used Engine Lathes (Sliding, Surfacing And Screw Cutting Lathes) for sale

Code 0782 Description Centerlathe Make A.I. Hembrug Model DR - 133 Serial No. DR 133 / F 4018 Year 1970 Distance between centers 750 mm Swing over bed 270 mm Swing over gap xxx mm Swing over crossslide 150 mm Spindle bore 35 mm Number of spindle speeds 28 Spindle speeds 18 – 3550 rpm Feeds Longitude and cross Motor power 3 kW – 380 Volts Thread cutting Metric, W.W., Modul and D.P. Accessoiries 3 chuck 2 x RSF DRO Condition Machine is in normal condition.

Description: Maximum distance between spindle and tailstock 1500 mmweight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 1,400 x 1,400 mm

Center height:165 mm Center width: 750 mm Spindle bore: 38 mm Bed width: 195 mm Speeds: (16) 35 - 2480 min-1 Motor power: 2.5 / 2.0 kW Tailstock mount: MK3 Quill stroke: 100 mm Dimensions, approx.: 1650 x 540 x 1450 mm Equipment: - 3-jaw lathe chuck - Emergency stop impact button - Quick release holder System Multifix - Bed stop - Reducing sleeve MK3, MK5 - Splash guard back panel - Interchangeable gears - Jaw chuck protection with limit switch - Coolant device - Operating tool - Service incl. oil change

turning diameter over bed: 400 mmturning diameter over slide rest: 280 mmturning length: 1000 mmturning diameter in the gap: mmturning speeds: 70 - 2000 U/mincentre height: 195 mmspindle bore: 54 mmtailstock quill taper MT: 3 MKconnected load frequency: 400 Vtotal power requirement: 2,2 kWweight of the machine ca.: 0.85 tdimensions of the machine ca.: 1,95 x 1,0 x 1,75 mProfessional industrial machine3-axis digital display3-jaw chuck 200 mm.4-jaw chuck 200 mm.Faceplate 280mmBezel fixedBezel rotating4-fold steel holder.Halogen machine lightMachine lightFoot brakeremovable chip tray, chip protection wallHardened and ground bed railsComplete coolant systemFeed protectionMachine feetMachine toolThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 350 mmturning diameter over slide rest: 450 mmturning length: 1000 mmturning diameter in the gap: 450 mmturning speeds: 70 - 2000 U/mincentre height: 175 mmspindle bore: 38 mmtotal power requirement: 2,2 kWweight of the machine ca.: 0,55 tdimensions of the machine ca.: 1,8 x 0,7 x 1,8 mCenter Lathe- 3-axis digital display- 3-jaw chuck 160mm- Multifix steel holder with 4 cassettes- Coolant system- Machine light- 2 pcs. bezelsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Tip width: 700 mm Tip height: 150 mm Circulation diameter over bed: 300 mm Bed width: 180 mm Spindle bore: 38 mm Mounting in the spindle bore: MK 5 Speed range, infinitely variable: 30 - 450 / 150 - 3000 rpm Range of longitudinal feeds: (14) 0.07 - 0.65 mm/U Area of plan feeds: (11) 0.03 - 0.12 mm/U Metric threads: (18) 0.2 - 3.5 mm Inch Thread: (21) 8 - 56 Gg/1" Pinole path: 85 mm Pinole holder: MK 3 Engine power S1 100%: 1.5 kW / 400 V Motor recording power S6 40%: 2.2 kW / 400 V Machine dimensions (W x D x H): 1380 x 640 x 500 mm Weight approx.: 235 kg without base Delivery: - Digital display - 3-jaw chuck PO3-160 mm steel version - Feed flange 160 mm - Solid grain tips - Interchangeable wheels - Quick-release steel holder size 20-2 with 2 straight inserts - Slip clutch - Micrometer longitudinal stop - Plan sled with top support - Frequency inverter ...

