WEINGARTEN av used machines

Weingarten Eccentric Press AV10 - With pliers feed - Reel and reel - When pressing, the speed can be set up with a frequency converter - Press force: 10 t - Stroke rate: 160 / min - Plunger stroke: 6-60 mm - Plunger adjustment: 40 mm Good condition, fully functional, can be viewed and tried out on site. Shipping also abroad. Viewing: Basically, I would like to point out that the article can be viewed and tested under power before purchase in order to rule out misunderstandings. Please ask questions before purchasing to avoid confusion. If you have any general questions or would like to make an appointment for a viewing, I can be reached at any time on the telephone number below or above. Errors in the description and prior sale excepted. VAT is shown separately on my invoices. Shipping with forwarding agent.

pressure: 63 t throat: 320 mm stroke: 8-100 mm no. of strokes: 120 Hub/min ram - range of adjustment: 63 mm table surface area: 730x600 mm ram surface: 540x360 mm table height: 850 mm tool hole in ram: Ø40 mm weight of the machine ca.: 5,5 t dimensions of the machine ca.: BxTxH 2000x2000x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

WEINGARTEN DE 200-20 press built in 1975 in Germany is used for precision workpiece machining. The rigid construction combined with a high press force of 200 tonnes make the machine the perfect solution for mass production of various types of parts. The process of precision sheet metal pressing can be fully automated when the WEINGARTEN press is retrofitted with a sheet metal feeder. Technical specifications of the WEINGARTEN DE200-20 200 t press - press force: 200 t - maximum slider stroke: 200 mm - minimum slider stroke: 15 mm - maximum number of slider strokes: 60/min - minimum number of slider strokes: 20/min - slider adjustment: 110 mm

Cylinder part for Multi for GDK3500 die casting machine, 931732, Frech/Müller Weingarten, new Special price !!! If you have a VAT number, we will gladly issue an invoice without VAT. Condition new The cylinder part for Multi comes from a spare parts warehouse at a production facility, has always been stored in a dry, sealed environment, is new and fully functional. The cylinder part for Multi item 931732 from Frech/Müller Weingarten. Suitable for Frech/Müller Weingarten GDK 3500 machines with 185-tonnes or 220-tonnes units.. Weight 720 kg. The goods can be viewed, inspected and collected from us at any time. We will also be happy to send you a sketch of the design or deliver the goods to your address. Attention: We offer various columns, adjusting nuts, tie bar expansion nuts and 2-piece nuts from: IDRA D330, D300, D260, D250, Oleopress/OP Die Casting: D285, D250, ...

Single column - eccentric press WEINGARTEN type E 40 Masch. No. 643 / 62 Year of construction 1963 Pressure capacity 40 ton. Projection 250 mm Table opening 150 x 80 and Ø 200 mm Table area 560 x 460 mm Plunger area 250 x 200 mm Adjustable ram stroke 8-88 mm Plunger adjustment 63 mm Installation height 320 mm Clamping pin bore Ø 40 mm Stroke rate 100 / 130 strokes / min. Motor power 2.2 / 3 kW Mains connection 400 volts, 50 Hz Table height above floor 840 mm - Clutch-brake combination thanks to WEINGARTEN friction threaded clutch with OT flow protection - Electric stroke release via two-hand operation - Overload protection by crushing plate - Manual grease central lubrication - Front crankshaft support bearing - Control cabinet adjacent - UVV for manual insertion work Space requirements L x W x H 1800 x 1500 x 2200 mm Weight 3.1 ton.

Single column - eccentric press WEINGARTEN type ERV 40Masch. No. 537 / 65 Year of construction 1965Compressive force 40 ton. Projection 230 mmTable size 570 x 470 mmPlunger area 250 x 200 mmClamping pin hole 40 mmInstallation height max. approx. 520 mmStroke adjustment 8 - 88 mmPlunger adjustment range 63 mmStroke rate 70 strokes per minuteDrive power 3 kWNetz connection 380 volts, 50 Hz- Table height adjustment- Overload protection by crushing plate- Clutch-brake combination by WEINGARTEN friction threaded coupling-

Single column - eccentric press WEINGARTEN type ER 63Masch. No. 52A / 63 Year of construction 1963Pressure capacity 63 ton. Projection 280 mmTable surface 630 x 530 mmAdjustable plunger stroke 8-100 mmPlunger adjustment 63 mmStroke rate 65 strokes / min. Engine power 4 kWNetz connection 380 Volt, 50 Hz- Clutch-brake combination by WEINGARTEN friction threaded clutch- Electrical stroke release via foot switch- Wheel counters- Overload protection by crushing plate- Front crankshafts Support bearingSpace requirement L x W x H 1500

