4 WEINBRENNER hydraulic shear used machines

Working width: 4100 mm sheet thickness: 16 mm projection: 300 mm rear gauge: 1500 mm power: 400 V, 45 kW space: 4800 x 3500 x 2600 mm weight: 28000 kg

Working width: 3050 mm sheet thickness: 6 mm throat depth: 200 mm rear gauge: 1000 mm power: 15 kW space: 4100 x 2300 x 2100 mm weight: 8500 kg well-preserved CNC hydraulic shear, with pivoting Panel, serial control. CYBELEC, CNC 1000, Hours of operation according to the operating hour counter: 2700 h

Manufacturer: Weinbrenner Type: TSV 6 / 3050 Year of constr.: End of 2015 demonstration machine Cutting length: 3050 mm Cutting capacity: 6 mm (steel) Hours of operation: 54 Control: Cybelec DNC 60 Dimensions L/W/H: 4100/2050/2100 mm Table height: 1000 mm Weight: 8500 kg Min. cutting angle: 1° Cutting angle max.: 2.5 ° Stroke rate minimum: 20 min. Max speed: 25 min. Cutting gap adjustment: motorized Cutting angle adjustment: hydraulic Number of holders: 14 Rear velocity range: 1000 mm Security: setting the photocell safety on the front and back Oil filling: 225 l Electrical power: 15 KW Power consumption: 3 x 400 V / 50 Hz Back-up fuse: 50 A Additional equipment: Extension of the side stop on 2050 mm Side stop side swing-away A total of 8 support arms freely movable along the entire length of the table The machine is a demonstration  ...

Scissors

Working width: 3050mm, material thickness: 6mm, throat depth: 200mm, back gauge adjustment: 1000mm, drive power: 15kW, cutting angle range: 1°-2°, table height: 900mm. Machine dimensions X/Y/Z: approx. 4100mm/2300mm/2100mm, weight: approx. 8500kg. On-site inspection is possible.

Hand guillotine shears, guillotine shears, sheet metal shears, sheet metal shears, folding machine, edging bench -Hand guillotine shears combined with: folding machine -Cutting width: 610 mm -Max. Section thickness: 1.0 mm -Swivel bending machine -Max. Working width: 610 mm -Max. Sheet thickness: 1.0 mm -Transport dimensions: 845/910/H1230 mm -Weight: 240 kg

pressure: 200 t chamfer lenght: 3050 mm distance between columns: 2550 mm Control: CYBELEC VisiTouch Pac stroke of ram: 524 mm weight of the machine ca.: 17.000 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t chamfer lenght: 2050 mm distance between columns: 1550 mm throat: 250 mm stroke: 200 mm adjustment of press crosshead: 200 mm stroke speed - idle stroke downwards: 105 mm/sec stroke speed - idle stroke upwards: 180 mm/sec stroke speed - under load: 9,5 mm/sec table width: 200 mm table height over floor: 900 mm dayligth: 280 - 480 mm back stop - adjustable: 3 - 729 mm control: CYBELEC SYNCHRO control: CNC 7400 PS total power requirement: 7,5 kW weight of the machine ca.: 10 t dimensions of machine L x W x H: 3,70 x 2,45 x 2,80 m Accessories: programmable back gauge, table extensions, various upper and lower dies segments The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 4050 mm plate thickness: 20 mm distance between columns: 4100 mm column daylight: 4200 mm no. of strokes: 10-20 Hub/min working pressure: 250 bar total power requirement: 85 kW weight of the machine ca.: 43,6 t dimensions of the machine ca.: 5,5x2,8x2,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressing force: 3200kN, enlarged stroke: 810mm, working width: 4050mm, ram speed: downwards: 130mm/s, pressing: 6.5mm/s, upwards: 75mm, stop time: 109ms, safety distance: 174mm, weight: approx. 29000kg, operating hours: 16010h, control: Cybelec ModEva 15S. Including 4 bending aids and angle measuring sensor. Dies, embossing tools, pointed punches, roe foot punches, closing bar, extension for upper tool, radius tool and adapter available on request. Documentation available.

