MAZAK integrex used machines

This 4-axis Mazak INTEGREX 200 Y was manufactured in 2000. It features a maximum turning diameter of 540 mm, a swing diameter of 540 mm, and a bar diameter capacity of 51 mm. The machine supports a workpiece weight up to 150 kg and offers a spindle speed range up to 5,000 rpm. It includes a Mazak KM 63 quick change tool system with 20 slots. If you are looking to get high-quality turning capabilities, consider the Mazak INTEGREX 200 Y machine we have for sale. Contact us for more information.

This 5-axis Mazak INTEGREX I-150 turn-mill centre was manufactured in 2012. Consider the opportunity to buy this Mazak INTEGREX I-150 turn-mill centre. Contact us for more information.

This 5-axis Mazak Integrex 400Y was manufactured in 2000. Ideal for complex machining, this turn-mill centre machine integrates multiple operations. Consider the opportunity to buy this Mazak Integrex 400Y Turn-Mill Centre machine. Contact us for more information.

This 5-axis Mazak INTEGREX J-200 S was manufactured in 2021. It features a maximum machining diameter of 500 mm, X-axis travel of 450 mm, Y-axis travel of 200 mm, and Z-axis travel of 960 mm. The machine is equipped with a 36-tool magazine and a maximum spindle speed of 4,000 rpm. If you are looking to get high-quality mill-turn capabilities, consider the Mazak INTEGREX J-200 S machine we have for sale. Contact us for further details.

This 5-axis Mazak INTEGREX i-200 S was manufactured in 2017. It features full 5-axis simultaneous machining, a maximum machining diameter of Ø658 mm, and a maximum machining length of 1519 mm. The machine includes a robust tool magazine capacity of 72 positions and is equipped with both main and second spindles for enhanced capabilities. If you are looking to get high-quality turning and milling capabilities, consider the Mazak INTEGREX i-200 S turn-mill centre. Contact us for further details.

MAZAK INTEGREX 200 SY + FLEX GL-100C. 2001. MAZATROL 640 MT control maximum turning diameter 540 mm Z-axis travel 1,065 mm Main spindle maximum RPM 5,000 rpm Main spindle full C-axis Counter-spindle maximum speed 6,000 rpm Y-axis +/-80 mm Milling spindle for turning and milling Spindle maximum speed 6,000 rpm Full B-axis, 225° Tool changer with 40 tool positions KM-63 tool mount Tooleye 1 x 3 - jaw Chuck, diameter 210 mm 1 x 3 - jaw Chuck, diameter 170 mm Gantry loader Flex GL-100 C. High pressure cooling through spindle, 20 bar Chip conveyor CE mark

MAZAK INTEGREX turning/milling center 200Y Bu. 1999 Mazatrol fusion control Max Drehdurchm. 520 mm Max Schwingdurchm. 540 mm Maximum turning length 1,018 mm Bar passage 51 mm C-axis + angetr. Tools Y-axis +/-70 mm Distance between the top 500 mm Drive 30 kW Maximum main spindle spindle speed 5,000 rpm Maximum speed milling spindle 6,000 rpm Tool changer with 40 stations 3-jaw Chuck 200 mm Tool measuring arm Tailstock Chip conveyor Total connected load 31 kVA Machine dimensions 3.50 m x 2.10 m x 2.50 m Machine weight 6,800 kG 25 tool holder KM 36 duty hours approx. 36,000

Mazak Integrex 200 lll S + GL 150 F CNC turning-milling center with second spindle CNC control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 rpm X-axis travel: 580 mm Y-axis travel 160 mm Z-axis travel: 1045 mm B-axis travel: 225 ° mm C-axis indexing 360° Spindle nose A2-6 Tool cone Capto C6 Number of tools in the magazine 40 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail.

Key data: 420 mm, 1524 mm, 3300 1/min

Stock number: 3963 CNC LATHE Manufacturer: MAZAK, Type: INTEGREX 400 III-S Machine NO.: 173882, Year of manufacture: 2005 Specifications: Max. circumferential diameter 420 mm dia. Max. turn. About Bed 850 mm Dia. Turning length 1524 mm Main motor power 30 kw Main spindle speed range 3300 rpm Drilling through drawing tube 102 mm dia. C axis - head spindle movement 0.001 degrees Y axis +/- 115 mm B Axis Movement -30/+195 degrees B axis spindle speed 12000 rpm B axis spindle effect 18.5 B axis tool system Capto C6 Sub-spindle C axis - counter pindle movement 0.001 degrees Engine power sub-spindle 26/22 Kw Total Power Consumption 99.9 kva Control Mazatrol 640 Fabr. Spindle Hours 7167 Hours Controlled in 6 Axes Accessories: ATC Tool magazine with 40 stations Hydr. Chuck main spindle 300 mm dia Hydr. Chuck Subspindle 300 mm dia  ...

