welding machines used for sale (1,693)

Technical data: -max load capacity 3000 kg -Faceplate cross 1600 x 1600 mm -Faceplate cross extension tubes - faceplate cross mot. adjustable 0-90 / 135 ° - rotation infinitely variable 0,01-4 U/min -Right - + rotation control -Transmission of welding current approx. 500 A -400 V - table height in horiz drive. Position without stand approx. 1200 mm -Table height at horiz. Position with frame approx. 2200 mm -Space requirement approx. B H 1600 x 1200 + 1000 X 2400 mm -Weight approx. 2700 kg

Technical data: -Load capacity 300 kg -Faceplate diameter 500 mm -Faceplate in grid levels of tilt - rotation Electr. infinitely variable approx. 0-1.2 m / min -Sweat power 650 A -Drive 220 V / 0.09 kW -Table height in horizontal position approx. 650 mm -Re + reverse - space requirement approx. B H 800 x 650 X 700 mm -Weight approx. 180 kg

Technical data: -Capacity approx. 200 kg -Throat depth 800 mm -Working height in horizontal position approx. 1000 mm -Mot boom. left + right swivel - arm arm manually Tiltable -Mot face plates. left + right rotatable - faceplate speed infinitely variable - faceplate diameter 300 mm - adjustable control panel with control make ESAB, type 6 PTF, BJ. 97 - space requirement approx. B H 1100 x 1300 X 1600 mm -Weight approx. 300 kg

Technical data: -Welding current 505 A 35% ED 433 A 60% ED 385 A 100% ED -Welding current 6 coarse steps + 6 fine levels adjustable - welding current adjustable from 40 A / 16 V to 505 A / 39.3 V - digital amp + voltmeter -separate stroke of wire feed case - 4 roll wire feed Steplessly adjustable - 2 + 4 stroke â regulation -E - welding equipment - hose water cooled approximately 6 YDS -Ground cable -Pressure reducer -Intermediate package machine - wire feed speed approx. 8 m - connection 400 V / 50 Hz 50 A -Space requirement approx. B 520 x H 1400 X 1000 mm -Weight approx. 170 kg

Technical data: -Lifting capacity 2000 kg -max load capacity horiz. 3500 kp -Faceplate hub 1750 x 1750 mm -Drehkreuzverängerungen -Faceplate geared motor Tiltable 0-90 ° -Rotation Electr. adjustable 0.2-1.5 m / min -Right - left rotation - welding current transmission 1200 A -400 V - table height in horiz drive. Position with frame approx. 2070 mm -Table height at horiz. Position without stand approx. 940 mm -Space requirement approx. B 1650 x H 1130 / 940 x H 2500 mm -Weight approx. 2.2 t

Technical data: -Equal water-cooled AC unit TIG TR 4,. -water-cooled MIG-MAG system DV - IV - XT - E. welding plant STH 400 for welding of: stainless steel, steel, aluminum, etc. -16 x welding program be selected with: -. Setting selection: Stick welding, Tig - welding AC / DC, MIG-MAG welding -Digital Volt + amp display -Welding current continuously adjustable by 10 A / 15 V to 400 A / 34 A - max welding current of 400 A max 60% ED 315 A 100% ED -Power 400 V / 43 A / 16 kVA -Heart monitor -Welding current rise - and welding power descent setting -Back fire setting -Gas before. - current setting -water cooled Tig welding - torch 8 m, lightweight design -E - welding cable + ground cable - water-cooled MIG - MAG torch â separate wire feed case DV - IV - XT for MIG - MAG welding -4 wheels - wire feed -Intermediate package welder - wire feed case 4500 mm -P ...

Rated output at 50% ED: 60kVA Short circuit current: 24kA Electrode force: 470daN / easy lift Throat depth: 435mm Arm distance, infinitely variable: 180-510 mm Electrodes Cone: Mk2 --- Welding control: WS 708 (7-times, 8-program) --- Incl. additional options: -Two hand start / footswitch -Main switch --- Warranty 6 months --- Training + commissioning on request --- Point welding electrodes + spares available from stock

Rated output at 50% ED: 25kVA Short circuit current: 14kA Electrode force: 220daN Throat depth: 455mm Arm distance, stufemlos: 168-443 mm Electrodes Cone: Mk1 --- Welding control: WS 402 (4-times, 2 program) --- Incl. additional options: -Foot switch -Main switch -3 m connection cable and Cekon-plug 32A --- Warranty 6 months --- Training + commissioning on request --- Point welding electrodes + spares available from stock

Machine type MIG/MAG welding system Make MERKLE Type RedMIG 2000 K Connection voltage 3 x 400 volts Setting range 25 - 200 amperes Switch-on time 30% ED at 200 amperes 60% ED at 140 amperes Current setting 7 switching stages Cooling transformer by built-in fan Cooling burner gas-cooled Design mobile compact system Wire feed 4-roller drive DV 26 Hedging 16 Ampere Dimensions L x W x H 800 x 460 x 655 mm Weight 70 kg Special accessories 4-roller gearbox DV 26 Age 6 months Condition very good, as new Scope of delivery Welding system with the following accessories: 1 piece welding torch SB 157 G, 3 mtr. Long 1 piece ground cable 4 mtr. long, 25 sqmm 1 piece pressure reducer argon with 2 pressure meters 1 roll welding wire D-300 coil, 5 kg 1 can of non-stick spray 1 piece hand shield 1 piece protective glass 10 DIN 1 piece glass whi ...

