14 TRUMPF cnc pressbrakes used machines

85 ton x 2700mm 5 Axis back gauge Laser guards With Tooling

TRUMPF 5130 B23 Year: 2021 Machine - C frame Press beam Spherical bearing of the press beam with press beam tilting On-Demand Servo Drive with 4-cylinder technology Distance measurement system (Y axis) with dynamic deflection compensation Hydraulic oil filling (life-long fill) Backgauge - Gauge fingers (two pieces) MACHINE OPTIONS Extension of the open height/stroke + 230 mm CNC-controlled wedge crowning 5-axis backgauge (X, Delta X, R, Z1, and Z2 axis) TRUMPF hydraulic upper tool clamp Keyboard and mouse Additional screen Shop floor programming TecZone Bend Tool Setup Optimizer (TSO) ACB Wireless (Automatically Controlled Bending) ACB Laser (Automatically Controlled Bending) Tool Indicator Part Indicator Front work area illumination Rear work area illumination Support bracket x 2 BendGuard Automatic

used press brake Trumpf TrumaBend V320 Year of construction 198 Bending length: 4100 mm Working stroke height: 365 mm Back gauge: 6 axes Bending aid: 2 pcs.

Key data: 200 mm

used press brake Trumpf TruBend V200 + BendMaster 60 Year of construction 2004 Pressing force max: 2000kN Stroke max: 365 mm Operating pressure max:340 bar 1 piece B0401A0009 = BendMaster 60 1 piece B0106A0073 = TRB V200-6A 1 piece of protective housing incl. lighting 1 piece of BendMaster roadway 14 meters in 2 meter segments 1 piece of system control system trump

TRUMPF Trumabend 125/3.1-DA24 hydraulic Press brake YOM 1994 Pressure 125 t chamfer lenght 3050 mm distance between columns 2550 mm total power requirement 15 kW column arm 350 mm ajustment speed 130 mm/sec work speed 1-10 m/min return speed 100 mm/sec back stop - adjustable 1000 mm Stroke 200 mm dayligth 400 mm Pressure power 280 bar dimensions of the machine ca. 3,6 x 2,3 x 2,8 m weight of the machine ca. 9,5 t Control unit CNC Maker of control unit DA24 4-Axis Control (y1,y2,x,r)

Specifications: Working length: 3050 mm Distance between stands: 2690 mm Pressing force: 130 tons CNC Control: DELEM DA69 adjustable back gauge Controlled axes: Y1 / Y2; X; R; Z1 / Z2 CNC Table Bending Compensation MODUFIX clamping hydr. Tool clamping at the top and bottom Pneumatic tool displacement Angle measuring system Stroke: 365 mm Projection : 410 mm 2 pcs bending aids Motor power: 12.5 kW CE mark Dimensions (length x width x height): approx. 3800 x 2350 x 3150 mm Weight : approx. 13 tons Accessories: Tool Condition: good condition

Inv. Num. : 8332 Type: TrumaBend V50 Producer: Trumpf Generated: Parameters: Compressive force: 85 t Maximum bending length: 1275 mm Distance between frame walls: 1040 mm Machine height: 2375 mm Machine length: 1930 mm Machine width: 2030 mm Machine weight: 4750 kg

pressure: 85.0 t chamfer lenght: 2050 mm distance between columns: 1750 mm column arm: 410 mm stroke: 365 mm dayligth: 535 mm ajustment speed: 200 mm/sec working feed: 1.0 - 10.0 mm/sec return speed: 135 mm/sec back stop - adjustable: max. 600 mm table width: 120 mm work height max.: 1050 mm Number of working hours: 28.500 h oil volume: 200 l operating pressure: 340 bar total power requirement: 14.0 kVA weight of the machine ca.: 9050 kg range L-W-H: 2680 x 2100 x 2885 mm ** with increased installation height / piston stroke ** very well maintained condition (!!) ** with only approx. 28.500 operating hours - in checked condition - machine video - https://www.youtube.com/watch?v=ZuwyPKJSYLw Equipment: - CNC electro-hydraulic press brake - including DELEM CNC control * swiveling control panel at the front left - CNC controlled axes: Y1 - Y2 - X - R - Z1 - Z2 - I + CNC crowning - CNC electr ...

pressure: 170 t chamfer lenght: 4080 mm distance between columns: 3680 mm column arm: 410 mm dayligth: 385 mm stroke: 215 mm ajustment speed: 200 mm/sec working feed: 1-10 mm/sec return speed: 135 mm/sec table width: 200 mm table height: 1050 mm Number of working hours: 25.430 h oil volume: 350 l total power requirement: 29 KVA weight of the machine ca.: 16.450 kg. range L-W-H: 4620 x 2210 x 2885 mm ** Machine in good condition ** Regularly serviced by the manufacturer ** CNC backgauge with 8 axes (!!) - in checked conditions - machinevideo - https://www.youtube.com/watch?v=yEaRj0XJAC4 Equipment: - CNC electro-hydraulic press brake/die bending press - DELEM CNC control - swiveling front left * High-resolution graphic screen * Clear, concise menus in the operators language * Large tool and product library * Graphic 2D programming * Automatic bend sequence calculation and collision detecti ...

