grinding machines used for sale (2,496)

ANCA RX-7 CNC TOOL & CUTTER GRINDER Manufacturer: ANCA Model: RX-7 Year: 2011 The RX-7 is a high-precision CNC grinding machine designed for production and regrinding of cutting tools and precision tooling. The machine features a rigid ANCAcrete polymer-concrete base and a high-speed integrated grinding spindle. Technical Highlights: X-axis travel: 250 mm / 9.8” Y-axis travel: 150 mm / 5.9” Z-axis travel: 220 mm / 8.7” Maximum tool diameter: approx. 220 mm Maximum workpiece weight: approx. 20 kg / 44 lb Grinding spindle power: 19 kW / 26 HP Spindle speed: 10,000–12,000 rpm Maximum grinding wheel diameter: approx. 202 mm / 8” Dual wheel-pack arrangement, up to four wheels per pack ANCA CNC control system ANCAcrete polymer-concrete machine base Approximate Machine Dimensions: 99” L × 79” W × 75” H Approximate Weight: 9,920 lb / 4, ...

2000 STUDER S145 CNC GRINDING MACHINE Manufacturer: STUDER Model: S145 Year: 2000 CNC Control: GE FANUC 16i-TB Machine Type: CNC cylindrical grinding machine Internal Grinding: 4-spindle configuration The STUDER S145 is a precision CNC grinding machine configured for demanding internal grinding applications. Its four-position internal spindle arrangement allows different grinding spindle configurations to be selected during production, making the machine suitable for complex components requiring several internal grinding operations. The machine is equipped with CNC-controlled workhead functions for form and thread grinding, together with a swivelling grinding head arrangement for angular applications. Working Range Approximate machining envelope: Maximum workpiece envelope: 19.7” × 4.7” X-axis travel: 4.7” Z-axis travel: 19.7” Maximum swing over bed ...

EWAG WS11 Tool Sharpener EQUIPMENT INCLUDED: x1 Z-axis approach: 4 C approach x1 X-axis transverse displacement: end transverse displacement 4 Q-M x1 Y-axis grinding stroke 3H: grinding stroke control either by lever or crank x1 Q 36-12 Full 9 JKP Grinding Spindle x1 workpiece pin for W25 collet x1 9 M foot pedal control - Z-axis approach to pedal. Infinitely adjustable approach travel x1 microscope - ISOMA front optics x1 Microscope Measuring Table x1 microscope - ISOMA top-optic microscope x1 SIEGFRIED STTV acoustic contact detector (grinding wheel/workpiece) in its case x7 Wheel Holder Flanges Various CBN Grinding Wheels Machine visible under tension for testing at our premises, by appointment. Price excl. VAT on request, including truck loading. Possibility of shipping throughout France as well as internationally. More photos and details on requ ...

ANCA TX7+ CNC Tool & Cutter Grinder Manufacturer: ANCA Model: TX7+ Year: 2005 Serial No.: 600… Machine Type: CNC Tool & Cutter Grinder Axes: 5-axis Swing: 12” Centers: 15.75” Grinding Wheel Diameter: 8” Spindle Speed: up to 10,000 RPM Installed Power: 49 HP Dimensions: approx. 9’ L × 7’ W × 7’7” H

grinding length: mmgrinding width: mmworkpiece height: mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Ziersch Z 715 - Surface Grinding Machine Mitsubishi Electric GOT2000 CNC Control Control panel with handwheel incl. technical documents and operating instructions Year of construction 2019 Technical data - Max. grinding area: 1500 x 800 mm - Transverse movement: 750 mm - Longitudinal movement: 1900 mm - Distance table to spindle center: 600 mm - Table load incl. magnet: 1600 kg - Feed rate - longitudinal axis: 1000 - 30000 mm/min - Feed - transverse axis: 0.01 - 2000 mm/min - Feed rate - vertical axis: 0.001 - 1500 mm/min - Grinding wheels: 400 x 80 x 127 mm - Power grinding spindle motor: 11 kW - Speed range: 900 - 2600 rpm - Max. cutting speeds of the grinding wheel: 35 or 50 m/s depending on the version - Oil volume: 300 l - Noise emission: < 70 dBA - Connection voltage: 400 V / 50 Hz - Nominal power: 27 kW - Pre-fuse: 50 A - Space requirement WxD: 5727 x  ...