Machine type MIG/MAG welding system Make Merkle Type RedMIG 1600 K Connection voltage 1 x 230 volts Setting range 25 - 160 amperes Switch-on time 30% ED at 160 amperes 60% ED at 130 amperes Current setting 7 switching stages Cooling transformer by built-in fan Cooling burner gas-cooled Design mobile compact system Wire feed 4-roll drive Hedging 16 Ampere Dimensions L x W x H 800 x 460 x 620 mm Weight 65 kg Age 12 months Condition workshop-tested, very good, incl. UVV test protocol Scope of delivery Welding system with the following accessories: 1 piece welding torch SB 157 G, 3 mtr. Long 1 piece ground cable 4 mtr long, 25 sqmm 1 piece pressure reducer argon with 2 pressure meters 1 roll welding wire, D-300 coil, 5 kg 1 can of non-stick spray 1 piece hand shield 1 piece glass 90 x 110 mm white 1 piece protective glass 90 x ...

Humpback welding machine year 1952 25 kW 500 V All data without gewaehr

Bolt feeders Manufacturer: Tucker Type: BV 50D.00.44/5.18F8 and BV 50D.10.01/5(12-25) There are 2 pieces. The price is for 1 PCs.

Projection welding machine Year of construction: 1979 Manufacturer: Roth electric Type 126 P 125.4 Rated current at 50% ED: 16.0 kA Rated output at 50% ED: 160 k Nennspennung: 380V/50 Hz All information without guarantee

Plasma extraction and filter system Filter BLOC TFK PL Series special central suction and filter unit for plasma smoke when burning and cutting the FILTER BLOC TFK PL series and CQC certified manufacturer according to ISO 15012 and CE drawing FILTER BLOCK - TFK PLASMA 40/60/80 Motor power 5,5 / 7,5 / 11 KW air volume 4000/5500/6200 m3 / h 124/186/248 m2 filter surface dust container 4x/6x/8x 84 liters Automatic jet cleaning system with testing for welding fume category W3 24 Months Warranty The price refers to the TFK PL 40 for further information on request; ready to use

Manufacturer: MicroStep Type: SPL-PA 3001.15+S500 Working range: 3000 x 1500 mm + 500 mm shaft technology: plasma built in 2006 Kjellberg HiFocus 160i with autom. Gas console; (see PDF) 2 x additional quick-release co-buttons PerCut 170 Div. Wear parts Donaldson filter system including disassembly and delivery within Germany. Commissioning on request.

Plasma cutting system with Hypertherm HPR 130 with automatic gas console Cutting up to 20mm Working range: 1500mm x 3000mm inlusive filter system Immediately available under current assembly and commissioning on request

Rated output at 50% ED: 80kVA Short circuit current: 35kA Electrode force: 100-600daN / easy lift Projection: 350-650mm --- Welding control: MPS 10 (5 times, 8-program) --- Incl. additional options: -Flow switch --- Warranty 6 months --- Training + commissioning on request --- Point welding electrodes + spares available from stock

see picture attached

Electric welding equipment FRONIUS WTU 205, 2 stub

approx. 2 tons, all original packed and 5 or 6 mm,see pictures

Thyristor-controlled, pneumatic point welding pliers with timer and compensation device 6kVA water-cooled

Connection - 380 V, 50 Hz, control voltage 24 V, output at 100% ED 3.5 kVA, Btto 235 kg, more tech. Info from nameplate

Trumpf TKF 103 welding edge shaper. 220 Volt under electricity ready for use Special price

A C H T U N G_____S o n d e r p r e i s ! ! ! TIG Welding Device Manufacturer Artec fully ready for use with all the no-fable lifts. Can also be used as an electrode device. Welding current 350 ampere DC, no alternating current! Weight approx. 200kg Geraet under electricity ready for use Immediately available Lorch Dalex Messergrießheim Cloos Special price

Weber, Masch. No. 1109226, orbital riveting machine with RT-stand Motor M 631 / 4 0.18 kW 1360 RPM KMT - APK T-3-S-60-Z SN 307 89 01 Riveting time - adjustable 0.15-3 s Control - Siemens Simatic S 7-200 External dimensions 30 x 20 x 86 cm - riveting machine Panel 50 x 40 x 30 cm More info and details. Photos upon request I am retailer offers to similar machines interested in financing through leasing or hire-purchase request send data protection
