Tool Grinding Machines used for sale (65)

Excellent condition - Fully operational - Loading / Transport possible! 5 AXIS CNC Toll & Cutter Grinder Walter Helitronic Power HMC-400 Specifications: Capacity of Workpiece Dia.: 1mm – 99mm Max. Peripheral Grinding: 254mm Max. End Face Grinding: 185mm Max. X Axis Travel: 350mm Max. Y Axis Travel: 200mm Max. Z Axis Travel: 470mm A Axis: Infinite C Axis Rotary: +/- 200° ( 0.001° ) Grinding Spindle Motor: 16 hp Grinding Wheel Type: Diamond or CBN Grinding Wheel Dia. Max.: 150 mm Grinding Wheel Speed: 500 to 10,500 RPM Programs include: Drill, End Mill and Form Tool Double side grinding spindle Walter Helitronic Power HMC-400 Equipped With: 10,500 RPM Precision Spindle Windows based Walter cnc Control CBN Diamond Wheel installed Probing system Coolant and Filtration System (small tanque) Full Enclosure WorkLight

- Maximum shaft rotation speed 2880 rpm. - Maximum peripheral velocity: 35 m/s. - Maximum length of the knife head 250 mm. - Wheel diameter 150 mm. - Operating conditions of this machine: unchecked. - Dimensions for transport approx. 1700 x 1100 x 1900 mm. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-46513-33

Kellenberger, 57 U, Beautiful universal and tool grinder, under power Surface grinding, cylindrical and internal cylindrical grinding, tool grinding. X-600mm, Cross: 300, Vertical: 300 Swivel Range 360 Degree Table: 1030 x 214, rotatable, Workpiece Spindle: MK5, 50-420rpm, Center Height: 125/175mm Accessories : Grinding spindle holders, internal grinding spindle, rear grinding device, univ. vice, ... A lot of accessories: see pictures!

Lid S0 incl. accessories see pictures Auction-ID: A1-46607-68

4-position tool grinding machine Fabr. SOLID Type DS 3 CD incl. cooling device and base with adjustable tables Grinding wheel pre-grind C: 200 x 50 x 51 mm Table: 400 x 150 mm Grinding wheel regrinding C: 200 x 50 x 51 mm Table: 400 x 150 mm Grinding wheel lap cut diamond: 125 x 12.5 x 51 mm Table: 400 x 150 mm 1 grinding wheel: 100 x 8 x 51 mm 2 engine speeds: 1400 / 2800 rpm. Drive power: 0.6 kW Dimensions L x W x H/: 1120 x 1000 x 1300 mm Weight: approx. 330 kg

ASSFALG 168 T Grinding Machine Auction-ID: A1-46607-97

Michael Deckel S0E Stylus Tool Grinding Machine, SOE Weilheim TOP Condition Total weight approx. 90kg Top grinding wheels with an outer diameter of up to max. 100mm are used Absolute top condition! Only one overhauled machine has a slightly superficial patina the bare metal parts. The pictures speak for themselves. The workshop dream in Reseda green :-) Plug with phase inverter

Technical details Manufacturer: HASCO (Germany) Model: A190 Machine number: 3338 Year: 1986 Type: Tool grinding / pin grinding machine Configuration: Lathe-type toolroom unit with dual spindle arrangement Spindle speeds: 2160 / 4450 rpm and 5400 / 11120 rpm Drive motor: - Voltage: 380 V - Power: Approx. 0.44 / 0.65 kW - Speed: 1400 / 2800 rpm Feed system: Manual carriage feed Clamping: Integrated clamping fixtures for pins and small parts Construction: Compact machine with integrated cabinet base Application: Grinding, polishing, and reconditioning of ejector pins and precision tooling components Condition: Used, typical workshop wear; functionality untested Dimensions and weight (approx.) Length: 900 mm Width: 600 mm Height: 1200 mm Weight: 150 kg Auction-ID: A7-46498-200

Center height 115 mm Tip distance 500 mm Clamping diameter 250 mm Largest / smallest distance clamping table surface to spindle center 370/70 mm Largest vertical distance between the centre of the grain and the centre of the spindle 255/45 mm Largest horizontal distance from the centre of the spindle to the centre of the grain / the edge of the clamping table 340/385 mm Longitudinal slide path / cross slide path 500/270 mm Perpendicular travel of the carriage beam 300 mm Swivel of the clamping table 90° Swivelling of the grinding head around the vertical axis 360° Tiltability of the grinding head to free angle below and above the center 15..0..15° Adjustability of the grinding head to twist angle right and left direction 60..0..60° Grinding spindle speeds 1100/2200 1/min Power of the drive motor / hydraulic motor 0.9 kW Net weight of the machine 780 kg

