KERN hspc used machines

This 5-axis KERN HSPC EVO was manufactured in 2005. It features a spindle speed of 50,000 RPM, a tool magazine with 95 pieces, and a workpiece magazine with 24 pieces. The machine includes a Heidenhain iTNC530 control system and HSK 25 special holder. Note: the changer arm requires repair. If you are looking to get high-quality milling capabilities, consider the KERN HSPC EVO machine we have for sale. Contact us for more information.

1 KERN high precision Micro 5 Axis CNC Milling & Drilling machine type HSPC 2216, year 1997, serial number 352, HEIDENHAIN type TNC 426 PB CNC 5-axes contouring controller, polymer concrete monobloc machine frame, working ranges X 220mm, Y 160mm, Z 248mm, electro pneumatic tool changer, magazine for 32 tools, tool changing time approx. 3,0 sec., mid chip-to-chip period approx. 7 sec., brushless and digital drive system travel speed 6.000 mm/min., Z-axis protection by s/s lamelles, half-round sliding door offering a maximum of operator handling comfort, standard chip tray for protection of the X and Y axis, with HEIDENHAIN electronic handwheel type TNC 426 for manual adjustment of the axes, Table 365 x 240mm, Max Clamping area 350 x 230mm, Max workpiece weight 40Kg, 4th & 5th Axis attachment, Fischer Precise Spindle 42,000rpm, 2.6Kw, HSK25E Tool Adapter,  ...

Controls: HEIDENHAIN TNC 426, connected load: 7.7kW, including Rotator 3R WorkPal, with documentation, without spare parts.

Controls: HEIDENHAIN TNC 426, connected load: 7.7kW, including Rotator 3R WorkPal, with documentation, without spare parts.

Used KERN K980 paper-endless cutting machine. The continuous cutter meets all the requirements of computer printout processing at maximum speed. The proof is 34,200 high-quality cuts per hour.

Used chamber filter press equipped for 10 filter plates & 10 filter cloths, pressure switch, pressure gauge, stainless steel cake tray, stainless steel piping, expansion tank, check valve, etc.

Key data: 560 mm, 1200 mm, 380 mm

Lathe Core Three-jaw chuck Multifix B 2 Holder Spindle bore 52 mm Speeds 38 - 1900 rpm Steels Chuck Sharpen 380 V 25 A Length 2.80 m Width 1.00 m Height 1.60 m

PRECISION SCALE M. No.: WD080052457 Equipment / Additional information: Max: 36 kg / d=10g

Industrial scale IFB 150K20DLM, weighing range 60 kg; 150 kg, readability 20 g; 50 g Mounted on trolleys Heavy-duty industry standard suitable for harsh use Platform: Stainless steel weighing plate, painted steel substructure, silicone-coated aluminium load cell, IP65 dust and splash water protection Large, backlit LCD display, digit height 52 mm Dimensions weighing plate, stainless steel W×D×H 650×500×142 mm Dimensions Evaluation Device W×D×H 250×160×58 mm

Circulation/rotation Ø over bed: 475 mm Rotation/rotation Ø via cross slide: 260 mm Sledge path plan: 260 mm centre distance: 1000 / 1500 / 2000 mm power capacity: 22 kW Gear stages. m= manual / e= electric.: 2 e Spindle head DIN 55026 / DIN 55027: A6 / 6 Spindle Ø in front bearing: 115 mm spindle bore: 78 / 70 mm turning speed range (V-constant): 1 - 3.000 U/min feed range flat: 1µ - 1.000 mm/U feed range lengthwise and thread: 1µ - 2.000 mm/U Rapid traverse plan/longitudinal: 5 / 10 m/min diameter of quill: 70 mm quill travel: 120 mm quill inner cone: 5 MK This machine is used for the production of individual parts and small batches from simple to the most complex contours. It is characterised by: --> Ease of operation Precision Working range

Kuvertiermaschine / Envelope Inserting Machine Kern 686 T-Linie Einzelblatt-Kuvertiersystem / Single Sheet Baujahr / Year 2016 Geschwindigkeit / Speed max. 8.000 cycles/h verarbeitet Briefumschlagformat von C6 bis C5 / processes envelope format from C6 to C5 Immer im Full-Service Vertrag / Always in a full-service contract

