37 VOLLMER used machine for sale

Sharpening machine Vollmer For circular saw blades Type CHC 25 H Year of manufacture 1985 Automatic sharpening machine for breast, back and free grinding Carbide-tipped circular saw blades Circular saws Outer diameter from 80 mm to 810 mm Bore diameters from 10 mm to 220 mm Blade thickness up to 5 mm Tooth pitch from 7 to 100 mm Rake angle from 6° to 45° Bevel grinding of tooth backs up to 45° Tooth breast up to 15° Grinding speed infinitely variable from 0.5 to 6 mm/s Working speed up to 18 teeth Grinding wheel diameter 125 mm Bore diameter 32 mm Circumferential speed 26 m/s Coolant pump flow rate 40 l/min. Connected load approx. 1.6 kW Areas of application Flat tooth at an angle on one side, left and right Interchangeable tooth, roof tooth, trapezoidal flat tooth, group tooth, Uneven tooth pitch, omitted teeth, format chipper saws Weight approx. 680  ...

Used grinding machine Vollmer CABG 50U – built in 1995 – Very good condition For sale is a fully automatic gang saw sharpening machine from the quality manufacturer Vollmer. The machine is in very good condition, is fully functional and can be used immediately. Ideal for sawmills or woodworking companies with regular sharpening needs. Specifications: Model: Vollmer CABG 50U Year of Make: 1995 Machine Type: Automatic Gang Saw Blade Sharpener Condition: Very good, regularly serviced Saw blade width: Up to approx. 200 mm Saw blade length: Up to approx. 1650 mm Rake angle adjustment: Approx. -10° to +25° Tooth pitch: Adjustable (depending on the type of saw blade) Abrasives: CBN or diamond grinding wheels Grinding cycle: Fully automatic incl. infeed and return Control: Electronic with program selection Cooling: Integrated coolant supply Connected load: 400 V / 50 Hz ...

Circular Saw Blade Sharpening Machine Vollmer Type CNS Suitable for CV circular saw blades for straight and bevel grinding Grinding wheel diameter maximum 150 mm Saw blade diameter 90 – 600 mm Sharpening speed 3 speeds 30/60/80 teeth per minute Drive warping disc motor power 0.2 kW Drive Feed 0.4 kW Dimensions 800 mm x 900 mm x H 1800 mm Weight approx. 250 kg

Vollmer electric line saw sharpener

Vollmer CHHF 21 H - Machine for single-sided grinding Year of construction: 1989 S/N 907 Make: Vollmer Germany in good working condition The technical data of the CHHF 21H at a glance: Circular saw blades Outer diameter 80 to 700 mm Bore diameter 20 to 105 mm Tooth pitch from 8 mm Hook angle up to 30° Radial clearance angle -7° to +3° Tangential clearance angle up to 5° Connected load approx. 0.52 kW Weight approx. 85 kg Dimensions: 70 x 50 x 80 cm Cisei8tfrg This machine has been specially designed for the repair of lack of carbide teeth. Newly inserted tips are used in the existing teeth. With this tabletop version, VOLLMER offers a a particularly economical, space-saving solution. The CHHF 21 H works according to the wet grinding process. During the grinding process, the grinding unit manually moved over the tooth flanks, with the saw blade Saw blade ...

Gate Sharper Manufacturer Vollmer for Inclined and straight ground

Hand cabinets for gate saws Tsa

Circular saw sharpening machine Vollmer Cne

total power requirement:0,55 kw Overall size:800 x 900 x 1600 mm Weight:220 kg accessories::mit Absaugung 0,2 kw

Suitable for automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters, etc. using the wire electro-erosion process. Accesories: Total enclosure,, Mist extractor, Probe,, Machine lamp,, Automatic central lubrication,, Coolant system dielectric fluid, Fire extinguishing system, Measuring mandrel, Alphanumeric keyboard, cutter outer diameter max: 250 mm, cutting length max.: 200 mm, shank tool diameter: 10 - 250 mm, cutting length: 200 mm, Outside diameter of disc-shaped tools max.: 250 mm, tool weight max.: 20 kg, X-axis travel: 220 mm, Y-axis travel: 300 mm, W axis travel: 200 mm, A-axis rotation range: 60 °, A-axis taper: ISO 40, E-axis swivel range: 120 °, number of revolutions: 80 - 2000 rpm., Dimensions L x W x H: 2235x2630x2130mm, mass: approx. 4500 kg, Connected load approx.: 400V / 50Hz / 4.5KW, colour: turquoise RAL 5021/gr ...

