4 MAZAK vertical processing centers used machines

Key data: 1050 mm, 510 mm, 510 mm

Inv. Num. : 7111 Type: NEXUS 510 C Producer: MAZAK Created: 2008 Parameters: Control system: MAZATROL MATRIX NEXUS Duty cycle: 14206 h Hours: 4777 h Work table length: 1300 mm Work table width: 550 mm Spindle drive power: 11 kW Speed: 12,000 rpm X-axis travel: 1050 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Cone: ISO 40 Number of stacking positions: 30 pieces Machine weight: 6886 kg Equipment: Tool Probe IKZ

Inv. Num. : 3505 Type: AJV-25/404 Producer: MAZAK Generated: Parameters: Control system: MAZATROL M-32 Work table length: 1240 mm Work table width: 550 mm Maximum table load (even): 800 kg Spindle drive power: 15 kW Minimum vertical spindle speed: 28 1/min Maximum vertical spindle speed: 4000 1/min Mechanical feed length axis X: 1000 mm Mechanical feed length axis Y: 508 mm Mechanical feed length axis Z: 460 mm Cone: ISO 40 Number of tools: 30 pieces Maximum tool diameter: 100 - 150 mm Max. tool weight: 8 kg Distance between uprights: 650 mm Accuracy: 0.02 mm Machine height: 3026 mm Machine length: 3810 mm Machine width: 2590 mm Machine weight: 8.1 t

Key data: 1050 mm, 510 mm, 510 mm

Inv. Num. : 9045 Type: VCN-510C Producer: MAZAK Created: 2005 Parameters: Control system: MAZATROL 640M NEXUS Work table length: 1300 mm Work table width: 550 mm Maximum table load (uniform): 1200 kg Speed: 12000 1/min X-axis travel: 1050 mm Y-axis travel: 510 mm Travel Z-axis: 510 mm Machine weight: 7100 kg

x-travel: 630 mm y-travel: 765 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Mazatrol Matrix 2-fold pallet changing device NC-swivel rotary table 80-fold tool changer high pressure coolant through the spindle 20bar chip conveyor Technische Daten / technical details: Verfahrweg X / X-Travel 630 mm Verfahrweg Y / Y-Travel 765 mm Verfahrweg Z / Z-Travel 510 mm Schwenkbereich A-Achse / swivel range A-axis -120 - +30 ° Drehbereich C-Achse / rotary range C-axis 360 ° Tischgröße / table size 500x500 mm Werkzeugschaft / spindle taper SK40 Drehzahl / spindle speed 35-12000 UpM /rpm Eilgang / rapid feed 50 m/min Anzahl der Werkzeugplätze / tool places in ATC 80 fach / fold Antriebsleistung Hauptantrieb / drive capacity main drive 26 kW Gewicht der Maschine ca. / weight 17000 Kg Technische Dat ...

Key data: 560 mm, 630 mm, 600 mm

Horizontal CNC Machining Center MAZAK PFH-4800 + 6APC Mazatrol PC FUSION 640 M Controller Year of manufacture 2004 6-fold pallet changer Pallet size: 400 mm x 400 mm Travel: X: 560 mm Y: 630 mm Z: 600 mm NC rotary table, 4th axis / 0.001° Distance pallet surface to spindle centre 80 mm – 710 mm Distance from pallet center to spindle nose 70 mm – 670 mm Spindle motor AC 30/22 kW Max. spindle speed 15,000 rpm SK-40, DIN69781 Tool changer with 240 tool positions, Tool Hive Multi Tool Loading 8 Tools Cooling by the spindle, 70 bar Separate coolant system with filter and high-pressure pump Chip conveyor, ejection to the rear CE mark

Key data: 1120 mm, 510 mm, 510 mm

For sale. Mazak vertical machining center type VTC-20B with Kitagwa integrated rotary axis. X-, Y- and Z-axis travels are 1,120 x 510 x 510 mm. Table size: 1410 x 510mm. Table capacity: 800Kg. Maximum speed is 6,000 rpm. SK-40 spindle holder. The number of tool positions is 24 pieces ATC, max. tool Ø / max. tool Ø 80 mm ditto for free places / max. tool Ø with free places besides 110 mm max. tool length 350 mm max. tool weight 8 kg Feed range xy / feed range xy 1-8000 mm/min. Vorschubbereich z / feed range z 1-8000 Mm/min. Rapid traverse X/Y / rapid feed X/Y 30 m/min. Drive power / drive capacity 15 kW Weight of the machine approx. / weight 6500 kg

