21 KAISER used machine for sale

High-performance mechanical automatic punching machine with coil system for strip material processing in series production. Manufacturer: Kaiser Pressen Model: KSTU 3150-15 R Machine Type: Automatic Punching Machine Year of Make: 1994 Press force: 3150 kN Drive type: mechanical Stroke rate: 20 – 120 1/min Plunger stroke: 20 – 150 mm Plunger adjustment: 150 mm Table surface: 1780 x 1250 mm Plunger area: 1500 x 1000 mm Installation height: 565 mm Tool weight max.: 3000 kg Strip width: 30 – 800 mm Band thickness: 0.5 – 3 mm Max. strap thickness: 4 mm Strip infeed height: 160 – 260 mm Belt speed: 4 – 30 m/min Straightening rollers: 9 pieces Feed accuracy: ± 0.1 mm Coil inner diameter: 508 mm Coil outer diameter: 1000 – 1500 mm Supply voltage: 3 x 400 V Air pressure: 5 bar Location: Radeberg

Roller feed KAISER ZR 12 Belt width - 120 mm Feed length 100 mm Feed angle - adjustable - 90 - 180 degrees Tech. Condition - good, complete With pneumatics. Spare parts Btto 250 kg

pressure:063 t stroke:70 fix mm no. of strokes:15 - 60 /min distance between columns:1340 mm width between oil collecting pans:1180 mm distance table/ram, max. stroke up, adjustment up:328 mm table surface area:1260 x 700 mm hole in the table:1000 x 100 mm table height over floor:1000 mm column travel -side:470 mm ram surface:1300 x 650 mm ram adjustment:100 mm power requirement:27,5 kW weight:13,7 t Dimensions (WxDxH):3,4 x 2,1 x 3,4 m clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

CONTROLS   PLC SIEMENS SIMATIC OP 47-12 PRESS FORCES   total force (nominal): 200 to PRESS TABLE   table surface (left-right): 2440 mm   table surface (front-back): 1500 mm SLIDE   table surface (left-right): 1500 mm   table surface (front-back): 1100 mm   stroke: 180 mm SLIDE (MECHAN. PRESS)   slide adjustment: 150 mm   stroke rate (min.): 20 /min   stroke rate (max.): 120 /min   main drive power: 45 kW OVERALL SPECIFICATIONS (COIL LINES)   sheet thickness max.: 2.5 mm DECOILER   sheet width max.: 300 mm   sheet width (min): 30 mm   coil weight max.: 3 to   max. diameter of coil: 1500 mm   mandrel expansion range from: 460 mm   mandrel expansion range up to: 530 mm LEVELLER UNIT   sheet width max.: 30 mm   sheet width (min): 300 mm   number of leveller rolls: 9   diameter of leveller rolls: 30 mm   number of intermediate rolls: 11   feed  ...

An eccentric press is offered. Press force: 7500kg, stroke: 1mm - 40mm, stroke rate: 60rpm - 240rpm, ram adjustment: 70mm. Precision roller feed, external control unit, digital process monitoring, sound insulation cabin, strip decoiler. Weight: approx. 1800kg, overall dimensions X/Y/Z: approx. 1400mm/1200mm/2100mm. Inspection possible by arrangement.

An eccentric press is offered. Press force: 45000kg, stroke: 8mm - 60mm, stroke rate: 80rpm - 400rpm, ram adjustment: 60mm, table area X/Y: 600mm - 700mm/450mm - 500mm, ram area X/Y: 450mm/300mm, installation height: 300mm - 350mm. Digital process monitoring, electronic cam control, servo feed control, pneumatic clutch-brake combination. Weight: approx. 4500kg, overall dimensions X/Y/Z: approx. 1800mm/1400mm/2600mm. Inspection possible by arrangement.

A high-speed press is offered. Press force: 38t, stroke rate: 60/300 per minute. Stroke: 6mm-50mm, ram adjustment: 40mm, infeed height: 90mm. Table surface X/Y: 550mm/440mm. Soundproof enclosure, accessories: external control cabinet, tool area lighting, vibration dampers. Total weight: approx. 2800kg, overall dimensions X/Y/Z: 1650mm/1450mm/2250mm. Inspection possible by arrangement.