length: ~ 700 mm width: ~ 600 mm height: ~ 2.000 mm Vollmer Junior B automatic bandsaw sharpener for sharpening bandsaw blades. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Suitable for automatic grinding of the tooth geometry on chip and flank faces (front and back) of HM - tipped circular saw blades. All common tooth shapes can be finish-ground in one cycle (also trapezoidal flat tooth)., Accessories: Total enclosure,, Motorized chip and clearance angle adjustment, Manual central lubrication, Coolant grinding system,, 1 arbor,, 2 magnetic sawblade holders,, 4 centering sleeves,, 1 grinding wheel holder., Circular saw blade diameter: 80-810mm, Circular Saw Bore Diameter: from 10 mm, blade thickness: up to 5 mm, Tooth pitch: 7-100mm, rake angle: - 20° to +40°, clearance angle: 6° to 45°, tooth height difference: any, Bevel cut on the back of the tooth: up to 45 °, Working speed: up to 20 teeth / min., Bevel cut on the tooth face: up to 15°, grinding path max.: 20 mm, Grinding wheel bore diameter: 32 mm, Grinding wheel diameter: 125 mm, Connected load: ...

Suitable for automatic, double-sided grinding of tooth flanks on circular saw blades with carbide tips., Accessories:, Partial enclosure,, 1 sawblade holder,, Coolant system., Circular saw outer diameter: 260 to 2200 mm, Circular saw bore diameter: 25 to 220 mm, sawblade thickness: up to 20 mm, Tooth pitch: from 10 mm, rake angle: any, Radial free angle: up to 6°, Tangential free angle: up to 6°, Grinding path: up to 75 mm, Grinding speed: 0.5 to 6 mm(s), Working speed: up to about 10 teeth/min, Grinding wheel diameter: 125 mm, Grinding wheel bore diameter: 32 mm, Grinding wheel peripheral speed: 26 m/s, Cooling lubricant pump capacity: 250 l/min, Coolant Tank Content: approx. 190 l, Connected load approx.: 6,5 kW (400 V / 50 Hz), Dimensions W x D x H =: 3050 x 1890 x 2050 mm, Weight approx.: 2160 kg, colour: green

Suitable for the automatic grinding of HM circular saw blades on the face and top in one setting. All known tooth geometries (flat, alternate, trapezoidal teeth, etc.) can be ground automatically and in one pass., Accessories:, Total enclosure,, Coolant system,, Equipment for robot operation with automatic loading door, ND 230 loader, Measuring device for measuring saw blades, Chip breaker grinding attachment, Stepless variable grinding speed of the two grinding spindles from 1600 to 5500 rpm., Grinding speed and grinding path stepless adjustable for each machining surface on the tooth., Automatic central lubrication, Software package for oscillation grinding at rake and clearance angles, Automatic shut-off flap, Automatic fire extinguishing system, Electrostatic oil mist separator N281, Measuring tool, Sawblade holder with guide bushing Ø 16 mm Saw holder >ø180, Sawblade holder with g ...

Suitable for attachment to a carbide saw blade grinding machine of the type Vollmer CHD 250/CHD 251/CHD 270, CHF 270/CHF 350, loading system for saw blades with up to 630 mm diameter. Accessories: DES 300 data input station, 3 loading trolleys, Oil collection tray,, Automatic central lubrication,, Control cabinet cooler., Simplest stack circular saw blade outside diameter: 100 to 630 mm, double stack: 100 to 305 mm, maximum saw blade weight single-sided occupancy: 9 kg, double-sided occupancy: 6 kg, Bore diameter: 16 to 180 mm, sheet thickness: up to 5 mm, Stack height: < 300 mm, Connected load approx.: 1.8 kVA (400 V / 60 Hz), Weight approx: 1400 kg, colour: Gray RAL 7035

Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as saws, milling cutters etc. using the wire-electro-erosion process., Accessories:, Total enclosure,, Adaptation to A-axis on HSK63-A,E incl. test mandrel Ø 25 mm System HSK63 A,E, Integrated loading system and workpiece magazine for automated processing of up to 12 workpieces., Probe,, Automatic central lubrication,, Coolant system for dielectric fluid,, Automatic fire extinguishing system,, Mist extractor,, Machine lamp., Cutter outside diameter: Max. 320 mm, Shank tool diameter: 10-320 mm, Outside diameter disc-shaped tools: Max. 320 mm, Cutting length: max. 480 mm, Tool weight: max. 20 kg, X axis travel: 500 mm, Y-axis travel: 300 mm, W-axis travel: 200 mm, A-axis rotation range: 360 °, E-axis swivel range: 180 °, Required space for the machine: 2535 x 2200 x 2280 mm, Weight a ...

Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters etc. using the wire-electro-erosion method. Accessories:, Total enclosure,, Cooling unit for dielectric,, automatic fire extinguishing system,, Mist extractor, Probe,, Machine lamp,, automatic central lubrication,, Workpiece carrier ISO50,, Measuring mandrel,, Tailstock., Cutter outside diameter: Max. 250 mm, Cutting length: max. 260 mm, Shank tool diameter: 10 - 250 mm, Outside diameter disc-shaped tools: Max. 250 mm, Tool weight max.: 20 kg, X axis travel: 275 mm, Y-axis travel: 300 mm, W-axis travel: 200 mm, A-axis mounting cone: ISWO 50, E-axis swivel range: 180 °, Required space for the machine: 2535 x 2200 x 2220 mm, Weight approx.: 4500 kg, Connected load: 4.5 kW (400 V / 50 Hz), colour: gray RAL 7045/7047

Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters etc. using the wire-electro-erosion method. Accessories:, Total enclosure,, Cooling unit for dielectric,, automatic fire extinguishing system,, Mist extractor N181, Probe,, Machine lamp,, automatic central lubrication,, Workpiece carrier ISO50,, Measuring mandrel,, Cutter outside diameter: Max. 250 mm, Cutting length: max. 260 mm, Shank tool diameter: 10 - 250 mm, Outside diameter disc-shaped tools: Max. 250 mm, Tool weight max.: 20 kg, X axis travel: 275 mm, Y-axis travel: 300 mm, W-axis travel: 200 mm, A-axis mounting cone: ISWO 50, E-axis swivel range: 180 °, Required space for the machine: 2535 x 2200 x 2220 mm, Weight approx.: 4500 kg, Connected load: 4.5 kW (400 V / 50 Hz), colour: gray RAL 7045/7047

This 6-axis VOLLMER QXD 250 grinding machine was manufactured in 2017. It features a robust 3 Phase 380Volts, 50hz, 8.7KVA power supply and a substantial coolant tank capacity of 310 liters. With a machine weight of 7,200kg and comprehensive axis movement, including a 360-degree swivel angle on the A-Axis and +/-20 degrees on the B-Axis, consider the opportunity to buy this VOLLMER QXD 250 grinding machine. Contact us for more information about this machine.

Universal machine for eroding and grinding various PCD tools up to 250 mm in diameter and 200 mm in length in production and service. Accessories: Total enclosure,, Extraction N183,, Cooling and cleaning device for dielectric,, Automatic fire extinguishing device,, Loader for erosion disc sets with CNC-controlled swivel arm for loading and unloading, 1 set of gripper fingers for workpiece automation HSK 63/SK40, Workpiece carrier adaptation A-axis from SK 50 to HSK 63 A,, 1 exchange element with flange,, 1 x flushing kit,, Test bar, X axis travel: 440 mm, B-axis: +/- 15°, Y axis travel: 876 mm, Z-axis travel: 420 mm, E-axis swivel range: 210°, A-axis rotation range: 360°, workpiece carrier base: SK 50, workpiece length max.: 200 mm, Workpiece diameter max.: 250 mm, workpiece weight: 15 kg, Connected load approx.: 6.7 kW 400V/50 Hz, Weight approx: 7000 kg, Dimensions W x D x H =: 1987  ...

Suitable for the automated machining of PCD-tipped milling cutters, end-cutting tools, and disc-shaped tools such as saws, milling cutters, etc., using wire EDM. Accessories: Total enclosure, External PC with contour management and Exprog software, Cooling unit for dielectric fluid, Automatic fire extinguishing system, Automatic central lubrication, Extraction system,, Measuring probe, Machine lamp, Workpiece carrier SK 40, Measuring mandrel SK 40, cutter outer diameter: Max. 320 mm, Shank tool diameter: 10-320 mm, Outer diameter disc-shaped tools: Max. 320 mm, Cutting length: max. 480 mm, X-axis travel: 500 mm, Tool weight: max. 20 kg, Y axis travel: 300 mm, Travel path W-axis: 200 mm, Machine space requirements: 2535 x 2200 x 2280 mm, A-axis rotation range: 360°, E-axis swivel range: 180°, Weight approx.: 4800 kg, Connected load: 5,4 kW, colour: grey RAL 7035/7043

Suitable for the automated machining of PCD-tipped milling cutters, end-cutting tools, and disc-shaped tools such as saws, milling cutters, etc., using wire EDM. Accessories: Total enclosure, External PC with contour management and Exprog software, Cooling unit for dielectric fluid, Automatic fire extinguishing system, Automatic central lubrication, Extraction system,, Measuring probe, Machine lamp, Workpiece carrier SK 40, Measuring mandrel SK 40, cutter outer diameter: Max. 320 mm, Shank tool diameter: 10-320 mm, Outer diameter disc-shaped tools: Max. 320 mm, Cutting length: max. 480 mm, X-axis travel: 500 mm, Tool weight: max. 20 kg, Y axis travel: 300 mm, Travel path W-axis: 200 mm, Machine space requirements: 2535 x 2200 x 2280 mm, A-axis rotation range: 360°, E-axis swivel range: 180°, Weight approx.: 4800 kg, Connected load: 5,4 kW, colour: grey RAL 7035/7043

