22 HAEUSLER used machine for sale

Hyundai RB Onsan Factory, located at Ulsan in South Korea produces welded pipes by means of LSAW – Longitudinal Submerged Arc Welding process. The line is offered complete, featuring advanced HAEUSLER (Switzerland) core equipment. This facility is capable of producing welded pipes with the following specifications: Diameter: 22 to 80 inches Thickness: 6.4 to 25.4 mm Length: 6,000 to 12,200 mm The production line is equipped with a comprehensive suite of machinery altogether ensuring seamless and efficient production of LSAW pipes, including: • Plate edge milling • 3-roll bending • Post bending • Tack welding • Inside welding • Outside welding • Copander • End facing • Pipe inside washing • Hydrostatic tester • X-ray • Semi-correction • Pipe roll conveyor with skid system

specifications: Max sheet width 3,000 mm Max sheet thickness at max yield strength 240 N/mm2 when bending to max. sheet width 35 mm when rounding Bend length 2.2 x S Max passage between rollers 145 mm Roller diameter upper roller 552 mm Underroller 532.4 mm Side rollers 400 mm Number of rollers 4 Powered rollers 2 top and bottom roller Drive of the rollers hydraulically Arrangement of the rollers symmetrically Rotation speed of the rollers 2-4 m/min Adjustable rollers 3 Type of adjustment of the rollers hydraulically Adjustment speed lower roller 0-200 mm/min. Side rollers 0-700 mm/min. Brake of the rollers pneumatic Actuation of the folding bearing hydraulically Operating voltage 3 x 380 V / 50 Hz Display device of the roll positions 4 x optical/analog Weight of the machine approx. 42 to Area 2.71 x 6.4 m Height 3.12 m

Technical data: 4 bending rolls Max bending range: 3,000 mm external switching and Control Panel, as well as counter holder

Technical data: maximum sheet width: 3000 mm maximum plate thickness at maximum yield of 240 N / mm² on bending: 35 mm On bending length: 2,2 x S Diameter of roller upper roller: 552 mm Bottom roll: 532,4 mm Side rolls: 400 mm

HAEUSLER Dishing press: - Max. force 1000 Ton - Retraction force 82.5 Ton - Approach speed 260 mm/Sec - Working 10 - 30 mm/Sec - Return speed 370 mm/Sec - Pressure 253 Bar   - Distance between column 9000 mm - Dimensions table plate 1500 x 1500 mm - Max Work piece diameter 8700 mm - Thickness at yield 450 N/mm2 90 mm   - Manipulator: - Max. dimanions 8700 x 90 mm - Min. dimensions table 1500 x 1500 = 3200 mm - Min. dimensions table 700 x 700 = 2200 mm - Work piece weight 42.000 Kg - Travelling speed 158 M/Sec - Power 165 kW - Weight 43000 Kg - Optional Dishing Dies (Gray GG-25) RUW 925 with    1500 diameter x R   950 – 1300 mm RUW 1205 with 1500 diameter x R 1305 – 1700 mm RUW  1520 with 1500 diameter x R 1705 – 2200 mm RUW 1905 with 1500 diameter x R 2205 – 2800 mm RUW 2395 with diameter 1500 x R 2805 – 3500 mm RUW 2885 with diameter 1500 x R 3505 – 4300 mm RUW 3515 ...

HAEUSLER FLANGING MACHINE HBM-HY 8700 x 90 mm   - Forming and Flanging rollers: - inclines positon 0 - 25 Degrees - Rotation sopeed 0 - 200 M/Min - Rapid adjustment speed 2500 mm/Min - Crawling speed 0 - 1200 mm/Min - Sleeve hydro mechanical rapid speed 6000 mm/Min   - Infeed carriage: - Work piece weight 42.000 Kg - Max. dished head 8300 mm - Min. dished head 1900 mm - Speed 20 M/Sec - Centering Automatic   - Data of Workpiece: - Cold 360 N/mm2 45 mm - Hot 360 N/mm2 90 mm - Min Knuckel Radius 100 mm - Max. Knuckel Radius 1200 mm - Min thickness dished 10 mm - Head diameter without device 2600 mm - Head diameter with device       1900 mm - Length off straight flange at flanged head 3,5 x thicness = 140 mm   - Hydraulic tank 2000 Liter - Power 350 kW - Form roller changing device in combi with lifgting sleeve - Auxiliary device for flanging heads from 1900 - 2600 x 25 mm thickness ...

Specificaties: 4 rollen Plaatbreedte: 3600 mm Diameter: 4000 mm Diameter van de bovenrol: 1500 mm Diameter van de zijrollen: 1100 mm Diameter van de onderste middenrol: 1450 mm 7000 ton Maximale dikte: 200 / 270 mm Maximale druk op de bovenste rol: 7300 ton Rolmateriaal 60CrMoV12.5 Hydraulische rotatieaandrijving Software: Beckhoff Besturing: Swiss Bend-IT Technology V.3.4.0 Luchtverbruik: 4 bar / 35 m³/u Afmetingen: 15000 x 7200 x 7890 Gewicht 750 ton IN TOPCONDITIE Number of rolls: 4 Roll capacity cold: 220 mm Roll capacity warm: 270 mm Type: VRM Hy 36-4712 Roll dia upside: 1500 mm Dia under roll - side rolls: 1450 / 1100 mm Driven rolls: Centre top and bottom rolls driven Power needed: 850 kW Length: 15 000 mm Depth: 7200 mm Hight: 7890 mm Weight: 750 ton

