9 VOLLMER circular saw blade grinding machines used machines

Circular saw sharpening machine Vollmer Cne

Suitable for the automatic grinding of HM circular saw blades on the face and top in one setting. All known tooth geometries (flat, alternate, trapezoidal teeth, etc.) can be ground automatically and in one pass., Accessories:, Total enclosure,, Coolant system,, Equipment for robot operation with automatic loading door, ND 230 loader, Measuring device for measuring saw blades, Chip breaker grinding attachment, Stepless variable grinding speed of the two grinding spindles from 1600 to 5500 rpm., Grinding speed and grinding path stepless adjustable for each machining surface on the tooth., Automatic central lubrication, Software package for oscillation grinding at rake and clearance angles, Automatic shut-off flap, Automatic fire extinguishing system, Electrostatic oil mist separator N281, Measuring tool, Sawblade holder with guide bushing Ø 16 mm Saw holder >ø180, Sawblade holder with g ...

Automatic circular saw sharpening machine completely overhauled. For fully automatic sharpening of HM circular saw blades, of all common tooth shapes. Equipped for oil cooling, fire extinguishing equipment. Technical data: Circular saws Ø with robot 130 to 600, without robot 130 to 840 mm, tooth pitch with robot 8 to 50 mm, without robot 8 to 120 mm. Available on request with loader robot ND 230, extraction system.

Suitable for automatic, double-sided tooth flank grinding on carbide-tipped circular saw blades., Accessories:, Total enclosure., Coolant System,, Automatic central lubrication,, Expansion of diameter range from 80 – 1,430 mm!!, Circular sawblade outer diameter: 80 to 1430 mm, Circular sawblade bore diameter: 10 - 220 mm, sheet thickness: up to 14 mm, rake angle: -15° to +40°, Radial free angle: -6° to 6°, Tangential free angle: up to +8°, Grinding path: Max. 30 mm, Grinding speed: 0.5 - 20 mm/s, Tooth pitch: 6 - 120 mm, Grinding wheel diameter: 80 to 125 mm, Grinding wheel bore diameter: 32 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Dimensions W x D x H approx.: 2395 x 1590 x 1970 mm, colour: green/grey, Weight approx: 1750 kg

Automatic machine for chest and back grinding of carbide-tipped circular saw blades; Refurbished and repainted

Suitable for automatic grinding of tooth faces, tooth backs, and bases on carbide-tipped circular saw blades in a single setup. All common tooth geometries (flat, alternate, trapezoidal, etc.) can be ground automatically and in a single pass. Accessories: Full enclosure Measuring probe Grinding device with oil cooling Automatic fire extinguishing system Grinding mist extraction system N 183 Alphanumeric keypad Oil drip tray Machine light, saw diameter: 80-840 mm, Bore diameter: from 10 mm, sheet thickness: < 8 mm, Tooth pitch: 6 - 120 mm, Cutting length:

Description: 4-axis CNC controlled grinding machine, suitable for the automatic grinding of tooth faces and tooth backs on carbide-tipped circular saw blades., Accessories:, Coolant system,, Total enclosure,, Automatic central lubrication,, Hollow face grinding unit, mist extractor N183, Motor driven rake and clearance angle adjustment,, Machine lamp,, Oscillation grinding at tooth face and tooth clearance,, Multifunctions handwheel,, 2 grinding wheel flanges for face and top grinding,, 1 centering ring 40 mm,, 1 mounting mandrel., Circular saw hole diameter: 10 - 180 mm, Circular saw blade diameter: 80 to 840 mm, sawblade centrebore: 10 - 180 mm, Sheet thickness: up to 8 mm, Tooth pitch: up to 100 mm, mass: approx. 1660 kg, Rake angle: -10 ° to + 40 °, Clearance angle: from 5 ° to 45 °, Angled grinding on the back of the tooth: up to 45 °, Angled grinding on the tooth face: up to 1 ...

