Eccentric Presses used for sale (92)

Dirinler CD/PC 600 H - Eccentric Press - incl. tools & accessories - Built in 1990 Specification - Capacity: 60 t - Stroke rate: 52 rpm - Plunger adjustment: 80 mm - Table dimensions: 750 x 480 mm - Plunger area: 360 x 250 mm - Table recess: Ø 170 mm - Projection: 250 mm - Engine speed: 1400 rpm - Motor power: 4 kW - Operating voltage: 400 V - Machine dimensions WxHxD: 950 x 2500 x 1900 mm - Dimensions control cabinet WxHxD: 60 x 115 x 35 mm - Weight: approx. 4000 kg

Machine number: 2810292Operating voltage: 380 VConnection: 1.5 kWMax. pressing force: 250 kNProjection: 190 mmPlunger strokes: 120/minPlunger adjustable: 5 mmStroke adjustable: 4 - 60 mmTable dimensions: 550 x 430 mmincl. straightening device from the manufacturer REBENDER Auction-ID: A7-46287-156

Eccentric press vineyard type AR160 tons With protective shield. YOC 1971 2 rotational speeds via mechanical gearbox Switchable. Central lubrication. Low-wear steep-threaded coupling. Table dimensions : 800x1000 mm Visits : possible at any time. Total weight approx. 10.5 tons

Machine number: 2561290max. load: 250 kNThroat: 190 mmPlunger strokes: 80 1/minPlunger adjustable: 45 mmStroke adjustable: 8 - 80 mmMotor power: 2.2 kWVoltage: 380 VTable dimensions: 555 x 430 mm Auction-ID: A7-46287-22

Specifications: Capacity 40 tons 2 strokes 57 + 86 H/min Projection 250 mm Plunger stroke 8 - 88 mm Plunger adjustment approx. 63 mm Table , WxD approx. 570 x 450 mm Max. installation height approx. 330 mm

Machine number: 0820592max. load: 25 kNThroat: 90 mmPlunger strokes: 75 1/minPlunger adjustable: 30 mmStroke adjustable: 2 - 40 mmMotor power: 0.25 kWTable dimensions: approx. 220 x 150 mmincl. The installed punching tool Auction-ID: A7-46287-215

Specifications: Capacity 300 to Stroke rate 35 strokes Plunger width 1000 mm Projection 450 mm Plunger stroke 20 - 140 mm Plunger adjustment 80 mm Engine power 30 hp Weight roughly estimated 18 tons

max. load: 25 kNProjection: 90 mmPlunger strokes: 220 1/minPlunger adjustable: 30 mmStroke adjustable: 2 - 40 mmTable dimensions: approx. 220 x 150 mmincl. The installed punching tool Auction-ID: A7-46287-210

Specifications: Capacity 63 tons Stroke rate 140 h/min Projection 250 mm Plunger stroke 8-100 mm Table , WxD approx. 700 x 480 mm Installation height approx. 400 mm

Pressure capacity: 35,000 kgPlunger strokes: 110 1/minThroat: 220 mmPlunger adjustable: 50 mmStroke adjustable: 0 - 70 mmMotor power: 3 hpVoltage: 220/380VTable dimensions: 550 x 460 mm Auction-ID: A7-46287-23

Specifications: Capacity 63 tons 2 strokes 105 rpm and 140 rpm large projection 450 mm ! Plunger stroke 8-100 mm Plunger adjustment approx. 70 mm Table , WxD approx. 700 x 780 mm Plunger, W x D approx. 450 x 280 mm

Machine number: 6750296max. load: 450 kNThroat: 230 mmPlunger strokes: 80 1/minPlunger adjustable: 55 mmStroke adjustable: 4 - 80 mmMotor power: 4 kWVoltage: 380 VTable dimensions: 700 x 520 mm Auction-ID: A7-46287-30

SPK KB 2132 eccentric press was manufactured in the USSR in 1980. Operating with a force of 160 tonnes, the press of almost indestructible design offers the highest quality and precision during the most demanding workpiece machining. The machine’s equipment includes among others a pneumatic clutch, a large-area slider performing up to 71 strokes per minute, central lubrication and manual control. The total weight of the press is 13200 kg. Technical data of the SPK KB 2132 press - maximum press force: 160 t - work table dimensions (L x W): 1000 x 700 mm - maximum slider stroke: 160 mm - minimum slider stroke: 25 mm - slider dimensions (L x W): 580 x 460 mm - slider adjustment range: 120 mm - slider stroke rate: 71/min - intermediate plate thickness: 110 mm - distance between work table and slider (slider in lower position, largest stroke, connector unscrewed): 480 mm - bore ...