turning length: 1000 mmturning diameter: 410 mmswing diameter over bed slide: 255 mmturning dia. in gap: 580 mmspindle bore: 52.0 mmturning speeds: 30 - 3000 U/minbed width: 250 mmspindle taper: 55029 D 1-6taper in tailstock: 4 MKquill travel: 120 mmtotal power requirement: 5.5 kWweight of the machine ca.: 1550 kg.range L-W-H: 2100 x 1200 x 1450 mm from a training workshop good condition - new price approx. 14.000 euros Special price on requestCharacteristics :- Standard with delta frequency converter- for high torque in the lower speed range. and almost constant speed under load- Infinitely variable speed control- The set speed is read via a digital display- Prism bed made of gray cast iron, induction hardened and precision ground- Central, handy switching for feeds and threads- with lead and pull spindle- Modern main spindle bearing with precision angular contact ball bearings- Standa ...

turning length: 1000 mmturning diameter: 410 mmswing diameter over bed slide: 255 mmturning dia. in gap: 580 mmspindle bore: 52.0 mmturning speeds: 30 - 3000 U/minbed width: 250 mmspindle taper: 55029 D 1-6taper in tailstock: 4 MKquill travel: 120 mmtotal power requirement: 5.5 kWweight of the machine ca.: 1550 kg.range L-W-H: 2100 x 1200 x 1450 mm from a training workshop good condition - new price approx. 14.000 euros Special price on requestCharacteristics :- Standard with delta frequency converter- for high torque in the lower speed range. and almost constant speed under load- Infinitely variable speed control- The set speed is read via a digital display- Prism bed made of gray cast iron, induction hardened and precision ground- Central, handy switching for feeds and threads- with lead and pull spindle- Modern main spindle bearing with precision angular contact ball bearings- Standa ...

turning length: 1000 mmturning diameter: 410 mmswing diameter over bed slide: 255 mmturning dia. in gap: 580 mmspindle bore: 52.0 mmturning speeds: 30 - 3000 U/minbed width: 250 mmspindle taper: 55029 D 1-6taper in tailstock: 4 MKquill travel: 120 mmtotal power requirement: 5.5 kWweight of the machine ca.: 1550 kg.range L-W-H: 2100 x 1200 x 1450 mm from a training workshop good condition - new price approx. 14.000 euros Special price on requestCharacteristics :- Standard with delta frequency converter- for high torque in the lower speed range. and almost constant speed under load- Infinitely variable speed control- The set speed is read via a digital display- Prism bed made of gray cast iron, induction hardened and precision ground- Central, handy switching for feeds and threads- with lead and pull spindle- Modern main spindle bearing with precision angular contact ball bearings- Standa ...

turning length: 1500 mmturning diameter: 460 mmswing diameter over bed slide: 270 mmturning dia. in gap: 690 mmspindle bore: 80,0 mmturning speeds: 25 - 1700 U/minbed width: 300 mmspindle taper: DIN 55029 D 1-8taper in tailstock: 4 MKquill travel: 130 mmtotal power requirement: 5,5 kWweight of the machine ca.: 1845 kg.range L-W-H: 2750 x 1080 x 1600 mmDescription:The Solid 460 Pro universal lathe was specifically designed to be economicalManufacture of individual workpieces and small series with high precisiondesigned. Even the basic equipment includes all the important onesAccessories, which make this machine universally applicable.Scope of delivery :- 3-axis digital display ES-12 V with LCD display- 3-jaw chuck PS3-250 mm / D8- Clamping disk 450 mm- Coolant device- Initial filling with Shell Tellus 46- Fixed bezel - Passage diam. max. 150mm- Revolving bezel - Passage diam. max. 110mm- ...

turning length: 2000 mmcentre height: 330 mmswing diameter over bed slide: 660 mmswing diameter over slide rest: 460 mmturning dia. in gap: 900 mmspindle bore: 105 mmturning speeds: 25 - 1600 U/minbed width: 400 mmspindle taper: 55029 D 1-8taper in tailstock: 5 MKquill travel: 235 mmtotal power requirement: 7,5 kWweight of the machine ca.: 2900 kg.range L-W-H: 3630 x 1200 x 1520 mmscope of delivery- 3-axis digital display ES-12 V with LCD display- slip clutch- Rapid traverse lengthways and flat- LED machine light- 3-jaw steel chuck PO3-315 mm / D8- clamping disc 450 mm- Fixed bezel - passage diam. max. 180 mm- Live steady rest - passage diam. max. 120 mm- 2 center points- Motor with magnetic brake according to CE standard- Foot pedal with brake function according to CE- First filling with Shell Tellus 46- coolant device- Quick change tool holder with 4 inserts- Protective device for quic ...

