3 HWACHEON vertical processing centers used machines

Control: Manufacture: FANUC 0i-MD x-travel: 1000 mm y-travel: 550 mm z-travel: 500 mm table surface area: 1100 x 500 mm spindle turning speed - stepless: 10000 U/min dimensions of the machine ca.: 3500 x 2200 x 2700 mmxmmxmm weight of the machine ca.: 6.5 t tool piece magazine with: 24 Plätzen The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8902 Type: Vesta 1000 12K Producer: Hwacheon Created: 2016 Parameters: Control System: FANUC Series Oi-MF Hours: 15976 h Work table length: 1100 mm Work table width: 502 mm Spindle drive power: 11 kW Maximum spindle speed: 12000 1/min X-axis travel: 1000 mm Y-axis travel: 550 mm Travel Z axis: 500 mm Cone: BT40 Max. tool length: 300 mm Max. tool weight: 8 kg Max. tool diameter: 80/150 mm Rapid traverse X/Y/Z: 36/36/30 m/min Machine height: 2670 mm Machine length: 3335 mm Machine width: 2200 mm Machine weight: 6500 kg Equipment: Tool probe Workpiece Probe 4th axis TSUDAKOMA

x-travel: 1000 mm y-travel: 550 mm z-travel: 500 mm CNC-control: Fanuc Oi-MD table-size: 1.100 x 500 mm max. table load: 700 kg spindle taper ISO: BT-40 spindle turning speed range: 10.000 U/min feed stepless: 24.000 mm/min rapid traverse: 36/36/30 m/min drive capacity - spindle motor: 15/11 kW tool change unit: 24 coolant: IKZ 20 bar voltage: 400 V total power requirement: 30 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,35 x 2,20 x 2,67 m chip conveyor: 2,40 x 1,50 x 1,40 m filter unit: 0,90 x 1,40 x 1,30 m Transformer: 0,60 x 0,55 x 0,55 m - Serial No..:M281361B5N D - Machine ON: 21,011 h - NC-Indexing Device Manufacturer KITAGAWA, (Call by M-Command) - control: FANUC Oi-MD - Internal coolant supply through spindle 20 bar - Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Vertical Machining Center HWACHEON Vesta-1000 10K Control: Heidenhain iTNC 620 Year of Make: 2014 Original pictures will follow. Travel: X-axis:1,000 mm Y-axis: 550 mm Z-axis: 500 mm Table size: 1,100 x 502 mm Table load: approx. 700 kg Recording: BT 40 Tool magazine: 30 compartment Spindle speed: 12,000 rpm Drive power:18.5 kW Equipment -Conveyor - Electronic handwheel - 4th axis

turning diameter: 210 / 350 mm turning length: 400 mm control: Fanuc 0i-TC swing diameter: 500 mm travel -x axis: 195 mm travel -z axis: 430 mm spindle speed:: 3500 1/min spindle bore: 75 mm bar diameter: 51 mm C-Axis: 0,001 ° turret head: 12 Pos. taper in tailstock-quill: MK 4 tailstock travel: 100 mm diameter of quill: 80 mm rapid traverse X-axis: 30 m/min rapid traverse Z-axis: 30 m/min drive capacity - spindle motor: 11 / 15 kW voltage: 400 V total power requirement: 30 kVA weight of the machine ca.: 4,2 t dimensions of the machine ca.: 2,70 x 1,90 x 2,10 m chip conveyor: 2,80 x 0,60 x 1,30 m Transformer: 0,60 x 0,45 x 0,55 m - Serial-No.: M015356K2F - Machine ON: 14.494 h - control: FANUC Oi-TC - Machine with C-axis and turret for life tools (1x radial + 1x axial in the accessories) - Tool meeasuring arm - Parts collecting tray - Collet chuck - 3-jaw chuck Samchully Ø 250 mm - O ...