Order number: 121789APress force: 100 kNStroke rate: 55 and 82 per min. Ram stroke: 8 - 140 mmRam adjustment: 80 mmTable dimensions: 1000 x 720 mm with three grooves Auction-ID: A7-46287-132

Stock Number: 3785 ECCENTRIC PRESS Manufacturer: PMB, Type: EPFT 100 Machine NO.: 004301, Year of manufacture: 2002 Specifications: Table size 780 x 590 mm Stroke length 8-120 mm Number of strokes per minute 55 Projection 300 mm Operating height 395 mm Total power 7.5 kW Pneumatic clutch. Gear ratio. Hydr. Overuse protection. Weight: 5500 kg

Machine number: 473678Delay time: 69 msSafety distance for hand control tool: 110 mmTable dimensions: 700 x 525 mm Auction-ID: A7-46287-17

Rotary indexing table with 12 stations Automatic ejector three pressing stages Pressure capacity 1,000 KN Stroke 12-120 mm Stroke rate 30-60 1/min Plunger adjustment 80 mm Total weight 9,500 kg

Machine number: 896471Pressure capacity: 5000 kgThroat: 115 mmPlunger strokes: 165 1/minAdjustable plunger: 40 mmStroke adjustable: 0 - 50 mmMotor power: 0.75 hpTable dimensions: approx. 280 x 220 mmwith pneumatic punching tool installed Auction-ID: A7-46287-199

Type / type: N 25 Year of make: 1977 Manufacturer / make: Weingarten Rated pressure: 25 t Number of strokes: 140 / min Radius slide center to frame: 200 mm Window in frame: 240 mm distance table slide: 250 mm Stroke adjustment / adjustment of stroke: 8 ... 80 mm Ram adjustability/adjustment of ram: 50 mm Ram size / surface of ram: 355 x 220 mm Table size / surface of bed: 560x 400 mm Hole in table: 160 mm Power of main motor:3 kW Weight / weight: 2,23 t

with mounted punching tool Auction-ID: A7-46287-175

Eccentric Press Brand Ebu Type EP15 Table size 400x430mm Max pressure 15 000kg Table height adjustment Table passage D160mm Stroke adjustment 4-70mm Ram bore 40mm Projection 200mm Max distance table-tappet 320mm Single/Duration Stroke Shield Flywheel D600mm 400V 1.0kW Machine weight ca. 870 kg The purchase price is net. Can be viewed and tested in our warehouse. Delivery is possible at an additional cost. All information without guarantee!

Machine number: 4801178max. load: 450 kNThroat: 230 mmLifts: 110 1/minLifts adjustable: 55 mmStroke adjustable: 4 - 80 mmMotor power: 3 kWTable dimensions at the bottom: approx. 700 x 460 mmTable dimensions at the top: approx. 380 x 180 mmwith a feed device Auction-ID: A7-46287-182

Specifications: - Compressive force 60 t - Projection 350 mm - Table size approx. 900 x 600 mm - Table height adjustable - Diarrhea hole in the table approx. 300 x 200 mm - maximum installation height approx. 360 mm - Stösselfläche approx. 340 x 160 mm - Cone hole in the plug 40 mm - Plug adjustability 60 mm - Stroke adjustment 10 - 90 mm - Stroke rate 110 1/min - 2 hand operation - Pneumatic connection 6 bar - Flywheel drive / speed infinitely adjustable - Rotary wedge coupling - Drive 400 V / 5.5 kW - Space requirement approx. W 2000 x H 2200 x D 2400 mm - Weight approx. 4500 kg - mechanical clamp feed MABU type ZPL 11 with 3 roller straightener

Auction-ID: A7-46309-70

Pressure capacity: 8000 kg Maximum cutting area - 200 mm2 for material strength 40 kg / mm2 Horizontal radius 200 mm Clearance between the side walls 160 mm Fixed hub 35 mm Pin hole in the Stossel 38 x 60 mm Adjustability of the Stossels 70 mm Weight of 400 kg of the Presse Operating instructions The machine is located in the new value. State, probably never in use. Control actuator Stober

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 130 toPRESS TABLE  table surface (left-right): 1200 mm  table surface (front-back): 700 mm  thickness of bolster plate: 80 mmSLIDE  table surface (left-right): 750 mm  table surface (front-back): 550 mm  stroke rate (max.): 60 /minSLIDE (MECHAN. PRESS)  slide adjustment: 100 mm  stroke min.: 19 mm  stroke max.: 165 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 525 mmELECTRICAL SPECIFICATIONS  total power consumption: 11 kW  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1685 mm  space requirements -front/back-: 1910 mm  total height: 3340 mm  total weight approx.: 11000 kg