Disc EDM machine for the complete machining of rotationally symmetrical workpieces with cutting edges made of ultra-hard materials. Workpieces are mounted vertically. Accessories:, Total enclosure, External PC incl. CAD/CAM and ExLevel Pro software, Software package with additional functions for metalworking tools,, Wheelchanger for up to 6 eroding/grinding discs,, Adaptation to A-axis on HSK 63-A-E, Coolant system with pump & cooling unit, Automatic central lubrication, Automatic fire extinguishing system, Automatic shut-off flap, Glass scales on the X, Y & Z linear axes,, Mechanical mist separators N280,, 3 grinding wheel change elements, Test mandrel HSK63A., Also available with workpiece magazine as an option!, Workpiece outer diameter: max. 320 mm, Tool outer diameter: Max. 200 mm, workpiece length: max. 250 mm, Bore diameter: Max. 60 mm, Travel path X1: 520 mm, Travel path Y1: 970  ...

Disc EDM machine for the complete machining of rotationally symmetrical workpieces with cutting edges made of ultra-hard cutting materials. The workpieces are mounted vertically (suspended). Accessories: Total enclosure,, Software for woodworking tools, Software for P-system peeling cutters, Software for scoring saws/radius cutters, Software for 360° path programme, Software for 360° peeling cutters, Workpiece magazine N250 (pallet magazine for max. 28 workpieces),, Disc changer for up to 6 eroding/grinding discs,, Adaptation to A-axis on HSK 63- F,, Coolant system with pump & cooling unit, Automatic central lubrication, Automatic fire extinguishing system, Automatic shut-off flap, Gripper fingers for workpiece automation,, 4 workpiece holders for workpiece magazine,, 1 exchange element with flushing kit,, Mechanical mist separator N183,, Test mandrel HSK63F., Maximum workpiece outer d ...

CNC-controlled erosion machine for the processing (erosion, grinding, polishing) of PCD tipped tools up to 400 mm diameter and 400 mm length, according to disc-electrical-erosion processes for use in service and in production., Accessories:, Total enclosure, Software path management, Filter system with chiller for dielectric fluid, Automatic fire extinguishing system DIN 14497, Standard programs for measuring, eroding etc., Program for chamfering of workpiece cutting edges,, Automatic Diagnosis program for machine operational status with text output on screen, Loader for workpieces, with CNC-controlled pivot for loading and unloading to a magazine,, 6 sided erosion wheel changer,, Workhead SK 50 with adapter to 12 HSK 63 A,, Turntable workpiece magazine for 12 workpieces SK 50,, Turntable workpiece magazine for 4 workpieces SK 50,, 6 flush sets, QXD250 CAD/CAM for external PC workstation ...

Suitable for automatic grinding of tooth faces, tooth backs, and bases on carbide-tipped circular saw blades in a single setup. All common tooth geometries (flat, alternate, trapezoidal, etc.) can be ground automatically and in a single pass. Accessories: Full enclosure Measuring probe Grinding device with oil cooling Automatic fire extinguishing system Grinding mist extraction system N 183 Alphanumeric keypad Oil drip tray Machine light, saw diameter: 80-840 mm, Bore diameter: from 10 mm, sheet thickness: < 8 mm, Tooth pitch: 6 - 120 mm, Cutting length:

saw blade diameter: - mm workpiece-spindlehead motor: 0,18 kW grinding wheel diameter: ? mm total power requirement: 0,18 kW weight of the machine ca.: 200 kg dimensions of the machine ca.: 0,8 0,5 1,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Loading trolley for all Vollmer ND loading centers available in as-is condition, unpainted or completely new and freshly painted.

Suitable for automatic tooth flank grinding on both sides of carbide-tipped circular saw blades. Accesories: full fairing coolant system Automatic central lubrication. Measuring system for measuring saw blades. Control panel with LCD color display. DNC service. Alphanumeric keyboard. Grinding speed and grinding path depending on the tooth surface, can be adjusted as required. 2 grinding wheel mounts Coolant level monitoring Automatic grinding wheel compensation Prepared for robot operation with automatic loading door oil pan 2 x saw blade magnet holder >Ø 320mm, >Ø 180 mm 1 centering ring., Circular saw blade diameter: 200 - 840mm, Circular Saw Bore Diameter: from 16 mm, Tooth pitch: 6 - 180mm, grinding path: up to 25 mm, tangential relief angle: 0 to 10 degrees, max. grinding wheel diameter: 125 mm, Grinding wheel bore diameter: 32 mm, Grinding spindle variable: 1600 - 5500 rpm,, Conn ...