NEW JOB CENTER! 480 HOURS TO POWER ON! COURSE AXIS X MM 1,000 COURSE ASSE Y MM 550 COURSE ASSE Z MM 500 TAVOLA DIMENSIONS MM 1.100x502 TAVOLA PLAN: 130-630 MM MAXIMUM LOAD ALLOWED: 700 KG ATTACK: BT40 GIRI/MIN VELOCITY SPEED 12,000 TOOL WAREHOUSE: 24 FANUC CONTROL 0i-MF COMPLETE OF TAVOLA 4/5th ASSE LEHMANN SOO EDITION 3

Hwacheon, mod Sirius III - 1250, Table 1400 * 700, X 1100 mm, Y 700, Z 650, Cambio utensili / Toolchanger 30 pos, ISO 50, 8000 RPM max 30kW, CNC Fanuc 18iMB, Still under power on the shop floor

Travel X/Y/Z: 560mm/410mm/460mm, Tool positions: 30, Tool interface: CAT40/BT40, Spindle speed: 8000rpm, Spindle power: 10HP, Spindle diameter: 70mm, Rapid traverse: 30m/min, Table dimensions X/Y: 605mm/380mm, Max. table load: 250kg, Number of pallets: 2. Machine dimensions X/Y: approx. 3050mm/2900mm, Weight: approx. 5000kg, Control: Fanuc. Documentation available. An on-site inspection is possible.

turning diameter: 300 mm turning length: 300 mm control: Sinumerik 810D total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Sinumerik 810D 12-fold revolver bar loading device Breuning Irco Simag 42.1R (max. bar diameter 42mm) chip conveyor tail stock Technische Daten / technical details: Umlaufdurchmesser über Bett / rotary diameter over bed 550 mm max. Drehdurchmesser / max. turning diameter 300 mm max. Drehlänge / max. turning lenght 300 mm X-Weg / X-travel 170 mm Z-Weg / Z-travel 335 mm max. Stangendurchlass / max. bar diameter 45 mm Drehzahl / spindle speed 6000 UpM /rpm Werkzeugrevolver / turret head 12 fach /holes Eilgang X / rapid feed X 36 m/min Eilgang Z / rapid feed Z 36 m/min. Antriebsleistung / drive capacity 20 kW Gewicht der Maschine ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibu ...

Inv. Num. : 8549 Type: Cutex-160B MC Producer: Hwacheon Created: 2017 Parameters: Control system: FANUC 0i-SERIES (TF) Max. turning diameter: 260 mm Maximum turning diameter over bed: 550 mm Maximum spindle speed: 4500 1/min Lathe chuck diameter: 200 mm Weight: 3280 kg

The machine is in good technical condition, testing possible after prior agreement. including a new chip remover

turning diameter: 950 / 650 mm turning length: 2000 / 2500 mm control: HEIDENHAIN Manual Plus 3-jaw-chuck diameter: 800 mm turning speed range: 40 - 1000 U/min total power requirement: 35 kW weight of the machine ca.: 12 t dimensions of the machine ca.: 8 x 3 x 3,5 m 12 x station Turret Tailstock 2 x Chip Conveyors Price EXW 17036 Neubrandenburg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 9102 Type: Hi-TECH 230 BL YMC Producer: Hwacheon Created: 2019 Parameters: Control system: FANUC Hours: 6623 h Maximum turning length: 584 mm Maximum turning diameter: 400 mm Maximum turning diameter over bed: 750 mm Maximum spindle speed: 3500 1/min Weight: 6650 kg

This HWACHEON VT550R was manufactured in 2008. It features a hydraulic chuck diameter of 500 mm, a maximum turning diameter of 650 mm, and a spindle speed up to 1,500 RPM. The machine includes a 12-position turret and a chip conveyor, ensuring efficient operation. Consider the opportunity to buy this HWACHEON VT550R turn-mill centre. Contact us for more information about this machine.

