PINACHO st used machines

This Pinacho STH 400-105×3000 was manufactured in 2017. A robust horizontal turning machine with a swing over bed of 400 mm and a distance between centers of 3000 mm. Features a high-torque spindle and CNC-controlled feed for precise heavy-duty turning. Ideal for machining shafts, pipes, and flanges. Consider the opportunity to buy this Pinacho STH 400-105×3000 horizontal turning machine. Contact us for more information.

This Pinacho Taurus 260 was manufactured in 2000. A robust horizontal turning machine, it features a maximum turning length of 1500 mm and a diameter of 520 mm. Equipped with a spindle speed of up to 2500 1/min and a main spindle power of 11 kW, it includes accessories like steady rests, a hydraulic chuck, and tool holders. Consider the opportunity to buy this Pinacho Taurus 260 horizontal turning machine. Contact us for more information about this machine.

Horizontal turning machine manufactured in 2007. This Pinacho Smart-turn6 260 features a distance between centers of 1,500 mm and a maximum turning diameter with soft jaws of 500 mm. It is equipped with a spindle speed of 2,400 rpm and a spindle bore of 80 mm. If you are looking to get high-quality turning capabilities, consider the Pinacho Smart-turn6 260 machine we have for sale. Contact us for further details.

Ref. -No.: 10314 Manufacturer: PINACHO Year of construction: 2005 Type of control: Konventionell Storage location: Halberstadt Country of origin: Spain Travel quill: 180 mm Turning Diameter: 630 mm Turning Length: 3000 mm Turning Diameter Over Bed: 620 mm Cross Movement. (X-Axis): 365 mm Tailstock Quill Diameter: 72 mm Turning diameter over cross slide: 880 mm

Universal CNC cycle separation machine of the brand Pinacho suitable for tooling, fixture construction, training and mold making Circumferential diameter 360mm Center width 1000mm Control Fagor 8055 Tailstock MK 3 Tool station Barufaldi 6-fold Speed 1-4000rpm Connection 380V - 5.5 KW

Universal CNC cycle separation machine of the brand Pinacho suitable for tooling, fixture construction, training and mold making Circumferential diameter 360mm Center width 1000mm Control Fagor 8055 Tailstock MK 3 Tool station Barufaldi 6-fold Speed 1-4000rpm Connection 380V - 5.5 KW

Key data: 400 mm, 1000 mm

Pinacho Mustang 200 - CNC lathe - Fagor 8055 CNC control - Operating modes: manual/cycle-controlled - 8-cavity tool turret - Year of construction 2001 Specifications Capacity: - Center height: 200 mm - Center width: 1000 mm - Permissible Ø over guide bed: 400 mm - Permissible Ø over longitudinal slide: 370 mm - Permissible Ø over cross slide: 210 mm - Bed width: 300 mm Headstock: - Bore main spindle: 65 mm - Main spindle nose: Camlock-n°6 / DIN 55027-n°6 - Morse taper of the main spindle: MK5 - Spindle speeds: 2 - Constant cutting speed: 0-750 / 750-3000 rpm Feeds: - Working thrust Z/X: 0 - 7000 mm/min - Rapid traverses Z/X: 10 m/min Tailstock: - Tailstock Ø: 58 mm - Tailstock shaft travel: 155 mm - Morse taper tailstock: 4 Engines: - Power main motor: 7.5 kW - Power DC motor Z-axis: 6.8 Nm - Power DC motor X-axis: 3.4 Nm - Motor pump power: 0.57 ...

A Pinacho CNC precision parallel lathe is available. Center height: 180mm, center width: 750mm-1000mm, turning diameter over guide bed/longitudinal slide/cross slide: 360mm/335mm/198mm, bed width: 250mm, bore: 42mm, speed: 4000rpm, feed X/Z: 10m/min, rapid traverse X/Z: 10m/min. Tailstock shank diameter: 58mm, tailstock shank length: 200mm, Morse taper: MK3, min. travel of moving/fixed steady rest: 10mm, max. travel of moving/fixed steady rest: 70mm/114mm, control: Fanuc 0i. Documentation available. On-site inspection is possible

Manufacturer: Pinacho Model: Smart Turn 6/180 Power: 7.5 kW Frequency: 50 Hz Control: FANUC CAPACITY • Center height: 180 mm • Center width: 750–1000 mm • Permissible diameter over bed: 360 mm • Permissible diameter over longitudinal slide: 335 mm • Permissible diameter over cross slide: 198 mm • Bed width: 250 mm SPINDLE • Spindle bore: 42 mm • Spindle nose: CAMLOCK no. 5 (DIN 55027 no. 5) • Spindle taper: Morse taper no. 4 • Number of spindle speeds: 1 • Cutting speed (constant surface speed): 0–4000 U/min FEED • Working feed Z,X (mm/min): 0–10000 mm/min • Rapid traverse Z,X (m/min): 10 m/min TAILSTOCK • Tailstock quill diameter: 58 mm • Tailstock quill travel: 200 mm • Tailstock taper: Morse taper no. 3 MOTORS • Main motor power: 5.5 kW • Feed force longitudinal (N): 4500 N • Feed force cross (N): 3500 N • Cool ...