- Total installed power approx. 1.10 KW. - Disc diameter from 100 mm to 650 mm. - Disc shaft diameter from 6 mm. - Disc thickness up to 6 mm. - Tooth pitch from 7 mm to 100 mm. - Angle of attack up to -10°. - Clearance angle from 0°. - Diameter of the abrasive disc from 100 mm to 125 mm. - Peripheral speed up to 23 m/s. - Coolant pump flow rate 48 l/min. - Coolant tank capacity 48 l. - Operating conditions of this machine: unchecked. - Dimensions for transport approx. 1300 x 900 x 2050 mm. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-46513-32

4 - Stations Tool Grinding Machine Pre-grinding - disc 200 x 50 x 5 1mm - table size 400 x 200 mm Regrinding - disc 200 x 50 x 51 mm - table size 400 x 200 mm Lap Cut - Disc / Diamond 125 - 12.5 x 51 mm - Table Size 400 x 200 mm Chip guide - disc -150 x 8 x 51 mm Coolant Setup Task light Engine speed 1,400 / 2,800 rpm Electrical values 380 V / 0.37 / 0.6 KW Space requirement W - 1,100 x D - 1,000 x H - 1,400 mm Weight approx. 340 kg

Working range 2-13 mm, collets ER20/12, speed 5300 1/min, suitable for point angles 90-140°, dimensions 300x130x190 mm, incl. work table without contents Auction-ID: A1-46480-3011

Walter Helitronic CNC Tool Grinding Machine - Grinding machine Hersteller [manufacturer]: Walter Type [ type]: Helitronic Control unit: Heidenhain TNC 360C Incl. handwheel Baujahr[construction year]: 10/2002 Travel path: X= 1500mm Y=500mm Z=450mm Workbench: L = 1800mm W=500mm Spindle [spindle]: swivel +-90° Feed speed [feed speed]: 10-4000mm/min Spindle rotation speed: 30-3000 rpm Feed force [feed force]: 10,000-15000N Tool holder: SK 50 after DIN2080 Weight: 7.000kg Approx. (W x D x H): 3.0m x 2.25m x 2.85m Incl. various accessories according to photos Full documentation is available. Inspection under power can be done at short notice. We will be happy to answer any further questions you may have. Tel. +4917621834834 Price, from stock here plus VAT. Condition: good - ready for demonstration Delivery: from stock - as seen Payment: purely net -  ...

\"CNC tool grinding machineSAACKE UWIA-CNC – Sinumerik 810CNC universal tool grinding machine SAACKE type UWIA-CNC with Siemens Sinumerik 810 control including extensive accessory package, extraction system and cooling water treatment.The machine is suitable for grinding shape milling cutters, roller milling cutters, disc milling cutters, end mills, hobbing cutters, reamers, cutter heads, countersinks and taps up to Ø 200 mm.Age-appropriate optical condition. Functional. Viewing under power possible by appointment.>br Working area • Center height: 150 mm • Grinding length: 300 mm • Usable table area: 710 x 120 mm • Motorized table stroke: 300 mm • Table speed: 0.005 – 5 m/minaxes • Transverse stroke Z-axis: 200 mm • Height stroke Y-axis: 200 mm • Swivel vertically: 360° • Swivel horizontally: 210°Grinding spindle • Ø 60 mm • 4 speeds: 2100 / 3000 / 4200 / ...

