Mechanical Presses used for sale (30)

NIDEC ARISA S-2-500-240-120-FD mechanical press was built in 2006 in Spain by Nidec Press & Automation Co. (NP&A). It is an extremely versatile press that is used in the series production of components for the broadly defined automotive or machinery industry. It enables even the most demanding metal forming operations, i.e. precise punching and stamping of metal parts. In addition to its standard purpose, with the appropriate tooling and material feeding systems, the machine can also be used as a transfer press or progressive press. All processes are performed with a high press force of 500 tonnes. The drive system of the NIDEC ARISA S-2-500-240-120-FD press is based on a flywheel and an eccentric gear, cooperating with two connecting rods. This solution guarantees even torque transmission and a smooth working cycle. The slider, on the other hand, is guided in multiple points by rolle ...

Rapid Toggle Press Auction-ID: A7-45416-82

ARISA S-2-630-240-120-LD mechanical press was built in 2005 in Spain by Arisa S.A. (now Nidec Press & Automation Co. (NP&A)). The machine on offer is an excellent choice for series production of components used in the broadly defined automotive or machinery industry. It enables even the most demanding metal forming operations, such as precise punching and stamping of metal parts. In addition to its standard purpose, depending on the tooling and material feed systems used, the machine can also be used as a transfer press or progressive press. All machining processes are performed with a high press force of 630 tonnes. The drive system, in the form of a flywheel and an eccentric gear, cooperating with two connecting rods, ensures even torque transmission and smooth control of the slider movement. The slider, on the other hand, is guided at eight points using roller guides, which increas ...

• Pneumatic press • Table dimensions 125 x 125 mm • Actuating by pedal • Operating conditions of this machine: unchecked. • Transport dimensions approx. 1200 x 800 x 600 mm. • This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A7-44536-118

ARISA S-2-400-260-FD mechanical press was built in 2000 in Spain by Arisa S.A. (now Nidec Press & Automation Co. (NP&A)). The machine on offer is an excellent choice for series production of components used in the broadly defined automotive or machinery industry. It enables precise punching and stamping of metal parts. All these machining processes are performed with a high press force of up to 400 tonnes, which, combined with a highly dynamic slider, guarantees the best machining results. The ARISA S-2-400-260-FD features a robust, stress-relieved gantry design with an open side wall. This design maintains high rigidity, stable parameters and repeatability during even the most intensive operations with high press force. It is distinguished by the use of two connecting rods, a flywheel drive and an eccentric pinion gear. This solution ensures even torque transmission and smooth and pr ...

Model No.: KFLU 008.002 Type: Toggle Press (Manual) Press force: approx. 8 kN Stroke: 0–220 mm (adjustable) Table size: approx. 130 × 110 mm Special features: High force at the bottom dead center Fine adjustment of the offset possible Robust steel construction Ergonomic hand lever Application: Assembly, Crimping, Stamping, Embossing, Small Batch Production Weight incl. packaging approx. 50kg Auction-ID: A1-45208-18

Ajax 1,000 Ton Straight Side Mechanical Forging Press S/N 4410 10” Stroke 33” Shut Height 36” x 36” Bed 80 Strokes Per Minute Partially Rebuilt Ajax 1,000 Ton Straight Side Mechanical Forging Press S/N 4621 10” Stroke 32” Shut Height 36” x 32” Bed 80 Strokes Per Minute Bolsters are included. Both presses are in working condition and under power.

machine ready for transport and to be assessed on viewing day Auction-ID: A1-44905-65

Nominal Power: 400 ton Stroke par minute: 16-48 Adjustable stroke: 10-250 mm Table dimension: 1200 x 1200 mm Ram dimension: 1200 x 1200 mm Distance table – slide: 1000 mm Adjustment slide : 200 mm Motovariator: 22-66 HP

machine ready for transport and to be assessed on viewing day. Machine has recently been repaired, see photos Auction-ID: A1-44905-64

Qty. 1 Second-hand press for production of Aluminium pots and discs Mfc.: SITI Built: 2005 Renewed in by experts Duration: 3-4 months Force: 4000 Ton Production of Aluminium discs & induction & normal pots Pots height: 120 / 140 mm The press will be overhauled and revamped and sold as specified below: New Piston Grinding of cylinder New Flange Table modification New pumps New gaskets etc . New electric and electronical parts New program