Inv. Num. : 8707 Type: TrumaBend V170 Producer: Trumpf Created: 2003 Parameters: Compressive force: 170 t Maximum bending length: 4080 mm Distance between frame walls: 3680 mm Stroke: 365 mm Machine weight: 18000 kg

pressure: 130 t chamfer lenght: 3060 mm distance between columns: 2690 mm column arm: 410 mm stroke: 215 mm dayligth: 385 mm ajustment speed: 200 mm/sec working feed: 1-10 mm/sec return speed: 135 mm/sec table width: 120 mm table height: 1050 mm tiltable up to: +/- 10 mm Number of working hours: 53.820 h compressed air: 5.0 - 7.0 bar oil volume: 250 l operating pressure: 340 bar voltage: 400 V total power requirement: 16.0 KVA weight of the machine ca.: 11250 kg range L-W-H: 3640 x 2210 x 2375 mm - in checked condition - machine video - https://www.youtube.com/watch?v=23IbxRaZ2KA Equipment: - CNC electro-hydraulic press brake - including DELEM CNC control model DA 65 * swiveling control panel, front left * 2D graphic programming & product display * tool & program library * including new TFT-LCD industrial monitor - CNC controlled axes: Y1 + Y2 / X / R - CNC electro-motor / controlled bac ...

Key data: 170 t

Trumpf Press Brake Trumabend V170, 1700KN, Stroke: 365,. L-530cm, W- 240cm, H-300cm, Weight: 18to,

Key data: 120 t, 3110 mm

Inv. Num. : 9174 Type: TruBend 3120 Producer: Trumpf Created: 2007 Parameters: Compressive force: 120 t Maximum bending length: 3110 mm Distance between frame walls: 2690 mm Machine height: 2330 mm Machine length: 3600 mm Machine width: 1750 mm Machine weight: 8300 kg

pressure: 130 t chamfer lenght: 3060 mm distance between columns: 2690 mm column arm: 410 mm stroke: 365 mm dayligth: 535 mm ajustment speed: 200 mm/sec working feed: 1.0 - 10.0 mm/sec return speed: 135 mm/sec table width: 120 mm table height: 1050 mm tiltable up to: +/- 10.0 mm Number of working hours: ca. 31.800 h compressed air: 5.0 - 7.0 bar oil volume: 250 l operating pressure: 340 bar voltage: 400 V total power requirement: 23.0 KVA weight of the machine ca.: 12950 kg range L-W-H: 3660 x 2310 x 2900 mm ** Machine in a well-maintained condition (!!) ** with only approx. 31.800 operating hours - in checked condition - machine video - https://www.youtube.com/watch?v=PBV-MDtZnlE Equipment: - CNC electro-hydraulic press brake - DELEM CNC control model DA 65 * swiveling control panel, front left * 2D graphic programming & product display * Tool & program library * USB keyboard and mouse  ...

Servo Electric punching head Large format 3000 x 1500mm With Sheet Master & Duplex carts Year: 2015 Just under 19,000 hours! With tooling

3000 x 1500mm Truflow 5000w Auto nozzle changer Auto pallet changer

3000 x 1500mm / 5000w / Siemens 840 - Single Head Technology

3000 x 1500mm 3000w TruDisc Fiber

Refurbished machine 3000 x 1500mm Laser: 5000w

Press brake TRUMPF TrumaBend V 85 Year of construction 1999 Machine specifications: working length 2050 mm - Stand passage 1750 mm - pressing force 850 kN - Distance table / plunger 410 mm - Stand projection 410 mm - Plunger stroke 285 mm - Lifting speeds - Downward speed rapid path 200 mm/sec - Upward speed 135 mm/sec - Downward press speed 1 - 11 mm/sec - Total drive power 13 kVA - Space requirement approx.B 3700 x H 2700 x D 2100 mm - Weight approx. 8000 kg

3000x1500mm

3000 x 1500mm 5000w

4000 x 2000mm 5000w with LoadMaster

Trumpf TRUBEND 5085 - WORKING INSIDE PRODUCTION WORKING HORS: PRESENT ON PHOTO OF SCREEN Year 2011 Compression force: 85 tonnes Table length: 2,200 mm Free travel speed: 220 mm/s Accessories: Increased lift height from 230 mm to 615 mm. 5-axis bending. Hydraulic tool clamping at the bottom. Hydraulic tool clamping at top. Automatic bombing. Bendguard guard ACB angle measurement FOR CLIENT WE ORGANIZE AS WELL DISMANTLING AND TRANSPORT

Combined Trumpf Trumatic 6000 TruFlow 2000 Co2 laser Preventive maintenance is carried out on the machine by Trumpf annually. installed January 2002 working hours 55734 laser on 16875 Field of work: combined exercise 2585x1280 punch press exercise 2585x1370 laser exercise 2585x1280 Performance: maximum sheet thickness 8mm punching force 220KN active blank holder (programmable) 4,5 - 20kn maximum piece weight 200kg passage height: in punching exercise 35mm in operation of laser 22mm workable materials of laser: iron maximum thickness 8mm stainless steel maximum 4mm aluminum maximum 3mm Speed': x-axis 90m/min y-axis 60m/min simultaneous 108m/min number of trips punching 900min marking 2800min c axis punching 60rpm threading 330rpm Tools: tool places 21 with three collets rotation of all tools tool change time 1.5 -5 seconds max folding height ...