Geibel & Hotz FS 1050 GT SL Surface Grinder Flat grinding grinder Specifications for the FS 1050 GTSL Assembly / Axis Parameter Value Working range grinding length (max.) 1,000 mm Grinding width (max.) 500 mm X-axis (longitudinal) longitudinal table stroke 50 – 1,050 mm Table speed 0.001 – 35 m/min (infinitely variable) Y-axis (vertical) Distance table to spindle center 180 – 625 mm (optionally up to 825 mm) Perpendicular speed 50 – 4,000 mm/min Z-axis (transverse) transverse travel (max.) 500 mm Grinding spindle Grinding wheel dimensions 400 x 100 x 127 mm (Ø x width x bore) Spindle drive (standard) approx. 11 kW Max. speed up to 2,380 rpm / 35 m/s Weight & installation Total weight of the machine approx. 4,500 kg Max. table load approx. 1,380 kg Various accessories included. If you have any questions, please contact us at Tel. 017621834834 ----- ...

surface grinding machine, year 1997. Used machine. More info & price on IndustrialBuyer.

grinding diameter: 350 mmgrinding length: 1000 mmcentre height: 175 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mÜberholte Maschine mit Messprotokoll nach NeumaschinentoleranzNEUE Steuerung Eckelmann ENCmit BEMA SchleifsoftwareAntriebe,Motoren,Maßstäbe aus Originalmaschine.Werkstückspindelstock nur umlaufend mit 320Nmnumerisch gesteuerte B-AchseInnnschleifeinrichtung Dia 120mm HF-SpindelSchleifscheibe links Durchmesser 400mmSchleifscheibe rechts Durchmesser 400mmInnenschleifeinrichtung für HF SpindelnReitstock mit MikroverstellungKEL SET MesssystemAktiv-Längspositionierung Kel-PosAnschnitt-Sensor MarpossThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 350 mmgrinding length: 1500 mmcentre height: 175 mmgrinding wheel diameter: 400 mmgrinding wheel width: 50 mmbore: 127 mm: MK5 work piece spindle speed: 20-400 U/minworkpiece spindle - bore: mmgrinding head swivelling: 360 °grinding spindle head - swivable: 180 + - °grinding spindle speed: 1500,1700,2200 U/min: 0,001-0,030 mm/Ø: 0-0,95 mm/Ø: ± 6 °longitudinal feed of the table: 1750 mmtable speeds: 0,02-6 m/min: 130 kg: 130 inkl. Spannugkg kg: mmgrinding depth: mm: 80 mmtotal power requirement: 6,5 kWweight of the machine ca.: 2,9 tdimensions of the machine ca.: 5,6 x 2,0 mKomplett überholt mit Umbau auf Technik der modernstenAusführung.-Neuer Schaltschrank-Modernes Hydraulikaggregat-Moderner Werkstückspindelstock-Moderner Reitstock mit Feinverstellung-Moderner Steuerblock,Zustellung,Getriebekasten-Innenschleifvorrichtung für Spindeln mit 80mm Durchmesser- ...

DELTA LC 400 - Rotary Table Grinding Machine -Magnetic clamping plate (rotary table) 300mm -Max. grinding diameter 400mm -Grinding height (distance table - grinding wheel) approx. 230mm -Spindle speed 2850 rpm -Fine adjustment 0.01 mm -Distance column - grinding wheel axle approx. 320mm -Spindle motor 3 KW -Grinding wheel dimensions 200x80x78mm -Machine enclosure -Coolant device -Documentation Dimensions: LxWxH 1.2x0.8x1.8 meters / weight approx. 700Kg

Centerless grinding machine manufactured in 2003. This KOYO 4515C features two available units, both equipped with FANUC LR Mate 200iD/7L loading robots and FANUC SR-6iA unloading robots. The first unit has 86,000 operating hours, while the second has 92,000 operating hours. If you are looking to get high-quality grinding capabilities, consider the KOYO 4515C machine we have for sale. Contact us for further details.

grinding diameter: 1300 mmgrinding length: 6100 mmgrinding wheel diameter: 1300 mmvoltage: 400 Vdrive capacity - workpiece: 23 kWcentre distance: 6500 mmmax. dia. of grinding wheel: 750 mmtotal power requirement: 50 kWweight of the machine ca.: 35 tdimensions of the machine ca.: m2 x Heavy Duty SteadiesCoolant SystemThe tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit.Your Markus Hirsch TeamThe data for this  ...

