UHLMANN ups used machines

A Uhlmann blister packaging line in need of repair is available. 1) Uhlmann UPS 4 ETX blister machine, year of manufacture: 2008, design: modular balcony design, modules: 12, blister capacity: 10 tablets, blister format X/Y/Z: 100mm/39mm/5.7mm, packaging output: 220blisters/min, roll width forming/sealing: 256mm/246mm, feed: 102mm, max. forming film roll diameter: 800mm, max. lidding film roll diameter: 300mm, filling section length: 1360mm, theoretical output: 50cycles/min, film width range: 63mm-300mm, punching width range: 28mm-284mm, max. forming depth: 12mm, min. blister dimensions X/Y/Z: 30mm/3.5mm/60mm, max. blister dimensions X/Y/Z: 110mm/12mm/145mm, max. stack height: 85mm, max. blisters per stack: 10, weight: approx. 7000kg. 2) Uhlmann C 2155 cartoner, year of manufacture: 2008, cartoning output: 10-150cartons/min, max. stacking output: 400blisters/min, product carrier height:  ...

Hopper and vibratory trough for Uhlmann UPS

Blister Machine Manufacturer: Uhlmann Type UPS 1070 Output 15 – 200/cycles min. Film width min. 150 mm – max. 300 mm including colour and filling material control, make Scanware, type LYNX Spectra CL/HR Blister machine with side channel blower 2016 new sealing head with adjustment dome Dimensions: 8000 mm length x 1800 mm width x 1900 mm height, weight approx. 7 tons

Blister Machine Manufacturer: Uhlmann Type UPS 1070 Output 15 – 200/cycles min. Film width min. 150 mm – max. 300 mm including colour and filling material control, make Scanware, type LYNX Spectra CL/HR Blister machine with side channel blower 2016 new sealing head with adjustment dome Dimensions: 8000 mm length x 1800 mm width x 1900 mm height, weight approx. 7 tons

Uhlmann UPS5ET blister machine for alu/alu blisters, including Uhlmann 149 buffer system. Maximum blister size 272 x 284mm (draw x width), maximum depth 40mm. SyPro feeding system for syringes etc with flexible robotic arm and vacuum grip head. Seidenader camera product presence checking system, VISIOtec VisoScan blister integrity tester, gas flushing with Dansensor MAP Check Combi for measuring the gas content within the pack. Domino D550+ laser printer with Seidenader print control camera. Output up to 400 blisters per minute. As new, with only 350 production hours.

Thermoformer - UPS4 Year - 1993 Min. - Max. Forming width - 62 - 226mm Cycles - 15 - 50 cycles/minute Forming depth - PVC - 12mm ALU - 10mm Blister Format - Min. - 60mm Max. - 140x39mm Punching Area - Length - 226mm Width - 284mm Forming Film width - Min. - 100mm Max. - 298mm Lidfoil Width - Min. - 100 Max. - 298 Tooling - PVC/Alu - 6 Blister line size 39x94mm Alu/Alu - 7 Blister line size 38x86mm Machine Control- PacControl version 2.17 Camera – not included Hapa Printer - H-231-1

Power installed :11 Kw. Power consumption :5,5 Kw. Production :15, 50 strokes per minute for 12 mm depth forming 15, 40 storkes per minute for 28 mm depth forming Index :Max. 145, 222 mm Format range :forming area 220 mm length 188mm width Depth forming :12 and 28 mm, forming reel : 460 mm, covering reel :Max. 300 mm Forming thickness :Min. 0,1 mm, max. 0,5 mm Width covering foil : min. 90mm max. 210mm, of the internal reel : 70......76 water consumption :aprox. 0,1 m3/h. Compress air consumption :aprox. 6 Nm3/h , without pre heating :aprox.14Nm3/h, with pre heating