turning diameter over bed: 490 mmturning diameter over slide rest: 280 mmturning length: 2000 mmcentre height: 245 mmcentre distance: 2000 mmspindle bore: 62 mmtotal power requirement: 7,5 kWweight of the machine ca.: 3,5 tdimensions of machine L x W x H: 3,78 x 1,17 x 1,42 mAccessories: 3-jaw chuck 240 mmø, face plate 400 mmø, MULTIFIX-tool post, solid steady, coolantThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 480 mmturning diameter over slide rest: . mmturning length: ca. 1000 mm3-jaw chuck: Röhm Ø 250 mmcentre height: 240 mmturning speeds: max. 2240 U/minspindle bore: 65 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mFeed protectionWork lightMultifix steel holder size. b1 removable cassetteIncludes three-jaw chuck with soft jawsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Including faceplate, multifix base holder, tailstock, digital displayDrehlänge: 549 mm, turning diameter over bed: 740 mm, turning diameter over slide: 540 mm, spindle bore: 130 mm, weight approx.: 5,500 kg, Approx. Onsite Dimension. (l x w x h): 8,000 x 800 x 2,000 mm

turning diameter over bed: 640 mmturning diameter over slide rest: 385 mmturning length: 3000 mmcenter height over bed: 315 mmcentre distance: 3000 mmdigital readout: 3-Achsen HEIDENHAINbed width: 450 mmspindle taper: KK 8 DIN 55022spindle bore: 82 mmturning speed range: 9 - 1800 U/minpower requirement: 22 kW3-jaw-chuck diameter: 400 mmquick change toolholder: MULTIFIX Typ Ctaper in tailstock-quill: MK 6 dia. of quill: 100 mmquill stroke: 280 mmcoolant: voltage: 400 Vtotal power requirement: 22 kWweight of the machine ca.: 6,5 tdimensions of the machine ca.: 5,70 x 1,80 x 1,90 mcoolant tank: 4,00 x 0,65 x 0,20 m- Serial-No.: 01192-01-808- NEW Bearings on Main Spindle- Main gearbox rebuilt, all gear shaft bearings renewed- guide ways of cross slide grinded and scraped - rapid traverse for Z, Z0 and X-Axis- autom. feed in top support- 3-jaw Chuck, wedge type SMW Ø 400 mm- 3-axis digital ...

No. 4620: 1 gebr. Guide and pull spindle lathe Fabr. BOLEY, Type 5 LZ, Arb.-Ber.: SpH 130 x 500 mm, Other: Spindle speeds: in 22 stages 28 - 2550 min-1 Space requirement: 1.5 x 0.9 x 1.25 m Weight ca 800 kg

Center height: 285 mm Center width: 1500 mm Circumferential Ø: above bed 580 mm Spindle bore: 72 mm Spindle mount: Size 8 Pick-up cone tailstock: 5 MK Spindle speeds: 20 - 2000 rpm Feeds: longitudinal/flat 0.05-16.32/0.025-8.16 mm/rev Thread pitches: 0.5 - 120 mm Electrical connection: 400 V, approx. 10 kW Dimensions: 3000 x 1250 x 1550 mm Weight: 2860 kg

turning diameter: 325 mmturning length: 1000 mmswing diameter over bed slide: 250 mmSwingdiameter in the bed bridge: 440 mmreus: 12 (85-2000) U/mintail stock: MK 3 quill stroke: 100 mmdiameter of quill: 40 mmspindle taper: DIN 55027 Nr. 5 spindle bore: 32 mmfeed: längs 0,006 - 1,77 m/minfeed: quer 0,003 - 0,885 m/mintotal power requirement: 2,2 kWweight of the machine ca.: 770 kgdimensions of the machine ca.: 2150 x 950 x 1350 mmFully equipped master and feed spindle lathes. TH 4215 withdigital position indicator DPA 21 / 3462070 - Hardened and ground Z-axis guideway- Spindle mount Camlock DIN ISO 702-2 No. 6- Precisely crafted slide- Hand wheels with adjustable fine scaling 0.04 / 0.02 mm- Quadruple steel holder- All guides can be adjusted using V-ledges- Adjustment range top slide ± 90°- Guaranteed concentricity of the spindle nose better than 0.015 mm- Main spindle running in oil b ...

