288 DMG MORI used machine for sale

Key data: 700 mm, 420 mm, 380 mm

General Manufacturer: DMG MORI Type: Milltap 700 Year of Make: 2016 Control: Siemens 840D SL Travel: X 700 mm Y 420 mm Z 380 mm Spindle Speed: 10,000 rpm Tool holder: DIN30 NC swivel rotary table Table load: max. 100 kg Swivel range A: -100/+120° Rotation range C: 360° Dimensions and weight Dimensions: 2,500 mm x 1,650 mm x 2,950 mm Weight: approx. 3,400 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Tool Changer Conveyor IKZ Internal tool cooling with high-pressure system Preparation for automation

Key data: 600 mm, 1200 mm

Machine Details Stock-No. 1105-04018 Type of machine CNC Lathe - Inclined Bed Type Make GILDEMEISTER DMG Type NEF 600 V3 Year of manufacture 2011 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time immediately Freight basis EX WORK Technical details turning diameter 600 mm turning length 1250 mm control SIEMENS 840 D greates pass round over bed 600 mm centre height 350 mm Spindle Bore 92 mm turning speed range 3500 rpm Rapid Travel - Longitudinal/Face 20 m/min Face Stroke 400 mm Tailstock Quill Diameter 100 mm Tailstock Quill Stroke 1150 mm tailstock taper MT 5 Turret (X-Stations) 12 turning diameter over slide 410 mm Additional information NEF 600 V3 FROM 2011 acc.: hydr. 3-jaw chuck 380 mm, chip conveyor, coolant 3 AXIS WITH LIVE TOOLS 3 AND 10 FIXED TOOLS

Machine-Details Stock-No. 1105-04006 Type of machine Machining Center - Vertical Make DMG MORI Type M 1 Year of manufacture 2022 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time IMMEDIATELY Freight basis EX WORK Price Technical details X-Travel 550 mm Y-Travel 550 mm Z-Travel 510 mm table-size 790 x 560 mm spindle taper ISO SK 40 turning speed range 10000 1/min Feeds longditudinal/cross/vertical 1 - 30000 mm/min Rapid Motion -Longitudinal/Cross/Vertical 30 m/min No. of tools in magazin 20 Workpiece diameter at full load 80 mm Wotkpiece diameter with 2 vacant positions 140 mm Workpiece length 300 mm Weight of tools max. 7 kg Table Load 600 kg spindle drive 9 / 11 kW control SIEMENS 828D total power requirement 30 kVA Additional information cnc SIEMENS 828 D ONLY 1400 SPINDEL HOURS VERY NICE El. handwheel, CH ...

turning diameter:356 mm turning length:705 mm control: CELOS M730 UM MAPPS swing dia.:742 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 ( ±50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min Rapid travel B-axis (parts transfer subspindle):734 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:15/18,5/18,5 kW Spindle 1 Torque:409/505 /599 Nm Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:4500 1/min Spindle 2 power:7,5/11 kW turret stations / rotary tool stations:20 / 20 BMT40 speed of driven tools:10000 1/min :3.7/5,5/5,5 kW torque rotary tools:14 / 24 Nm total power requirement:38 kVA weight of the machine ca.:6,3 t dimensions of the machine ca.:4 (9) x 2,1 x 2,2 m Parts catcher:Sp. 1 und Sp. 2 Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) Tool presetter:Spindle 1 & 2 High precision Turning and Millin ...

turning diameter:670 mm turning length:1540 mm control:F31iB5 Celos Fanuc 35iB5 swing diameter max. over bed cover:700 mm Travel turret No.1 (milling spindle) x/y/z:495 / ± 150 / 1562(+164) mm Rotation B-axis:-30° / +210° Rapid traverse feeds turret 1 (milling head) x/y/z:40/40/40 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:20,2/18,8 kW Torque of milling spindle:120 / 44 Nm tool taper milling spindle:Coromant Capto C6 Tool magazine for milling spindle (turret 1):76 Tool change time tool/tool, milling spindle:1,25 s Spindle 1 RPM:3000 1/min Spindle 1 Power:36 / 30 / 25 kW C-axis spindle 1:0,001 ° Bar capacity spindle 1:102 mm Spindle 2 RPM:4000 1/min Spindle 2 power:26 / 22 / 15 kW C-axis spindle 2:0,001 ° Bar capacity spindle 2:80 mm dimensions of the machine ca.:7,8 x 3,6 x 2,9 m Linear scales on axis:X, Y programmable steady:KLU-A530 & SLU-X3.2 Spindle 1 ...

x-travel:560 mm y-travel:560 mm z-travel:660 mm control:Celos Siemens 840D SL Operate ERGOline Multitouch turning speeds:20 - 20.000 1/min spindle drive:25/ 35 kW max. torque on the spindle:86 / 130 tool taper:HSK-A63 Number of tool station:60 diameter of tools max.:70 mm Tool diameter with no neighbouring tools:170 mm tool length - max.:450 mm weight of tools max.:12 kg numbers of pallets:2 Pallet dimension:400 x 400 mm max. workpiece diameter:630 mm workpiece height max.:900 mm table load:400 kg rapid travel x/y/z:60 m/min Feed x/y/z:60 m/min internal coolant system feed:70 bar weight of the machine ca.:8,5 t dimensions:3200 x 4800 x 2900 mm Renishaw probe (spindle):Vorbereitung / preparation only Horizontal machining center with Siemens - Celos control, full b-axis, tool magazine with 123 pos. HSK-A 63, coolant through spindle 40 bar. The machine has just received a new milling spind ...

