Tape Straightening Machines used for sale (15)

Sheet width - max.: 200 mm Straightening roller diameter: 40 mm Number of leveling rollers: 5 Driven infeed and outfeed rollers Sheet thickness - min: 0.4 mm Sheet thickness - max.: 2.0 mm Weight: 170 Infinitely variable feed speed Clockwise and counterclockwise rotation Operating mode selector switch for manual and automatic operation Belt loop control very good condition

CONTROLS  electronic controls OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 300 mm  sheet thickness max.: 4 mmDECOILER  coil weight max.: 1.25 toLEVELLER UNIT  sheet width max.: 300 mm  sheet thickness max.: 4 mm  sheet thickness min.: 0.3 mm  material cross section max. (450 N/mm2): 350 mm²  number of leveller rolls: 11   diameter of leveller rolls: 60 mm  drive power: 2.7 kW  loop controls: yes ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2200 mm  space requirements -front/back-: 1000 mm  total height: 1700 mm  total weight approx.: 1250 kgEquipment:- SOP unwinder- SOP belt controlPneumatic infeed rollers Ø 80 ...

Belt width 350 mm Number of straightening rollers - 11 pcs Diameter 60 mm Capacity 350 x 2.5 mm Motor 4 kW Speed adjustable by variator drive

material width: 650 mmcoil weight: 15 tmaterial thickness: 16 mmThe year of construction is estimated, the system is as good as newThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

5 rollers straightening machine, Diameter of leveling rollers 40 mm, Belt passage 350 mm, a D80 mm feed roller with pneumatic pressure, Infeed roller basket Control cabinet, Connection cable with CEE connector 16A.

CONTROLS   SIEMENS S5 DECOILER  sheet width max.: 370 mm  sheet width (min): 80 mmLEVELLER UNIT  sheet thickness max.: 2.5 mm  sheet thickness min.: 1 mmELECTRICAL SPECIFICATIONS  mains frequency: 50 Hz

Bandwidth of 50-500 mm Band thickness 0.8 3.6 mm Belt speed 5-40 m / min Feed rollers 2 PCs Richwalzen (80 mm) - 11 PCs Working direction optional

CONTROLS  electronic controls OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 200 mm  sheet thickness max.: 4.5 mm  coil weight max.: 0.5 toDECOILER  coil weight max.: 0.5 to  mandrel expansion range from: 250 mm  mandrel expansion range up to: 550 mmLEVELLER UNIT  sheet width max.: 300 mm  sheet width (min): 20 mm  sheet thickness max.: 4 mm  sheet thickness min.: 0.5 mm  material cross section max. (450 N/mm2): 800 mm²  number of leveller rolls: 7   diameter of leveller rolls: 65 mm  number of infeed-/outfeed rolls: 4   diameter of feed rolls: 65 mm  drive power: 1.5 kW  loop controls: yes ELECTRICAL SPECIFICATIONS  mains voltage: 380 V  mains frequency: 50 Hz

material width: 0400 mmcoil weight: 1,50 tmaterial thickness: mmnomb. of straightening rolls: 9 diam. of the rolls ca.: 30 mmrange of expansion ca.: 460 - 530 mmcoil outside - diam. ca.: 1500 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CONTROLS  PLC SIEMENS S7 OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 260 mm  sheet thickness max.: 6.5 mm  coil weight max.: 3 to  feed velocity max.: 20 m/min  feedstock transport direction: right to left COIL CHAIR  coil weight max.: 3 toDECOILER  design: single reel, traversable   sheet width max.: 260 mm  coil weight max.: 3 to  mandrel expansion range from: 460 mm  mandrel expansion range up to: 530 mmLEVELLER UNIT  sheet thickness max.: 6.5 mm  material cross section max. (450 N/mm2): 1500 mm²  number of leveller rolls: 21   diameter of leveller rolls: 50 mm  loop controls: yes decoiler KOHLER, type 3000.1 with coil-chairstraightening machine KOHLER, type KRM 50.260/2transfer bridge 6970 mm, hydrau ...

OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 500 mm  sheet thickness max.: 16 mm  coil weight max.: 8 to  feedstock transport direction: left to right COIL CHAIR  coil weight max.: 8 toDECOILER  max. diameter of coil: 1800 mm  mandrel expansion range from: 470 mm  mandrel expansion range up to: 530 mmCROP SHEAR  cutting force: 800 kNLEVELLER UNIT  sheet width max.: 800 mm  sheet width (min): 80 mm  sheet thickness max.: 16 mm  sheet thickness min.: 1.5 mm  material cross section max. (450 N/mm2): 3510 mm²  number of leveller rolls: 17

CONTROLS  PLC SIEMENS S5 115U OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 140 mm  sheet thickness max.: 6 mm  coil weight max.: 3 toCOIL CHAIR  coil weight max.: 3 to  stroke: 500 mmDECOILER  design: single reel   sheet width max.: 300 mm  coil weight max.: 3 to  max. diameter of coil: 1300 mm  mandrel expansion range from: 360 mm  mandrel expansion range up to: 430 mmLEVELLER UNIT  sheet width max.: 140 mm  sheet thickness max.: 6 mm  sheet thickness min.: 3 mm  number of leveller rolls: 21   diameter of leveller rolls: 50 mm  feed velocity max.: 43 m/minELECTRICAL SPECIFICATIONS  total power consumption: 35 kWKOHLER coil line consisting of:- Coil loading chair CS3000- Decoiler 300.1 H- V ...

CONTROLS  PLC OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 500 mm  sheet thickness max.: 4 mm  coil weight max.: 10.5 to  feedstock transport direction: right to left COIL CHAIR  coil weight max.: 10.5 to  stroke: 750 mmDECOILER  design: single reel   sheet width max.: 500 mm  sheet width (min): 150 mm  coil weight max.: 10.5 to  max. diameter of coil: 2020 mm  mandrel expansion range from: 470 mm  mandrel expansion range up to: 530 mm  feed velocity max.: 20 m/minCROP SHEAR  sheet thickness max.: 4 mm  working width max.: 530 mm  stroke rate (max.): 20 /minLEVELLER UNIT  sheet width max.: 500 mm  sheet width (min): 150 mm  sheet thickness max.: 4 mm  sheet thic ...

CONTROLS  PLC SIEMENS S5 115 U OVERALL SPECIFICATIONS (COIL LINES)  sheet width max.: 350 mm  sheet thickness max.: 8 mm  coil weight max.: 4 to  feed velocity max.: 10 m/min  feedstock transport direction: left to right DECOILER  design: single reel   sheet width max.: 350 mm  coil weight max.: 4 to  max. diameter of coil: 1500 mm  mandrel expansion range from: 370 mm  mandrel expansion range up to: 530 mm  feed velocity max.: 10 m/minLEVELLER UNIT  sheet width max.: 350 mm  sheet thickness max.: 8 mm  number of leveller rolls: 21   diameter of leveller rolls: 50 mm  number of infeed-/outfeed rolls: 2   diameter of feed rolls: 120 mm  feed velocity max.: 10 m/minELECTRICAL SPECIFICATIONS& ...

material width: 350 mmcoil weight: 2x 1 tmaterial thickness: 3 mmcoil internal dia.: 480-530 mmcoil outside dia.: 1400 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