Single-column eccentric press WEINGARTEN type E 40Masch. No. 643/62 Year of construction 1963Pressure capacity 40 ton. Projection 250 mmTable opening 150 x 80 and 200 mmTable area 560 x 460 mmPlunger area 250 x 200 mmPlunger stroke adjustable 8-88 mmPlunger adjustment 63 mmInstallation height 320 mmPin hole 40 mmStroke rate 100/130 strokes / min. Motor power 2.2 / 3 kWNetz connection 400 volts, 50 HzTable height above floor 840 mm- Clutch-brake combination by WEINGARTEN friction threaded coupling with TDC

Locking block for die casting machine GDK2500 by Frech, PADS1117.400, Parker, overhauled-as good as new Special price!! If you have a VAT number, we will be happy to issue you an invoice without VAT. Refurbished! The locking block was overhauled by Parker, is in the original packaging and is in an immediately usable, top condition. The locking block can be viewed, checked and picked up at any time. We will also be happy to send you a sketch of the execution or deliver the goods to your address. Locking block, Parker, PADS1117.400, Suitable for the GDK 2500 machines from Frech/Müller Weingarten The block was still delivered to machines from Müller Weingarten and has SAE connections. Art. 937009 Weight 650kg Attention: We offer various columns, adjustment nuts, tie bar expansion nuts and 2 piece nuts from: IDRA D330, D300, D260, D250, Oleopress/OP Die Casting: D285, ...

Piston head for Frech die-casting machine, bronze, 931603, Frech/Müller Weingarten, new Special price !! If you have a VAT number, we will be happy to issue you with an invoice without VAT. New! - never been used and is completely new, - comes from a spare parts warehouse of a certified production facility, - is in its original packaging, Piston head for Frech/Müller Weingarten die casting machine, Outer diameter 251.5 mm, thread inner diameter 196.5 mm, height 200 mm, 34 kg

A complete 8-stage transfer press line with a Weingarten double-column transfer press is available. 1) Mechanical double-column transfer press Weingarten S.3100.08.70.1, year of manufacture: 1969, tool stations: 9, forming stages: 8, total press force: 3100t, press force blanking slide/drawing slide: 300t/2800t, strokes: 28/min, blanking slide stroke: 200mm, drawing slide stroke: 500mm, max. drawing depth: 120mm, drawing slide ejector stroke: 100mm, blank holder stroke: 50mm, drawing cushion force: 25t, transfer pitch: 700mm, max. blank dimensions X/Y: 450mm/450mm, max. blank diameter: 540mm, table dimensions X/Y: 1200mm/5600mm, main motor power: 300kW, machine dimensions X/Y/Z: approx. 10500mm/7500mm/9700mm, weight (according to documentation): approx. 524t, stroke counter reading (September 2024): approx. 25 million. 2) Blanking and cutting press Georg Maschinentechnik PKD 630, year of ...

Weingarten Excenter Press

Type / type: N 25 Year of make: 1977 Manufacturer / make: Weingarten Rated pressure: 25 t Number of strokes: 140 / min Radius slide center to frame: 200 mm Window in frame: 240 mm distance table slide: 250 mm Stroke adjustment / adjustment of stroke: 8 ... 80 mm Ram adjustability/adjustment of ram: 50 mm Ram size / surface of ram: 355 x 220 mm Table size / surface of bed: 560x 400 mm Hole in table: 160 mm Power of main motor:3 kW Weight / weight: 2,23 t

Tie bar expansion nut for die casting machine GDK2500, TR300x10, 946263, Frech/Müller Weingarten, new Special price !!! If you have a VAT number, we will gladly issue an invoice without VAT. Condition new The nut is new and fully functional. Tie bar expansion nut, Tr300x10, D500/400/340mmx360mm high. Approx. 230kg The goods can be viewed, inspected and collected from us at any time. We will also be happy to send you a sketch of the design or deliver the goods to your address. Attention: We offer various columns, adjusting nuts, tie bar expansion nuts and 2-piece nuts from: IDRA D330, D300, D260, D250, Oleopress/OP Die Casting: D285, D250, Frech: D375, D330, D300

Folding nut for die casting machine, TR330x10, 931375, Frech/Müller Weingarten, new Special price !!! If you have a VAT number, we will gladly issue an invoice without VAT. Condition new The nut is new and fully functional. Folding nut, Tr330x10, 2 pieces 550x220x220mm high. Approx. 270kg, 931375, The nut has been preserved by us. The goods can be viewed, inspected and collected from us at any time. We will also be happy to send you a sketch of the design or deliver the goods to your address. Attention: We offer various columns, adjusting nuts, tie bar expansion nuts and 2-piece nuts from: IDRA D330, D300, D260, D250, Oleopress/OP Die Casting: D285, D250, Frech: D375, D330, D300

