Inv. Num: 5407 Type: 8000 Series Producer: MultiCam Generated: 2013 Parameters: Working table length: 4293 mm Working table width: 2200 mm Number of synchronized axes: 5 pieces Tool magazine: 12 pieces Maximum distance between the spindle and the table: 24000 mm Max workpiece dimensions: 2600x2050x800 mm 2020: GO at the spindle Vacuum table with grid Electric HSD spindle head
Control: HEIDENHAIN ITNC 530 Travel: X-axis: 670 mm Y-axis: 830 mm Z-axis: 600 mm A +120° to -120°, C 360° Workspace Turntable diameter 800 mm, 9 T-slots, Table load 1200 kg, Tool changer Tool holder: HSK-A 63 96-fold tool changer Tool length max.: 300 mm Tool diameter max.: 75 mm Tool diameter with adjacent empty station max.: 125 mm Tool weight max.: 7 kg Tool change time: 3 s Rapid traverse and feed Express feed X Y Z 60 m/min, + max. speed A-axis 50 rpm C-axis 100 rpm Acceleration X Y Z max. 7 ms², General data Repeatability/positioning accuracy for new delivery 0.004 mm/0.008 mm (VDI/DGQ 3441) incl. tool holders with tools on the tool changer, Oil mist extraction IKZ Conveyor Nominal power 90 kVA Full load current 125 A max. current load 200 A 400 V 50 Hz
Inv. Num. : 7212 Type: MF 630C Producer: Quaser Created: 2015 Parameters: Control system: Siemens 828D Table diameter: 500 mm Number of synchronized axes: 5 pieces Maximum vertical spindle speed: 12000 1/min X-axis travel: 800 mm Y-axis travel: 700 mm Z-axis travel: 610 mm Cone: SK 40 Maximum tool length: 280 mm Workpiece diameter: 630 mm Maximum tool diameter: 76.2 mm Max. tool weight: 7 kg Machine weight: 8750 kg Equipment: Tools Workpiece Probe Renishaw OMP40 ECO Cooler Rinsing gun Rinsing chips from the work area Spiral conveyors
Inv. Num. : 6291 Type: MF630/15C Producer: Quaser Generated: 2017 Parameters: Control system: Heidenhain iTNC 640 Number of synchronized axes: 5pcs Minimum vertical spindle speed: 20 1/min Maximum vertical spindle speed: 15000 1/min Travel X-axis: 800 mm Travel Y-axis: 700 mm Travel Z-axis: 610 mm Maximum tool weight: 300 kg Machine height: 2530 mm Machine length: 3710 mm Machine width: 3230 mm Machine weight: 9050 kg Equipment: Workpiece probe Renishaw Jigs Axis X Y Z C A Tools
Control: HEIDENHAIN iTNC-530 x-travel: 885 mmy-travel: 800 mmz-travel: 520 mmB-axis (table): +30/-120 °c-axis: 360 °table-size: 600x500 mmtool magazin:: 60 spindle taper ISO: 40 Big Plusspindle turning speed - stepless: 15000 U/mintotal power requirement: 25 kWrapid travel x/y/z: 36 mm/minrapid traverse (slewing motion): 60 U/minrapid traverse feeds rotary table: 100 U/mindimensions of the machine ca.: 3.8x3.6x3.0 mweight of the machine ca.: 12,1 tCoolant through spindle: pressure: 20 bar3D measuring tracer: RENISHAW Chip conveyor: Coolant installation: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Control: HEIDENHAIN iTNC-530 for axes: 5 x-travel: 712 mmy-travel: 508 mmz-travel: 515 mm-A-axis table swivelling: +30/-120 °-C-axis table rotating: 360 °rotary table dia.: 330 mmno. of tools in magazin: 60 max. tool diameter: 88 mmmax. tool-dia with free toolbox: 125 mmmax. tool length: 280 mmmax. tool weight: 7 kgspindle taper: SK40 Big Plus spindle turning speed range: -15000 U/minpower capacity - milling spindle: 25 kWweight of the machine ca.: 12.8 tdimensions of the machine ca.: 303x395x367 cm3D measuring tracer: RENISHAW Zero point clamping system:: LANG TECHNIK Coolant through spindle: pressure: 20 barThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Control: HEIDENHAIN iTNC530 x-travel: 1500 mmy-travel: 800 mmz-travel: 1000 mmspindle head swivable left - right: 0-180 °c-axis: 360 (0.001) °b-axis: +/-90 (0.001) °table-size: 1430X800 mmtable diameter: 802 mmworkpiece weight max.: 1500 kgtool magazin:: 60 spindle turning speed range: -16000 U/minspindle taper: HSK63 feeds x/y/z -stepless: 0-30000 mm/minfeeds rotary table: 20 U/mindimensions of the machine ca.: 4x3.5x3 mweight of the machine ca.: 18 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CONTROLS CNC controls HEIDENHAIN I TNC 530 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 5 X-axis travel: 1500 mm Y-axis travel: 800 mm Z-axis travel: 1000 mm rotating range B-axis from: 90 ° rotating range B-axis up to: -90 ° rotating range C-axis from: 0 ° rotating range C-axis up to: 360 °TABLE table surface (left-right): 1480 mm table surface (front-back): 800 mm clamping surface diameter: 802 mm workpiece load (max): 1500 kgSPINDLE / HEAD spindle revolutions (max): 16000 /min tool fixture: HSK A63 drive power: 48 kWTOOL MAGAZINE number of positions: 60 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS ...