Hilger & Kern P80 Pump Basic version P80 Barrel size 80l Gear ratio (drive) 56:1 Flow rate (with 20 double lifts) l/min 0.61 Material Viscosity (ball valve pump/scoop piston pump) 2.5 million Working pressure (max.) bar 20-250 (315) Air consumption at 20 double strokes l/min 220 Dimensions base plate (A x W) mm 610 x 500 Height retracted mm 1400 Height extended mm 2200 Weight without container kg 65 / 72 Maximum container height mm 750 Maximum container size 80 Maximum container Ø outside mm 440 A single pump is included Complete plant closure, large selection of mezzanines, pallet racks, shelving racks, paternosters. High Quality Industrial Machinery, Lathes, Grinding Machines, Hand Machinery Suppliers in China More items - new and used - can be found in our shop! International shipping costs on request!

Center height: 230mm, center width: 1500mm, swing diameter over bed/cross slide: 475mm/260mm, max. workpiece weight: approx. 500kg, spindle diameter: 1000mm, spindle bore: 62.5mm, max. chuck diameter: 250mm, travel X/Z: 1330mm/280mm, rapid traverse X/Z: 8m/4m/min, speed: 3150rpm. Machine dimensions X/Y/Z: approx. 3400mm/2000mm/1600mm, weight: approx. 3300kg, control: Bosch CC 200T. Documentation vorhanden. An inspection on site is possible.

max: 1500 KG min: 10 KG serial number: CO13136LG documentation: keine : 30 € The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis KERN CD 480/2000 horizontal turning machine was manufactured in 2010. It features a Heidenhain Manual Plus 620 control, C-axis, driven tools, a 12-fold revolver, and a chip conveyor. With a spindle speed of up to 3000 UpM and a spindle bore of 82 mm, its ideal for precise turning operations. Consider the opportunity to buy this KERN CD 480/2000 horizontal turning machine. Contact us for more information.

A two stage tea and spice mixer Gebrüder Kerner with renewed control circuitry and wiring is available. Volume: 2000l, Material: steel, Drive power: 3.1kW, Control: Siemens. Without stand and feet. An on site inspection is possible.

Absolute encoder, encoder, rotary encoder, encoder, incremental encoder -Manufacturer: Balluff, Incremental Encoder from lathe Kern CD 480 -Type: BDG 6360-0-05-W031-1024-65// -Price: complete -Dimensions: 100/90/80 mm -Weight: 4.3 kg

Flat belt pulley, toothed pulley, multi-belt pulley, Toothed Pulley -Toothed disk: from a Kern CD 480 lathe -Type: P60-5M -Mount: hollow shaft Ø 25 mm -Dimensions: Ø 103 x 77 mm -Weight: 2.9 kg

CO₂ laser cutting machine manufactured in 2022. This KERN KER60120-KT500 OPF features a working area of 1524 × 3048 mm and a maximum workpiece height of 50 mm. It includes a powerful 500 W CO₂ laser and offers various work tables for different materials. If you are looking to get high-quality cutting capabilities, consider the KERN KER60120-KT500 OPF machine we have for sale. Contact us for further details regarding this machine.

Kern EWJ 6000-1SM Precision Balance – 6000 g / 0.1 g, legal-for-trade (calibrated until 2027) Sell a Kern EWJ 6000-1SM precision balance for laboratory, workshop, pharmacy, manufactory or quality control. High-quality brand scale from Kern & Sohn (Made in Germany). The scale is calibrated, the calibration is still valid until 2027 – a real advantage, as it can be used immediately and the calibration costs are saved. Technical data: Manufacturer: Kern & Sohn Model No.: EWJ 6000-1SM Weighing range: 6000 g Readability: 0.1 g Legal-for-trade, calibrated by 2027 Functions include: counting, percentage weighing, tare Mains and battery operation Condition: good Price: 280 € VB plus VAT Pick-up only The sale is commercial under exclusion of warranty. As this is a used item, it is not possible to return or exchange.