A Hwacheon CNC lathe is offered. Max. turning diameter: 680mm, swing over bed: 900mm, max. turning length: 1986mm, chuck diameter: 380mm, max. bar capacity: 116mm, max. spindle speed: 1800rpm, spindle power: 37kW/30kW, max. spindle torque: approx. 3071Nm/2493Nm, tool turret: 12 stations, tool interface: BMT-75, X/Z-axis travel: 360mm/2050mm, X/Z-axis rapid traverse: 18m/min, coolant tank capacity: 300l, control: Fanuc 0i-TF. Equipment: C-axis, driven tools, automatic in-process tool measurement, programmable tailstock and programmable quill, C-axis spindle clamp, chucking pressure monitoring, centralized lubrication and hinge-belt chip conveyor with chip container. Control ON: approx. 15961h, machining time: approx. 4258h, total part count: 34601. Weight: approx. 15000kg. Documentation available. Inspection possible by appointment.

turning diameter: 280 mm turning length: 400 mm control: Fanuc 18 T spindle bore diameter: 51 mm number of controlled axis: 2 turning speed range: 0 - 4000 U/min rapid speed: 30 m/min number of tapers in turret head: 12 VDI 40 tail stock: Ja dimensions: 3,9 x 1,6 x 2,1 m weight of the machine ca.: 3,9 t power requirement: 15 kW Used CNC- Lahte with box way, 2 axis - 3 jaw chuck Ø 200 mm - chip conveyor - oil dust collector The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Horizontal turning machine manufactured in 2012. This HWACHEON CUTEX 160 B VDI features a swing over bed of 550 mm and a maximum spindle speed of 4500 rpm. It offers travels of 170 mm in the X-axis and 335 mm in the Z-axis, along with 12 tool positions. If you are looking to get high-quality turning capabilities, consider the HWACHEON CUTEX 160 B VDI machine we have for sale. Contact us for further details.

turning diameter: 590 mm turning length: 1100 mm control: Fanuc turning diameter over bed: 800 mm total power requirement: --- kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 590 mm turning length: 1100 mm control: Fanuc turning diameter over bed: 800 mm total power requirement: --- kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 260 mm control: Fanuc Oi-TC x-axis: 170 mm z-axis: 335 mm - path correction: turning length: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Fanuc Oi-TC 12-fold revolver driven tools C-axis chip conveyor tail stock coolant device Technische Daten / technical details: Umlaufdurchmesser über Bett / rotary diameter over bed 550 mm max. Drehdurchmesser / max. turning diameter 260 mm X-Weg / X-travel 170 mm Z-Weg / Z-travel 335 mm max. Stangendurchlass / max. bar diameter 51 mm Drehzahl / spindle speed 4500 UpM /rpm Drehzahl angetr. WKZ /speed of driven tools 5000 UpM /rpm Werkzeugrevolver / turret head 12 fach /holes Eilgang X / rapid feed X 36 m/min Eilgang Z / rapid feed Z 36 m/min. Gewicht der Maschine ca. / weight ca. 3280 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unv ...

Table clamping surface: 2 x 350 x 300 mm traverse path x/y/z: 700/300/250 mm spindle retainer: BT 30 ISA kl. / gr. Table/spindle distance: 450 mm spindle speeds: 6-6000 rpm number of tool stations: 10 pieces feeds: 5-10000 mm / min rapid traverse: x & y/z 25/20 m / min spindle drive: 3,1/4,1 kW Electr. Supply: 400 V kW weight: 2600 kg

FZ15KS HIGH SPEED 4 axis vertical machining center X: 550mm Y: 400mm Z: 360mm 4th axis original Peiseler CNC Siemens 840D Table surface 1050 x 450mm Toolchanger 48 posts ISO 40 Spindle speeds up to 12000 1/min with 4th axis Renishaw broken tool detector Coolant through spindle swarf conveyor Can be inspected under power in our warehouse. Mimu machine tools (Italy)

Table size: 1000 x 490 mm traverse path x/y/z: 800/510/500 mm spindle retainer: ISO 40 ISA kl. / gr. Table/spindle distance: 120/620 mm spindle speeds: 40-6000 rpm number of tool stations: 22 pieces feeds: x/y 1-3200 / z 1-2000 mm / min rapid traverse: x/y 1-3.2, z 1-2 m / min. Supply: 380 V, 19 kW space: 2850 x 2150 x 2600 mm weight: 3800 kg

MODEL: VERSAMATIC 400 TYPE: TV-MO SERIAL NUMBER: VS4 166 YEAR OF BUILD: 1995 CNC: HEIDENHAIN

Control Siemens 828 D Travel X/Y/Z 850/550/550 mm Speed 8000 rpm Tool magazine for 24 tools BT40 Table size 950x550 mm