Key data: 630 mm, 1100 mm, 600 mm

Clamping area: Ø700 x 500 mm Rapid traverse X/Y/Z: 60/60/56 m/min Milling spindle Max. spindle speed: 18,000 rpm SK-40 Other equipment Air on the workpiece Cooling by the spindle, 70 bar Renishaw RMP 600 Probe F) Tool tip control 5-axis simultaneous machining Tool radius compensation – 5-axis simultaneous Drilling cycle with torque-dependent chip breaking G00 slope constant Synch. Threading Cylinder interpolation EIA Dynamic Compensation 2 (included 1) KNOLL Coolant System KF200/1250 Paper Belt Filter 70 bar high-pressure pumoe KNOLL Chip Conveyor 640-S-1

The machine is in good technical condition, after prior agreement it is possible to test it. Matrix NEXUS 2- control system Pallets 2x YES. Chip conveyor Yes ATC- YES High pressure 70 Bar Spindle 10 125 hours •Total machine start-up 32 348 hours Pallet 630 × 630 mm Number of pallets 2 Max. workpiece size Ø 1050 × 1300 mm Max. pallet load 1500 kg X travel 1050 mm Y travel 900 mm Z travel 980 mm 4th axis Yes (NC rotary table) Spindle taper BT50 / CAT50 Spindle speed 8000 rpm (standard) Optional speed 10,000 rpm Spindle power approx. 37 kW Tool magazine 40–120 positions Control system Mazatrol Matrix Nexus 2 Production type Production series machining Typical applications Cabinets, cast iron, steel, automotive Machine weight approx. 20–22 t Automatic pallet change Yes

x-travel: mm y-travel: mm z-travel: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 560 mm, 510 mm, 510 mm

Inv. Num. : 9279 Type: HTC 400 Producer: MAZAK Created: 1998 Parameters: Control System: Mazatrol Work table length: 400 mm Work table width: 400 mm Maximum table load (even): 300 kg Spindle drive power: 5.5 kW Maximum spindle speed: 10000 1/min X-axis travel: 560 mm Y-axis travel: 510 mm Travel Z-axis: 510 mm Number of stacking positions: 24 pieces

x-travel: 2165 mm y-travel: 1600 mm z-travel: 1345 mm : 2300 mm Turning Speed of the Rolls: 2300 x 1684 mm : 7000 kg notching width: 300 1/min : 0,0001 ° Positioning speed: 10000 1/min : 37 /30 kW : 150 ° Feeds (X,z,u,w-axis): 0,0001 (360°) ° : ISO 50 : 42 Control: Mazatrol Smooth X Rapid Travel X / Y / Z-Achse: 42 m/min total power requirement: 141 kVA weight of the machine ca.: 51,5 t dimensions of the machine ca.: 4,4 x 5,2 , 7,8 m 5-axis multitasking machine featuring: - Mazatrol Smooth X CNC control - Direct-drive table with C-axis accuracy of 0.0001° - Milling spindle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Number of machnines: 10 0 Cycle time: . /min production capacity: . Control: . Everything must go due to business closure: High-quality machining centers (Deckel Maho, DMG, Mazak, Spinner) & accessories, cabinets, vices, material, grinding machines, EDM machine, measuring machine, on July 16, 2026 Dear Sir or Madam, dear business partners and interested parties, Due to the complete liquidation of the mechanical engineering company Schröter Maschinenbau GmbH, we are organizing an exclusive, one-day sale for the entire company, machine, and workshop equipment. Take this opportunity to acquire professional production facilities and extensive accessories directly from the location. Prospectus & Sale Overview: • Date: Thursday, July 16, 2026 • Time: 9:00 AM to 2:00 PM • Address: Lenneperstr. 188, 42855 Remscheid • Type of Sale: Direct sale against cash payment / or upon pickup an ...

x-travel: 1120 mm y-travel: 510 mm z-travel: 510 mm control: Mazatrol 640 M total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1660 mm y-travel: 510 mm z-travel: 510 mm control: Mazatrol 640M total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1660 mm y-travel: 510 mm z-travel: 510 mm control: Mazatrol 640M total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 500 mm z-travel: 550 mm Control: Mazatrol Smooth G spindle turning speed - stepless: 15000 U/min spindle motor: 11 kW distance table - lower edge spindle: 150 - 700 mm rapid traverse: 42 m/min table surface area: 1050 x 500 mm workpiece weight max.: 750 kg tool taper: CAT 40 total power requirement: kW weight of the machine ca.: 5,7 t dimensions of the machine ca.: m dimensions of the machine ca.: 3,34 x 2,33 x 2,9 m - CNC control Mazatrol Smooth G - 30-fold tool changer (CAT 40) - NIKKEN 4th Axis -ROBOJOB MA-PAL Robot with Controller & Accessories - Loading & Unloading Pallets - Swarf Conveyor & Swarf Bin. EXOMIST Mist Extractor - Renishaw Tool Setter - Renishaw Probe - Renishaw Receiving Unit - Peripheral Safety Guarding - Selection of Spindle Tooling - Set of Manuals. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1740 mm, 760 mm, 660 mm