Suitable for automatic, double-sided tooth grinding of carbide-tipped circular saw blades., Accessories:, Wet grinding attachment,, Motorized rake angle adjustment,, 2 grinding wheel holders,, 1 mounting bolt., Circular saw blade outer diameter: 80 to 1270 mm, Circular saw drill diameter: 10 - 220 mm, sheet thickness: up to 14 mm, Tooth pitch: 6-120 mm, Grinding path: max. 16 mm, Cross angle : -15° to +40°, Tangential free angle: 0 to 5°, Grinding speed: 0.5 to 6 mm/s, grinding wheel diameter: 125 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Weight approx: 1300 kg, colour: green RAL 6011

Suitable for automatic, double-sided tooth grinding of carbide-tipped circular saw blades., Accessories:, Wet grinding attachment,, Motorized rake angle adjustment,, 2 grinding wheel holders,, 1 mounting bolt., Circular saw blade outer diameter: 80 to 1270 mm, Circular saw drill diameter: 10 - 220 mm, sheet thickness: up to 14 mm, Tooth pitch: 6-120 mm, Grinding path: max. 16 mm, Cross angle : -15° to +40°, Tangential free angle: 0 to 5°, Grinding speed: 0.5 to 6 mm/s, grinding wheel diameter: 125 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Weight approx: 1300 kg, colour: green RAL 6011

Circular Saw Blade Sharpening Machine Vollmer Type CNS Suitable for CV circular saw blades for straight and bevel grinding Grinding wheel diameter maximum 150 mm Saw blade diameter 90 – 600 mm Sharpening speed 3 speeds 30/60/80 teeth per minute Drive warping disc motor power 0.2 kW Drive Feed 0.4 kW Dimensions 800 mm x 900 mm x H 1800 mm Weight approx. 250 kg

saw blade diameter: - mm workpiece-spindlehead motor: 0,18 kW grinding wheel diameter: ? mm total power requirement: 0,18 kW weight of the machine ca.: 200 kg dimensions of the machine ca.: 0,8 * 0,5 * 1,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Sharpening machine Vollmer For circular saw blades Type CHC 25 H Year of manufacture 1985 Automatic sharpening machine for breast, back and free grinding Carbide-tipped circular saw blades Circular saws Outer diameter from 80 mm to 810 mm Bore diameters from 10 mm to 220 mm Blade thickness up to 5 mm Tooth pitch from 7 to 100 mm Rake angle from 6° to 45° Bevel grinding of tooth backs up to 45° Tooth breast up to 15° Grinding speed infinitely variable from 0.5 to 6 mm/s Working speed up to 18 teeth Grinding wheel diameter 125 mm Bore diameter 32 mm Circumferential speed 26 m/s Coolant pump flow rate 40 l/min. Connected load approx. 1.6 kW Areas of application Flat tooth at an angle on one side, left and right Interchangeable tooth, roof tooth, trapezoidal flat tooth, group tooth, Uneven tooth pitch, omitted teeth, format chipper saws Weight approx. 680  ...

Manufacturer: Vollmer, Type: CMS 13M, Year: 1994, Bore diameter: 5 - 50, Max. disk diameter in mm: 200, Min-max external diameter mm: 20 - 525, Min.-max. tooth pitch mm: 26 , Year :1994

length: ~ 700 mm width: ~ 600 mm height: ~ 2.000 mm Vollmer Junior B automatic bandsaw sharpener for sharpening bandsaw blades. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

total power requirement:0,55 kw Overall size:800 x 900 x 1600 mm Weight:220 kg accessories::mit Absaugung 0,2 kw

Vollmer electric line saw sharpener

Gate Sharper Manufacturer Vollmer for Inclined and straight ground

Vollmer CHHF 21 H - Machine for single-sided grinding Year of construction: 1989 S/N 907 Make: Vollmer Germany in good working condition The technical data of the CHHF 21H at a glance: Circular saw blades Outer diameter 80 to 700 mm Bore diameter 20 to 105 mm Tooth pitch from 8 mm Hook angle up to 30° Radial clearance angle -7° to +3° Tangential clearance angle up to 5° Connected load approx. 0.52 kW Weight approx. 85 kg Dimensions: 70 x 50 x 80 cm Cisei8tfrg This machine has been specially designed for the repair of lack of carbide teeth. Newly inserted tips are used in the existing teeth. With this tabletop version, VOLLMER offers a a particularly economical, space-saving solution. The CHHF 21 H works according to the wet grinding process. During the grinding process, the grinding unit manually moved over the tooth flanks, with the saw blade Saw blade ...

