Wire Cutting Spark Erosion Machine Tools used for sale (57)

Wire EDM Machine Agie Charmilles Cut 2000 BJ 2011

Manufacturer: Sodick Model: SL600Q Smart Linear Machine type: CNC Wire-Cut EDM Drive system: Linear Motor Drive Axes: X / Y / Z / U / V Control: Sodick CNC touchscreen control Manual control: Sodick handheld control unit Power supply: 200 V, 3-phase Frequency: 50/60 Hz Rated capacity: 13 kVA Full load current: 38 A RMS symmetrical current: 50 A Included: Machine documentation / instruction manual Condition: Used, powered on at time of inspection Remarks: Offered as pictured. Auction-ID: A1-51216-1

Key data: 400 mm, 300 mm, 220 mm

Manufacturer: SODICK Model No.: VL 400Q Year: 2020 Condition: Used Stock number: 9621 Max. travel length of the X-axis: 400 mm Max. travel length of the Y-axis: 300 mm Max. travel length of the Z-axis: 220 mm Feed length in U-axis (+-): 80 mm Feed length in the V-axis (+-): 80 mm Maximum wire gauge: 0.1 -0.3 mm Tank dimensions: 860 x 690 mm Machine height: 2020 mm Machine length: 1990 mm Machine width: 2310 mm Machine weight: 2750 kg

Auction-ID: A1-51216-69

Key data: 600 mm, 400 mm, 310 mm

Technical details Dimensions and weight Total weight: 3,500 kg Total length: 3,030 mm Overall width: 2,687 mm Total height: 2,150 mm Processable Material / Processable Products Wire diameter (max.): 0.3 mm Axle Specifications X-axis travel: 600 mm Y-axis travel: 400 mm Travel Z-axis: 310 mm

Manufacturer: Sodick Model: AQ55L Year: 2002 Machine type: CNC Die-Sinking EDM Drive system: 3-axis linear motor drive Axes: X / Y / Z Control: Sodick LN1 Linear Servo Controller Travel X / Y / Z: approx. 550 / 400 / 350 mm Work table: approx. 750 x 550 mm Max. workpiece weight: approx. 1,500 kg Max. electrode weight: approx. 50 kg Dielectric system: Integrated work tank with dielectric filtration system Machining system: CNC electrical discharge machining (EDM) Included: Sodick handheld control unit, machine documentation / maintenance manual Condition: Used, powered on at time of inspection Remarks: Offered as pictured. Auction-ID: A1-51216-3

Key data: 320 mm, 220 mm, 255 mm

Manufacturer: FANUC Model: Robocut Alpha-0iC A04B Year: 2006 Condition: Used Stock No: 9607 Control System: FANUC Series 180iS-WB Max. travel length of the X-axis: 320 mm Max. travel length of the Y-axis: 220 mm Max. travel length of the Z-axis: 255 mm Feed length in U-axis (+-): 120 mm Feed length in the V-axis (+-): 120 mm Maximum table load: 500 kg Machine weight: 2000 kg

Manufacturer: Sodick Model: AQ537L Premium Year: 2008 Machine type: CNC Wire-Cut EDM Drive system: Linear Motor Drive Control: Sodick LP33W CNC Travel X / Y / Z: 570 / 370 / 350 mm Travel U / V: 120 / 120 mm Max. workpiece dimensions: 770 x 520 x 340 mm (flushing); 770 x 520 x 280 mm (submerged) Max. workpiece weight: 1,000 kg Max. taper angle: ±25° / 100 mm Wire diameter: 0.15–0.30 mm Max. wire feed speed: 420 mm/s Wire tension: 3–23 N Work tank: approx. 1,050 x 710 mm Dielectric tank capacity: approx. 800 l Filtration: 3-filter system Automatic wire threading: Yes Power supply: 200/220 V, 3-phase, 50/60 Hz Total power input: approx. 10.5 kVA Display: 15.1\" TFT-LCD Approx. dimensions: 2,600 x 2,740 x 2,390 mm Approx. weight: 5,200 kg Included: Machine documentation / manuals Condition: Used, powered on at time of inspection Remarks: Offered as pictured. Auction-ID: A1-51216- ...

