machines and plants for process engineering used for sale (7,561)

centrimax.de Centrimax - Winkelhorst Trenntechnik GmbH has specialized in the supply of used SEPARATors from GEA Westfalia Separator and Alfa Laval for more than 30 years. The separators are overhauled by us and delivered with warranty. Our large stock of several hundred separators includes plate separators (self-cleaning separators, full-coat plate separators and nozzle separators) as well as chamber separators, for the clarification and separation of suspensions and liquid mixtures. Ask us if you are looking for advice on solving problems in the field of centrifugal separation technology. Buy from the specialist !

ENTRY STRIP THICKNESS: MAX. 12 MM, EXIT THICKNESS: 1.8 MM, STRIP WIDTH: 1000 - 1500 MM, AGC SYSTEM (2000), COMPLETE LINE!

DANIELI, 1989, 550 T/DAY, BILLETS SQUARE: 130 x 6000 MM, REBARS: D8 - D14

PICKLING LINES, TANDEM MILL, 18 ANNEALING FURNACES, TEMPER MILL, SLITTING LINES, SHOT BLAST MACHINE, STRIP WIDTH: 1000-1279 MM, ENTRY THICKNESS: 1.8 - 4.5 MM, EXIT THICKNESS: 0.7 MM

used, kpl. 1 year warranty, plate size 400 x 400 mm, 25 plates, open outlet, 25 mm cake thickness, capacity 75 liters, filter area 6.5 m2, pressure max. 10 bar, dimensions 2000 x 800 x 1600 mm, weight approx. 800 kg

used, kpl. 1 year warranty, built in 1999, plate size 1200 x 1200 mm, 70 plates with 50mm cake thickness (3500 liters capacity + 160 m2 filter area) or 90 plates with 30 mm cake thickness (2700 liters capacity + 205 m2 filter area), open outlet, pressure max. 15 bar, dimensions 9000 x 2000 x 2400 m m, weight approx. 18 to, PP - drip plate (motorized)

used, kpl. 1 year warranty, plate size 800 x 800 mm, optional 60 - 85 plates, open outlet, 25 mm cake thickness, pressure 15 bar, capacity 800 - 1100 liters, filter area 64 - 90 m2, dimensions 7000 x 1500 x 2400 mm, weight approx. 11 tons

used, kpl. 1 year warranty, plate size 300 x 300 mm, 10 plates, open outlet, 25 mm cake thickness, pressure max. 10 bar, capacity approx. 20 liters, filter area 1.5 m2, dimensions 1200 x 600 x 600 mm, weight 400 kg, optionally with manual or motor hydraulics, available now

used, kpl. 1 year warranty, plate size 250 x 250 mm, 15 plates, open outlet, 15 mm cake thickness, pressure max. 15 bar, capacity 10 liters, filter area 1.5 m2, dimensions 1300 x 500 x 1300 mm, weight 300 kg, optionally with manual or motor hydraulics, with or without feeding pump and Piping

used, kpl. 1 year warranty, plate size 500 x 500 mm, 45 plates, open outlet, 20 mm cake thickness, pressure 15 bar, capacity approx. 171 liters, filter area approx. 18m2, dimensions 3500 x 900 x 1200 mm, weight 1.5 to, optionally with hand pump or motor hydraulics, with or without filter cloths

used, kpl. 1 year warranty, built in 1994, plate size 800x800 mm, 60 plates, open outlet, 25 mm cake thickness, pressure 15 bar, capacity approx. 800 liters, filter area 64m2, dimensions 5500 x 1500 x 2200 mm, weight approx. 6 to

used, kpl. 1 year warranty, plate size 800x800 mm, 50 plates, open drain, 25 mm cake thickness, pressure 15 bar, capacity approx. 660 liters, filter area 53m2, dimensions 5500 x 1600 x 1200 mm, weight approx. 5 to

used, kpl. 1 year warranty, plate size 800 x 800 mm, 95 plates, closed drain ( 4-hole), 30 mm cake thickness, pressure 15 bar, capacity approx. 1350 liters, filter area 95m2, dimensions 7500 x 1300 x 2000 mm, weight approx. 7 to

Nitrogen generators membrane or PSA systems for laboratory up to production (500 L/h to several m3/h) No more gas cylinders in laboratory, plant or car repair shop (tyre gas)! Wear-free operation >99.5% pure nitrogen from mostly existing in-house compressed air Constant and safe gas generation guarantees reliable analytical results Operation-free 24-hour operation also in hazardous areas Safe operation due to low operating pressures Economically thanks to fast payback even on a technical scale! N2 production according to the membrane process The nitrogen generators continuously supply nitrogen up to a maximum purity of 99.5%. After the compressed air flows through highly effective filters, the compressed air is decomposed in a hollow fiber membrane module into a concentrated nitrogen flow and an oxygen-enriched portion. The membrane process has ...

with 15 cards + Rack S5 187U with 10 expansion cards. scope of delivery as seen in the photos.

Type: VGL 5000. Double-current mixer in standard steel version with 5,000 l. useful content, cylindrical mixing tank and conical bottom, with vertical middle screw, distribution arm and power line controller, rectangular connector for pocket filter, manhole, lower Screw bearing with air flushing, pneumatic flat slider at the outlet.