Technical data: -Compressive force 100 t -Throat 320 mm -Wide stand below the Guide 400 mm -Table size approx. 850 x 610 mm -Discontinued diarrhea hole in the table 335 / 300 mm -thickness of the table clamping plate 90 mm -gr. Height approx. 300 mm -Plunger area 600 x 335 mm -Adjustable height of the RAM 80 mm -Stroke adjustment 10-130 mm -Emissions er hub in the RAM 32 mm -Speed continuous operation approx. 56 / min -Drive 400 V / 11 kW -Space requirement approx. B H 1900 x 2800 X 2200 mm -Weight approx. 9000 kg Starring:-UVV press backup controller PREVENTA -Hydr. + pneumatically actuated clutch -LUTEX auxiliary braking system -Central lubrication

PRESS DESIGN  drive system: eccentric / crank   table cushion: yes PRESS FORCES  total force (nominal): 100 to  nominal work capacity: 1000 kNmPRESS TABLE  table surface (left-right): 1100 mm  table surface (front-back): 660 mm  thickness of bolster plate: 100 mmSLIDE  table surface (left-right): 640 mm  table surface (front-back): 420 mm  spigot hole diameter: 50 mm  stroke: 130 mm  stroke rate (max.): 60 /minSLIDE (MECHAN. PRESS)  slide adjustment: 110 mm  stroke min.: 20 mm  stroke max.: 130 mmDIE CUSHION (TABLE CUSHION)  number of cushions: 1 TOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 450 mm  distance table - slide max.: 580 mmELECTRICAL SPECIFICATIONS  total power consumption: 7.5 kW  mains voltage: 380 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1610 mm  space requiremen ...

Tech. Data Nominal press force 1000 kN at maximum stroke adjustment - commute 6.5 mm 1250 kN at maximum stroke adjustment - commute 3.5 mm Strokes with endurance 125/83/63 Hube/min Usable stroke rate 50 50 38 / min. Throat depth 320 mm, clamp 380 mm Stroke adjustment 10-120 mm, Stosselverstellung 80 mm Stosselflaeche 800 x 320 mm, recording journal 50 / 85 Tabletop table top hole, 900 x 630 mm 230 mm, Durchfalloch in the table 300 / 400 x 250 mm Drive - 7,5 / 5,5 kW Bulk 1350 x 2080 x 2780 mm, Btto 8900 kg

CONTROLS   SIEMENS SIMATIC PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 160 toPRESS TABLE  table surface (left-right): 1200 mm  table surface (front-back): 970 mmSLIDE  stroke rate (max.): 90 /minSLIDE (MECHAN. PRESS)  slide adjustment: 120 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 3200 mm  space requirements -front/back-: 1600 mm  total height: 4400 mm  total weight approx.: 32000 kg

Capacity: 50 ton Projection: 225 mm Stroke: 320 p/min Large table: 500 x 800 mm

PRESS FORCES  total force (nominal): 100 toPRESS TABLE  table surface (left-right): 950 mm  table surface (front-back): 660 mm  thickness of bolster plate: 68 mmSLIDE  table surface (left-right): 540 mm  table surface (front-back): 450 mm  spigot hole diameter: 60 mm  stroke: 130 mm  stroke rate (max.): 65 /minSLIDE (MECHAN. PRESS)  slide adjustment: 100 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 370 mmDIMENSIONS / WEIGHTS  total weight approx.: 7000 kgLocated in Barcelona - Spain2 identical units available

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 40 toPRESS TABLE  table surface (left-right): 650 mm  table surface (front-back): 380 mm  thickness of bolster plate: 60 mm  opening in bed (diameter): 120 mmSLIDE  table surface (left-right): 350 mm  table surface (front-back): 250 mm  spigot hole diameter: 40 mm  stroke: 78 mm  stroke rate (max.): 145 /minSLIDE (MECHAN. PRESS)  slide adjustment: 60 mm  stroke min.: 8 mm  stroke max.: 78 mm  main drive power: 3 kWTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 297 mmELECTRICAL SPECIFICATIONS  total power consumption: 3.05 kW  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1300 mm  space requirements -front/back-: 1100 mm  total height: 2150 mm  total weight approx.: 2200 kgATTACHMENTS ...

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 55 toPRESS TABLE  table surface (left-right): 750 mm  table surface (front-back): 450 mmSLIDE  table surface (left-right): 400 mm  table surface (front-back): 300 mm  spigot hole diameter: 45 mm  stroke: 50 mm  stroke rate (max.): 100 /minSLIDE (MECHAN. PRESS)  slide adjustment: 70 mm  stroke min.: 6 mm  stroke max.: 50 mm  stroke rate (min.): 50 /min  stroke rate (max.): 100 /minTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 310 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1200 mm  space requirements -front/back-: 1500 mm  total height: 2500 mm  total weight approx.: 3850 kgATTACHMENTS (PRESSES)  strip feeder: optional   feeder type: grip feeder   saf ...