Equipment: Precision Six-Jaw Chuck 1. Cylindrical grinding device Partial Setup Coolant system Instruction manual

Auction-ID: A1-46315-5

Sharpening machine for band saw blades Manafacture: Alber Sharpening machine for band saw blades Sharpening circuit Fabr. Alber Model: TB1 - AE2 Year of construction: 1978

Auction-ID: A7-46309-5

BN 102 C Producer Tos Swing 280 mm Distance between centres 630 mm Cross table adjustment 250 mm Longitudinal table adjustment 510 mm Vertical milling head adjustment 290 mm Machine weight 1000 kg

with accessories Auction-ID: A1-43429-89

Gate Sharper Manufacturer Vollmer for Inclined and straight ground

2 UNITS/SETS OF LON0016 PACKED TOGETHER. A SINGLE LON0016 CORRESPONDS TO: Benchtop machinery for sharpening multiple types of tools (turning tools, knives, boring tools, etc.). Work surface with single guide, 360° rotating motor, double-direction rotation wheel. Maximum workable diameter: 300 mm Stroke: 150 mm Working area approx.: 130 x 550 mm Grinding wheel size: Ø 125 x 50 x Ø 32 mm Speed: 2800 rpm Engine: 3/4 hp - 220/380 V Item size: 700 x 630 x 630 mm Item weight: 160-170kg Machine condition: unchecked. Approx. Transport dimension: LxWxH 660 x 660 x 760 mm; Approx. Weight: 170kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. TOTAL APPROX. DIMENSIONS OF THE LOT WITH 2x LON0016 PACKED TOGETHER: 660 x 1320 x h760 mm - 340 kg. PACKAGING WILL BE PERFORMED DEPENDING ON WEIGHT AND DIMENSION. Auctio ...

Machine engineered to sharpen circular blades made in carbide and steel. With accurate setting it can sharpen teeth automatically with adjustable speed. The motor can rotate in 2 directions so as to sharpen both angles of the blade. Sharpening diameters: from 60 to 300 mm, up to 45 teeth per minute. Power 550 W. Item dimensions 650 x 650 x 1050 mm. Item weight 103 kg. Machine condition: unchecked. Approx. Transport dimension: LxWxH 650 x 630 x 1130 mm; Approx. Weight: 103kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-250

HSK mount with accessories Auction-ID: A1-43429-88

Specialize in grinding screw tap. It's precise, easy operation and efficient, also can save large sum of expense for purchasing blade annually. With diamond wheel, can be secondary re-used, with accurate angle and long service life. The electrical controlled high-rate DC motor features stable power, strong horsepower, efficient and long service life. Patent product can grind all the front cutting face, also include the front cutting lip. M20 tap shank is within 14 for grinding. Point Angle:5°~30°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:CBN (for HSS), Standard collets:Φ5,Φ7,Φ8,Φ9,Φ13,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 360 x 270 x 310 mm; Approx. Weight: 16kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-313

electrically drivendrum volume: approx. 580 x 520 x 520 mm (estimated volume) drum with 8 sidesdistance from parallel sides to each other: approx. 560 mm Auction-ID: A7-46287-194

2 UNITS/SETS OF LON0020 PACKED TOGETHER. A SINGLE LON0020 CORRESPONDS TO: Machine engineered to sharpen circular blades made in carbide and steel. With accurate setting it can sharpen teeth automatically with adjustable speed. The motor can rotate in 2 directions so as to sharpen both angles of the blade. Sharpening diameters: from 60 to 300 mm, up to 45 teeth per minute. Power 550 W. Item dimensions 650 x 650 x 1050 mm. Item weight 103 kg. Machine condition: unchecked. Approx. Transport dimension: LxWxH 650 x 630 x 1130 mm; Approx. Weight: 103kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. TOTAL APPROX. DIMENSIONS OF THE LOT WITH 2x LON0020 PACKED TOGETHER: 650 x 1260 x h1130 mm - 206 kg. PACKAGING WILL BE PERFORMED DEPENDING ON WEIGHT AND DIMENSION. Auction-ID: A7-45991-336

2 UNITS/SETS OF LON0020 PACKED TOGETHER. A SINGLE LON0020 CORRESPONDS TO: Machine engineered to sharpen circular blades made in carbide and steel. With accurate setting it can sharpen teeth automatically with adjustable speed. The motor can rotate in 2 directions so as to sharpen both angles of the blade. Sharpening diameters: from 60 to 300 mm, up to 45 teeth per minute. Power 550 W. Item dimensions 650 x 650 x 1050 mm. Item weight 103 kg. Machine condition: unchecked. Approx. Transport dimension: LxWxH 650 x 630 x 1130 mm; Approx. Weight: 103kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. TOTAL APPROX. DIMENSIONS OF THE LOT WITH 2x LON0020 PACKED TOGETHER: 650 x 1260 x h1130 mm - 206 kg. PACKAGING WILL BE PERFORMED DEPENDING ON WEIGHT AND DIMENSION. Auction-ID: A7-45991-22

