STAMA mc used machines

Key data: 500 mm, 380 mm, 360 mm

Vertical 5-Axis Machining Centre – Mill-/Turn Centre Stama MC726/MT – Milling / Turning – from billet Year 2008 Siemens Sinumerik 840D sl CNC 2-Axis NC Rotary / Tilting table with collet chuck Clamping capacity 15~80mm diameter C-Axis 360° A-Axis 120° X 500 mm Y 380 mm Z 360 mm 42 station ATC Turning spindle 20/50KW / 4000 rpm Milling spindle 17/37 KW / 10500 rpm 2 x machines available as a machining cell or individual machines sale They are currently connected in a production line. Both machines have their own chip conveyor, but they have only one coolant tank with different coolant pumps. Under power in the factory. Both machines are well maintained and in perfect condition. Regular maintenance carried out by Stama up to 2021, since then only low utilization. ALSO AVAILABLE AS SINGLE MACHINE ! Proposal reference MV-6363 /  ...

This STAMA MC526 was manufactured in 2008. It features a 40-tool magazine, NC swivel table, chip conveyor, belt filter system, and an internal coolant supply via the spindle. Additional amenities include a high-pressure system, Renishaw probe, and an extraction system. Consider the opportunity to buy this STAMA MC526 vertical machining centre. Contact us for more information.

STAMA Mod. MC 2 1997-325S pallet (Pendeltisch Peiseler ATK 520) Aufspannflaeche Pallet: 2 x 550 mm x 330 mm Max Werkstueckgewicht: 2x180kgs X = Y = Z 500 300 = 350 mm Min/Max Distance Spindelnase-Tisch: 200-550 mm rapid traverse X, Y, Z = 40/40/45 36 40 36 Werkzeuge ISO-9000 RPM Spindle IKZ CNC SIEMENS 840 c # 2 LEHMANN doppel 4. Achsen IKZ Unter Strom in unserem Lager It machined \\input shafts\\ (car power steering component) Special price for quick removal

4 axis vertical machining center for input shafts machining 2 pallets STAMA MC 325S 2 pallet with rotopallet Peiseler X=500 Y=300 Z=350 mm Rapids X,Y,Z = 40/40/45m 36 tools ISO 40 36-9000 rpm Table 950 x 800 mm CNC SIEMENS 840 N.2 double 4th axis Coolant through spindle Lavorazione input shafts (ex TRW) INTERESTING PRICE (package of 2 machines)

Stama MC531 Nr.5311119 BJ. 1999 Spindle revolutions 1/min 1050 SK40 Travel ranges mm X 800 Y 400 Z 355 Number of tools Tool diameter mm Tool length mm Max. tool weight kg B Axis NC Power kVA 53 Control system Sinumerik 840D

Stama MC325 106 BJ1997 SN KMM3251165 Main spindle SK40 Feed speed X-Y-Z axis 1-10000mm/min Rapid traverse speed X 40000mm/min Y 45000mm/min Z 45000mm/min Tool magazine Tool diameter max 88mm Tool diameter with free neber places 100mm Tool length max 220mm Tool weight max 10kg Number of magazine slots 36 Times Chip-to-chip 2.8s Workpiece change time of pendulum table 2.8s Connection value of the compl. System 28kVA Compressed air system Supply pressure min 6bar

Vertical Machining center STAMA MC326

x-travel: 5000 mm y-travel: 550 mm z-travel: 550 mm Control: Fanuc type: Series 15 M table surface area: 5000x520 mm Table load: 4000 kg quill stroke: 550 mm throat: 580 mm distance between table/spindle: 250-800 mm spindle taper ISO: 40 spindle turning speed range: 40-2000 U/min Tool changer: 40 total power requirement: 55 kW weight of the machine ca.: 20 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: mm y-travel: mm z-travel: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: mm y-travel: mm z-travel: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 400 mm z-travel: 350 mm Control: SIN840D A - axis: 360 x 0,001 ° B - axis: -30 - +90 x 0,001 ° workpiece diameter: 15 - 80 mm workpiece length - max.: 800 mm tool taper: SK40 spindle turning speed - stepless: 36 - 12.000 U/min power capacity - milling spindle: 14 / 21 kW feed X/Y/Z/-axis: 1 - 10.000 mm/min rapid traverse X/Y/Z: 45,00 m/min toolpiece magazine: chain magazine: 60 Stück tool length - max.: 250 mm tool diameter: 88 mm wotkpiece diameter with 2 vacant positions: 125 mm weight of tools max.: 12,00 kg total power requirement: 37,00 kW weight of the machine ca.: 11,00 t dimensions of the machine ca.: 6,00 x 5,00 x H3,50 m 5-axis machining center with Siemens SINUMERIK 840D control, IRCO RBK7212 bar feeder, chip conveyor, coolant system, coolant through the spindle (70bar). The data for this ad was created with ModulMWS - the software solution of L ...