Mazatrol PC Fusion CNC 640 M Control 30-fold tool changer SK-40 Tool holder according to DIN 69871 Automatic tool length measurement Cooling by the spindle Chip Conveyor, Right Discharge Detachable handwheel Rapid traverses X/Y/Z: 36 m/min CE mark

x-travel: 1660 mm y-travel: 510 mm z-travel: 510 mm Control: M+ Mazatrol Table dimensions: 2000x510 mm table load: max. 1.000 kg number of spindle speeds: 7.000 UpM tool taper: SK 40 tool piece magazine with: 48 Stück weight of the machine ca.: 7.500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Paletchanger 2 tafels Hoge druk koeling 15 bar Schroottransportband Maximale werkstukafmetingen: 3240 x 880 x 640 mm X-axis: 3000 mm Y-axis: 800 mm Z-axis: 585 mm Table dimensions: 3240 x 750 mm Max weight on the table: 3 ton Passage between uprights: 860 mm Admission in spindle (ISO): ISO 50 Power on the spindle: 30 kW Control : Mazatrol 640 Toolchanger: yes Number of toolholders: 40 positions Number of rotations: max 6000 rpm Number of pallets: (2x) 750 x 3240 mm Length: 3274 mm Depth: 8100 mm Height: 3546 mm Weight: 19 ton

hogedrukkoeling via de spindel spanentransporteur X-axis: 1660 mm Y-axis: 510 mm Z-axis: 510 mm Table dimensions: 2000 x 510 mm Max weight on the table: 1000 kg Admission in spindle (ISO): BT-40 Power on the spindle: 18,5 kW Control : Mazatrol 640M Toolchanger: yes Number of toolholders: 30 positions Number of rotations: 12 000 rpm Weight: 8250 kg

x-travel:1660 mm y-travel:760 mm z-travel:660 mm weight of the machine ca.:8700 t dimensions of the machine ca.:4.320 x 3.380 mm distance spindlenose - table min./max.:808 mm distance work spindle /surface of the table:155 - 815 mm Machine height:2850 mm floor space required (w/o switchgear cabinet):4.320 x 3.380 mm spindle motor:11 (10 Minuten) /7,5 (30 Minuten)/ 5,5 (Dauerbetrieb) kW tool taper:SK 40 Spindle RPM:40 - 7.000 (Standard ) / 40 - 10.000 ( Option ) 1/min surface area:2.000 x 760 mm max. table load:1.000 kg feeds X-axis:1 - 5.000 mm/min rapid traverse X-axis:24.000 m/min rapid traverse Y-axis:24.000 feeds Y-axis:1 - 5.000 mm/min feeds Z-axis:1 - 5.000 mm/min rapid traverse Z-axis:20.000 m/min

Mazak Integrex 200 lll S + GL 150 F CNC turning-milling center with second spindle CNC control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 rpm X-axis travel: 580 mm Y-axis travel 160 mm Z-axis travel: 1045 mm B-axis travel: 225 ° mm C-axis indexing 360° Spindle nose A2-6 Tool cone Capto C6 Number of tools in the magazine 40 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail.

X-axis: 3000 mm Y-axis: 800 mm Z-axis: 720 mm Rapid traverse: X/Y/Z axis: 50m/min Control: SIEMENS 840D Recording: SK40 Speed: 18,000 rpm Mileage: total approx. 5,000 hours (of which approx. 500 hours since the overhaul) Spindle motor: 321V - 116 A Work table: W 3500 x L 820 mm Dimensions: L 5250 x W 4046 mm Drives: SIEMENS The machine is a 5-axis machine, where the turntable is both vertical, as well as horizontally. - Subject to technical errors and prior sale. -

MAZAK QUICK TURN NEXUS 100MS CNC lathe was built in 2005 in Japan by YAMAZAKI MAZAK CORP. The machine, designed for precision machining of workpieces with a maximum diameter of 280 mm, is distinguished by the use of reliable components with excellent technical parameters, such as two spindles (main spindle and sub-spindle) and a 12-position turret. The machining process is performed inside a large, fully illuminated workspace by means of a powerful spindle with an integrated motor design that minimises vibrations at high speeds. This is all complemented by an intelligent CNC control that simplifies daily work by allowing even the most advanced machining programmes to be created in just a few steps. The MAZAK QTN-100MS CNC turning center weighs 4100 kg. Technical specifications of the MAZAK QUICK TURN NEXUS 100MS metal lathe - CNC control: MAZATROL 640T NEXUS - maximum turning diamet ...

control: MAZAK Mazatrol 640T Nexus swing over bed: 610 mm swing diameter over bed slide: 350 mm turning length: 982 mm c-axis: indexing: 0.001 ° turning speeds: 4000 U/min tool taper: ASA A2-8 tailstock quill taper MT: 5 rapid traverse X-axis: 30 m/min rapid traverse Z-axis: 33 m/min Overall size: 4500 x 2000 x 1600 mm weight of the machine ca.: 6.5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