turning diameter: 440 mmturning length: 1500 mmswing diameter over bed slide: 210 mmSwingdiameter in the bed bridge: 620 mmcentre height: 210 mmreus: 21 (20 - 2000) U/mintail stock: MK5 quill stroke: 180 mmdiameter of quill: 70 mmspindle taper: DIN 55027 Nr. 8 spindle bore: 62 mmfeed: längs 0,04 - 12 m/minfeed: quer 0,02 - 6 m/mintotal power requirement: 7,5 kWweight of the machine ca.: 2430 kgdimensions of the machine ca.: 2850 x 980 x 1330 mmFully equipped master and feed spindle lathes. TH 4215 withdigital position indicator DPA 21 / 3462070 - Hardened and ground Z-axis guideway- Spindle mount Camlock DIN ISO 702-2 No. 6- Precisely crafted slide- Hand wheels with adjustable fine scaling 0.04 / 0.02 mm- Quadruple steel holder- All guides can be adjusted using V-ledges- Adjustment range top slide ± 90°- Guaranteed concentricity of the spindle nose better than 0.015 mm- Main spindle r ...

turning diameter: 660 mmturning length: 1500 mmswing diameter over bed slide: 420 mmSwingdiameter in the bed bridge: 850 mmcentre height: 330 mmreus: 15 (9 - 1320) U/mintail stock: MK6 quill stroke: 225 mmdiameter of quill: 105 mmspindle bore: 103 mmfeed: längs 0,039 - 18 m/minfeed: quer 0,02 - 9 m/mintotal power requirement: 11 kWweight of the machine ca.: 4170 kgdimensions of the machine ca.: 2850 x 980 x 1330 mm- Coolant device- Machine light- Chip back wall- Spindle protection- Lathe chuck protection- Tool holder protection- Interchangeable gearsSpecial equipment- 3-jaw chuck Ø 250 mm type 3204/ DIN6350, BISON- MULTIFIX quick-change holder type B, including 4 tool holders- 3-axis digital display DRO Newall- Foot pedal with brake function CEThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 760 mmturning length: 3000 mmswing diameter over bed slide: 520 mmcentre height: 380 mmreus: 17 (7,5 - 1015) U/mintail stock: MK6 quill stroke: 225 mmdiameter of quill: 105 mmspindle bore: 132 mmfeed: längs 0,039 - 18 mm/minfeed: quer 0,02 - 9 mm/mintotal power requirement: 15 kWweight of the machine ca.: 4700 kgdimensions of the machine ca.: 4900 x 1650 x 1650 mm- Coolant device- Machine light- Chip back wall- Spindle protection- Lathe chuck protection- Tool holder protection- Interchangeable gearsSpecial equipment- 3-jaw chuck Ø 250 mm type 3204/ DIN6350, BISON- MULTIFIX quick-change holder type B, including 4 tool holders- 3-axis digital display DRO Newall- Foot pedal with brake function CEThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 440 mmturning length: 1000 mmswing diameter over bed slide: 210 mmSwingdiameter in the bed bridge: 620 mmcentre height: 210 mmreus: 21 (20 - 2000) U/mintail stock: MK5 quill stroke: 180 mmdiameter of quill: 70 mmspindle taper: DIN 55027 Nr. 8 spindle bore: 62 mmfeed: längs 0,04 - 12 m/minfeed: quer 0,02 - 6 m/mintotal power requirement: 7,5 kWweight of the machine ca.: 2250 kgdimensions of the machine ca.: 2450 x 980 x 1330 mm- Coolant device- Machine light- Chip back wall- Spindle protection- Lathe chuck protection- Tool holder protection- Interchangeable gearsSpecial equipment- 3-jaw chuck Ø 250 mm type 3204/ DIN6350, BISON- MULTIFIX quick-change holder type B, including 4 tool holders- 3-axis digital display DRO Newall- Foot pedal with brake function CEThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Slotting machine CABE 170 ST -Stroke adjustable up to max. 170mm -Projection to the middle of tool holder +- 275mm -Swivel butt head Right/Left -Rotary table - three-jaw chuck approx. 200mm -Tool cabinet with approx. 30 pieces - Push chisel Dimensions: LxWxH 1.1x0.7x1.7 meters Weight approx. 700Kg Blv0xavcuuo

