3 KOVOSVIT MAS vertical numerically controlled machining centres used machines

overhauled: 2024 Control Heidenhain ... TNC 620 Clamping table surface ... 1300 x 600mm Axis X ... 1016mm Axis Y ... 610mm Axis Z ... 660mm Spindle speed ... 0-10000 rpm controlled axes ... 3 cooling... 20bar ISO 40 L x W x H ... 2700x3000x2940mm Machine weight... 5500kg Magazine spaces ... 20 The machine has undergone a complete overhaul. More info on request.

Key data: 1016 mm, 610 mm, 710 mm

Control Heidenhain ... TNC 530 Clamping table surface ... 1300 x 600mm Axis X ... 1016mm Axis Y ... 610mm Axis Z ... 710mm Spindle speed ... 0-10000 rpm controlled axes ... 3 IKZ ISO 40 Magazine spaces ... 24 Machine weight ... 5500kg

Key data: 1000 mm, 600 mm, 660 mm

Control Heidenhain ... TNC 620 Clamping table surface ... 1300 x 600mm Axis X ... 1000mm Axis Y ... 600mm Axis Z ... 660mm Spindle speed ... 0-10000 rpm controlled axes ... 3 cooling ... 20bar, Grundfos ISO 40 Max. table load ... 700 kg L x W x H ... 3000 x 2700 x 2940mmmm Machine weight... 5500kg Magazine spaces ... 24 Handwheel Heidenhain HR510FS Workpiece Probe Heidenhain TS460 Rinsing gun 10bar The machine has undergone a complete overhaul. More info on request. The machine is ready for the viewings.

Vertical machining center MAS MCV 1016 QUICK

This 5-axis KOVOSVIT MAS MCV 1000 Speed 5AX was manufactured in 2011. It features a spindle speed range of 20-12,000 rpm and a spindle drive power of 33/45 kW. The machine can handle a maximum tool weight of 6.5 kg and includes a 30-tool magazine. With a table load capacity of 400 kg and dimensions of 5145 x 3665 x 3330mm, its ideal for complex machining tasks. If you are looking to get high-quality milling capabilities consider the KOVOSVIT MAS MCV 1000 Speed 5AX machine we have for sale. Contact us for more information.

This 3-axis KOVOSVIT MAS MCV 750 was manufactured in 2004. It features an X-axis travel of 750 mm, Y-axis travel of 500 mm, and Z-axis travel of 500 mm. The machine includes a table size of 1000 x 500 mm and a maximum spindle speed of 10,000 RPM. If you are looking to get high-quality machining capabilities, consider the KOVOSVIT MAS MCV 750 vertical machining centre we have for sale. Contact us for further details.

This 3-axis KOVOSVIT MAS MCV 750 was manufactured in 2014. It features an X-axis travel of 750 mm, Y-axis travel of 500 mm, and Z-axis travel of 500 mm. The machine is equipped with a spindle speed of 12,000 rpm and a tool magazine that holds 20 tools. If you are looking to get high-quality machining capabilities, consider the KOVOSVIT MAS MCV 750 vertical machining centre we have for sale. Contact us for further details.

Radial drilling table Dimensions LxWxH 600 x 750 x 550 mm Tilting 0o - 90o This radial drilling table is unused

Arm length: 1600 mm Drilling capacity in steel: Ø 50 mm Tapping in steel: M50 x 1.5 mm Spindle holder: MK 5 Spindle speeds: 28 - 2500 rpm. Spindle feed: 0.05 - 2 mm/rev Spindle stroke: 310 mm Spindle -> slab: 1500 mm max. Tension throwers; 1000 x 750 mm Clamping flat floor plate: 1820 x 986 mm Complete with: - Kuhlanlage - Operating instructions Spindle motor: 4 kW Country of origin: Czech Republic Machine Weight: 4300 kg Machine LxWxH: 3250 x 1120 x 3400 mm

Control Heidenhain ... Manual Plus 4110 Turning diameter ... 500mm Turning length ... 1500mm Spindle bore... 82mm Spindle speed ... 0-3000 rpm. Machine weight ... 2500kg L x W x H ... 3092 x 1370 x 1785mm Main engine power ... 17kW Max. workpiece weight ... 1000kg Circumferential diameter via support ... 350mm The machine is in good condition, possible to test under power.