Lathe Pinacho smart turn 6 BJ 2006

This Pinacho SE325 was manufactured in 2018. A reliable horizontal turning machine, it offers consistent performance for various machining tasks. Ideal for workshops seeking a dependable solution for turning operations. Contact us for more information.

Manufacturer PINACHO Model RHINO SK – 425 Year 2005 CNC GE Fanuc Series 21i-T Capabilities and advances Distance between points 5,000 mm. Stitch height 425 mm. Support Guides 2 Maximum allowable turning on a bed 850 mm. Maximum turning on transverse carriage 560 mm. Bed width 425 mm. Fast Forward X/Z Axes 10,000 mm/min Work progress X/Z axes 7,000 mm/min Head Head shaft pitch 85 mm. Nose head DIN 55027-nº8 Main Spindle Morse Taper 5 Head speed 0-2,000 rpm Automatic head ranges 2 Main Motor Power 11 kW Turret Automatic Turret Type Turret Positions 8 Counterpoint Hydraulic tailstock rod outlet INCLUDED Ø of the tailstock shaft 96 mm. Tailstock shank travel 215 mm MORSE 6 tailstock cone Equipment Self-centering 3-jaw hydraulic chuck, diameter 300 mm INCLUDED 4-support bezel Ø450 mm. INCLUDED 3-support bezel Ø250 mm. INCLUDED Plate Protection INCLUD ...

Details Turning diameter 165 mm Turning length 1000 mm Total power requirement 2 kW Turning diameter over bed 335 mm Rotary diameter via tool carriage 310 mm large turning diameter via cross slide 168 mm Bed width 250 mm Main spindle diameter 42 mm Main spindle nose CAMLOCK n-5 - DIN 55027 Morse taper 4 Spindle speeds 9 Speed range: 60-2000 rpm max. working feed 0-5000 mm/sec Rapid traverse 5 m/min Shaft diameter 48 mm Tailstock-Spindle Travel 140 mm Machine weight approx. 1100 kg Control CNC Control Name FANUC 21i/210i

Digital Turning diameter 120 mm Turning length 700 mm Spindle speed 2000 min-1 Tailstock

Center width: 1000mm, turning diameter over bed/crank/trolley: 360mm/510mm/205mm, spindle bore: 42mm, speed: 2100rpm, machine dimensions X/Y/Z: approx. 1950mm/900mm/1350mm, weight: approx. 750kg. On-site inspection is possible.

weight of the machine ca.: 3,9 t : 50 control: Fanuc changer: 6 fach centre distance: 1500 mm spindle bore: 80 mm available since 22th of september: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: GE Fanuc Series 21i-T Distance between centres: 5000 mm center bore: 425 swing over bed: 850 mm bed width: 425 mm rapid feed: 10000 mm/min working feed: 7000 mm/min main spindle bore: 85 mm Main spindle: DIN 55027-n°8 taper: 5 spindle speeds: 0-2000 U/min Spindle power: 11 KW tailstock quill diameter: 96 mm tailstock travel: 215 mm weight of the machine ca.: 7 t dimensions of the machine ca.: 7.300x1.700x1.900 m Support Guides 2 Swing over cross carriage 560 mm. Automatic ranges 2 Turret type Automatic Turret positions 8 Hydraulic tailstock quill stroke INCLUDED Tailstock taper MORSE 6 3 Jaw Auto-centering hydraulic chuck Ø 300 mm. INCLUDED 4 support steady rest Ø 450 mm. INCLUDED 3 support steady rest Ø 250 mm INCLUDED Chuck protection INCLUDED Complete rear protection INCLUDED Dual handwheel for carriage control INCLUDED Foot pedals for hydraulic chuck operati ...

Center height: 225mm, distance between centers: 1000mm, swing over bed/cross slide: 450mm/260mm, spindle bore: 65mm, max. spindle speed: 3000rpm, max. feed rate: 10m/min, tool turret: 4, main motor power: 7.5kW, control: Fanuc 0i Mate TC. Machine dimensions X/Y/Z: approx. 3500mm/1500mm/1700mm, weight: approx. 1550kg, operating hours: approx. 27000h, feed hours: approx. 1329h. Documentation available. An on-site inspection is possible.

turning diameter:570 mm turning length:- mm control:- Diameter of rotation above the bed slide:360 mm Maximum width:2.000 mm revolutions per minute:max. 2500 U/min :11 kW max. longitudinal feed:7,5 m/min max. transverse feed:7,5 m/min rapid traverse longitudinal:12 m/min rapid traverse cross:15 m/min Pinole diameter:95 mm Pinolenhub:220 mm Pinolen intake: MK 5 weight of the machine ca.:2,97 t dimensions of the machine ca.:3,8m x 1,3m x 2m m Technical description: - Tool turret - automatic - 8-fold (see also options) - CAPTO Revolver Disc - Machine bed - made of perlite casting GG-26 - high stiffness due to strong ribbing - Bed slides - guideways hardened and ground - automatic lubrication of the bed rail - Reitstock - manual - Quick clamp - Operator station - two movable handwheels on the operator panel - a movable handwheel - Control - "Siemens 828 D" CNC control - Siemens "Comfort" (in ...