As good as new machine Operating hours in motion: 29.5 Hour meter: 2244 Strokes: 159328 incl. interchangeable decoiling device, strip straightener and Scrap ejection. Mains voltage: 3LNPE/400V/50Hz Control: Beckhoff/PNOZ multi Electrical wiring diagram: E$-M02070 Pre-fuse: 160 A Nominal power: 37 KW Nominal force: 2000 KN Working capacity: 16000 J Stroke rate in continuous stroke: 30-150 min-1 Max. stroke rate in single stroke: 30 min-1 Max. clutch cycles in single stroke: 20 per min Runtime: 0.158 s Min. safety distance: 317 mm Clutch pressure: 5.0 bar System pressure: 6.0 bar Stroke length: 20-220 mm Max. plunger adjustment: 150 mm Usual stopping point of the ram: OU Table dimensions: 1800x1100 Plunger dimension, max. tool dimension (WxD): 1800x1100 mm Max. weight tool top: 1700 kg Mass without additional equipment: 29000 kg Auction-ID: A7-44908-1

Auction-ID: A7-44908-4

Toggle hand presses >br>HK 1700 stroke 60 mm with crank with working height fine adjustment>br>height of the stand 450 mm>br>Even more pressure in production without additional effort.>br>Maximum pressure output shortly before the end of the stroke thanks to knee lever technology.>br>Particularly stable construction of spindle head and stand>br>pressure 17.0 kN>br>stroke 60 mm>br>projection 105 mm>br>working height from up to 75 -180 mm>br>table surface 170 x 130 mm>br>spindle diameter 25 mm>br>machine weight approx. 35 Kg>br>Dimensions L x W x H 260 x 130 x415 mm >br>condition: never used / new (5) Auction-ID: A7-44817-154

Toggle press>br>• Working height adjustable by simply loosening the clamping screws on the stand>br>• Fine working height adjustment with HK 800 = millimetre-precise adjustment of the >br> press head to the desired working height. Fine adjustment is >br> forcibly arranged in both directions via a threaded spindle>br>• Hand lever arranged in a user-friendly manner, return via spring>br>pressure 8.0 kN>br>stroke 40 mm>br>projection 90 mm>br>Working height of up to 50 - 200 mm>br>Table surface 120 x 160 mm>br>Machine weight approx. 22 Kg>br>Dimensions L x W x H 160 x 230 x 410 mm >br>Condition: never used / new (5) Auction-ID: A7-44817-187

Model No.: KFLU 008.002 Type: Toggle Press (Manual) Press force: approx. 8 kN Stroke: 0–220 mm (adjustable) Table size: approx. 130 × 110 mm Special features: High force at the bottom dead center Fine adjustment of the offset possible Robust steel construction Ergonomic hand lever Application: Assembly, Crimping, Stamping, Embossing, Small Batch Production Weight incl. packaging approx. 50kg Auction-ID: A1-45208-80

The Dorst TPA 70S is a used powder compaction press, known for its precise and reliable performance. It delivers a maximum pressing force of 700 kN with a withdrawal force of 400 kN, making it suitable for diverse compaction needs. The machine features a pressing travel of up to 30 mm, with a maximum filling height of 70 mm and operates at speeds between 14 to 40 strokes per minute. This ensures efficient throughput, ideal for high-demand production environments. With an upper punch stroke of 120 mm and adjustable travel of 200 mm, the Dorst TPA 70S offers flexibility in application. It requires a compressed air supply with an intake of approximately 200 liters per minute, and operates on a total connected load of about 20 kW. To enhance functionality, the machine is constructed robustly, maintaining a workplace-related sound level of 78 dB(A), and features a press housing capacity of 19 ...

The Dorst TPA 20/3 is a reliable used powder compaction press known for its robust construction and precise operations. It offers a maximum pressing force of 200 kN and a withdrawal force of up to 100 kN. With a maximum filling height of 140 mm and pressing travel extending to 70 mm, it accommodates a range of powder compaction tasks efficiently. The press is capable of operating at speeds ranging from 5 to 22 strokes per minute, supporting a variety of production needs. It features an upper punch stroke of 200 mm, with an adjustable travel of 160 mm for flexibility across different applications. The machines air supply intake is approximately 160 liters per minute, and it has a connected load of about 15 kW. Constructed with dimensions of around 2000 mm in width, 1700 mm in depth, and 3250 mm in height, the Dorst TPA 20/3 weighs approximately 4,900 kg. It maintains a workplace sound lev ...

CONTROLS  electronic controls SIEMENS S7 300 PRESS DESIGN  drive system: eccentric / crank   openings in uprights: yes   number of suspensions: 2   table cushion: no   quick die change system: yes PRESS FORCES  total force (nominal): 250 toPRESS TABLE  table surface (left-right): 2000 mm  table surface (front-back): 1100 mm  height above floor level: 1105 mm  opening in bed (left-right): 1700 mm  opening in bed (front-back): 305 mmSLIDE  table surface (left-right): 2080 mm  table surface (front-back): 1000 mm  stroke rate (max.): 120 /minSLIDE (MECHAN. PRESS)  slide adjustment: 120 mm  stroke adjustment: yes   stroke min.: 20 mm  stroke max.: 180 mmTOOL ASSEMBLY DIMENSIONS  shut height (str ...