Portable end mill sharpener is accurate and rapid, easy operation with no skill to grind. Can grind 2-flute, 3-flute, 4-flute end mill. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. Standard with SDC grinding wheel for the Carbide material. Grinding Range:Φ4-Φ14, Point Angle:0°~5°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:SDC (for carbide material)×1, Six collets:Φ4,Φ6,Φ8,Φ10,Φ12,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 350 x 250 x 250 mm; Approx. Weight: 15kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-37

Portable end mill sharpener is accurate and rapid, easy operation with no skill to grind. Can grind 2-flute, 3-flute, 4-flute end mill. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. Standard with SDC grinding wheel for the Carbide material. Grinding Range:Φ4-Φ14, Point Angle:0°~5°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:SDC (for carbide material)×1, Six collets:Φ4,Φ6,Φ8,Φ10,Φ12,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 350 x 250 x 250 mm; Approx. Weight: 15kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-101

Grinding is accurate and rapid, easy operation with no skill to grind. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life. Bearing shaft and locking unit. The machine is set up with the function of adjusting a point (central point) size, which can effectively coordinate with the material of drill hole and the rotation speed. It can control the quality precision and prolong the service life of the drill bit. Standard with CBN grinding wheel for the HSS material, Optional SDC grinding wheel for the carbide material. Grinding Range:Φ3-Φ13, Point Angle:100°~135°, Power:AC220V, Motor:120W, Speed:4400rpm, Dimension:32x18x19 cm, Weight:9kg, Standard Equipment:Grinding wheel:CBN (for HSS)×1, Eleven collets:Φ3,Φ4,Φ5,Φ6,Φ7,Φ8,� ...

Specialize in grinding screw tap. It's precise, easy operation and efficient, also can save large sum of expense for purchasing blade annually. With diamond wheel, can be secondary re-used, with accurate angle and long service life. The electrical controlled high-rate DC motor features stable power, strong horsepower, efficient and long service life. Patent product can grind all the front cutting face, also include the front cutting lip. M20 tap shank is within 14 for grinding. Point Angle:5°~30°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:CBN (for HSS), Standard collets:Φ5,Φ7,Φ8,Φ9,Φ13,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 360 x 270 x 310 mm; Approx. Weight: 16kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-132

3 UNITS/SETS OF LON0008 PACKED TOGETHER. A SINGLE LON0008 CORRESPONDS TO: Specialize in grinding screw tap. It's precise, easy operation and efficient, also can save large sum of expense for purchasing blade annually. With diamond wheel, can be secondary re-used, with accurate angle and long service life. The electrical controlled high-rate DC motor features stable power, strong horsepower, efficient and long service life. Patent product can grind all the front cutting face, also include the front cutting lip. M20 tap shank is within 14 for grinding. Point Angle:5°~30°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:CBN (for HSS), Standard collets:Φ5,Φ7,Φ8,Φ9,Φ13,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 360 x 270 x 310 mm; Approx. Weight: 16kg The item for sale may not be the one shown in pictures, but will have equal spe ...

2 UNITS/SETS OF LON0016 PACKED TOGETHER. A SINGLE LON0016 CORRESPONDS TO: Benchtop machinery for sharpening multiple types of tools (turning tools, knives, boring tools, etc.). Work surface with single guide, 360° rotating motor, double-direction rotation wheel. Maximum workable diameter: 300 mm Stroke: 150 mm Working area approx.: 130 x 550 mm Grinding wheel size: Ø 125 x 50 x Ø 32 mm Speed: 2800 rpm Engine: 3/4 hp - 220/380 V Item size: 700 x 630 x 630 mm Item weight: 160-170kg Machine condition: unchecked. Approx. Transport dimension: LxWxH 660 x 660 x 760 mm; Approx. Weight: 170kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. TOTAL APPROX. DIMENSIONS OF THE LOT WITH 2x LON0016 PACKED TOGETHER: 660 x 1320 x h760 mm - 340 kg. PACKAGING WILL BE PERFORMED DEPENDING ON WEIGHT AND DIMENSION. Auctio ...