Max. Drilling Diameter... 50mm Spindle holder ... ISO 50. Max. vertical arm adjustment ... 875mm Max. distance of the spindle axis from the stand ... 1250mm Main engine power ... 4kW Total power requirement ... 6kVA L x W x H ... 2750 x 1120 x 3271mm Machine weight ... 4550kg

KOVOSVIT MAS S80i CNC turning center was built by KOVOSVIT MAS a.s. in the Czech Republic. This extremely powerful machine is used for precision hole drilling, threading and turning of cylindrical, conical and spherical surfaces. The offer also includes a wide range of equipment in the form of components from renowned brands, which guarantee excellent repeatability of the manufactured parts over many years of intensive operation. These include, among others, a new tool measuring probe, a hydraulic tailstock and a HEIDENHAIN intelligent CNC control. All this makes the S80i CNC CNC lathe the perfect choice for both unit and small batch production. The total weight of the machine is 6700 kg. Technical specifications of the KOVOSVIT MAS S80i universal lathe - maximum turning diameter above the bed: 680 mm - maximum turning diameter over the slide: 430 mm - maximum bar diameter: 80 mm  ...

bore capacity in steel (diameter): 60 mm / MK5 arm length: 1600 mm quill stroke: 310 mm spindle speed:: 28...2500 U / min table-size: 1470 x 986 mm total power requirement: 4 kW weight of the machine ca.: 4,6 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Tool changer turret, material ejection, control unit with analogue counting unit, bar feeder in front, L = approx. 3,000 mm,

Horizontal turning machine manufactured in 2005. This KOVOSVIT MAS OPTIMAT A42 features a machine weight of 2500 kg and a total power consumption of 12 kVA. With 2 units available, if you are looking to get high-quality turning capabilities, consider the KOVOSVIT MAS OPTIMAT A42 machine we have for sale. Contact us for further details.

This 2-axis KOVOSVIT MAS Optimat A52 was manufactured in 2003. It has a machine weight of 2520 kg and includes a bar feeder guide tube system, tool turret station, and cooling fluid hose lines. If you are looking to get high-quality turning capabilities, consider the KOVOSVIT MAS Optimat A52 vertical horizontal turning machine we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 1998. This KOVOSVIT MAS OPTIMAT A50CA weighs 2530 kg and includes a bar feeder system with a long loading channel attached to the machine. If you are looking to get high-quality turning capabilities, consider the KOVOSVIT MAS OPTIMAT A50CA machine we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 1994. This KOVOSVIT MAS OPTIMAT A50CA features a robust design with a machine weight of 2490 kg. It includes essential equipment such as a bar feeder guide channel system and a tool turret assembly. If you are looking to get high-quality turning capabilities, consider the KOVOSVIT MAS OPTIMAT A50CA machine we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 2002. This KOVOSVIT MAS Optimat A42 features a robust design with a weight of 2505 kg and a total power consumption of 12 kVA. It is equipped with a manual guide bar/tube loading support system for enhanced functionality. If you are looking to get high-quality turning capabilities, consider the KOVOSVIT MAS Optimat A42 machine we have for sale. Contact us for further details.

bore capacity in steel (diameter):40 mm arm length:1200 mm workpiece height max.:1227 mm surface area:1475 x 900 mm no. of flutes:3 groove width:25/ 50 mm spindle cone:MORSE 4 number of spindle speeds:45- 2800 U/min spindle headstock:Bew.Arm : 945 mm with vertical adjustment:Arm 710 mm spindle diameter:35 mm bore depth:300 mm total power requirement:3,0 kW weight of the machine ca.:2800 kg dimensions of the machine ca.:2290 x 910 x 2860 mm

bore capacity in steel (diameter):40 mm arm length:1200 mm workpiece height max.:1227 mm surface area:1475 x 900 mm no. of flutes:3 groove width:25/ 50 mm spindle cone:MORSE 4 number of spindle speeds:45- 2800 U/min spindle headstock:Bew.Arm : 945 mm with vertical adjustment:Arm 710 mm spindle diameter:35 mm bore depth:300 mm total power requirement:3,0 kW weight of the machine ca.:2800 kg dimensions of the machine ca.:2290 x 910 x 2860 mm

Inv. Num. : 6521 Type: Compact A35 Producer: Kovosvit Generated: 2005 Parameters: bar diameter: 35 mm Maximum main spindle power: 7.5 kW Maximum spindle speed: 7000 1/min Number of CNC controlled axes: 8pcs Length: 2250 mm Width: 1480 mm Height: 1890 mm Weight: 3450 kg Equipment: Bar feeder (3 meters) LNS Sprint 555 Part of the sale: Collets Auxiliary head Polished holders VDI25/ER32 Axis tool holder VDI25 Straight and angled power tool holders Equipping the machine with tools (square 16x16 mm) The feeder is equipped with guide channels, pushers and reducing bushes

Radial drilling machine, used Manufacturer: KOVOSVIT Type: VO 50 Year built:1999 Projection: 1600 mm Drilling capacity: 60 mm Quill stroke 310 mm Table / footprint 1470 x 986 mm Weight: approx. 5 t

Catalog No. : 7654 Type: MT 50 Producer: KOVOSVIT Made in: 2001 Characteristic: Control system: Siemens Sinumerik 810 D Maximum-turning length: 1500 mm Turning diameter over bed (max): 500 mm Workpiece weight: 350 kg Total power demand: 30 kVA Weight: 2500 kg Equipment: Chip conveyor Tailstock Knife head

Manufacturer: KOVOSVIT Model : VO 50 Year of Manufacture: 1995 Condition: Used Weight (Kg): 4300 kg Find more here - / Contact us at -