Machine code: IT352 Manufacturer: Uhlmann Model: UPS300 Year of construction: 2001 Uhlmann This is a fully automatic, intermittent motion Blisterpacking machine with a capacity up to 50 cycles per minute. The maximum output is 200 Blisters per minute depending on blister size. The machine is of ‘balcony construction’ - all relevant stations are individual modules, which are cantilevered off a large aluminium plate that forms the front of the machine housing. The remainder of the machine cabinet is constructed from fabricated steel and houses the drive unit, gear trains, chain drives and the electrical control equipment. PVC, PVC/PVDC, PVC/Aclar film is drawn from a reel and is first heated and softened and then deep-drawn in the blister forming station. The blisters are formed in the mould with the aid of compressed air – the web is then pulled forward, up and across  ...

Universal Blister machine with platen sealing for pharmaceutical production incl. various format parts and LYNX-5-fill control. The machine processes ALU/PVC blisters and is suitable for tablets, dragées und capsules. The forming an packing machine operates in single stroke (ET), i.e. all stations for the main functions forming, sealing and punching operate in the same cycle, while the film runs through the machine intermittently. Output: 15-50 cycles/min. at 12 mm forming depth | 15-40 cycles/min. at 28 mm forming depth.

Uhlmann UPS3ET/C130 blister packing & cartoning line for ampoules, etc. comprising UPS3ET blister machine with ampoule feeder, blister size max. 220 x 196 mm (in web travel direction x across web), index length max. 222 mm, forming depth max. 28 mm, reel diameter forming foil 400 mm (on machine) and 700 mm (on unwinding stand), reel diameter lid foil max. 300 mm, thickness of forming foil 0,1 bis 0,5 mm, web width forming foil 115 to 244 mm, web width lid foil 105 to 244 mm, reel core diameter 70/76 mm, Siemens SIMAT S7 PLC, electrics 400V/50Hz, connected load 19kW, compressed air 6-8 bar, machine net weight approx. 4800 kg, capacity 15 to 40 cycles/min., transfer of the blister in-line directly into Uhlmann C-130 horizontal cartoning machine for blisters with blister fedeer suitable for blisters containing ampoules, etc., format range carton min. 30 x 15 x 70 mm, max. 100 x 85 x 150 mm, ...

Intermittent-motion blister machine with plate sealing and manual product feeding, incl. filling station for liquids. The machine can process ALU/PVC. Output: 15–50 cycles/min at 12 mm forming depth 15–40 cycles/min at 28 mm forming depth

UHLMANN BLISTER LINE Ideal for pharmaceutical production in cleanrooms, fully automated and modular, easy to integrate into existing production lines. Comes from a GMP-compliant cleanroom environment, regularly maintained, comes with complete technical documentation and has been decommissioned for internal production. Consisting of: 1) UHLMANN BLISTER PACKER, MODEL UPS 4 Year of construction: 2006 PRODUCTION CHARACTERISTICS - Output: 15-50 cycles/min - Forming width: 62 - 226 mm (min - max) - Blister format: min. 60 mm; max. 140×39 mm - Depth: pvc 12 mm; alu 10 mm DIMENSIONS - Weight: 4.950 kg ENERGY CONSUMPTION - Voltage: 3/N/PE AC 400 V - Current: 30 A 2) UHLMANN CARTONING MACHINE, MODEL C2206 Year of construction: 2005 PRODUCTION CHARACTERISTICS - Max. output: 200 cartons/min. - Closures: tuck-in, hot-melt - Products: ...

Vial blister machine Manufacturer: Uhlmann Model No.: UPS4 Year of Make: 2000 Serial Number: 460 Bottles Carton Packaging 2 bottle feeders PACCONTROL PCL Production Capacity: • 15 to 50 cycles/min up to a punching depth of 12 mm • 15 to 40 cycles/min up to a punching depth of 28 mm Maximum feed length: 222 mm Format range: longitudinal 220mm x transverse 284mm Actual format: • Tray for 10ml ampoule (Ø17.5×87) and 10ml vial (Ø15×50), tray dimensions (LxWxH): 99x54x26 • Tray for five 10ml vials (Ø24×50), tray dimensions (LxWxH): 146x66x26 • Tray for a 10ml vial (Ø24×50), tray dimensions (LxWxH): 99x54x26 Thermoforming film diameter: • On the machine : 400mm • On bobbin holder : 800mm Coil diameter of the lidding film: max. 300 mm Min/Max Thermoforming Film Thickness: 0.15/0.5mm Width of the sheath material: • Thermoforming film: 145 to 300 m ...