Kern GAB 30K5DNM Bench Scale Counting Scale – 30 kg, legal-for-trade (Made in Germany) Description: Sell a robust Kern GAB 30K5DNM bench and counting scale for commercial, warehouse, shipping, production, pharmacy or sales. Brand quality from Kern & Sohn. Ideal for packing, dosing and portioning as well as for counting small parts via the piece counting function. Technical data: Manufacturer: Kern & Sohn Model No.: GAB 30K5DNM Weighing range: 30 kg (dual: 0-15 kg / 5 g, 15-30 kg / 10 g) Legal-for-trade (calibration class III) Piece counting function, tare, weighing with tolerance range Large LCD display Mains and battery operation (battery optional) Condition: as new, hardly used – the original protective film on the weighing plate is still present. Price: 200 € VB plus VAT Pick-up / shipping only by arrangement. The sale is commercial under exclusion of  ...

CONTROLS   NC controls HEIDENHAIN BASIC FUNCTIONS   number of spindles: 1 WORKING RANGE TURNING   swing diameter (max): 320 mm   turning diameter (max): 150 mm   worpiece length max.: 750 mm MAIN SPINDLE   spindle revolutions (max): 4000 /min   drive power: 16 kW TAILSTOCK   sleeve diameter: 60 mm   taper: MK 4 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 2500 kg ATTACHMENTS (TURNING)   European CE standards: yes 6000 Hours

turning diameter: 650 mm turning length: 2000 mm turning diameter over slide: 260 mm Holder Multifix: control: Siemens type: Sinumerik tailstock quill taper MT: 5 transmission ratio: 2 turning speeds: 1-2000 U/min spindle bore: 106 mm total power requirement: 38 KW weight of the machine ca.: t dimensions of the machine ca.: 7,4x2,5x2,5 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hi ...

greates pass round over bed: 650 mm Swing dia. over traverse guideway: 420 mm Distance between centres: 2.000 mm control: Sinumerik Siemens slide travel X-axis: 440 mm slide travel Z-axis: 2.000 mm Main spindle:: turning speed range - main spindle: 1 - 3.000 min/-1 power capacity - main spindel: 33 / 27 / 22 kW transmission ratio: 2 spindle diameter in front bearing: 140 mm spindle bore: 106 mm standard chuck diameter: 250 - 400 mm spindle head: DIN 55026 / A8 turret head: 12 pos. turning tool - shaft cross cut: 32 x 32 mm feeds:: rapid traverse: X: 5 m/min rapid traverse: Z: 10 m/min feed range: X: 0,001 - 1.000 mm/min feed range: Z: 0,001 - 2.000 mm/min power feed coss: 9.000 N power feed longitudinal: 12.000 N Tailstock:: diameter of quill: 100 mm quill travel: 200 mm taper of center: MK 6 total power requirement: 38 kW weight of the machine ca.: 6,0 t dimensions of the machine ca. ...

greates pass round over bed: 650 mm Swing dia. over traverse guideway: 420 mm Distance between centres: 2.000 mm control: Sinumerik Siemens slide travel X-axis: 440 mm slide travel Z-axis: 2.000 mm Main spindle:: turning speed range - main spindle: 1 - 3.000 min/-1 power capacity - main spindel: 33 / 27 / 22 kW transmission ratio: 2 spindle diameter in front bearing: 140 mm spindle bore: 106 mm standard chuck diameter: 250 - 400 mm spindle head: DIN 55026 / A8 turret head: 12 pos. turning tool - shaft cross cut: 32 x 32 mm feeds:: rapid traverse: X: 5 m/min rapid traverse: Z: 10 m/min feed range: X: 0,001 - 1.000 mm/min feed range: Z: 0,001 - 2.000 mm/min power feed coss: 9.000 N power feed longitudinal: 12.000 N Tailstock:: diameter of quill: 100 mm quill travel: 200 mm taper of center: MK 6 total power requirement: 38 kW weight of the machine ca.: 6,0 t dimensions of the machine ca.&nb ...
