MAYER fsk used machines

Glue dosing station MAYER AND MAYER DXR R2020R L-P-PUB PDX20 40-100 P manufactured in 2015 in Germany by MAYER & MAYER HANDELS GMBH. The station was in use for about 3 months in the process. After this time, it was shut down, cleaned and properly secured. All gaskets in the station were replaced with new ones. It is a charging station for manual dispensing / application guns for two-component adhesives. The gun is included for free. Spare parts are offered for the station. Price of the parts to be individually agreed.

8-30 mm Still in operation: Yes Available: immediately

<br>8-30 mm<br><br>Still in operation: Yes<br>Available: immediately

Veneer saw

Veneer saw Mayer Maximum insert length 3050mm good condition first-hand

KARL MAYER RS-3-MSUS-V RS MSUS-V High-performance warp-knitting machine with course-oriented weft insertion for the production of heavyweight fabrics and composite fabrics GEO-TEXTILE FABRIC 540CM 6 gauge Year 2007 Serial number 96700 Running condition (Currently producing fabric for bullet proof jackets) Product features • Production of grid structures or closed fabrics • Combination with substrate fabric according to the product application • Strong knitting elements and yarn feeding guides for the processing of thick, high-performance yarn materials • Special feeding elements for the production of fabrics with fiberglass, carbon and other high-performance fibers possible Karl Mayer Warping beamer DS 21/30 Year 1997 Running condition and video is available

Qty. 1 Second-hand plate saw Mfc.: Mayer Model: PS3 E Built: 1989 – new electrical panel in 2010 Plate dimensions: Length: 3100 mm Thickness: 70 mm Saw Motor power: 11 kW, 2890 RPM Blade dia.: 350 mm Blade tension: Hydraulic Footprint: 5700 x 7500 mm –W x L Lubrication: Micro-spray ACCU-LUBE

A)01 Karl Mayer Direct Warper – ZM – SP 1700/1000 year 1997, working width 180 cm, Max. Beam Flange Diam. 1,016 mm with 01 Karl Mayer warping creel, H-type, 630 creeling positions Disc brakes, electr. stop motion, pitch 30 cm – adjustable abbot. 60-70 fractional beams (for direct warper and sizing) B)01 Karl Mayer Rotal Sizing machine, type ELC-O-TENS year 2000, with Pleva humidity and tension control, warp beam creel, for max. 16 warp beams Nom. working width 180 cm max. beam flange Ø 1,016 mm pneum. Brakes 1 sizing double trough Nom. working width 180 cm Pre-Wetting double dip and squeeze roller pair Cylinder Dryer 10 drying cylinder Ø 800 mm Partitioning Field Abt. 4.5 mtrs. Waxing device Beaming machine / headstock max. nom. working width 240 cm, max. beam flange Ø 1100 mm speed up to 140 m/min Beam Pressure Device Size kitchen turbo cooker,

Key data: 6500 mm, 100 mm

Horizontal panel sizing saw Longitudinal saw with 6,500mm cutting length Panel dimension 6,300mm Main saw motor 35KKW frequency-controlled Feed speed saw carriage 5-80m/min. Max. saw blade diameter 550mm with 130mm protrusion Saw blade deviation sensor Cut-gap closers Pressure device 2,600 - 100mm Material tray 6,300mm Extension to 10,900mm 9 Parcel jammers 4 Cross aligners Pressing device 100- 2,600mm, approx. 2,000mm behind the cutting line Pressing device 100- 2,600mm, approx. 4,000mm behind the cutting line Electronic Control PC6200 Machine Tables Air Cushions with Steel Nozzles 1 angle table 2,600x1,000mm with angle stop rail 4 side table 2.600x800mm More information on request!

Pos. 9749.13 - 1 MAYER type Relanit 3.2 II, gauge 28, diameter 30, jersey open knit, 2640 needles, 96 feeders, lycra, 3+1 tracks Pos. 9750.11 - 1 MAYER type Relanit 4, gauge 28, diameter 30, jersey tubular knit, 2640 needles, 96 feeders, 3+1 tracks Pos. 9751.18 - 1 MAYER type Relanit 4, gauge 24 installed and spare cylinder gauge 28, diameter 30, jersey tubular knit, 2268 needles, 96 feeders, 3+1 tracks Pos. 9752.1 - 1 MAYER type MV4 II, gauge 20 installed and spare cylinders gauge 24 and 28, diameter 30, jersey tubular knit, 1872 needles, 96 feeders, 4 tracks Pos. 9753.8 - 1 MAYER type FLF, gauge 14, diameter 30, rib tubular knit, 2 x 1320 needles, 44 feeders, lycra, 1/1 tracks Pos. 9754.5 - 1 MAYER type MLBF, gauge 22, diameter 30, plush tubular knit, 2068 needles, 96 feeders, 4 tracks Pos. 9755.17 - 1 SANTONI type Zenit SV, gauge 28, diameter 34, jersey open knit, 29 ...

