grinding machines wood used for sale (671)

CATALOG NUMBER 6145 TECHNICAL DATA - max workpiece width 1100mm - max workpiece height 140mm 3 aggregates: 1) grooved rubber roller for 15kW calibration 2) grooved rubber roller for 11kW calibration 3) grooved rubber roller for 11kW calibration in advance: - metal skid roller - rubber skid roller - aggregate - 2 rubber rollers, sliding - aggregate - 2 rubber skid rollers - aggregate - rubber skid roller from down: - feeding table 3600x1000mm - feed speed adjustable on the inverter 0.25kW - pulling tape - 3 rubber rollers, sliding, leading out - oscillation of pneumatic strips on photocells - blowing off the tapes - electric table lifting - 0.75kW motor lifting - smooth regulation of the feed speed - 2.2kW feed motor - with a vacum pump - 4kW pump motor - diameter of the extraction port 110mm, 80mm - working pressure 6-8bar - diameter of the extraction port 3 ...

Weibert KS30 Edge grinding machine with oscillation, rotary star and veneer cut with rotary star 60-100-120mm WEIBERT WJ-KS30 new 400V 3 KW (4 hp) n=2840 min Work table 960x350 mm Table height adjustment 230 mm Abrasive back wall 1050x200 mm Band speed 20 m/sec Oscillation stroke 20 mm Oscillation motor 0.25 KW (0.34 hp) Can be switched on/off Machine table and guides made of GRAUGUSS Quick adjustment of the swivel 90°-45° with degree display Weight of 400 kg Suction nozzles 120 mm Rotary star with 3 additional contact rollers 60-100-120mm Bandwidth 150 mm WJ-R00200K1 Roller pull-out table widening

Weibert WJ-KS26 Edge grinding machine with oscillation NEW MACHINE! 400V 3 KW ( 4 hp) S1 100% n=2840 min. Grinding table 750x300mm Table height adjustment 200mm Abrasive back wall 850x200mm Grinding belt dimension 2600x150mm Grinding unit swivelable 90°-45° with quick adjustment Band speed 20m/sec. Oscillation on and off motor 0.25 KW (0.34 hp) Central suction connection 120mm Manual adjusting m degree display! WJ-R00100 The following options included in the price! Roller pull-out table widening WJ-R00101 Miter stroke WJ-R00102 Driving device WJ-R00103 Feed machine 3 rollers 120mm with bracket special price

Grinding machine for curved parts Molded part grinding machine Make Calmbach & Söhne Double-sided grinding of shaped parts Oscillating rubberized grinding rollers Workpiece thickness maximum 120 mm Workpiece width maximum 130 mm Engine strength 2 motors 1.5 kW each Oscillation electromotor 4 speeds Suction connection diameter 120 mm Includes 20 grinding belts grit 60 + 120 Dimensions 1200 mm x 1500 mm x H 1550 mm

Long belt grinding machine, roller spacing approx. 3000 mm

Belt grinding machine for wood & metal, roller spacing approx. 3000 mm

Grinding machine • For grinding curves and internal radii

Table belt grinding machine Hunziker L x W x H: 3.5 x 1.7 x 1.7 m The machine is in good condition, ready for operation. Changes, mistakes, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

TECHNICAL DATA: Working width mm: 1600 No 2 side brushes Lengthwise brushing unit Horizontal brush Horizontal brush Brush roller (transversal) Weight Kg: 2500 Total power installed kW: 11

TECHNICAL DATA: Working width mm: 400 Workpiece length min mm: 350 Thickness mm: 150 No 2 brushing units (Turnable) Total connection kW: 1,83 Weight Kg: 1200

Handcuper Meinert PH6 for gate saws

Automatic oscillating curve grinding machine Grinding width 300 mm Grinding height from 3 - 100 mm Feed continuously from 25 - 25 m/min Feed motor 0.55 KW Drive motor 7.5 kW Grinding belt 320 x 2000 mm

Working Length: 3100 or 4100

TECHNICAL DATA: Required space mm: 830 x 860 x H 1150 01 Vertical brush KW 0,37 Motion: right - left Weight Kg: 250

Technical data: Total length mm: 19800 Working width: mm 1000 Working length mm: 6600x1000 Pass-through height mm: 100 Polishing discs: Yes Polishing discs for edges: yes Diameter polishing discs mm: 200 Vacuum table: Yes

Workpiece width max mm: 1700 Material thickness max mm: 100 02 Workbenches mm: 5000 x 1700 02 Oscillating aggregates Rollers (cotton) mm: 350 02 Roller motors HP: 18.5 Vacuum Table - HP 12.5