Machine engineered to sharpen circular blades made in carbide and steel. With accurate setting it can sharpen teeth automatically with adjustable speed. The motor can rotate in 2 directions so as to sharpen both angles of the blade. Sharpening diameters: from 60 to 300 mm, up to 45 teeth per minute. Power 550 W. Item dimensions 650 x 650 x 1050 mm. Item weight 103 kg. Machine condition: unchecked. Approx. Transport dimension: LxWxH 650 x 630 x 1130 mm; Approx. Weight: 103kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-350

Benchtop machinery for sharpening multiple types of tools (turning tools, knives, boring tools, etc.). Work surface with single guide, 360° rotating motor, double-direction rotation wheel. Maximum workable diameter: 300 mm Stroke: 150 mm Working area approx.: 130 x 550 mm Grinding wheel size: Ø 125 x 50 x Ø 32 mm Speed: 2800 rpm Engine: 3/4 hp - 220/380 V Item size: 700 x 630 x 630 mm Item weight: 160-170kg Machine condition: unchecked. Approx. Transport dimension: LxWxH 660 x 660 x 760 mm; Approx. Weight: 170kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-134

Grinding is accurate and rapid, easy operation with no skill to grind. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life. Bearing shaft and locking unit. The machine is set up with the function of adjusting a point (central point) size, which can effectively coordinate with the material of drill hole and the rotation speed. It can control the quality precision and prolong the service life of the drill bit. Standard with CBN grinding wheel for the HSS material, Optional SDC grinding wheel for the carbide material. Grinding Range:Φ3-Φ13, Point Angle:100°~135°, Power:AC220V, Motor:120W, Speed:4400rpm, Dimension:32x18x19 cm, Weight:9kg, Standard Equipment:Grinding wheel:CBN (for HSS)×1, Eleven collets:Φ3,Φ4,Φ5,Φ6,Φ7,Φ8,� ...

Portable end mill sharpener is accurate and rapid, easy operation with no skill to grind. Can grind 2-flute, 3-flute, 4-flute end mill. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. Standard with SDC grinding wheel for the Carbide material. Grinding Range:Φ4-Φ14, Point Angle:0°~5°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:SDC (for carbide material)×1, Six collets:Φ4,Φ6,Φ8,Φ10,Φ12,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 350 x 250 x 250 mm; Approx. Weight: 15kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-273

With accessories Auction-ID: A1-43429-90

3 UNITS/SETS OF LON0008 PACKED TOGETHER. A SINGLE LON0008 CORRESPONDS TO: Specialize in grinding screw tap. It's precise, easy operation and efficient, also can save large sum of expense for purchasing blade annually. With diamond wheel, can be secondary re-used, with accurate angle and long service life. The electrical controlled high-rate DC motor features stable power, strong horsepower, efficient and long service life. Patent product can grind all the front cutting face, also include the front cutting lip. M20 tap shank is within 14 for grinding. Point Angle:5°~30°, Power:220V, Motor:160W, Speed:4400rpm, Standard Equipment:Grinding wheel:CBN (for HSS), Standard collets:Φ5,Φ7,Φ8,Φ9,Φ13,Φ14 Machine condition: unchecked. Approx. Transport dimension: LxWxH 360 x 270 x 310 mm; Approx. Weight: 16kg The item for sale may not be the one shown in pictures, but will have equal spe ...

Machine engineered to sharpen circular blades made in carbide and steel. With accurate setting it can sharpen teeth automatically with adjustable speed. The motor can rotate in 2 directions so as to sharpen both angles of the blade. Sharpening diameters: from 60 to 300 mm, up to 45 teeth per minute. Power 550 W. Item dimensions 650 x 650 x 1050 mm. Item weight 103 kg. Machine condition: unchecked. Approx. Transport dimension: LxWxH 650 x 630 x 1130 mm; Approx. Weight: 103kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-290

2 UNITS/SETS OF LON0020 PACKED TOGETHER. A SINGLE LON0020 CORRESPONDS TO: Machine engineered to sharpen circular blades made in carbide and steel. With accurate setting it can sharpen teeth automatically with adjustable speed. The motor can rotate in 2 directions so as to sharpen both angles of the blade. Sharpening diameters: from 60 to 300 mm, up to 45 teeth per minute. Power 550 W. Item dimensions 650 x 650 x 1050 mm. Item weight 103 kg. Machine condition: unchecked. Approx. Transport dimension: LxWxH 650 x 630 x 1130 mm; Approx. Weight: 103kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. TOTAL APPROX. DIMENSIONS OF THE LOT WITH 2x LON0020 PACKED TOGETHER: 650 x 1260 x h1130 mm - 206 kg. PACKAGING WILL BE PERFORMED DEPENDING ON WEIGHT AND DIMENSION. Auction-ID: A7-45991-276