The Dorst TPA 15/3 is a used mechanical powder compaction press designed for precision and efficiency in industrial applications. It provides a maximum pressing force of 150 kN and a withdrawal force of 100 kN, supporting a variety of compaction tasks. With an upper punch stroke of 100 mm and a range of 70 mm for adjusting the travel, this machine offers flexibility for different requirements. Operating at speeds of 7 to 32 strokes per minute, it ensures a reliable production throughput. This press allows for a maximum filling height of 70 mm and pressing travel up to 35 mm, suitable for a range of powder compaction needs. The machine is fitted with a compressed air system that has an intake of around 70 liters per minute and a total connected load of approximately 6 kW. It is compact yet robust, with dimensions of about 1400 mm in width, 1300 mm in depth, and 2650 mm in height, weighing ...

The Dorst TPA 6 is a used mechanical powder compaction press suitable for various industrial applications due to its robust performance and flexibility. It boasts a maximum pressing force of 60 kN and a withdrawal force of 30 kN, addressing a wide range of compaction needs. The machine supports a maximum filling height of 70 mm and a pressing travel of 30 mm, with an upper punch stroke of 95 mm and an adjustable travel of 50 mm. This ensures precise control over the compaction process. Operating at speeds between 7 to 32 strokes per minute, the Dorst TPA 6 consumes approximately 70 liters of compressed air per minute and has a total connected load of about 3.5 kW. It measures 2220 mm in width, 1060 mm in depth, and 2250 mm in height, weighing around 1,200 kg. With a gear oil capacity of 12 liters and a workplace-related sound level of 75 dB(A), it is designed to endure continuous use whi ...

The Dorst TPA 50/4 is a reliable, used mechanical powder compaction press designed for precision and efficiency. Offering a robust maximum pressing force of 500 kN and a maximum withdrawal force of 400 kN, it supports a variety of powder compaction tasks. With a filling height up to 180 mm and a pressing stroke of up to 90 mm, this machine is adaptable to diverse requirements. Equipped with an upper punch stroke of 120 mm and an adjustable travel of 220 mm, the Dorst TPA 50/4 provides flexibility for different applications. It operates at a speed of 7 to 32 strokes per minute, ensuring efficient production. The press requires a compressed air supply, consuming approximately 200 liters per minute, with a total connected load of around 18 kW. Constructed with durability in mind, the press measures approximately 2000 mm in width, 1700 mm in depth, and 3250 mm in height, and weighs around 5, ...

The Dorst TPA 50/2 is a used mechanical powder compaction press engineered for precision and efficiency, making it suitable for demanding industry applications. With a maximum pressing force of 500 kN and a maximum withdrawal force of 400 kN, this machine is robust and reliable. This model press allows you a maximum filling height of 180 mm and a pressing travel of up to 90 mm. Designed for versatility, it features an upper punch stroke of 120 mm and an adjustable travel of 220 mm, operating at speeds ranging from 7 to 32 strokes per minute. It requires a compressed air supply with an intake of approximately 200 liters per minute and has a total connected load of around 18 kW. The construction is sturdy and occupies a footprint with dimensions of approximately 2000 mm in width, 1700 mm in depth, and 3250 mm in height, weighing approximately 5,500 kg. The press operates at a workplace-rel ...

The Dorst TPA 5 is a refurbished mechanical powder compaction press, designed for precision and efficiency in industrial applications. It offers powerful performance with a maximum pressing force of 50 kN and a withdrawal force of up to 40 kN. This makes it suitable for a variety of powder compaction tasks, with a filling height of 50 mm and pressing travel capability of 25 mm. This machine provides flexibility with an upper punch stroke of 85 mm and an adjustable travel span of 70 mm, operating at 6 to 30 strokes per minute. It consumes around 50 liters of compressed air per minute and has a total electrical load of approximately 4.00 kW. With durable construction, the Dorst TPA 5 maintains a quiet operation at a sound level of 70 dB(A). The presss compact dimensions, approximately 1200 mm in both width and depth and a height of 2150 mm, with a weight of about 1,200 kg, make it a manage ...