Description: Distance entre les points 2m Collection on: 29/04/2024  ,  ,Collection times by arrangement  , IMPORTANT: Collection times may vary if separate collection times are explicitly stated in , in the item descriptionweight approx.: 2,100 kg, Approx. Onsite Dimension. (l x w x h): 3,405 x 1,175 x 1,295 mm

Machine Details Warehouse number 1105-03364 Machine type lead and pull spindle lathe Make CAZENEUVE Type HB 525 X 1000 Year of construction 1965 Conventional control type Storage location HAGUENAU Country of origin France Delivery time Immediate Freight base EX WAREHOUSE Technical details Turning diameter over bed 500 mm Turning diameter via support 220 mm Turning length 1000 mm Spindle speeds 25-2000 rpm various accessories YES Information IN GOOD WORKING CONDITION LOT OFF ACCESSORIS WITH MULTIFIXE TOOL HOLDER SYSTEMS

turning diameter over bed: 500 mmturning diameter over slide rest: 280 mmturning length: 1000 mmcentre height: 250 mmturning speeds: 2500 U/mintotal power requirement: 9 kWweight of the machine ca.: 1,9 trequired space: 2,5 x 1,25 x 1,6 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Distance between points: 1m500 With display Collection on: 29/04/2024  ,  ,Collection times by arrangement  , IMPORTANT: Collection times may vary if separate collection times are explicitly stated in , in the item descriptionweight approx.: 2,700 kg, Approx. Onsite Dimension. (l x w x h): 2,640 x 1,270 x 1,360 mm

IN THE RETROFITTING PHASE Height tips 900 mm Point distance 7,000 mm Turnerable diameter on the bench 1,850 mm Turnerable diameter on trolley 1,350 mm Turnerable diameter on recess 2,150 mm Bench width 1,000 mm Bar passage diameter 206 mm ASA A1 15" spindle attachment Top speed 300 RPM Diameter of the tank counterpoint 220 mm Row stroke counterpoint 450 mm Withworth threads - metrics - diametrics - module Weight allowed between tips without lunettes 15 ton Weight allowed between tips with a 20-ton bezel

peak heights: 250 mm point distance: 1500 mm bar pass: 105 mm

: 0460 mm: 270 mm: 1500 mm: 230 mm: 76 mm: 11 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0460 mm: 270 mm: 1500 mm: 230 mm: 76 mm: 11 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 360 mmcentre height: 170 mmcentre distance: 650 mmturning dia. over face-slide: 196 mmspindle bore: 42 mminner taper MT: 5 spindle turning speed - stepless: 20-3250 U/minweight of the machine ca.: 1,6 tdimensions of the machine ca.: 200 x 125 x 165 cmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 350 mmturning diameter over slide rest: 196 mmturning length: 1250 mmturning speeds: 3250 U/mindigital readout: bed width: 350 mmtotal power requirement: 7,5 kWweight of the machine ca.: tdimensions of the machine ca.: 8x2x1,8 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0350 mm: 196 mm: 0650 mm: 170 mm: 42 mm: 7,5 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0350 mm: 196 mm: 0650 mm: 170 mm: 42 mm: 7,5 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. turning length: approx. 2000 mm, centre height: approx. 300 mm, hollow spindle diameter: approx. 100 mm, with Multifix clamping system

: 0554 mm: 370 mm: 2000 mm: 280 mm: 104 mm: 11 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0554 mm: 370 mm: 3000 mm: 280 mm: 104 mm: 11 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0330 mm: 210 mm: 0635 mm: 167 mm: 40 mm: 2,2 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0330 mm: 210 mm: 1000 mm: 167 mm: 40 mm: 2,2 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0330 mm: 210 mm: 0635 mm: 167 mm: 40 mm: 2,2 kWspindle turning speed - stepless: 30-3000 U/minThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Center width: approx. 500 mm Diameter over bed: approx. 330 mm Diameter above support: approx. 160 mm Through-hole: approx. 40 mm diameter Speed range: 34 - 1500 rpm With accessories as shown in the pictures, including various three-jaw chucks and four-jaw chucks and 2 face plates Diameter of the face plates: approx. 300 mm Example diameter of three-jaw chuck: approx. 205 mm Example diameter of four-jaw chuck: approx. 255 mm With various steady rests and other accessories as shown in the pictures Dimensions of the lathe: approx. 1550 x 1000 x 1400 mmweight approx.: 1,400 kg, Approx. Onsite Dimension. (l x w x h): 2,750 x 1,000 x 1,400 mm