Starting Hole Wire EDM Machine WDS SB 2M

Cleancut EDM650 CNC Wire EDM & Eroding Machine Type: Wire EDM and eroding machine Manufacturer: Cleancut Model: EDM650 CNC Year of manufacture: 1999 Serial number: 904669 Electric connection: 380 V / 50-60 Hz Amps: 150 A Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51509-17

Key data: 600 mm, 400 mm, 310 mm

High-quality FANUC wire EDM machine in top condition. The machine is well-maintained, ready for operation and is suitable for precise wire EDM work in tool, mould and precision machine construction. Manufacturer: FANUC Model: ROBOCUT α-1iD Type: A04B-0320-B001 #E5 Machine No.: P089D1671 Year of manufacture: 09/2008 Control: FANUC Series 310iS-WA Machine Type: CNC Wire EDM Machine X-axis: 600 mm Y-axis: 400 mm Z-axis: 310 mm U-axis: 200 mm V-axis: 200 mm Rapid traverse X: 900 mm/min Rapid traverse Y: 900 mm/min Rapid traverse Z: 900 mm/min Rapid traverse U: 450 mm/min Rapid traverse V: 450 mm/min Max. workpiece weight: 1,000 kg Machine weight: 3,000 kg Mains connection: 200 V AC, 3-phase, 50/60 Hz Connected load: 13 kVA Automatic threading of the wire Processing in a full bath Suitable wire diameter: 0.10-0.30 mm Condition: Top Condition Location: Freiburg

AGIE AGIECUT Progress 2 CNC Wire EDM Machine | Year of manufacture 2003 For sale is an AGIE AGIECUT Progress 2 CNC wire EDM machine in industrial design. The machine comes from a production plant and was professionally dismantled. AGIE is one of the world's leading manufacturers of wire EDM machines and stands for the highest precision, reliability and process reliability. The AGIECUT Progress series is ideal for tool and mould making, precision parts, stamping tools and general mechanical engineering. Technical data Manufacturer: AGIE Model: AGIECUT Progress 2 Year of Make: 2003 Control: MC Progress Operating voltage: 3 × 400 V Frequency: 50 Hz Connected load: 12.1 kVA Rated current: 17.5 A Machine weight: approx. 2,650 kg Facilities CNC control MC Progress Automatic wire threading Original AGIE Generator Complete dielectric system Automatic wire feeder Wire Coil System Complete ...

Key data: 320 mm, 220 mm, 255 mm

Inv. Num. : 9242 Type: Alpha-0iC Producer: FANUC Created: 2005 Parameters: Control System: FANUC Series 180-is-WB Max. travel length of the X-axis: 320 mm Max. travel length of the Y-axis: 220 mm Max. travel length of the Z-axis: 255 mm Feed length in U-axis (-): 120 mm Feed length in the V-axis (-): 120 mm Max. workpiece weight: 500 kg Machine weight: 1200 kg

AGIE filter system / dielectric treatment DA-19 for wire EDM machine For sale is an original AGIE filter and dielectric treatment system type DA-19. The system is used to clean and reprocess the dielectric of AGIE wire EDM machines and is suitable as a spare part or for rebuilding existing machines. Technical data Manufacturer: AGIE Type: DA-19 Serial number: 063.004 Weight: approx. 430 kg Made in Switzerland Application area AGIE Wire EDM Machines Filtering of the dielectric Process water treatment Spare parts dispenser or repair Condition The plant comes from an industrial company and was removed from an AGIE EDM machine. The interior shows the usual signs of wear and tear and residues from the EDM process. Viewing possible by appointment. Functionality untested. Auction-ID: A1-51577-16