pressure: 200 t chamfer lenght: 3050 mm distance between columns: 2550 mm stroke of ram: 274 mm control: Cybelec ModEva Pac total power requirement: kW weight of the machine ca.: 17.000 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 80.0 t chamfer lenght: 2050 mm distance between columns: 1550 mm column arm: 250 mm table width: 85.0 / 135 mm stroke: ca. 390 mm dayligth: ca. 585 mm ajustment speed: 180 mm/sec working feed: 1.0 - 10.0 mm/sec return speed: 135 mm/sec work height max.: 1050 mm Number of working hours: 32.495 h oil volume: 200 l operating pressure: 320 bar total power requirement: 11.6 KW weight of the machine ca.: 7300 kg range L-W-H: 3700 x 2000 x 3000 mm ** Good/well-maintained condition (!!) - in checked conditions - machinevideo - https://www.youtube.com/watch?v=IKyUmzB0WTI ------------------------------------------------- CNC electro-hydraulic press brake with: * Increased installation height .. approx. 550 mm * Increased cylinder stroke .. approx. 390 mm ------------------------------------------------- Features: - Robust electro-hydraulic press brake * MADE IN GERMANY (!!) - CYBELEC CNC ...

pressure: 200 t chamfer lenght: 3600 mm distance between columns: 2650 mm dayligth: 500 mm throat: 300 mm stroke: 250 mm working feed: 10,5 mm/sec return speed: 100 mm/sec ram stroke speed: 150 mm/sec table height: 900 mm oil volume: 500 l total power requirement: 37 kW weight of the machine ca.: 17800 kg dimensions of the machine ca.: 3710 x 1800 x 3390 mm Equipment: - Controlled axes Y1 + Y2 - Manual X-axis with digital position display - Set of upper and lower tools - 2x stop fingers - 2x front support arms - Hand and foot controls - Side + rear safety guard - Operating instructions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

* General * SKU332X713 * LocationBarneveld * MakeIgefa Weinbrenner * Type061U-600-600 * No.50467 * Year of construction2014 * Pressure * Vacuum possiblecheck * Vacuum possible jacketcheck * Working pressure shell10 Bar * Vacuum possible shellcheck * Working pressure tubes10 Bar * Tubular vacuum possiblecheck * Main Features * Shell (Material)Stainless steel * Tube (Material)Stainless steel * Surface41 m2 * Specified Features - Shell and tube heat exchanger * MaterialStainless steel 1.4571 (316Ti) * Heat exchangercheck * Horizontalcheck * Heating surface41m² * Tube capacity582 l. * Number of tubes:178 * Tube diameter33,7 mm * Tube length2200 mm * Wall thickness tubes2 * Max. temperature0°C/+200°C * Shell capacity252 l. * Shell diameter600 * Shell length2500 * Max. temperature0°C/+200°C * Shell connectionsDN80 * Cover connectionsDN500 * Information * Mounted on framecheck * Total heig ...

pressure: 250 t chamfer lenght: 3550 mm distance between columns: 3000 mm Control: Cybelelc DNC 1200 total power requirement: kW weight of the machine ca.: 18.500 kg dimensions of the machine ca.: 4300x2750x3750 mm Accessories: - 2-hand foot switch - Lasersafe Fisseler - Hydraulic tool clamping at top and bottom - Die shift - Hydraulic crowning - Support arms - Cybelec DNC 1200 control - 1 set of upper and lower tools - Controlled axes y1, y2, x, r, z1, z2, inclined stop - Protective grille The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Type of press: 2-cylinder synchronized press, pressing force: 125t, rated pressing force: 110t, bending length: 3000mm, ram stroke: 360mm, installation height: 540mm, distance between frames: 2550mm, hydraulic pressure: 256bar, weight: approx. 12000kg, control system: Cybelec DNC 7000 Graphic. Including various tools. The control system and the screen were renewed in mid/late 2025. An on-site inspection is possible.