- New ( 2026) Digital read out position side rolls - Hydraulic drop end - Minimum bending diameter 420 mm - Full hydraulic machine - Roll quality C60 900N/mm2

- Set universal rolls - Horizontal and Vertical positioning - Hydraulic machine - Scales for position side rolls

Die EVO ist die neueste Innovation in der Blechbearbeitung. Sie ist mit zahlreichen innovativen und patentierten Funktionen ausgestattet, die Ihre Produktionskapazität und Produktivität erhöhen, und weist gleichzeitig die niedrigsten Gesamtbetriebskosten auf. Die hochwertigen Komponenten, die bei dieser Maschine verwendet werden, sowie die neueste Version der BENDtronic®-Steuerung, welche serienmässig auf allen EVO-Maschinen installiert ist, sind besondere Highlights. Ab Lager verfügbar: HAEUSLER EVO 31031 4-Walzen Rundbiegemaschine / Walzenbiegemaschine Hersteller: Haeusler Typ: EVO 31031 4-Walzen Rundbiegemaschine / Walzenbiegemaschine Ursprung: Deutschland / Schweiz Baujahr: 2024 Zustand: NEU, Austellungsmaschine Verfügbarkeit: sofort Leistung: Arbeitsbreite 3100 mm Rundbiegeleistung 14 mm Anbiegeleistung 12 mm Nicht die Passende Maschine? Als Vertreter von Haeusl ...

A Haeusler CNC large-format 4-roll plate bending machine is available. Number of rolls: 4, Roll width: 3050mm, Max. prebending plate width: 3000mm, Max. prebending plate thickness: 60mm, Max. rolling capacity at max. plate width and 3500mm bending diameter: 70mm, Roll diameter top/bottom/side: 620mm/600mm/500mm, Max. top roll load: 12000kN, Operating speed: 4m/min, Connected load: 132kW, Weight: approx. 85t. Including cone bending device. Documentation available. An on-site inspection is possible.

- Force lower rol upper roll 1178 Ton - Cone bending attachment - Hardned and grounded rolls - Width between upper and lower roll 200 mm - Power 180 kW

- Smallest bending diameter 640 mm - Pressing force against upper roll 5800 kN - Conical bending attachment - Central lubrication - Equipped for change rolls 570 / 500 / 430 mm

sheet width: 4000 mm plate thickness: 30 / 35 mm pre-bending: 30 mm diameter of upper rolls: 570 mm side roll diameter: 450 mm diameter of lower rolls: 540 mm bending speed: 4 m/min min. bending diameter: 650 mm total power requirement: 60 kW weight of the machine ca.: 52 to dimensions of the machine ca.: - m The machine was overhauled in 2022 Equipment: - Hydraulic 4-roller round bending machine - Roll material: 61 MnCrMo 43 - Driven rolls: 2 Top-and bottom roll -- Drive: over 2 hydro motors direct flanged -- Adjustment speed bottom roll: 0-200 mm/min -- Adjustment speed side rolls: 0-700 mm/min - Speed compensation between top-and bottom roll: automatic - Operation of the tilting bearing: hydraulic - Tilting of the top roll: hydraulic - Bearing block: hydraulic - Indicator device of roll position: digital The data for this ad was created with ModulMWS - the software solution of Logo ...

Bending length: 4200 mm pre-bending: 34 mm Bending strength: 38 mm power capacity: kW Number of rollers: 4 Stk Adjustable rollers: Stk diameter of upper rolls: 540 mm diameter of lower rolls: 500 mm side roll diameter: 365 mm work speed: 0 - 8 m/min total power requirement: 55 kW weight of the machine ca.: 35 t Control: Haeusler Bendtronic 2.0 dimensions of the machine ca.: 7.5 x 2.1 x 2.4 m Equipped with: - Haeusler BENDtronic 2.0 control system - Smallest possible bending diameter with upper roller Ø540mm: 595mm (depending on springback) - Roller bearings: Self-adjusting roller bearings - Max. cylinder force against upper roller: 3,245kN - Roller material: 42CrMo4 (1.7225) - Speed compensation between upper and lower roller: automatic when the two-roller drive option is selected - Roller adjustment: hydraulic - Tilting of the lower roller and both side rollers for cone bending: infini ...

Manufacturer: HAEUSLER Model: HPR 330 V+H Year of Manufacture: 2007 Approximately 10 pallets of tools for round bar processing are included, with diameters of 60.5, 137, 91, 168, 76, 51, 152, 129, etc. Condition : Machine currently not in use and therefore not fully assembled Technical Data: - Maximum bending moment (at 240 N/mm² yield strength): 200–330 cm³ - Number of bending rolls: 3 - Roll arrangement: asymmetric / symmetric - Roll diameter: 520 mm - Driven rolls: all 3 - Roll drive: hydraulic - Working speed: 0–7 m/min, stepless - Speed compensation between upper and lower rolls: automatic - Roll rotation reversal: electro-hydraulic - Adjustable bending rolls: 2 - Adjustment of bending rolls: hydraulic - Roll position display: digital, 0.1 mm accuracy - Roll bearings: roller bearings - Number of pressure roller systems: 2 - Adjustment of pressure roller systems: hydrauli ...
