 3,900 × 2,800 mm Spindle nose to table: 150 – 760 mm Table surface to floor: approx. 900 mm

Travel (X / Y / Z) 762 mm / 508 mm / 610 mm Table size 1,020 mm × 510 mm Table load max. 1,000 kg Spindle holder SK 40 (DIN 69871) Spindle speed max. 10,000 min⁻¹ Spindle power 11 kW Tool Stations 24 Stations, Automatic Tool Changer (ATC) Iobjwt Rfwstfb Tpmjic Max. tool weight 7 kg Max. tool length 300 mm Max. tool diameter 80 mm Rapid traverse (X / Y / Z) 24 m/min / 24 m/min / 20 m/min Feeds programmable up to approx. 7,600 mm/min Control HURCO Ultimax 4 Machine weight approx. 4,700 kg Machine dimensions (L × W × H) approx. 3.9 m × 2.4 m × 2.7 m

Year of manufacture 2007 Travel X 1270 mm Travel Y 660 mm Travel Z 610 mm Table size 1500 mm × 660 mm Table load 1300 kg Spindle speed up to 12,000 min⁻¹ Spindle drive approx. 18 kW Tool holder SK 40 Tool Stations 24-Fold Tool Changer Rapid traverse (X/Y) 30 m/min Rapid traverse (Z) 20 m/min Machine weight approx. 9000 kg to 9500 kg Machine dimensions (L×D×H) approx. 3.25 m × 2.35 m × 2.95 m

Description Machining Center Hurco BMC 30 Details Serial No. B3HM-92206089EB with control Ultimax approx. 45 tool holders Replacement spindle 4382 Hours

x-travel: 1.060 mm y-travel: 610 mm z-travel: 610 mm control: Winmax 9 (Upgrade) table-size: 1.270 x 610 mm max. table load: 1.100 kg number of T-slots: 5 T-slot - width: 18 mm T-slot - distance: 100 mm turning speed range - milling: ~ 10.000 U/min power capacity - milling spindle: 18 / 11 kW tool taper: SK 40 Tool changer: 24 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 120 mm max. tool length: 300 mm max. tool weight: 7 kg feed: ~ 15,4 m/min rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 30 m/min rapid traverse Z-axis: 20 m/min weight of the machine ca.: 7,0 t dimensions of the machine ca.: 3,5 x 3,2 x 3 m Chip conveyor: Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: elektr. hand wheel: Machining Center - Vertical HURCO VMX 42 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 610 mm y-travel: 510 mm z-travel: 610 mm table-size: 760 x 510 mm workpiece weight: 1350 kg spindle taper:: SK 40 spindle turning speed range: 15000 U/min spindle motor: 9 kW distance spindle /table: 150-760 mm rapid traverse: 38/38/32 m/min Control: WinMax 5 total power requirement: 19 kVA Total weight, approx.: 5000 kg dimensions of the machine ca.: 2,3 x 2,95 x 2,55 m 3-axis machining centre with electric spindle (D series) equipped with: - WINMax 5 CNC control with 3D simulation graphics & handwheel - 30-fold Toolchanger (SK 40) - Chip conveyor - Renishaw probe - Dynamic diret tdrives on all axes - High-pressure cooling system - Spindle cooler The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 610 mm y-travel: 510 mm z-travel: 610 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m - ULTIMAX 4 control - toolchanger for 24 tools - coolant through spindle - chip tank - electronical hand wheel Technische Daten / technical details: Verfahrweg X / X-Travel 610 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 610 mm Tischgröße / table size 760x510 mm Werkzeugschaft / spindle taper SK40 Drehzahlbereich / spindle speed 10-10000 UpM /rpm Anzahl der Werkzeugplätze / tool places in ATC 24 fach Eilgang / rapid feed 30 m/min Gewicht der Maschine ca. / weight 4700 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control Winmax Travel X/Y/Z: 1270 x 660 x 610 mm Spindle speed 10,000 min-1 Tool magazine for 24 Wkz., SK 40 IKZ 20 bar Pocket milling machines with islands Synchronous threading

Control Winmax Travel X/Y/Z: 760 x 510 x 610 mm Table clamping surface: 1020 x 510 mm Spindle speed 12,000 min-1 Tool magazine for 24 Wkz., SK 40 Cooling by the spindle 20 bar

BAZ Hurco VMX 40 built in 2001

Key data: 762 mm, 508 mm, 610 mm

Hurco VMX 30 Year 04/2007 Travel (X / Y / Z) 762 mm / 508 mm / 610 mm Spindle holder SK 40 Spindle power 11 kW Tool Stations 24 Stations, Automatic Tool Changer (ATC) Max. tool weight 7 kg Max. tool length 300 mm Max. tool diameter 80 mm Control HURCO WinMax ver. V8 01.09.25... Options see pictures Machine weight approx. 4,700 kg Machine dimensions (L × W × H) approx. 3.9 m × 2.4 m × 2.7 m Interior was painted, scrapers of the telescopic covers were renewed. Machine can be viewed under power by appointment. Price is net plus VAT. Freely loaded onto trucks

Key data: 1630 mm, 860 mm, 760 mm

Basic machine data Used 3-axis machining center from HURCO Make: HURCO Type: VMX64 Year of Make: 2006 Condition: Used - In working order Control: Name: HURCO Ultimax 4 CNC Track Control Drive power: 285 kW Travels: x-travel: 1630 mm // y-travel: 860 mm // z-travel: 760 mm Technical data: • Spindle 25-8000 rpm • SK 50 interface • Clamping table size: 1650 mm x 9000 mm • 32-fold tool changer • Feed range: 1-18000 mm/min • IKZ • Dividing head type Kitagawa NC 300 rotary and swivel table • Chip conveyor The machine is in good condition. Prior sale is reserved. No liability is assumed for the technical information provided here. The legal provisions apply.

BAZ Hurco VMX 24 t

x-travel: 1270 mm y-travel: 660 mm z-travel: 610 mm total power requirement: kW weight of the machine ca.: 8680 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The machine is in good technical condition, after prior agreement it is possible to test it. CONTROL SYSTEM Control language - completely in Czech 3D simulation - yes Programming type - Dialogue and NC TABLE Table dimensions - 1,270 x 610 mm T-slots - 5 x 18 mm Max. table load - 1,350 kg Distance between the spindle face and the table - 150 - 760 mm TRAVELS X-axis - 1,070 mm Y-axis - 610 mm Z-axis - 610 mm SPINDLE Max. spindle speed - 12,000 rpm Spindle taper - SK40 TOOL MAGAZINE Number of tools - 24 Max. tool diameter - 80 mm Max. tool weight - 7 kg