PRESS DESIGN  drive system: eccentric / crank   table cushion: yes PRESS FORCES  total force (nominal): 63 to  nominal work capacity: 630 kNmPRESS TABLE  table surface (left-right): 900 mm  table surface (front-back): 560 mm  opening in bed (diameter): 250 mmSLIDE  table surface (left-right): 450 mm  table surface (front-back): 310 mm  clamping surface diameter: 50 mm  stroke: 100 mm  stroke rate (max.): 100 /minSLIDE (MECHAN. PRESS)  slide adjustment: 80 mm  stroke min.: 17.5 mm  stroke max.: 100 mmDIE CUSHION (TABLE CUSHION)  number of cushions: 1 TOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 340 mm  distance table - slide max.: 440 mmELECTRICAL SPECIFICATIONS  total power consumption: 5.5 kW  mains voltage: 380 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1310 mm  space require ...

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 50 toPRESS TABLE  table surface (left-right): 700 mm  table surface (front-back): 450 mmSLIDE  table surface (left-right): 440 mm  table surface (front-back): 360 mm  spigot hole diameter: 40 mm  stroke: 90 mm  stroke rate (max.): 70 /minSLIDE (MECHAN. PRESS)  slide adjustment: 70 mm  stroke min.: 0 mm  stroke max.: 90 mm  main drive power: 3 kWTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 300 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 700 mm  space requirements -front/back-: 1295 mm  total height: 2360 mm  total weight approx.: 3000 kg

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 80 toPRESS TABLE  table surface (left-right): 860 mm  table surface (front-back): 620 mm  thickness of bolster plate: 70 mm  opening in bed (diameter): 165 mmSLIDE  table surface (left-right): 570 mm  table surface (front-back): 390 mm  spigot hole diameter: 50 mm  stroke: 120 mm  stroke rate (max.): 67 /minSLIDE (MECHAN. PRESS)  slide adjustment: 90 mm  stroke min.: 9 mm  stroke max.: 120 mm  main drive power: 5.5 kWTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 360 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 1420 mm  space requirements -front/back-: 1700 mm  total height: 2990 mm  total weight approx.: 5600 kg

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 45 toPRESS TABLE  table surface (left-right): 700 mm  table surface (front-back): 440 mm  opening in bed (diameter): 40 mmSLIDE  table surface (left-right): 410 mm  table surface (front-back): 280 mm  stroke rate (max.): 110 /minSLIDE (MECHAN. PRESS)  slide adjustment: 65 mm  stroke min.: 0 mm  stroke max.: 90 mm  main drive power: 5.5 kWTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 380 mm  distance between columns (H-frame): 360 mmATTACHMENTS (PRESSES)  2-hand engagement: yes   foot engagement: yes   European CE standards: yes

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 15 toPRESS TABLE  table surface (left-right): 360 mm  table surface (front-back): 260 mmSLIDE  stroke rate (max.): 165 /minSLIDE (MECHAN. PRESS)  slide adjustment: 40 mm  stroke min.: 7 mm  stroke max.: 60 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 226 mmELECTRICAL SPECIFICATIONS  total power consumption: 1.15 kW  mains voltage: 400 VDIMENSIONS / WEIGHTS  total weight approx.: 630 kgATTACHMENTS (PRESSES)  safety guard / safety door: yes   2-hand engagement: yes   foot engagement: yes   European CE standards: yes

CONTROLS  conventional PRESS DESIGN  drive system: eccentric / crank   frame design: C-frame, single sided PRESS FORCES  total force (nominal): 100 toSLIDE  slide force: 100 to  stroke rate (max.): 72 /minSLIDE (MECHAN. PRESS)  slide adjustment: 80 mm  stroke adjustment: yes   stroke min.: 8 mm  stroke max.: 112 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 407 mmATTACHMENTS (PRESSES)  2-hand engagement: yes for safe tools only

PRESS DESIGN  drive system: eccentric / crank PRESS FORCES  total force (nominal): 80 toPRESS TABLE  table surface (left-right): 850 mm  table surface (front-back): 550 mmSLIDE  table surface (left-right): 560 mm  table surface (front-back): 376 mm  spigot hole diameter: 50 mm  stroke: 110 mm  stroke rate (max.): 60 /minSLIDE (MECHAN. PRESS)  slide adjustment: 80 mm  stroke min.: 0 mm  stroke max.: 110 mmTOOL ASSEMBLY DIMENSIONS  shut height (stroke down, adjustment up), BDC: 360 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 855 mm  space requirements -front/back-: 1635 mm  total height: 2640 mm  total weight approx.: 5400 kgATTACHMENTS (PRESSES)  2-hand engagement: yes   foot engagement: optional   European CE standards: yes

: ja weight of the machine ca.: 9,5 tserial number: 10457/2 : 160000 KGstroke of worktool slide: 41 Hub/minPlease note:The machine is dismantled and ready for loading. It is not possible to show it under power or make a video.Our offer includes already the best pictures. So we don’t have and won’t send additional pictures.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