Press capacity: 125 ton Ram stroke adjustable: 30 - 120 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 450 mm Free frontal opening L-R: 1.290 mm Free lateral opening F-B: 450 mm Table surface area : 1.250 x 800 mm Slide area: 1.250 x 650 mm Hole in table: 1.050 x 260 mm Number of strokes: 30 - 220 s.p.m. Table height over floor: 1.200 mm Required power: 39 kW Height over floor approx.: 3.800 mm Dimensions L x W x H: 3.500 x 2.200 x 3.800 mm Weight of machine approx.: 21,5 ton

Press capacity: 35 ton Ram stroke adjustable: 6 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 250 mm Free frontal opening L-R: 430 mm Table surface area : 410 x 410 mm Slide area: 307 x 187 mm Hole in table: 170 x 110 mm Number of strokes: 60 - 300 s.p.m. Weight of machine approx.: 2,4 ton

Tool holder, milling holder, milling tool -Number: 8x SK50 mounts -different designs -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -is only sold complete -Weight: 32 kg

Tool holder, milling tool holder -Number: 14x SK50 recording -Tool holder: Ø 36 mm -Drill chucks: Surface clamping chucks, reducing sleeves, cutter heads, end mills, spindle tools -suitable for tool changers -Price/Sale: complete -Dimensions: 800/315/H650 mm -Weight: 62 kg

Tool holder, milling holder, milling tool -Number: 3x SK50 holders -different designs -Bore chucks, flat chucks, reducing sleeves, cutter heads, shell end mills, spindle tools -suitable for tool changers -Sale: only complete -Weight: 10 kg

Boring head, spindle head, drill head, plunge drill head, plunge head, spindle drill head, boring head, spindle tool -Quantity: 2x spindle tools -Recording: SK50 -Spindle dimensions: 145-230/225-310 mm Price: complete -Weight: 14 kg/piece

Press capacity: 63 ton Ram stroke adjustable: 8 - 60 mm Slide adjustment: 80 mm Shut height (stroke down, adjustment up): 300 mm Table surface area : 810 x 550 mm Slide area: 700 x 420 mm Hole in table: 550 x 140 mm Distance between oil tray: 700 mm Table height over floor: 920 mm Number of strokes: 65 - 400 s.p.m. Weight of machine approx.: 8 ton Dimensions L x W x H: 2935 x 1170 x 3000 mm Main Motor: 11 kW

Press capacity: 100 ton Ram stroke: 300 mm Slide adjustment: 125 mm Shut height (stroke down, adjustment up): 600 mm Free frontal opening L-R: 2.020 mm Free lateral opening F-B: 620 mm Table surface area : 2.000 x 1.000 mm Slide area: 2.000 x 900 mm Hole in table: 1.700 x 300 mm Number of strokes: 10 - 50 s.p.m. Table height over floor: 1.200 mm Required power: 39 kW Height over floor approx.: 4.400 mm Dimensions L x W x H: 5.166 x 2.500 x 4.400 mm Weight of machine approx.: 38 ton

Press capacity: 40 ton Ram stroke adjustable: 8 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 310 mm Free frontal opening L-R: 820 mm Table surface area : 810 x 450 mm Slide area: 720 x 350 mm Hole in table: 600 x 110 mm Number of strokes: 100 - 1.000 s.p.m. Table height over floor: 1.030 mm Required power: 19,5 kW Weight of machine approx.: 6,8 ton

Press capacity: 50 ton Ram stroke: 54 mm Slide adjustment: 80 mm Shut height (stroke down, adjustment up): 303 mm Table surface area : 810 x 550 mm Number of strokes: 65 - 400 s.p.m. Weight of machine approx.: 7,5 ton Main Motor: 11 kW

Press capacity: 40 ton Ram stroke adjustable: 8 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 290 mm Free frontal opening L-R: 600 mm Free lateral opening F-B: 190 mm Table surface area : 600 x 500 mm Slide area: 600 x 400 mm Hole in table: 500 x 110 mm Number of strokes: 65 - 400 s.p.m. Table height over floor: 1100 mm Required power: 32 kW Height over floor approx.: 2.800 mm Weight of machine approx.: 6,2 ton

Pressure total: 315 ton Ram stroke: 160 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 1.050 mm Free frontal opening L-R: 2.740 mm Free lateral opening F-B: 1.500 mm Distance between oil tray: 2.400 mm Table surface area : 2.740 x 1.800 mm Slide area: 2.400 x 1.700 mm Number of strokes: 10 - 60 s.p.m. Required power: 75,5 kW kW Working hours machine: 77.341 h Height over floor approx.: 5.500 mm Dimensions L x W x H: 5.400 x 3.300 x 5.700 mm Weight of machine approx.: 80 ton Control: Siemens S5

pressure: 25 t no. of strokes: 60-300 Hub/min sheet width: 150 mm ram - range of adjustment: 6-50 mm table surface area: 350x400 mm ram surface: 250x250 mm hole in the table: 130x150 mm weight of the machine ca.: 3 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t stroke: 10-80 mm no. of strokes: 65-400 Hub/min ram - range of adjustment: 80 mm table surface area: 1030x550 mm ram surface: 920x450 mm hole in the table: 700x200 mm : 420 mm weight of the machine ca.: 10 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