Piston dosing pump, type EK 1 H, with batch control via electric pulse preselection counter incl. remote summier movement. Working pressure 7.5 bar, max dosing current 290 l./h, pipe connection Rd 34 x 1/8 inch with hose sleeve NW 15, with control cabinet, mounted on table.

Horizontal batch mixer with 630 l. gross content, pneumatic outlet flap (new cylinder), 37 kW engine, Flender gearbox (N2 = 58.58 UPM) and carbide-armoured mixing tools. Workshop overhauled in 2016; very good condition.

Type: Pipeline Model 63, magnet separator for removing iron from ceramic chippings etc., input: 380/220/115 V, output: 24 V / 7.5 A (transformer built-in), 2.4 to./h.

Type: RHS 1 U 200 GR 360, Y&cams: 1995, engine: Loher, 4,500 rpm / 5.5kW, on base frame, with suction and pressure bellows and 7 vibration dampers.

Type: HM 200, high-performance mixer, partly in VA, Y:00, 1987, 6.5 / 9.5kW, 2 knife heads, control cabinet, completely on base frame, drives can be polum-switched.

Type: 100 FSG, Y&l: 1986, granulation plant with circular gas operation, sifter 100 ATP (4 kW Vario, up to 11,500 rpm), and reblow filter K 6 R (2.4 m2 filter area). All in stainless steel. Very good condition.

Maximize the power and efficiency of your machinery with the DENISON M3B Series Hydraulic Motor, specifically engineered to convert hydraulic pressure into rotary motion for heavy-duty industrial applications. The M3B 012 1N00 B102 model delivers exceptional torque and precision, ideal for applications requiring high performance and reliability. Type: Fixed Displacement Rotary Hydraulic Motor Max Pressure: Up to 350 bar Speed Range: Up to 4000 RPM Nsbmsv D H Nney Ex Ipocu Applications: Industrial machinery, hydraulic systems, mobile equipment Made In: France Features: 1. Rotary Motion: Converts hydraulic energy into rotational power for driving mechanical systems 2. Durability: Built to withstand high torque and pressure in demanding environments 3. Efficient Operation: Suitable for continuous, high-load applications 4. Compact Design: Space-efficient for easy integ ...

Hydraulic motor PMH MCF55 Nobmjv D Hwrey Ex Ipecu Displacement cc/rev 55 Max output speed rpm 4,300 Max pressure bar: 500 The max output torque: Nm 350 Weight: 25 kg Manufacturer: PMP Industries Part Number: MCL.5502.1 Serial Number: PP0377490 Customer Code / Model: PMH MCF55 Country of Manufacture: Italy 1 piece in stock

Ball valve DN200 Material: cf-8m (ss316) Weight: 160 kg

Manufacturer: BAC (Spain) Model: F-150-10-150 Type: Ball Valve Size: 6" (DN150) Pressure Rating: 150 lbs (ANSI Class 150) Material: • Valve Body: CF8M Stainless Steel (AISI 316 equivalent) • Ball: 316 Stainless Steel • Gasket: PTFE (Teflon) Connection: ANSI Flanged Ends

Manufacturer: BAC (Spain) Model: POR-100-12-150 Type: Ball Valve Size: 6" (DN150) Pressure Rating: 150 lbs (ANSI Class 150) Material: • Valve Body: CF8M Stainless Steel (AISI 316 equivalent) • Ball: 316 Stainless Steel • Gasket: PTFE (Teflon) Connection: ANSI Flanged Ends

Brand-new Sauer Danfoss 11028185 Hydraulic Pump—a high-performance, durable hydraulic component designed for industrial and mobile machinery applications. Model Code: JRR045BLS192 Serial No: S074826737 Max Pressure: Up to 350 bar (verify with specs) Country of Manufacture: Made in Slovakia Ideal for heavy equipment, construction, and hydraulic systems Model No./Ident No.: 11028185 Net weight: 29 kg Manufacturer: Sauer Danfoss Availability: 2 Ncobsv D H Evomy Ex Ipeu

Grundfos CR1-10 AAAE-HQQE Vertical Multistage Centrifugal Pump Model: A96516180P10544 Serial No.: 0001 Power: 0.55 kW Pmax/Tmax: 16 bar / 120°C This is a high-performance vertical multistage centrifugal pump with inline inlet and outlet ports for easy integration. The pump head and base are constructed from durable cast iron, while all wetted parts are made from corrosion-resistant stainless steel. Key Features: Reliable cartridge shaft seal for safe handling and easy maintenance Rigid split coupling for efficient power transmission Ncsbmy Eowtd Hnjx Ipsu Pipe connection via oval flanges with internal RP threads Fitted with a 3-phase, fan-cooled asynchronous motor The steel, cast iron, and aluminum components are coated using a high-quality epoxy-based cathodic electro-deposition (CED) process. This ensures a thin, uniform protective layer that enhances corrosi ...

Danfoss 83024044 PUMP-VAR-DISPL HYDRAULIC PISTON PUMP Weight: 24.6 kg Availability: 1 P.max. - 350 bar Nobmy Exov D Hk Ej Ipocu REF/Serial Number: 026-67039-0 Part number: C5V08-311B1 Manufacturing site/service centre: 41564 KAARST Germany PTS ID/Tracking ID: VKU82E77 Unique Identifier