Mazak Integrex 200 Y, 20 tool positions, x,y,z = 530,140,1065. 30 kW spindle motor, 35-4500 rpm, chuck size 210 mm, through-hole diameter 61 mm, under power

This 5-axis Mazak Integrex 100 IV ST was manufactured in 2011. It features a main spindle with a 6 hydraulic chuck, 4,000 rpm max speed, and 30 kW power. The second spindle matches these capabilities. Its milling spindle can reach up to 20,000 rpm. Includes a high-speed ATC with a 20-tool capacity, expandable to 120. Ideal for single-setup machining with its heavy-duty construction and MAZATROL MATRIX CNC control. Contact us for more information about this machine.

This MAZAK INTEGREX 200 IV S Lathe was manufactured in the year 2007. It is equipped with a Matrix control unit. The machines disposes od a spindle, a counter spindle, a milling spindle and a chip conveyor.

Control for Mazak Intergrex (new) Technical data see pictures Good condition fully functional can be visited on site and tried out. Shipping abroad. Visit: Basically I would like to point out that the article may be viewed and tested under power to exclude misunderstandings, like before you buy. Please ask questions before you purchase to avoid ambiguity. For general questions or an appointment for a visit I am at the below telephone number, available. Errors in the description and intermediate sale is reserved. Shipping with freight forwarding.

Ref. -No.: 10364 Manufacturer: MAZAK Year of construction: 1997 Type of control: CNC Control: MAZATROL T PLUS Storage location: Halberstadt Country of origin: Japan Machine length: 6365 mm Machine width: 3180 mm Machine Height: 2800 mm Weight Of The Machine Ca.: 7 t Bar passage: 64 mm Max rotation diameter: 510 mm Turning Diameter: 400 mm Turning Length: 1539 mm Spindle power: 22-26 kW Spindle Speed Min.: 35 RPM Spindle Speed Max.: 3500 RPM Rapid Travel Speed X-Axis: 12 m / min Rapid Travel Speed Y-Axis: 10 m / min Rapid Travel Speed Z-Axis: 18 m / min Motor power milling spindle: 7,5 kW Max. speed milling head: 15-6000 RPM X-axis travel: 450 mm Y-axis travel: +/- 90 mm Z-axis travel: 1539 mm Number of tools in the chain magazine: 40 (15 + 25) POS Further information: The main spindle was replaced with a new one in Oktober 2019. In the course of this, small spare parts were renewed or r ...

Key data: 670 mm, 1 mm

Smooth Ai Control Max. turning diameter: 670 mm Max. turning length: 1,011 mm Travel: X/Y/Z: 695/300/1,077 mm B: -30° to +210° (0.0001°) Main spindle drive power: 22 kW Main spindle max. speed: 5,000 rpm Milling spindle Drive power: 24 kW Milling spindle max. speed: 12,000 rpm Tool Magazine 74 Tool Positions Capto C6 Preparation for Renishaw RMP60 Chip Conveyor, Right Discharge Automatic door Air blow-out on the milling spindle Mazak API Cylinder interpolation Overload Monitoring Max. program size: 8 MB G00 slope constant 5-Axis Simultaneous Machining Package for Smooth Ai EIA/ISO Function Simultaneous 5-Axes Tool Center PointControl/Simult.5-Axes Fine Spiline Interpolation (EIA) MT connect adapter Smooth synchronised tapping Robot Interface (Advance/Ethernet/IP)

Key data: 760 mm, 1504 mm

Mazatrol Matrix Control max. turning diameter 760 mm max. turning length 1,504 mm Spindle motor main spindle 30 kW Max. speed main spindle 3,300 rpm C-axis, 0.0001° 3-jaw chuck, Kitagawa diam. 300 mm Y-axis 230 mm Spindle motor milling spindle 18.5 kW max. speed milling spindle 12,000 rpm B-axis, 0.0001° Tool changer with 40 stations Capto C6 System Hydraulic bezel, SMW Autoblok, clamping range up to 165 mm NC controlled tailstock, integrated MK5 rotating quill Tooleye Cooling by the milling spindle, 15 bar 3-jaw chuck Kitagawa B-15 Conveyor Dimensions L/W/H 4,912 mm/ 2,343 mm/ 2,798 mm Weight 12,800 kg CE mark