x-travel:800 mm y-travel:400 mm z-travel:350 mm total power requirement:44 kW weight of the machine ca.:8,8 t dimensions of the machine ca.:6,1 x 4,1 x 3,3 m tool taper:HSK63 number of spindle speeds:36-12.000 Number of tools:2 x 21 St. rotary table diameter:1340 mm

WE OFFER AN EXCELLENT STAMA , JUST PERFECT CONDITION WITH TOOLS STAMA TECHNICAL DETAILS MACHINE DATA Machine type: Machining center Manufacturer: Stama Model: MC 526 Compact Machine number: KMM 526 1508 Year of construction: 2005 Condition: used Functionality: fully functional TECHNICAL DETAILS Travel distance X-axis: 1,000 mm Travel distance Y-axis: 400 mm Travel distance Z-axis: 360 mm Rapid traverse X-axis: 45 mm/min Rapid traverse Y-axis: 45 mm/min Rapid traverse Z-axis: 45 mm/min Feed rate X-axis: 10,000 mm/min Feed rate Y-axis: 10,000 mm/min Feed rate Z-axis: 10,000 mm/min Torque: 60 Nm DESCRIPTION TECHNICAL DETAILS Travel x: 1000 mm Travel y: 400 mm Travel z: 360 mm Control: Fanuc 18i-MB5 Projection: 350 mm Work ...

This 7-axis STAMA MC 526/M was manufactured in 2005, featuring a Siemens Sinumerik 840 D control system. It includes a milling spindle with a speed of 10,500 rpm and a turning spindle speed of 5,000 rpm. The machine offers a tool magazine with 132 tools capacity and rapid traverse rates up to 60 m/min. Ideal for complex milling and turning tasks. If you are looking to get high-quality milling and turning capabilities consider the STAMA MC 526/M machine we have for sale. Contact us for more information.

This 3-axis STAMA MC 526 vertical machining center was manufactured in 2008. It features a Fanuc 18i-MB5 CNC, twin-spindle with double tool changer, and a high-pressure coolant system. The machine offers a spindle speed of 12,000 rpm, spindle power of 21 kW, and a tool capacity of 60. X/Y/Z travels are 1000/400/360 mm respectively. If you are looking to get high-quality milling capabilities consider the STAMA MC 526 machine we have for sale.Contact us for more information.

This 4-axis STAMA MC 326 vertical machining centre was manufactured in 2011. It features a travel of 700 mm in the X-axis, 400 mm in the Y-axis, and 360 mm in the Z-axis. The machine is equipped with a spindle power of 18.5 kW and a tool magazine capacity of 48 tools. If you are looking to get high-quality machining capabilities, consider the STAMA MC 326 machine we have for sale. Contact us for further details.

BRAND: STAMA YEAR: 2015 MODEL: MC 430- GÜ APPLICATION TYPE: MILLING LOCATION: GERMANY MACHINE TYPE: MILLING MACHINE AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MACHINE WEIGHT: 12300 KG MAIN DRIVE SPINDLE SPEED RANGE: 45-3600 1/MIN SPINDLE MOTOR POWER: 10 KW MOVEMENT X-AXIS MOVEMENT: 1000 MM Y-AXIS MOVEMENT: 600 MM Z-AXIS MOVEMENT: 300 MM Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - DISTANCE SPINDLE NOSE COORDINATE TABLE: 150-950 MM - COORDINATE TABLE - CLAMPING SURFACE: 600 - 1250 MM

Machine Details Warehouse number 1105-03578 Machine Type Machining Center - Vertical StAMA ROBODRILL brand Type MC 010 Year of construction 1990 Control type CNC Storage location HAGUENAU Country of origin JAPAN Delivery time IMMEDIATELY Freight base from stock Technical details x-travel 500 mm y-travel 380 mm z-travel 300 mm Spindle holder ISO 30 sk sa Clamping surface 650 x 380 mm Tool magazine with 10 seats Tool change time 5 sec workpiece weight 200 kg Speeds - autom. switchable 60 - 8000 rpm Feed speed 1 - 4095 mm/min Feed force 400 kp (X, Y) Feed force 1000 kp (Z) Rapid traverse speed 36 m/min (X, Y) Rapid traverse speed 30 m/min (Z) Information Equipped with/ Equipped with: - FANUC 0 M Control - 10-fold tool changer SK 30 - Coolant system / cooling attachment - 4 T-slots / 4 T-slots TOOLS SK 30