Wire EDM machine Sodick AQ 537L with few operating hours

AGIE AGIECUT Progress 2 CNC Wire EDM Machine | Year of manufacture 2004 For sale is an AGIE AGIECUT Progress 2 CNC wire EDM machine in industrial design. The machine comes from a production plant and has been professionally dismantled. The AGIECUT Progress series is one of AGIE's proven wire EDM machines and is suitable for tool and mould making, precision manufacturing and general mechanical engineering. Technical data Manufacturer: AGIE Model: AGIECUT Progress 2 Year of Make: 2004 Control: MC Progress Operating voltage: 3 × 400 V Frequency: 50 Hz Connected load: 12.1 kVA Rated current: 17.5 A Machine weight: approx. 2,650 kg Facilities CNC control MC Progress Automatic wire threading AGIE Wire Feeder System Original AGIE Generator Complete dielectric system Original control panel Precision Work Table Complete protective enclosure Condition The machine comes from an industrial co ...

Wire EDM machine Fanuc alpha IB BJ 2002

AGIE AGIECUT 150 HSS Wire EDM Machine – Year 1995 For sale is an AGIE AGIECUT 150 HSS CNC wire EDM machine. The machine comes from an industrial company and was taken out of service due to a change in operations. AGIE is one of the most renowned manufacturers of wire EDM machines and stands for the highest precision and reliability. Technical data Manufacturer: AGIE Model: AGIECUT 150 HSS Year of Make: 1995 Control: AGIEMATIC CF 50 SE Generator: AGIEPULS HSS Voltage: 3 × 400 V Frequency: 50 / 60 Hz Operating hours: approx. 69,713 h Travels X: 300 mm Y: 200 mm Z: 250 mm Workpiece Max. workpiece weight: approx. 550 kg Facilities CNC control AGIEMATIC CF 50 SE AGIEPULS HSS Generator Automatic Wire Threading (HSS) Dielectric tank Complete machine bed Control panel Control cabinet Cooling and filtration system Condition The machine is sold as used. It comes from a production hall ...

Key data: 600 mm, 400 mm, 350 mm

For sale Sodick CNC wire EDM machine type ALC 600G. Used CNC wire EDM machine with minimal soot traces. Type ALC600G Premium • With linear motors in X, Y, U and V directions • With Smart Pulse (SP) CNC generator • High-speed wire feeder unit • Smart Linear • Automatic wire feeder in 9 seconds • Triple filtration system •Jumbo 20kg wire roll feeder is standard • Smart control with 19" TFT multi touch screen Technical data machine: Travel X-Y axis: 600 x 400 mm Travel U-V axis: 150 x 150 mm Travel Z-axis: 350 mm Max. workpiece dimensions: 800 x 570 x 310 mm (in a water bath) 800 x 570 x 340 mm (coaxial flushing) Working tank dimensions: 1050 x 710 mm Max. workpiece weight: 1000 kg Distance between floor and top of the table: 995 mm Controlled axes: 5 (X, Y, Z, U, V) Max. positioning speed m/min: 2.0 Wire diameter ø: 0.1–0.3 mm (optionally 0 ...

Type: A04B-0312-B001#E5. Power: 13 KVA. Auction-ID: A1-51529-18

Control: FANUC Travel distance: X= 500, Y= 350 Z= 300 mm Max. table load: 350 kg Dimensions: 3500 x 2400 x 2400 mm Weight: 3,000 kg

Type: A04B-0309-B001/E5. Power: 13 KVA. Auction-ID: A1-51529-19

EDM machine Makino DUO64 vintage 2011.

Fanuc Tape Cut Model WO CNC Wire EDM Machine Manufacturer: Fanuc Ltd. Model: Tape Cut Model WO Type: A04B-0248-B042 Equipment type: CNC Wire EDM Machine Year: 1991 Serial number: P918W0443 Country of manufacture: Japan CNC wire electrical discharge machining (Wire EDM) machine designed for precision cutting of electrically conductive materials using a continuously fed wire electrode. Technical specifications: X-axis travel: 200 mm Y-axis travel: 350 mm Z-axis travel: 160 mm Connected load: 9 kVA Electrical supply: 200–550 V, 50/60 Hz Equipment / features: Fanuc CNC control Automatic wire-feed system Wire tension/feed equipment Dielectric / flushing system Enclosed machining tank and work area Operator control panel Approx. dimensions (L × W × H): 1,800 × 1,600 × 2,000 mm Approx. weight: 1,800 kg Condition: Used. Main machine, CNC control, wire-feed equipment and machining tan ...