Key data: 750 mm, 1524 mm

Control Mazatrol Matrix Max. Rotary Diameter 760 mm Max. turning length 1,524 mm Travel X-axis: 630 mm Y-axis: 230 mm Z-axis: 1,585 mm W-axis: 1,530 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed 3,300 rpm C-axis Max. bar passage: 102 mm Sub-spindle Drive power: 26kW Max. spindle speed 4,000 rpm C-axis Milling spindle Drive power: 18.5 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 80 tool positions Max. tool diameter: 90/125 mm Max. tool length: 400 mm Max. tool weight: 10 kg Special equipment Cooling by the spindle High pressure pump 70 bar 20 l/min . PLC with 7 pressure levels Chip conveyor MAYFRAN CONSEP 2000 II 70 bar 20 l/min . PLC with 7 pressure levels Interface for bar feeder Automatic Parts Catcher Synchronized Threading ...

Key data: 660 mm, 1495 mm

Mazatrol Matrix Max. Rotary Diameter 660 mm Max. turning length 1,495 mm Travel X-axis: 580 mm Y-axis: 150 mm Z-axis: 1,545 mm W-axis: 1,490 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 22 kW Max. spindle speed 4,600 rpm C-axis Max. bar passage: 65 mm Sub-spindle Drive power: 18.5 kW Max. spindle speed 5,000 rpm C-axis Milling spindle Drive power: 18.5 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 120 tool positions Max. tool diameter: 90/125 mm Max. tool length: 300 mm Max. tool weight: 10 kg lower turret Drum turret 9 tool stations 6 powered tool stations Max. speed: 6,000 rpm Special equipment Mayfran Consep 2000 II Chip Conveyor, Double Switching Filter Preparation IKZ 70 bar 70 bar high pressure pump Milling spindle synchronized threading Cyl ...

turning diameter: 500 mm turning length: 1000 mm control: Mazatrol Smooth G number of spindle speeds: 5000 U/min spindle motor: 11/7,5 kW axis stroke (X,Y,Z): 450, 200, 960 mm travel -w axis: 950 mm b-axis: -30 / +210 ° c-axis: 360, 0,0001 ° bar material dia.: 65 mm milling spindle: spindle bore: 76 mm spindle turning speed range: 12000 U/min spindle motor: 7,5 / 5,5 kW tool taper: HSK A 63 rapid travel x/y/z: 40000 mm/min weight of the machine ca.: 9.5 t dimensions of the machine ca.: 3900 x 2600 x 2400 mm equipped with: - CNC control Mazak Smooth G - Main and counter spindle - milling spindle - Y-axis - Tool holder: HSK A 63 - Tool magazine: 72 places - Tool Eye - Mazak monitoring system B (RMP 60) - Coolant and compressed air (1.5 MPA) - Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 545 mm turning length: 753 mm control: Mazatrol Matrix 2 Main Spindle:: c-axis: 0,0001 ° spindle motor: 11 kW spindle turning speed range: 6000 U/min x-axis: 410 mm z-axis: 805 mm y-axis: 140 mm w-axis: 903 mm b-axis: 225 ° bar material dia.: 61 mm Rapid Travel X / Y / Z-Achse: 30/26/30 m/min 2nd Spindle:: c-axis: 0,0001 ° power capacity: 11 kW spindle turning speed range: 5000 U/min milling spindle: spindle turning speed range: 12000 U/min spindle motor: 5,5 kW total power requirement: 45,6 kVA weight of the machine ca.: 7,7 t dimensions of the machine ca.: 3,1 x 2,495 x 2,5 m 5-axis simultaneous machining - CNC control Mazatrol Matrix 2 - Main & counter spindle - 9-position tool turret - Tool changer (20-fold) - Capto C6 milling spindle - Coolant system IKZ 20bar - Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech ...