Ref. -No.: 10372 Manufacturer: STAMA Year of construction: 2021 Type of control: CNC Control: SINUMERIK Siemens 840 D sl Storage location: Halberstadt Country of origin: Switzerland Turning Speeds: 4200 RPM X-axis travel: 615 mm Y-axis travel: 290 mm Z-axis travel: 500 mm Number of tools in the chain magazine: 64 Max. Rapid traverse: 65 m / min Max. Feed force: 4000 N Acceleration (X): 7 m/s² Acceleration (Y): 9 m/s² Acceleration (Z): 13 m/s² Further information: - Ball screw - Automation - Workpiece loading/unloading chuck parts with X- / Z- gantry loader - Clamping pressure preselection 15 - 50 bar for both spindles - Buffer station for constant short chip-to-chip times - NCU High Performance NCU 730.3.m - Magnetic gripper

1 CNC lathe spinner type CNC TC82 Fanuc 1998 2 CNC machining machine (miling) Stama type CNC 014 Fanuc 2000 3 CNC BAZ milling machine AXA type VHC 2-M Haidenhain 1999 4 CNC lathe (lathe) Takisawa type TS 20 Fanuc 1985 5 CNC Drawing Machine (lathe) Unitec Type UT6 Siemens 2008 6 CNC lathe (lathe) spinner type TC 108 Fanuc 2003 Note: Machine parameters must be fed into item 1, but otherwise works perfectly. Pos. 2 also works single-wall, but a heat sensor must be replaced

STAMA MC325 / S 2-palllet Double fourth axes Spindle 9000 rpm / 36 tools priced to sell low price - good deal The machine is visible in our warehouse in Gussago BS., Mimu Machine Tools, Gussago BS Italy, The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations, with a single set-up on multiple surfaces of the same work piece. It is generally equipped with several motion axles and one, automatic tool exchange system and sometimes multiple pallets, CNC type: Siemens, Fourth axis: 2 + 2, Number of pallets: 2, Spindle speed RPM: 9000

CNC Spindle Manufacturer: STAMA Model: MC 325/S Item number: T600.011-374-3/e Condition: used Dimensions (L×W×H): 450×140×150 mm Weight: 18.54 kg Price: plus VAT

A CNC 3-axis machining center Stama is available. Travel X/Y/Z: 1000mm/400mm/350mm, table dimensions X/Y: 1500mm/430mm, max. table load: 1200kg. Spindle power: 5.5kW, spindle taper: SK30, tool positions: 12, torque: 47Nm, spindle bearing diameter: 60mm, speed: 6000rpm. Positioning resolution: 0.001mm, positioning tolerance: +/-0.01mm, repeatability: 0.005mm, rapid traverse: 20m/min, feed rate: 5m/min. Drilling capacity (steel): 25mm, tapping capacity (steel): M24, milling capacity (steel) SK30/SK40/aluminum: 150cm³/180cm³/500cm³. Machine dimensions X/Y/Z: approx. 3200mm/2300mm/2500mm, weight: approx. 5500kg, control: Fanuc Series 0-M. Including C-axis and floppy disk drive. Without vises and tool holders (SK30). The cover of the Y-axis ball screw is missing. Documentation available. An on-site inspection is possible.

General Manufacturer: Stama Type: MT 733 two Year of Make: 2020 Control: Siemens Sinumerik 840D SL Travel: X 615 mm Y 290 mm Z 500 mm Rapid traverse: 65 m/min Feed: x 4,000 N / Y 4,000 N / Z 8,000 N Main spindle unit Speed: 12,500 rpm Tool holder: HSK-T63 Pull-in force: 18 kN Spindle bearing diameter: 80 mm Tool magazine Number of available magazine slots: 64 Tool diameter max. when fully equipped: 78 mm Tool diameter max. with free secondary positions: 140 mm Tool length: max. 300 mm Tool holder: HSK-A/T63 Tool weight: max. 10 kg Total chain load: max. 115 kg Rotary swivel unit Swivel angle: +30 to -180° Swivel axis repeatability: ±1" Swivel axis speed: max. 61 1/min Clamping torque tangential swivel axis: 3,000 Nm Clamping torque tangential counter bearing: 1,800 Nm Condition Condition: Used Functional: tested and fully functional

This Stama MC 535 Vertical Machining center was manufactured in the year 2001 in Germany. It is equipped with 4 t-slots and operates with 3-axis. The max. workpiece weight is 3000 kg and the max. spindle speed 8000 rpm. The machine is in top condition and fully operational with currently 18,485 operating hours. It will be sold because of replacement with a new and larger one. For the moment it is not connected but upon agreement, on-site testing is possible.