Wire EDM Machine Charmilles Robofil 4030 SI BJ 2001

Jitem P-50 Wire EDM & Eroding Machine Type: Wire EDM and eroding machine Manufacturer: Jitem Model: P-50 X-axis travel: 400 mm Y-axis travel: 300 mm Z-axis travel: 400 mm Approx. dimensions (L x W x H): 2220 x 2300 x 2150 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51153-29

Max workpiece size 1030x800x350 mm Table size 950x630 mm Can be inspected under power

Charmilles Robofil 510 Wire EDM & Eroding Machine Type: Wire EDM and eroding machine Manufacturer: Charmilles Model: Robofil 510 Year of manufacture: 1995 Workpiece weight max.: 300 kg Electric connection: 380 V Approx. machine weight: 3350 kg Table dimensions: approx. 700 x 500 mm Maximum workpiece height: approx. 310 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51153-68

EDM machine Gantry Eagle 500 Year 2011 Travel: x/y/z = 525x400x450 Changer: 24 times Weight: 5000 kg

CONTROLS  CNC controls WORKING RANGE -WIRE CUTTING-  worpiece length max.: 1050 mm  worpiece width (max): 650 mm  workpiece height (max): 250 mm  X-axis travel: 550 mm  Y-axis travel: 350 mm  z-axis travel (vertical): 256 mm  U-axis travel: 140 mm  V-axis travel: 140 mmTABLE  workpiece load (max): 400 kgAXIS DRIVES  rapid traverse X: 3000 mm/min  rapid traverse Y: 3000 mm/minWIRE SYSTEM  wire diameter (min): 0.1 mm  wire diameter (max): 0.3 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2685 mm  space requirements -front/back-: 2115 mm  total height: 2247 mm  total weight approx.: 4500 kgMachine(s) in excellent condition, regularly serviced.X = High-precision versionUV ± 70 mmOne or two Agie Chamilles CUT 3000X machines are for sale.Both machines are automatically loa ...

Machine with water tank and automatic wire threading, cooling unit and software. XYZ axes 500 x 300 x 210 mm, taper +/- 15° at 100 mm height. Accessories: Dongel & laptop, various spare parts (nozzles, filters, etc.)

Jitem P-50 Wire EDM & Eroding Machine Type: Wire EDM and eroding machine Manufacturer: Jitem Model: P-50 X-axis travel: 400 mm Y-axis travel: 300 mm Z-axis travel: 400 mm Approx. dimensions (L x W x H): 2220 x 2300 x 2150 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51509-29

For sale is a good used CNC wire EDM machine of the brand Fanuc Robocut Alpha C600iB from November 2016. The EDM machine is immediately available. Prior sale and errors excepted.

table length: - mmtable width: - mmampere: Atotal power requirement: kWweight of the machine ca.: 5200 kgdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 450 mm, 320 mm, 162 mm

For sale Charmilles wire EDM machine type Robofil 4020.1. The machine is in very good condition. Still to be seen under power. Lots of accessories!