Dedicated feeder for any tablets or capsules on blistering machines f.e. Uhlmann UPS 1070 • intermittent motion • for diverse product shapes • 60 strokes/min • format area max. 295 x 285 mm • own control unit, therefore universally applicable on different machines • suitable for Uhlmann rail system, easy mounting • incl. transport rack, mobile

Uhlmann C 100 horizontal cartoning machine - Fully automatic bottle packaging and simultaneous feeding of    leaflets - Max. Power 100 FS / min - Bottle length max. 150 mm Format: L = 70 x 130 mm B = 30 x 100 mm H = 15 x 85 mm New hardware and software PLC Mitsubishi control and 8 inch color touch panel mechanically overhauled Optional: - GUK folder folder 4 fold folding - Cognex 1D barcode and 2D matrix codes reading system for brochure leaflets    and carton code - Luminance control, presence check for leaflets in carton - embossing station - brochure feed - Vacuum pump / Venturi nozzle

Uhlmann C 100 horizontal cartoning machine - Fully automatic bottle packaging and simultaneous feeding of    leaflets - Max. Power 100 FS / min - Bottle length max. 150 mm Format: L = 70 x 130 mm B = 30 x 100 mm H = 15 x 85 mm New hardware and software PLC Mitsubishi control and 8 inch color touch panel mechanically overhauled Optional: - GUK folder folder 4 fold folding - Cognex 1D barcode and 2D matrix codes reading system for brochure leaflets    and carton code - Luminance control, presence check for leaflets in carton - embossing station - brochure feed - Vacuum pump / Venturi nozzle

Uhlmann C 100 horizontal cartoning machine - Fully automatic bottle packaging and simultaneous feeding of    leaflets - Max. Power 100 FS / min - Bottle length max. 150 mm Format: L = 70 x 130 mm B = 30 x 100 mm H = 15 x 85 mm New hardware and software PLC Mitsubishi control and 8 inch color touch panel mechanically overhauled Optional: - GUK folder folder 4 fold folding - Cognex 1D barcode and 2D matrix codes reading system for brochure leaflets    and carton code - Luminance control, presence check for leaflets in carton - embossing station - brochure feed - Vacuum pump / Venturi nozzle

Uhlmann C 100 modified fully automatic blister Strip packaging and simultaneous feeding of leaflets 2016 - horizontal cartoning machine -Max power 100 FS / min Format: L = 70 x 150 mm B = 30 x 100 mm H = 15 x 85 mm New hardware and software PLC Mitsubishi control and 8 inch color touch panel Accessories: -GUK leaflet folding apparatus 4 Pocket fold -Cognex 1 d barcode and 2D matrix code reading system for prospectus leaflets and folding box code -Luminizenskontrolle, presence control for leaflet in folded box -Stamping station -Prospectus before insertion -Vacuum pump

Electrical consumption: 4.0 kW average consumption: 3.5 kW mechanical Speed max. 100 Cartons/minute product power supply: max. 300 blister/min Size: A x B x H Min. 30x15x70 mm Max. 100 x 85 x 150 mm Folding machine Prospectus Guk sizes. 3000 x 1300 x 1660 mm compressed air consumption 4-6 bar without elevation 1-2 Nm3/h with prospectus 5-8 Nm3/h Leatus for prospectus code, case and prospectus presence