grinding length: 1000 mmgrinding width: 600 mmworkpiece height: 600 mmtable surface area: 1360 x 590 mmfeed x-axis: 30 - 30.000 mm/minfeed y- axis: 1200 mm/minFeed z- axis: 1500 mm/min.stroke of the table: 1200 mmspindle diameter: 60 mmgrinding wheel size: 400 x 100 x 127 mmspindle speeds (infinitely variable): 1000 - 3500 U/minweight of the machine ca.: 6,5 tdimensions of the machine ca.: 4,10 x 3,70 x 2,85 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Surface Grinding JONES & SHIPMAN 540 L Travel X: 406 mm Travel Y: 470 mm Travel Z: 168 mm Year of construction: 1981 Magnetic chuck dimensions: Length 355 mm x Width 150 mm Grinding wheel diameter: Ø 180 mm Spindle motor: 2 speeds motor Motorised raising/lowering Equipped with: Lubricant tank Voltage: 220 V Tri Dimensions (L x W x H): 1300 x 1300 x 1900 mm Total width with lubricant tank: 2000 mm Weight: approx 1,2 T

cylindrical grinding machine, year 2002, CNC 21i-T. Used machine. More info & price on IndustrialBuyer.

Manual Surface Grinding Machine MONOPRECIS type 1D Travel X: 350 mm Travel Y: 200 mm Travel Z: 220 mm Magnetic chuck dimensions: Length 255 mm x Width 130 mm Grinding wheel dimensions: Max Ø 140 mm Manual movement on X - Y - Z Electrical cabinet redone in 2017 Equipped with1 vacuum system Voltage: 220 V Tri Vaccum system dimensions: L 500 x W 500 x H 800 mm Width: 1300 mm Depth: 1200 mm Height: 1600 mm Weight: approx 500 KG

Manual Surface Grinding MONOPRECIS type 1 Travel X: 350 mm Travel Y: 160 mm Travel Z: 220 mm Magnetic chuck dimensions: Length 255 mm x Width 130 mm Grinding wheel dimensions: Max Ø 140 mm Manual movement on X - Y - Z Electrical cabinet redone in 2017 Equipped with1 vacuum system Voltage: 220 V Tri Vaccum system dimensions: L 500 x W 500 x H 800 mm Width: 1200 mm Depth: 1000 mm Height: 1600 mm Weight: approx 500 KG

Cylindrical grinding machine manufactured in 1999. This Cetos BHU 50 A x 2000 features a swing diameter of 500 mm and a center distance of 2000 mm. It has a maximum grinding wheel width of 200 mm and can accommodate workpieces weighing up to 300 kg. If you are looking to get high-quality grinding capabilities, consider the Cetos BHU 50 A x 2000 machine we have for sale. Contact us for further details.

grinding length: 300 mmgrinding width: 150 mmworkpiece height: ? mmcup wheel dimensions: Ø 175 mmtotal power requirement: - kWweight of the machine ca.: 0,3 tdimensions of the machine ca.: 111,8 mVertical Grinding MachineWorkspace: Table 300 x 150Control: Grinding Wheel Diameter 175 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 26188 Technical data: - Brush diameter up to approx. 120 mm - Brush width up to approx. 90 mm - Shaft mount 20 mm each - Manual height adjustment of the top brush by handwheel - Drive per motor 400 V / 2.5 kW - Space requirement approx. W 650 x H 1150 x D 450 mm - Weight approx. 80 kg

CNC grinding machine SCHNEEBERGER Gemini DMR TECHNICAL FEATURES: Year: 2014 NC Type: FANUC 31i B5 Software version installed: Quinto Qg1 Color Touch Screen: Yes Number of axes: 5 X-axis travel: 380 [mm] Maximum speed X-axis stroke: 20000 [mm/min] X-axis resolution: 0.0001 [mm] Y-axis travel: 300 [mm] Maximum speed Y-axis stroke: 5000 [mm/min] Y-axis resolution: 0.0001 [mm] Z-axis travel: 280 [mm] Maximum speed Z-axis stroke: 20000 [mm/min] Z-axis resolution: 0.0001 [mm] Table length: 500 [mm] Table width: 330 [mm] Wheel Holder Spindle Attachment: HSK-50 Maximum speed Grinding spindle: 10000 [rpm] Spindle power : 14 [kW] Max. diameter Grinding wheel: 250 [mm] Inner cone workpiece spindle: ISO 50 Number of hours in operation: 12340 [h] Supply voltage: 400 [V] Rated Current: 63 [A] Weight: 8100 [Kg] EQUIPMENT INCLUDED: x1 8-Station Wheel Changer  ...