4 Belt grinding unit 2 grinding brushes Carpet length mm: 5500 Carpet width mm: 400 (extendable) Weight Kg: 800

Drawer fitting machine husband Type: XII LOD 2 oscillating abrasive belts Grinding wall surface 760 mm long x 280 mm high max. drawer width - fit width 1000 mm maximum drawer height 250 mm Width adjustment by handwheel Support tables on each grinding wall outside Support table size 650 mm x 235 mm Engine strengths 1 x 4.8 kW and 1 x 7.5 kW Dimensions 1900 mm x 1300 mm x H 1200 mm

A) Total grinding units: 02 - longitudinal - bottom Grinding units total: 02 - transverse - top - bottom B) Total grinding units: 02 oscillating - right C) Total grinding units: 02 oscillating - links D) Orbital grinding unit total: 02 Complete loading

Length: 2900 mm

Grinding width mm: 1350 Pass-through height mm: 3 - 160 Feed max m/min: 2 - 20 - Inverter KW 4 01 Grinding unit: Grinding belt length mm: 1380 x 3250 - 15 KW (INV) 01 Orbital grinding unit "Spinbrush" - KW 4 (INV) 01 Grinding unit: Grinding belt length mm: 1380 x 3250 - 15 KW (INV) Machine Control: Viet "IPC 15" Touch Screen Blow-off device 1 Blow-off device 2 Vacuum table Scotch Brite Weight KG: 7200

Grinding width mm: 1350 Pass-through height mm: 3 - 160 Feed max m/min: 2 - 20 - Inverter KW 3 01 Grinding unit: Grinding belt length mm: 1380 x 3250 - 24 SH - 15 KW Blow-off device Vacuum table Scotch Brite x mm 200 Machine Control: Viet "IPC 15" Touch Screen Centering device Weight Kg: 3970

Grinding units Grinding belt length mm: 8000 Grinding width mm: 120 Feed max: 2200 m/min Manipulation unit Max machining range mm: 2100x650x400 Total connection kW: 7.2

Pass width mm: 1300 02 Engines KW: 1 + 1 02 Brushes Brush diameter mm: 300 Vacuum table Control cabinet KW: 8.5

Code: 0705 Brand: LANDONIO - ITALIA Model: LAR 600 Double disc sanding machine for working of patterns , moulds, wood pieces , metal and synthetic material Disc diameter mm 600 Motor Hp 6 Table size mm 800 x 300 Tables inclination 0-30° upwards/downwards Disc rpm 950 Spare disc Overall dimensions : mm 1250 x 800 x 1150 h Weight kg 580

Table belt grinding machine Bürkle L x W x H: 3.5 x 1.7 x 1.8 m Built in 1963 Weight approx. 650 kg The machine is in good condition, ready for operation. Changes, errors, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

EDGE SANDING machine for PANEL and PROFILES type FMB 2 I composition : 1° belt : tilting variable speed sander (with Inverter) - motor power Hp 2 2° belt : tilting variable speed sander (with Inverter) - motor power Hp 2 Blowers for belt cleaning Carpet speed variator from 5 to 25 mt / min Upper adjustable presser with rubber wheels Lateral support for wide panels volt. 380/50

Technical data: Anti vibration welded steel construction Continuous Kettennantrieb 86 mm wide, chain parts made of steel and plastic, self-lubricating bearings, shift on prismatic Guide Adjustable belt speed 5-25 m / min Minimum height work table 870 mm (adjustable) The top pressure unit with adjustable Ã? rubber wheels 60 mm ball bearing Lateral pressure unit with rubber wheels Ã? 40 mm ball bearing Working height min / max 10/100 mm Minimum length 50 mm Minimum width of 30 mm The maximum width 200 mm Feed motor power 3 kW 1 milling unit kW / 2,4 2800 RPM 4 grinding machines with oscillating engines of Leistunj per 4 x 1.7 kW 2800ot RPM Total power consumption 12.5 kW Maschinenewicht 3000 kg very good Zistand, factory tested CE

Long belt Sanders for intermediate lacquer sanding Technical data: Grinding width: max 2,300 mm, min. 200 mm Workpiece height 8-200 mm 1.Schleifbandmasse 100-120 mm x 9000 mm 2.Schleifbandmasse 150 mm x 9000 mm Pressure plate tape measures 10 x 7280 mm Speed 4-12.5 m / min Suitable for intermediate lacquer sanding Grinding motor power kW 10/16 Total power: 20 kW Machine dimensions approx. B 4590 x L 2344 x H 1640 mm Engine weight 2150 kg

calibrating sanding machine SCM SANDYA 16S - 135 second hand machine carpet in rubber max. working width mm. 1350 machine composed by 2 belts : 1° belt : roller in rubber diam. mm.200 . shore 80 2° belt : combined roller in rubber diam. mm.160 . shore 35 + electronic pad belts size mm. 2620 x 1370 motor power Hp 20 volt. 380/50