The Cartoner C 2205 belong to the continuous cartoners for the exible packaging of small and medium sized batches. Convincing attributes include the GMP and pharmaceutically compliant cantilever design with V2A stainless steel lining of the inner surfaces, the modular structure for subsequent upgrading of separate stations, as well as the consistent separation of the drive elements and operating assemblies. Thanks to the patented carton feeders TwinStar and TriStar, the cartoner offer uniform top quality and productivity – not only under ideal production conditions but also when cartons of critical quality are processed. The 5“ pitch Cartoner C 2205 is designed for a maximum output of 250 cartons/minute with an option of up to 300 cartons/minute. The machine packages blisters, ampoules . Technical details : Max Output 250 cartons per minute Pitch 5” Max carton size (AxBXH) 100 x 90 ...

Uhlmann C2504 continuous motion cartoner, carton size range min. 30x15x65 mm (AxBxH), max. 80x90x155 mm (AxBxH) Blister/tray size range min. 30x3.5x60 mm (LxWxH), max. 75x12x150 mm (LxWxH), suitable for blister count from 1 - 12 blisters per carton, Leaflet/Booklet feeder (leaflets/booklets are automatically taken from their carton/trays and placed into the infeed system), the machine is also prepared to accept a GUK leaflet folder and feeder. Includes Wolke m600 advanced inkjet printer for variable data and codes, set up for reverse tuck cartons with Nordson PROblue 4 hot melt glue system for tamper evidence. The cartons discharge though a Pago Pagomat 6/2 labeller for top labelling (vignette/bollino) Electrics 400 V/230 V/50 Hz, 20 A, connected load 10kW Compressed air 6-10 bar Machine footprint ca. 7289 x 2041 mm (LxW) Height ca. 2254 mm Machine nett weight ca. 8000 kg Output u ...

Folding carton boarding machine Uhlmann C 100 LB • Format range folding carton B 30-100, H 15-75, L 70-200 mm • Capacity 10-80 folding cartons/min, clocked • For offset plug-in closure on both sides • Product feed for blister via blister stack shaft • Code reading Laetus Argus for 2x brochure code (front + back), 1x folding carton code, 1x brochure absence in folding carton • Brochure folding and inserting machine from the magazine GUK FA 21/4 Cartonac 91 • Colour embossing station for folding flap opposite the insertion side, 2-line, with embossing numbers • Poor ejection with ejection counter-control • Vacuum generators • SPS Eberle PLS 514 • Connection 400V/50Hz Optional: - New hardware/software Mitsubishi with 8" color Tuach Panel - Code reader Cognex - Validation documentation

DESCRIPTION: • Format range folding carton B 30-100, H 15-75, L 70-200 mm • Capacity 10-80 folding cartons/min, clocked • For offset plug-in closure on both sides • Centrally adjustable cup chain • Product feed for blister via blister stack shaft • Monitoring of packaged goods height in cup chain • Code reading Laetus Argus 4 for 2x brochure code (front + back), 1x folding carton code, 1x brochure presence in folding carton • Brochure folding and inserting machine from the magazine GUK FA 21/4 Cartonac 91 • Colour embossing station for folding flap opposite the insertion side, 2-line, with embossing numbers • Poor ejection with anti-ejection control • Vacuum generators • SPS Eberle PLS 514 • Connection 400V/50Hz

Control panel Pacmation made of Uhlmann C130 YOC 1996

Uhlmann C 130 horizontal cartoning machine - Fully automatic blister strip packaging and simultaneous feeding of package inserts - max. output 120 FS/min / depending on product Format: L= 70 x 150mm W= 30 x 100mm H= 15 x 85mm New hardware and software PLC Mitsubishi control and 8 inch color touch panel 10-year spare parts procurement warranty Mechanically overhauled Accessories optional: - GUK brochure folder 4-fold folding - Cognex 1D Barcode and 2D Matrix Codes Reading System for Leaflet and Carton Code - Luminizens control, presence control for package inserts in folding boxes - Embossing station - Brochure insertion -Vacuum pump