turning diameter: 658 mm workpiece length - max.: 1519 mm control: Mazatrol Matrix 2 swing diameter: 658 mm clamping range for bar work: 102 mm workpiece weight: 1000 kg ------------ MAIN SPINDLE ------------: turning speeds: 35 - 3300 U/min passage of spindle: 112 mm c-axis: 0,0001 spindle motor: 30/22 kW spindle nose: A2-8 milling spindle: spindle motor: 22 / 15 kW milling head speed: 12000 U/min b-axis: -30 / +210 ° travel -x axis: 615 mm travel -y axis: 260 mm travel -z axis: 1585 mm rapid travel x/y/z: 50 / 40 / 50 m/min 2nd Spindle:: spindle turning speed range: 4000 U/min spindle motor: 26 / 22 kW spindle nose: A2-8 spindle passage: 91 mm w-axis: 1539 mm total power requirement: 108,53 kVA weight of the machine ca.: 18 t dimensions of the machine ca.: 5,2 x 2,8 x 2,75 m - CNC control Mazatrol Matrix 2 - Main & counter spindle - Milling spindle (Capto C6) - 36-position tool cha ...

Control Mazatrol Smooth X 5-axis simultaneous machining Max. Rotary Diameter 658 mm Max. turning length 1,519 mm Travel X-axis: 615 mm Y-axis: 250 mm Z-axis: 1,585 mm W-axis: 1,574 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed 4,000 rpm C-axis Max. bar passage: 80 mm Sub-spindle Drive power: 26 kW Max. spindle speed 4,000 rpm C-axis Milling spindle Drive power: 22 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 72 tool positions Max. tool diameter: 90/125 mm Max. tool length: 400 mm Max. tool weight: 12 kg Special equipment Knoll Chip Conveyor Knoll coolant system with paper belt filter Preparation IKZ 70 bar 70 bar high-pressure pump, 7 pressure levels Air blowing device on the upper turret Milling spindle synchronized threading ...

Control Mazatrol Smooth X 5-axis simultaneous machining Max. Rotary Diameter 658 mm Max. turning length 1,519 mm Travel X-axis: 615 mm Y-axis: 250 mm Z-axis: 1,585 mm W-axis: 1,574 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed 4,000 rpm C-axis Max. bar passage: 80 mm Sub-spindle Drive power: 26 kW Max. spindle speed 4,000 rpm C-axis Milling spindle Drive power: 22 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 72 tool positions Max. tool diameter: 90/125 mm Max. tool length: 400 mm Max. tool weight: 12 kg Special equipment Knoll Chip Conveyor Knoll coolant system with paper belt filter Preparation IKZ 70 bar 70 bar high-pressure pump, 7 pressure levels Air blowing device on the upper turret Milling spindle synchronized threading ...

Year of construction 2017 Commissioning 06-2017 Control Mazatrol Smooth X 5-axis simultaneous machining Max. Rotary Diameter 658 mm Max. turning length 1,519 mm Travel X-axis: 615 mm Y-axis: 250 mm Z-axis: 1,585 mm W-axis: 1,574 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed 4,000 rpm C-axis Max. bar passage: 80 mm Sub-spindle Drive power: 26 kW Max. spindle speed 4,000 rpm C-axis Milling spindle Drive power: 24 kW (oil-air lubrication) Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 72 tool positions Max. tool diameter: 90/125 mm Max. tool length: 400 mm Max. tool weight: 12 kg Special equipment Mayfran Consep 2000 II Chip Conveyor, Double Switching Filter Preparation IKZ 70 bar 70 bar high-pressure pump, 7 pressure levels Air bl ...

Mazatrol Matrix Control Max. turning diameter 530 mm Max. machining length 500 mm Max. bar passage 52 mm Travel X/Y/Z 450/200/550 mm Main spindle max. speed 5,000 rpm C-axis Milling spindle max. speed 12,000 rpm B-axis -30°-190°, 1° indexing Capto C6 Tool Holder Tool magazine with 72 tool positions Max. tool diameter 90 mm Max. tool diameter with free secondary positions 125 mm Max. tool length 210 mm Tailstock MK5 Automatic Parts Catcher (D:65 x L:120 x 2.5KG) Automatic Tooleye Conveyor Cooling by the spindle, 70 bar Coolant system with 70 bar high-pressure pump and paper belt filter Milling spindle synchronized threading Rapid traverse stylus angle of inclination during movement Cylinder (G07) + Polar Interpolation (G12.1) Signal lamp 1 pcs Irco Bar Feeder ILS-MUK-7012 -Max. rod length: 1,200 mm 1 pc oil mist extraction