Ram, rams for an eccentric press, single column press, punching machine, single column eccentric press, eccentric press - single column, press -Spare part: comes from a Weingarten eccentric press -Stroke adjustment: 10-80mm -Plunger area: 320 x 65 mm -Plunger mount: O 40 mm -Plunger adjustment thread: M64 x 6 mm -Plunger adjustment ball head: approx. 92 mm -Dimensions: 875/320/H190 mm -Weight: 164 kg -Pressure unknown

pressure: 160 t no. of strokes: 40 - 120 Hub/min sheet width: mm total power requirement: 40 kW Pressing capacity 160 ton Table clamping area 1,100 x 1,280 mm Ram clamping area 850 x 890 mm Distance between guides 1,120 mm Distance between columns (below guide ways) 1,350 mm Distance between Table and ram in upper position approx. 400 mm No. of strokes 40 - 120 /min Adjustment of stoke 67 / 115 / 160 mm Ram adjustment, motor driven 125 mm Ejector travel 50 mm Total electrical load, approx. 40 kW - 500 V - 50 Hz Weight, approx. 24,000 kg Accessories / Special Features * WEINGARTEN Sheet Metal Uncoiler with overhead loop control (space saving because it does not need a loop-pit). Strip width 375 mm. The loop control guides the strip-material from the uncoiler to the machine thru a straightening device with automatic supervision. * 8-track slide bearing guide. * Automatic oil-circulation l ...

Technical data Weingarten Mechanics Press 800 to Year of construction 1999 Nominal pressing force from 12.7 mm before UT 8000 kN Working stroke rate 10 - 40 strokes/min Setup stroke number 5 - 15 stroke/min Plunger stroke 200 mm Maximum tool installation height 1200 mm Stroke at the bottom, adjustment at the top Minimum tool installation height 900 mm Plunger adjustability 300 mm Standard tool installation height (closed tool if power setup springs are present) 980 mm Table top dimensions, length x width 3600 mm x 230 mm Plunger plates dimensions, length x width 3600 mm x 23 Passage between the uprights in length 3600 Passage between the uprights in width 2300 Standard infeed height above press table 750 mm Inlet height adjustment range 620 - 800 mm Quick Tension Plunger Plate: Hollow piston cylinder, variable 4 pcs. on each side Too ...

Technical data Weingarten Mechanics Press 1600 to Nominal press force from 20 mm before UT 16000 kN Endurance stroke rate at idle infinitely variable 10 - 22 strokes/min Setup stroke number 5 - 10 stroke/min Plunger stroke 600 mm Maximum tool installation height 1200 mm Stroke at the bottom, adjustment at the top Minimum tool installation height 900 mm Plunger adjustability 300 mm Standard tool installation height (closed tool if power setup springs are present) 1150 mm Table top dimensions, length x width 3600 mm x 23 Plunger plates dimensions, length x width 3600 mm x 23 Passage between uprights in length 3650 mm Passage between the uprights in the width of 2300 mm Transfer height above press table 750 mm Quick Tension Plunger Plate: Swivel voltage, stationary 4 pcs. on each side Tool clamping flange thickness 70-0.2mm Clamping force  ...

Split nut, for die casting machine, TR370x12, 924399, Frech/Müller Weingarten, new Special price !! If you have a VAT number, we will be happy to issue you with an invoice without VAT. New! - never been used and is completely new, - comes from a spare parts warehouse of a certified production facility, - is in its original packaging, Split nut, Tr370x12, 560x560x435mm high. 700kg Nut for automatic SZ F./PI. GDK/3800/4100 The nut has been preserved by us. The goods can be viewed, inspected and collected from us at any time. We will also be happy to send you a sketch of the design or deliver the goods to your address. Attention: We offer various columns, adjusting nuts, tie bar expansion nuts and 2-piece nuts from: IDRA D330, D300, D260, D250, Oleopress/OP Die Casting: D285, D250, Frech: D370, D330, D300

Offer is a Weingarten crank press Type. ZS 1600.32 ex location for sale. The technical data can be found in the photos.

sheet width:2000 mm plate thickness:1.8 mm Controls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mm RAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mm DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diamet ...

pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F

see picture in the appendix

pressure: 63 t distance between columns: 0 mm stroke: 160 mm table surface area: 630 x 500 mm dayligth: 400 mm total power requirement: kW weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