Working range 5-80 mm for tip grinding, tip angle infinitely adjustable from 50-180 °, tool speed 8-23 1/min, diameter of pointed disc 100 mm, speed of sharpening disc 2800 1/min, diameter of tip grinding wheel 300 mm, speed of tip grinding wheel 1420 1/min, grinding feed infinitely variable from 0.4-4 mm/min Auction-ID: A1-46480-3009

centre height: 140 mmtable-size: 610 x 100 mmgrinding length: 250 mmgrinding head - revolution: 360 °weight of the machine ca.: 0.47 tdimensions of the machine ca.: 0.9 x 0.95 x 1.4 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

hydraulic: . centre height: 130 mmtable-size: 900 x 200 mmgrinding length: 400 mmgrinding head - revolution: 360 °weight of the machine ca.: 1.4 tdimensions of the machine ca.: 1.6 x 1.8 x 1.8 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Benchtop machinery for sharpening multiple types of tools (turning tools, knives, boring tools, etc.). Work surface with single guide, 360° rotating motor, double-direction rotation wheel. Maximum workable diameter: 300 mm Stroke: 150 mm Working area approx.: 130 x 550 mm Grinding wheel size: Ø 125 x 50 x Ø 32 mm Speed: 2800 rpm Engine: 3/4 hp - 220/380 V Item size: 700 x 630 x 630 mm Item weight: 160-170kg Machine condition: unchecked. Approx. Transport dimension: LxWxH 660 x 660 x 760 mm; Approx. Weight: 170kg The item for sale may not be the one shown in pictures, but will have equal specifications and performance. Auction-ID: A7-45991-322

Suitable for automatic grinding of all types of tools. Accessories: Total enclosure, Knoll E53319 bandfilter system, Numrotoplus software, Numroto software for simple milling cutters and cords,, Numroto software for simple and complex drills, Pallet loader, CNC handwheel, Control cabinet cooler,, automatic tailstock, automatic central lubrication, Glass scales on the X, Y, Z linear axes, Measuring probe, Hydraulic workpiece clamping, Oil collection tray, 2 loading pallets,, 1 grinding wheel holder., X axis travel: 800 mm, Y axis travel: 270 mm, Z-axis travel: 660 mm, B axis travel: 400 °, Rapid traverse: 30/15/30 m/min, Workpiece mount: ISO 50, Tool holder cone: ISO 50, Grinding spindle drive power: 12 kW, Grinding spindle speed stepless: max. 9000 rpm,, Grinding wheel diameter: max 203mm, Connected load approx.: (400V/50Hz), Dimensions L x W x H: 1900 x 2300 x 2300 mm, Weight approx: 5 ...

dia. of draw-in collets: - mminternal taper of cone draw-in collets: - max. radius to grind: - mmtotal power requirement: - kWweight of the machine ca.: - tdimensions of the machine ca.: - mStichelschleifmaschineThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. grinding diameter: 200 mmgrinding length: 450 mmworkpiece length: / mmworkpiece height: 220 mmtotal power requirement: 1,14 kWweight of the machine ca.: 1,5 tdimensions of the machine ca.: 1,7 x 1,6 x 1,6 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 700 mmy-axis: 410 mmz-axis: 500 mmfeed range: 30000 mm/minA-Axis: 175 mmC-axis: 320 °workpiece dia.: 340-500 mmworkpiece length: 700-1000 mmworkpiece weight max.: kgmax. dia. of grinding wheel: mmspeed spindle max.: 8000 U/min.power capacity: 11,5 / 14,5 kWControl: Siemens 840 Dsl tool taper: HSK 50E table-size: 1200 x 500 mmtotal power requirement: - kVAweight of the machine ca.: 8,5 tdimensions of the machine ca.: 3 x 2,6 x 3,55 m5 AXIS CNC TOOL AND CUTTER GRINDER- CNC Control Siemens 840Dsl- Milling Unit– Tooling- high-pressure coolant system- Tool ChangerThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