CONTROLS CNC controls HEIDENHAIN ITNC 640 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 5 .. among of them simultaneous CNC axes: 5 X-axis travel: 1300 mm Y-axis travel: 1450 mm Z-axis travel: 1000 mm rotating range A-axis from: -1 ° rotating range A-axis up to: 90 ° rotating range C-axis from: 0 ° rotating range C-axis up to: 360 °TABLE table surface (left-right): 1200 mm table surface (front-back): 1000 mm clamping surface diameter: 1200 mmSPINDLE / HEAD spindle revolutions (max): 12000 /min tool fixture: HSK A100 AXIS DRIVES rotation speed C-axis: 400 /minTOOL MAGAZINE number of positions: 103 ELECTRICAL SPECIFICATIONS mains voltage: 400 V&nb ...
Inv. Num. : 7446 Type: DYNAMIC FC 3000 CNC Producer: SAHOS Created: 2011 Parameters: Control system: HEIDENHAIN Spindle drive power: 18 kW X-axis travel: 3000 mm Y-axis travel: 1500 mm Z-axis travel: 1070 mm
Inv. Num. : 7445 Type: DYNAMIC FC 4000 CNC Producer: SAHOS Created: 2015 Parameters: Control system: HEIDENHAIN Work table length: 4000 mm Work table width: 1500 mm Machine weight: 10,500 kg
Inv. Num. : 7444 Type: FC 10000 CNC 5X Producer: SAHOS Created: 2008 Parameters: Control system: HEIDENHAIN Spindle drive power: 22 kW X-axis travel: 10000 mm Y-axis travel: 3000 mm Z-axis travel: 2000 mm Maximum feed speed axis X: 60 m/min Maximum feed speed axis Y: 30 m/min Maximum feed speed axis Z: 30 m/min Machine weight: 14,500 kg
Description: b-axis -5 / +100 ° c-axis + / - 360 ° Clamping surface Ø 630 x 500 mm Table load max. 200 kg Total power requirement 38 KVA Description: manual. handwheel Spindle oil cooling system Coolant filter system with Ruma centrifuge Kraft & Bauer fire extinguishing system (incl. extinguishing agent bottle) Elbaron air purification system 4 machine feetz-motion: 400 mm, x-motion: 500 mm, y-motion: 450 mm, control: SIN 840 D, taper: DIN 69893 HSK-A63, toolchanger positions: 16, turning speed range: 10,000 rpm, weight approx.: 5,000 kg, Approx. Onsite Dimension. (l x w x h): 5,000 x 5,500 x 2,500 mm
x-travel: 230 mmz-travel: 640 mmturning length: 600 mmturning diameter: 310 mmrod passage: 65 mmmachine weight ab.: 4200 kgdimensions: 2700 x 1440 x 1620 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Ref. -No.: 10286Manufacturer: STARRAG HECKERTYear of construction: 2007Type of control: CNCControl: Siemens Sinumerik 840 DStorage location: HalberstadtCountry of origin: SchweizMachine-No.: 24139 X-Travel: 2800 mmY-Travel: 2100 mmZ-Travel: 1900 mmTable Dimensions (Lengthxwidth): 2 x 1.250 x 1.600 mmMax. Tool Weight: 35 kgWorkpiece Diameter At Full Load: 110 mmTool Piece Magazine With: 60 Pcs./pcs.Tool dimensions (with occupied adjacent spaces): 125 mmNumbers Of Pallets: 2 Operating hours: 26180 Hspindle running time: 26180h 43m 46s h/m/sautomatic mode: 28559 Hon time: 120 Hpallet change time: 60 sFurther information:internal coolant supply