Used grinding machine Vollmer CABG 50U – built in 1995 – Very good condition For sale is a fully automatic gang saw sharpening machine from the quality manufacturer Vollmer. The machine is in very good condition, is fully functional and can be used immediately. Ideal for sawmills or woodworking companies with regular sharpening needs. Specifications: Model: Vollmer CABG 50U Year of Make: 1995 Machine Type: Automatic Gang Saw Blade Sharpener Condition: Very good, regularly serviced Saw blade width: Up to approx. 200 mm Saw blade length: Up to approx. 1650 mm Rake angle adjustment: Approx. -10° to +25° Tooth pitch: Adjustable (depending on the type of saw blade) Abrasives: CBN or diamond grinding wheels Grinding cycle: Fully automatic incl. infeed and return Control: Electronic with program selection Cooling: Integrated coolant supply Connected load: 400 V / 50 Hz ...

A Vollmer CNC 5-axis tool grinding machine for machining rotationally symmetrical solid carbide tools, milling cutters and drills is available. Grinding wheel interface: HSK50, max. workpiece diameter: 50mm, max. workpiece length: 265mm, max. grinding length: 200mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 350mm/450mm/500mm. Machine dimensions X/Y/Z: approx. 2200mm/2200mm/2800mm, weight: approx. 4900kg. Documentation available. An on-site inspection is possible.

A Vollmer CNC 5-axis tool grinding machine for the complete machining of solid carbide rotary tools is available. Tool holder: HSK50, tool positions: 8, max. workpiece length: 340mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 330mm/450mm/500mm, workpiece magazine: pallet magazine, workpiece capacity: 272. Machine dimensions X/Y/Z: approx. 2650mm/2800mm/2200mm, weight: approx. 5550kg, control: Vollmer. Including automatic HP160 workpiece magazine. Documentation available. An on-site inspection is possible.

A Vollmer CNC 5-axis tool grinding machine for the manufacture and regrinding of solid carbide rotary tools is available. Grinding spindle interface: HSK50, max. workpiece diameter: 100mm, max. workpiece length: 360mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 350mm/450mm/500mm, workpiece magazine: pallet magazine, workpiece capacity: 272. Machine dimensions X/Y/Z: approx. 2650mm/2800mm/2200mm, weight: approx. 5550kg, control system: Vollmer. Including automatic workpiece magazine HP160. Documentation available. An on-site inspection is possible.

A Vollmer CNC 5-axis tool grinding machine for the complete machining of solid carbide rotary tools is available. Tool holder: HSK50, tool positions: 8, max. workpiece length: 340mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 330mm/450mm/500mm, workpiece magazine: pallet magazine, workpiece capacity: 272. Machine dimensions X/Y/Z: approx. 2650mm/2800mm/2200mm, weight: approx. 5550kg, control: Vollmer. Including automatic HP160 workpiece magazine. Documentation available. An on-site inspection is possible.

Loading trolley for all Vollmer ND loading centers available in as-is condition, unpainted or completely new and freshly painted.

CNC-controlled erosion machine for the processing (erosion, grinding, polishing) of PCD tipped tools up to 400 mm diameter and 400 mm length, according to disc-electrical-erosion processes for use in service and in production., Accessories:, Total enclosure, Software path management, Filter system with chiller for dielectric fluid, Automatic fire extinguishing system DIN 14497, Standard programs for measuring, eroding etc., Program for chamfering of workpiece cutting edges,, Automatic Diagnosis program for machine operational status with text output on screen, Loader for workpieces, with CNC-controlled pivot for loading and unloading to a magazine,, 6 sided erosion wheel changer,, Workhead SK 50 with adapter to 12 HSK 63 A,, Turntable workpiece magazine for 12 workpieces SK 50,, Turntable workpiece magazine for 4 workpieces SK 50,, 6 flush sets, QXD250 CAD/CAM for external PC workstation ...