Auction-ID: A1-50076-471

Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Max. shaft diameter: 320 mm -Max. grinding length: 345 mm -Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg -functionally tested

1 Gebr. Surface Grinding Machine Fabr. Proth, Type PSGS-2550, Year 1987 Specifications (Proth PSGS-2550) • Manufacturer: Proth Machinery • Model: PSGS-2550 (or often as semi-automatic variant PSGS-2550AH with hydraulic longitudinal and transverse feed) • Clamping surface / table size: 500 x 250 mm (approx. 20" x 10") • Max. sanding area (length x width): 500 x 250 mm • Travels (X / Y / Z): ◦ Longitudinal stroke (X-axis): approx. 600 mm ◦ Transverse stroke (Z-axis): approx. 340 mm ◦ Vertical stroke (Y-axis / spindle head): approx. 280 mm – 312 mm • Max. distance from spindle center to table: approx. 500 mm • Table speed (infinitely variable): approx. 5 to 25 m/min ⚙️ Grinding wheel & drive • Grinding wheel dimensions: approx. 350 (or 355) x 25 x 31.75 mm • Spindle speed (at 50 Hz): approx. 2,900 rpm • Grinding spindle motor: approx ...

CONTROLS  CNC controls SIEMENS WORKING RANGE SURFACE GRINDING  grinding length: 600 mm  grinding width: 250 mm  vertical travel: 280 mmTABLE (SURFACE GRINDING)  magnetic table: yes SPINDLESTOCK GRINDING SPINDLE  X-axis travel: 600 mm  spindle revolutions (min): 800 /min  spindle revolutions (max): 2400 /minGRINDING TOOL  type of grinding tool: wheel   diameter (max): 300 mmDRESSING DEVICE  dressing tool: single diamond ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 2500 kgATTACHMENTS (GRINDING)  coolant unit: yes

grinding diameter: 200 mmprofile depth: 30 mmworkpiece length - max.: 2790 mmgrinding length: 2310 mmMaximum pitch of the screw: -/+ 50 °Maximum number of gears: 1-999 workpiece weight max.: 250 kgz-travel: 3000 mmx-travel: 185 mmmax. dia. of grinding wheel: 450-330 mmGrinding wheel thickness (with recess): 20-70 mmroll diameter: 120 mmSpeed of the grinding wheel spindle: 1500 - 6000 U/minWorkpiece spindle speed: 0 - 600 U/minSpeed of the pitch axis: 0-4 1/minSpeed of the dressing spindle: 1500-16000 1/minfeed speed z-axis: 0-10000 mm/minfeed speed x-axis: 0-10000 mm/mintotal power requirement: 150 kVAcontrol: Siemens Sinumerik 840D SL weight of the machine ca.: 30 tdimensions of the machine ca.: 10,65 x 5,37 x 2,75 mFeatures/Accessories: - Filtration system: KNOLL VL1500/5000 - many accessories—list to follow - documentation The data for this ad was created with ModulMWS - t ...

grinding length: 400 mmgrinding width: 200 mmworkpiece height: mmweight of the machine ca.: 1,2 ttotal power requirement: kWdimensions of the machine ca.: mautomatic infeedelectro magnet platedressing devicecoolant deviceTechnische Daten / technical details:max. Schleiflänge / max. grinding length 400 mmmax. Schleifbreite / max. grinding width 200 mmX-Achse, Tischlängshub / X-axis table longitudinal travel 420 mmZ-Achse, Querweg / Z-axis cross travel 190 mmSchleifscheibenabmessungen / grinding wheel dimensions 225x25x51 mmAnschlussleistung / drive capacity 7 kWGewicht ca. / weight ca. 1200 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Rema Grinding and Polishing Machine SMZ57. Speed: 700/1400/2400. 7hp. Year of construction: 07/2001. Double belt tensioning arm + belt tensioning hood.

Manufacturer: TSCHUDIN Model No.: HTG 410 Condition: Used Stock number: 9550 Maximum grinding length: 420 mm Maximum speed of the grinding wheel spindle: 500 1/min Maximum grinding wheel diameter: 350 mm