: 200 mm mechanical: ja weight: 1,5 t : ja The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

We have a package of KARL MAYER machines YEAR: MACHINE # LA-TEKS # BRAND: GAUGE WIDTH NAME 2000 86213 J30 KARL MAYER E14 230" RJPC 1996 82352 J2 KARL MAYER E14 230" RJSC 2000 86212 J29 KARL MAYER E14 230" RJPC 1994 78964 J8 KARL MAYER E14 150" RJSC 1999 86449 J11 KARL MAYER E14 130" RJPC 1995 80286 J45 KARL MAYER E14 130" RJSC 2002 89060 J31 KARL MAYER E18 230" RJPC 2002 89061 J32 KARL MAYER E18 230" RJPC 2000 86208 J26 KARL MAYER E18 230" RJPC 2000 86209 J27 KARL MAYER E18 230" RJPC 2000 86224 J28 KARL MAYER E18 230" RJPC 1996 81110 J1 KARL MAYER E18 230" RJSC 1995 81832 J10 KARL MAYER E18 230" RJSC 1996 82353 J7 KARL MAYER E18 130" RJSC 1994 78965 J9 KARL MAYER E18 130" RJSC 1995 81363 J43 KARL MAYER E18 130" RJC 3/2 F 2002 88923 J5 KARL MAYER E24 230" RJPC 20 ...

This MAYER Otto Meyer Type PS80P was manufactured in 2019. A robust panel saw with a cutting length and width of 4300 mm each, powered by a 9 kW main motor. Features include optimized travel speeds via an additional frequency converter and an automatic electronic clamping detection for panel corners. Consider the opportunity to buy this MAYER Otto Meyer Type PS80P panel saw. Contact us for more information.

Mayer FH2-3120 veneer saw, fine-cutting saw with joining unit (planing unit) and veneer stop table Robust mechanical engineering from Mayer A video of the running machine can be sent on request. For tear-free and joint-tight cutting of veneer, including heavy-cut veneer Cutting length max. 3100mm The sawing unit and joining unit are combined in one unit, so that only one unit has to be moved. Easy to guide sawing unit, runs on linear guides. Rear storage table with penetrating finger stop, adjustable from approx. 2 - 62cm, with pneumatic clamping and digital display Pneumatic workpiece clamping Drive motor saw 1.8kW, milling 1.0kW The motors can be switched on practically on the handle, so they only run when they are needed. HM-tipped fine-cut blade, sharpened Plough head Z4, equipped with new carbide indexable inserts Practical front veneer shelf, pull-out for pla ...

Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor -Power: 1.3 kW at 2800 rpm at 50 Hz -Voltage: 380 volts -Receiving shaft: Ø 24 mm -Tool: Ø 118 mm -Dimensions: 380/200/H240 mm -Weight: 25 kg

A direct warping machine Karl Mayer is available. Working width: 42inch, yarn feeding: NC. Including memory, roller unit and all reeds. Without creel. An inspection on site is possible.

Two similar Karl Mayer warp knitting machines are available. 1) Karl Mayer KS 3, year of manufacture: 1988, working width: 130 inch, gauge: E28, yarn feed: FAG GB1-2-3, latch needles: L-28-66H-49, guide bars: SPEC.51.50.G.104, sinker: P-28-66-VP19, speed: 1500, yarn monitoring: Laser 4080, fabric monitoring: Scanner 5090. 2) Karl Mayer KS 3, year of manufacture: 1986, working width: 84 inch, gauge: E28, yarn feed: FAG GB1-2-3, latch needles: L-28-66/3-49, guide bars: SPEC.51.50.G.104, sinker: P-28-66-V-3-19, speed: 1300, yarn monitoring: Laser 4080. An on-site inspection is possible.