Cleancut EDM650 CNC Wire EDM & Eroding Machine Type: Wire EDM and eroding machine Manufacturer: Cleancut Model: EDM650 CNC Year of manufacture: 1999 Serial number: 904669 Electric connection: 380 V / 50-60 Hz Amps: 150 A Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51153-17

Key data: 320 mm, 220 mm, 180 mm

Inv. Num. : 6869 Type: Robocut 0iA Producer: FANUC Created: 2000 Parameters: Control system: FANUC Max. travel length of the X-axis: 320 mm Max. travel length of the Y-axis: 220 mm Max. travel length of the Z-axis: 180 mm Feed length in the U-axis ( -): 120 mm Feed length in the V-axis ( -): 120 mm Machine weight: 1200 kg

Key data: 250 mm, 400 mm, 210 mm

Inv. Num. : 2399 Type: 254Y/FF3 Producer: HITACHI Created: 2004 Parameters: Max. travel length of the X-axis: 250 mm Max. travel length of the Y-axis: 400 mm Max. travel length of the Z-axis: 210 mm Feed length in the U-axis ( -): -100 mm Feed length in the V-axis ( -): -100 mm Rapid traverse X/Y/Z: 1500 mm/min Max. workpiece dimensions: 600x400x210 mm Max. workpiece weight: 400 kg

X – Axis Travel (600 mm) Y – Axis Travel (400 mm) Z – Axis Travel (270 mm) U, V Axis Travel (80 x 80 mm) Wire Diameter Range (min ~ max) (0.10 ~ 0.30 mm) Work Tank Dimensions (W x D) (1040 x 780 mm) Maximum Workpiece Weight (850 kg)

Key data: 500 , 350 , 300

Travel X 500 / Y 350 / Z 300, Water bath machine, automatic wire threading, incl. 20 KG option incl. cooler

Travel x 350 mm y 250 mm z 220 mm Water bath machine Automatic wire threading Glass scales x / y incl. box for large coils incl. cooler incl. functional guarantee

FANUC ROBOCUT α-C800iB Wire EDM MachineTechnical Specifications:Max. Workpiece Dimensions: 1,250 × 975 × 300 mmMax. Workpiece Weight: 3,000 kgWire Diameter: 0.10–0.30 mmMax. Taper Angle: ±30° / 150 mmMax. Wire Spool Weight: 16 kg

Wire EDM SystemGF AgieCharmilles CUT 2000 with loading robot (WorkPartner)General InformationMachine type: CNC wire EDM machine with automationModel: CUT 2000Automation: GF WorkPartner loading robotControl: Vision 5 (Windows XP)Generator: AGIE IPG-V high-performance generatorOperating Hours Power On: 91,716 h Work On: 17,889 hWorking Area / TravelsX-axis: 350 mm Y-axis: 250 mm Z-axis: 256 mmU/V Axes Travel: ±70 mmWorkpiece DataMax. workpiece size (W × D × H): 750 × 550 × 250 mmMax. workpiece weight: 200 kg (standard), 400 kg (optional / bath load)Working table: 700 × 450 mmMachining ParametersTaper: 30° at 100 mm workpiece heightAvailable wire diameters: 0.10 – 0.30 mmBest achievable surface finish: Ra 0.05 µmWire threading: automaticDielectric SystemDielectric capacity: 700 litersFlushing: coaxial flushing systemCooling: external cooling requiredAutomationLoading robot: GF Wo ...

movement of X-axis: 500 mmmovement of Y-axis: 350 mmvert. movement Z-axis: 256 mmworkpiece weight max.: 800 kgweight of the machine ca.: 4.5 t: +/- 70 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Working range: 1.050 x 650 x 250 mmmax. workpiece weight: 400 (800) kgcontrol: Agievision AGIEmax. conicity: 30° / 100mm travel -x axis: 500 mmtravel -y axis: 350 mmtravel -z axis: 426 mmtravel U x V-axis: +/-70 / +/-70 mmrapid traverse X-axis: 3 m/minrapid traverse Y-axis: 3 m/minrapid traverse U-axis: 0,6 m/minrapid traverse V-axis: 0,6 m/minrapid traverse Z-axis: 0,6 m/minwire dia.: 0,2...0,33 mmtotal power requirement: 12,1 kVAweight of the machine ca.: 3,9 tdimensions of the machine ca.: 2,8 x 2,4 x 2,3 mDocuments: Wire Eroding MachineAGIE - Agiecut Progress 3 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