1 x L+Z lathe Colchester Mascot 1600/600 Built: c.1975 Very stable lathe. Ideal machine for locksmiths or agricultural machine mechanics. Technical data: Turning diameter over crimson: 710 mm Turning diameter over bed:432 mm Turning diameter via support:267 mm Turning length: 1,000 mm Spindle speeds:20 - 1600 rpm Spindle bore:76 mm Drive motor:5.6 kW Feeds: 0.6 - 10 mm/u Metric threads: 40 (0.4 - 14 mm incline) Machine weight approx.:2000 kg Room requirements approx.:l:2.65 x w:1.1 x h:1.6 m Accessories: 3 - Jaw lining UVA 310 mm 4 Set of change jaws Bfraed8ae0 Tripan quick-change system 4 x Interchangeable holder running counter tip in tailstock (MK 5) Countertip in spindle Alternating wheels Manual Mudguard complete documentation The machine can be inspected at our warehouse in Reichenbach under electricity.

Used lathe Internal machine number m3533 Manufacturer: Colchester Type Triumph 2000 Ma.Number 36658 Center width 750 mm Center height 190 mm Spindle bore 54 mm Speeds 25 to 2,000 rpm. Weight approx. 1,200 kg With cabinet and accessories Location: 59425 Unna The machine can be viewed and tried out under electricity. We will be happy to send you more photos by e-mail. A forklift for loading is available. We reserve the right to sell in advance. It is possible to expertly inspect the items for sale on site. Specific questions should be clarified in advance. The information, such as technical data, dimensions, year of construction, condition are non-binding and have been shown to the best of our knowledge and belief. Errors are therefore reserved. The warranty/guarantee is excluded. The goods are sold from the location / warehouse, with the transfer of risk to ...

: 0400 mm: 246 mm: 1250 mm: 195 mm: 54 mm: 7,5 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 400 mmcentre height: 195 mmturning diameter over slide rest: 246 mmturning length: 650 mmspindle turning speed - stepless: 0-2500 U/mintotal power requirement: 7,5 kWweight of the machine ca.: 1,8 tdimensions of the machine ca.: 2x1.3x1.6 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 800 mmturning diameter over slide rest: 580 mmturning length: 3.000 mmcenter height over bed: 400 mmcentre distance: 3.000 mmdigital readout: 3-Achsen HEIDENHAINbed width: 400 mmspindle bore: 110 mmturning speed range: 25 - 1.610 U/minpower requirement: 9,2 kW3-jaw-chuck diameter: 315 mmquick change toolholder: MULTIFIX Typ Ctaper in tailstock-quill: MK 5 dia. of quill: 100 mmquill stroke: 340 mmcoolant: voltage: 380 Vweight of the machine ca.: 3,6 tdimensions of the machine ca.: 4,90 x 1,60 x 2,00 m- Serial No.: 7634- Rapid feed for Z- and X-Axis- 3-Axis DRO System HEIDENHAIN- 3-Jaw Chuck FORKARDT F+315, dia.31 5mm- Quich Change Tool Holders MULTIFIX- fixed steady rest - rotating center- Face chuck, dia. 800 mm- various tool holders- Coolant equipmentMachine is in excellent condition!The data for this ad was created with ModulMWS - the software solution of Lo ...

Tip height: 107 mm top width: 350 mm circular diameter: bed 200 mm spindle bore: 25 mm taper tailstock: 2 MK spindle speed: 35 - 3500 rpm feeds: longitudinal and mm/U thread pitches plan: 0.2-3 mm electrical connection: 380 V, approx. 2.2 kW space: 600 x 1300 x 1230 mm weight: 850 kg

Description: Serial number F2015, including 3-jaw chuck, diameter approx. 310 mm, a Multifix basic holder and a 2-axis digital display Manufacturer SINO SDS 2-2L, and a tailstockDrehlänge: 2,100 mm, turning diameter over bed: 500 mm, turning diameter over slide: 300 mm, spindle bore: 100 mm, weight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 3,700 x 1,100 x 1,600 mm

: Aufnahmen Divers K50 Diameter: 50 mm: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