Hydraulic guillotine shears STEINER type HTS 30/20 RMasch. No. 315 Year of construction 1982Cutting length 3050 mmCutting thickness 20 mmBack gauge 800 mm controlledMotor power approx. 30 kWNet connection 400 volts, 50 Hz- Back gauge with positioning control ELGO- Back gauge adjustment via ball screws- Safety light barrier SICK front as protection against interference- 3 pieces Material Support arms with ball rollers- Electric foot switch- Replacement knifeSpace requirement of the basic machine L x W x H 4650 x 2610 x 3200

Hydraulic guillotine shears STEINER type HTS 30/20 RMasch. No. 315 Year of construction 1982Cutting length 3050 mmCutting thickness 20 mmBack gauge 800 mm controlledMotor power approx. 30 kWNet connection 400 volts, 50 Hz- Back gauge with positioning control ELGO- Back gauge adjustment via ball screws- Safety light barrier SICK front as protection against interference- 3 pieces Material Support arms with ball rollers- Electric foot switch- Replacement knifeSpace requirement of the basic machine L x W x H 4650 x 2610 x 3200

Guillotine Shears, Metal Shears DIGEP Type OL 3Workshop Overhauled Guillotine ShearFabr. No. 1312 Year of construction 1977Cutting length 1250 mm (nominal cutting length)Cutting length max. 1300 mmCutting thickness at 450 N/mm² 3 mmSingle back gauge 500 mmStand projection 200 mmCutting angle 2 stroke rate at full cutting length max. 50 strokes/min. Working height 860 mmMotor power 2.2 kWNew connection 380 Volt, 50 Hz- LED cutting area-Lighting- Simple backgauge with manual adjustment- Mechanical

Guillotine Shears, Metal Shears DIGEP Type OL 3Workshop Overhauled Guillotine ShearFabr. No. 1312 Year of construction 1977Cutting length 1250 mm (nominal cutting length)Cutting length max. 1300 mmCutting thickness at 450 N/mm² 3 mmSingle back gauge 500 mmStand projection 200 mmCutting angle 2 stroke rate at full cutting length max. 50 strokes/min. Working height 860 mmMotor power 2.2 kWNew connection 380 Volt, 50 Hz- LED cutting area-Lighting- Simple backgauge with manual adjustment- Mechanical

Guillotine shear LOTZE type HSS 20 / 7Cutting length 2050 mmCutting thickness 7 mmwith single back gauge; used

Hydraulic guillotine shears FASTI type 509 - 25/4Masch. No. 5418 Year of construction 1991Cutting length 2535 mmCutting thickness 4 mmBack gauge 5-1000 mm (controlled)Cutting angle adjustableHydraulic pressure max. 290 barMotor power 7.5 kWNeching connection 400 volts, 50 Hz- Back gauge with positioning control ELGO ELECTRIC Type 85- Sheet metal holding device under the back gauge- Manual cutting gap adjustment with dial gauge display on the right and left- Stepless cutting length adjustment- Hydraulic

Hand lever shears VEB Scherenbau Nossen type ScDH10Knife length: 180 mmSheet thickness: max. 10 mmFlat material: 50x15 mm4-edge solid material: 22x22 mmRound steel: 24 mmAngle steel: 60x7mmT-steel: 60x7mmon mobile undercarriageWeight: approx. 150 kg; used

Hydr. Swing cut guillotine shears HERA type HSS IIIFabr. No. 598 Year of manufacture 1986Cutting length 3100 mmCutting thickness 3 mmStand projection 200 mmKnife strokes 25 strokes/min. Mains connection 380 Volt, 50 HzMotor power 3 kW- motorized adjustable back gauge 1070 mm- actual digital display for the back gauge- cutting gap adjustment- cutting length adjustment- front side stop left 1000 mm- 4 pieces sheet metal support arms 1000 mm- el. Foot switchSpace requirement without sheet metal support arms L x W x H 3630 x

Swing-cut guillotine shears KÖLLSCHEN type BSK 2000/2Fabr. No. 69 1307 Year of construction 1969Cutting length 2000 mmCutting thickness 2 mmStand projection 90 mmWorking height 920 mmMains connection 380 volts, 50 HzEngine power 4 kW- Drive via geared motor with brake and crankshaft- mechanical sheet metal hold-down- manual back gauge 500 mm- stop adjustment via 2 handwheels, rear on the backgauge guide with measuring scale- front side stop left 720 mm- electric foot switch- manual