A Raschel warp knitting machine Karl Mayer is available. Working width: 130inch, gauge: E32, yarn feed: EBA-1, guide bar element: C-32-28/P2, guide needle element: Spec-38-45 G105, latch needle element: L-32-93H-0, knock-over comb element: S-32-93H-0, speed: 1800-2000, yarn monitoring: Laser 4080. Including computer. Documentation available. An on-site inspection is possible.

Flange ball valve ball valve Böhmer DN600 DN 600 PN16 Naturist FSK 016.600 ball valve lanschkugelhahn / ball valve Manufacturer: Böhmer DN 600 PN 16 Model: Naturist FSK 016.600 Year of construction: 2006 NEW, from stock reversal

3-channel foil nozzle EDS FSK-600 with flex lip (tire tubes) Output capacity: 40 -50 kg/h Lip adjustment with screws and storage beams in the main layer Film width: max. 600 mm Film thickness: 0.1 – 3.0 mm 3 computer-calculated hanger channels for optimal melt distribution Distribution: A 10-15%, B 70-80%, C 10-15% Drilled nozzle lip for liquid temperature control 9 heating zones with high-performance cartridge heaters Connected load for nozzle: 18 kW (0.5 kW x 36) Fully wired for 240 V / single-phase Nozzle dimensions (L x W x H): 450 x 650 x 400 mm, weight: 760 kg Coex adapter block for one middle and two outer layers Dimensions adapter (L x W x H): 320 x 210 x 400 mm Remark: Tool steel 1.2311 All flow surfaces are chrome-plated (25-30 μm)

Manufacturer: FieldComm Group Model: HCF-Tool-35 (part of the HART Physical Layer Test Kit) Type: HART FSK Physical Layer Test Interface (Modem) Function: Specifically designed to test the conformity of HART master and slave devices to the Physical Layer specification Used as a PC interface for all physical layer testing Technical features: RS-232 interface to PC Output signal amplitude adjustable (via potentiometer without stop) Output voltage: typ. 60 mV to max. 1.6 V over 250 Ohm load Compatible with desktop and notebook PCs (4-6 V output voltage recommended) Supports XMTR-MULTIVARIABLE software for simulation and testing Auction-ID: A1-45208-67

Manufacturer: FieldComm Group Model: HCF-Tool-35 (part of the HART Physical Layer Test Kit) Type: HART FSK Physical Layer Test Interface (Modem) Function: Specifically designed to test the conformity of HART master and slave devices to the Physical Layer specification Used as a PC interface for all physical layer testing Technical features: RS-232 interface to PC Output signal amplitude adjustable (via potentiometer without stop) Output voltage: typ. 60 mV to max. 1.6 V over 250 Ohm load Compatible with desktop and notebook PCs (4-6 V output voltage recommended) Supports XMTR-MULTIVARIABLE software for simulation and testing Auction-ID: A1-45208-68

1 stitch bonding machine KARL MAYER type MALIMO MALIWATT 1405C N3600, machine fully overhauled in 2013, width 3600 mm, gauge 18, 2 bars,

Various woodworking machines from different manufacturers are available. 1) Max Striffler type 2750 double mitre saw, year of manufacture: 1983. 2) Stegherr KSF-V universal cross rung miller, year of manufacture: 1991. 3) Stegherr SDB dowel drilling machine for frame constructions, year of manufacture: 1988. 4) Axel Wirth LW 100.5/300, year of manufacture: 2008. 5) Ruchser RU-EBL2.5-M fitting drilling machine, year of manufacture: 2001. 6) Max Mayer (MAKA) STV 170 oscillating chisel mortising machine, year of manufacture: 1994. 7) Max Mayer (MAKA) STV-71 oscillating chisel mortising machine, year of manufacture: 1987. On-site inspection is possible. The machines are only available as a package.

Format4 Kappa Automatic FELDER Group cutting 3200 x 3200 m cutting height 80mm saw diameter 320 mm scoring diameter 150 mm motor power 14 kW optimization Other offers - click - Mayer Holzma Panhans Schelling Meyer Striebig Holz-Her Elcon Strebig Holzher Holzing Scm Nohoma Holzma Altendorf Martin Format4 Rema Felder Sicar Scm Bernardo Casadei Holzmann Stomana Robland Sac Schnaider Steton Winter Scheer