CONTROLS  PLC SIEMENS S7 PRESS DESIGN  drive system: knuckle-joint   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   feedstock transport direction: left to right PRESS FORCES  total force (nominal): 315 to  nominal work capacity: 38 kNmPRESS TABLE  table surface (left-right): 2000 mm  table surface (front-back): 1200 mm  thickness of bolster plate: 200 mmSLIDE  slide force: 315 to  table surface (left-right): 1995 mm  table surface (front-back): 1100 mm  stroke: 160 mm  stroke rate (max.): 80 /minSLIDE (MECHAN. PRESS)  slide adjustment: 140 mm  stroke rate (min.): 20 /min  stroke rate (max.): 80 /min  main drive power: 90 kWTOOL ASSEMBLY DIMENSIONS& ...

The Dorst DK 250 is a robust used powder compaction press engineered by DORST, offering a substantial pressing force of up to 2500 kN. It supports operations with a maximum withdrawal force of 150 kN and a supporting force in the pressing position reaching 120 kN. Designed for precision, this model includes a 220 mm upper punch stroke with an adjustable travel of 120 mm. The press accommodates a pressing travel and withdrawal travel, each up to 50 mm, making it versatile for various pressing tasks. Operational performance ranges from 6 to 25 strokes per minute, and it provides a filling height of up to 100 mm. The Dorst DK 250 is efficient, consuming approximately 500 liters of air per minute and demanding a connected load of around 60.0 kW. Its dimensions, at 2500 mm in width, 1900 mm in depth, and 4800 mm in height, alongside a weight of approximately 18,500 kg, underscore its solid co ...

Pressing Force max.: 2000 Kn, Withdrawal force max.: 1500 Kn, Supporting force in pressing position max.: 1200 Kn, Die return force max.: 50 Kn, Upper punch stroke: 220 mm, Upper punch adjusting travel: 200 mm, Number of strokes: 5-18 1/min, Filling height max.: 180 mm, Pressing travel max.: 90 mm, Withdrawal travel max.: 90 mm, Top pressing travel max: 18 mm, Upper punch pneumatic preload max.: 60 mm, Compressed air supply , Air consumption, Intake air aprox.: 140 1/min, Total connected load aprox.: 26,0 Kw, Width aprox.: 2350 mm, Depth aprox.: 3500 mm, Height aprox.: 5900 mm, Weight of the press aprox.: 19.900 Kg, Press housing: 260 l (gear oil), Workplace-related sound: 78 dB (A)

Mechanical Dorst TPA 45, Pressing Force max. 450 Kn, Withdrawal force max. 250 Kn, Supporting force in pressing position max. 130 Kn, Die return force max. 60 Kn, Upper punch stroke 120 mm, Upper punch adjusting travel 70 mm, Number of strokes 6-22 1/min, Filling height max. 120 mm, Pressing travel max. 60 mm, Withdrawal travel max. 60 mm, Top pressing travel max 6 mm, Upper punch pneumatic preload max. 30 mm, Compressed air supply , Air consumption , Intake air aprox. 70 l/min, Total connected load aprox. 14,0 Kw, Press dimensions:, Width aprox. 1550 mm, Depth aprox. 1650 mm, Height aprox. 2200 mm, Weight of the press aprox. 3900 Kg, Oil filling quantity :, Press housing 45 l (gear oil), Workplace-related sound 79 dB (A)

Pressing Force max.: 1000 Kn, Withdrawal force max.: 800 Kn, Supporting force in pressing position max.: 600 Kn, Die return force max.: 40 Kn, Upper punch stroke: 220 mm, Upper punch adjusting travel: 200 mm, Number of strokes: 5-18 1/min, Filling height max.: 180 mm, Pressing travel max.: 85 mm, Withdrawal travel max.: 95 mm, Top pressing travel max: 18 mm, Upper punch pneumatic preload max.: 80 mm, Compressed air supply , Air consumption, Intake air aprox.: 140 1/min, Total connected load aprox.: 23,0 Kw, Width aprox.: 1950 mm, Depth aprox.: 1550 mm, Height aprox.: 3900 mm, Weight of the press aprox.: 9.900 Kg, Press housing: 180 l (gear oil), Workplace-related sound: 78 dB (A)

Pressing Force max: 1400 Kn, Withdrawal force max: 1100 Kn, Die return force max: 70 Kn, Upper punch stroke: 220 mm, Upper punch adjusting travel: 220 mm, Number of strokes: 5-18 1/min, Filling height max: 180 mm, Pressing travel max: 90 mm, Withdrawal travel max: 90 mm, Top pressing travel max: 18 mm, Total connected load aprox: 25,0 Kw, Width aprox: 1950 mm, Depth aprox: 1750 mm, ISO 9001: 2008 CERTIFIED COMPANY, Height aprox: 4380 mm, Press housing: 240 l (gear oil), Workplace-related sound: 78 dB A