GeneralCNC Turning Centre; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways710 mmTransverse stroke260 mmLongitudinal stroke1345 mmClamping chuck diameter max.315 mmWork spindle (left)Spindle bore91 mmSpindle diametre on front bearing140 mmMain drive 1Drive power (100% DC)22 kWSpeed range- 4000 rpmTorque (100% DC)410 NmMax. torque (40% DC)525 NmAccuracy at point stopping0,001 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-6000 rpmPower max. (100% DC)10 kWFloor space/WeightDimensions (L x W x H)5,4 x 2,07 x 2,6 mWeight approx.7800 KgTechnologie cycle alternating speedTechnology cycle for the application of an alternating speed for vibration sensitive set-ups (Only in conjunction with Siemens control)Chuck rinsing device, outsidechuck rinsing device, outside (main spindle)Main s ...

x-travel: 1.135 mm y-travel: 1.050 mm z-travel: 750 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 14.000 min/-1 power capacity - main spindel: 19 kW max. Torque: 100 Nm tool taper: HSK-A 63 table surface area: 1.400 x 1.050 mm max. table load: 2.500 kg max. workpiece sizes: 1.400 x 1.240 mm max. workpiece height: 750 mm tool magazin:: number of toolpositions: 30 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool length: 365 / 395 mm max. tool weight: 8,0 kg change-time chip to chip: 6,1 sec feeds:: feed speeds: max. 40.000 mm/min rapid traverse: 40 m/min Accelaration: 6 m/s² Feed force ( X / Y / Z ): 14 / 20 / 14 kN total power requirement: 44 kVA weight of the machine ca.: 14,4 t dimensions of the machine ca.: 6,0 x 5,0 x 3,3 m Documents: Chip conveyor: Coolantsystem: high pressure coolan ...

x-travel: 1135 mm y-travel: 1050 mm z-travel: 710 mm 0: dia 1240 x 690 mm control: Heidenhain TNC 640 : : 15000 min/-1 : 35 kW tool taper: SK 40 work table:: table surface area: 1050 x 860 mm max. table load: 2000 kg : : 30 pos. tool taper: SK 40 change-time chip to chip: 6 sec feeds:: : 40 m/min feed speeds: 40000 mm/min total power requirement: - kW weight of the machine ca.: 18 t dimensions of the machine ca.: 5,1 x 3,99 x 3,4 m 5-Axis Machine equipped with: - CNC Control Heidenhain TNC 640 - universal Milling Head (B-Axis +30/-130°) - NC- rotary Table dia 800mm (C-Axis) - BMF coolant and filtration system. - electr. Handwheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Working area 1Longitudinal650 mmCross520 mmVertical475 mmGeneralUniversal Milling Machine; Control: CELOS X with Siemens 840D SL Operate Technical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemToolchangertoolchangerBenefit PackageBenefit Package consisting of: Swarf conveyor, with cleaned slot screen Internal coolant supply 40bar/600l Air blast through spindle centre Application Tuning Cycle 3D quickSET (pre selection, measuring probe)Max. tool dia. with free neighbouring pockets 130 mmMax. tool diameter with occupied adjacent pock ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110° ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minClamping SystemHSK-A 63 Rapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110° ...

GeneralTraveling column machine; Control: CELOS X with HEIDENHAIN TNC7 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal2000 mmCross800 mmVertical850 mmTool changerType of magazineChain Number of tools50 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmSwivelhead, B-axisControlled NC swivel milling head 12,000 rpm (B-axis) with clamping in position Continuously positioning NC- swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel speed: 50 rpm Swivel range: ±12Clamping System HSK-A 100Spindle taper HSK-A 100Speed range 20 -12000 rpmTorque (40% DC) 288 NmTorque (100% DC) 187 NmDrive power (40% DC) 44 kWDrive power (100%  ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minIntegrated motor spindle speedMASTER®Drive power (100% DC) 25 kWClamping System HSK-A 63Spindle taper HSK-A 63Speed range - 20000 rpmTorque (40% DC) 130 NmTorque (100% DC) 86 NmDrive power (40% DC) 35 kWNC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationTool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)Tool magazine 30 pockets HSK-A63Tool magaz ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal700 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30Clamping System ISO 7388-3 - JD30ToolchangertoolchangerNumber of tools 15Type of magazine DiskIntegrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 4-channels Inclusive Software packageRotary joint, 6 channelsRotary lead thr ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Cross420 mmLongitudinal700 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWClamping System ISO 7388-3 - JD30Spindle taper BT 30Speed range 20 - 15000 rpmTorque (40% DC) 48 NmTorque (100% DC) 41 NmDrive power (40% DC) 8,5 kWToolchangertoolchangerType of magazine WheelNumber of tools 25Integrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 4-channels Inclusive Software packageProduction package band filter ICS 40b ...

GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: CELOS X with HEIDENHAIN TNC7 Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minTool changerApplicationVertical Type of magazineChain Type of gripperDouble gripper Number of tools60 Working area 1Longitudinal450 mmCross580 mmVertical460 mmSpecial equipmentFischer spindle 40,000 rpm with wave cooling 5-axis design Tool magazine 60 places HSK-E50 Production package high chip volume with IKZ (chip conveyor, rinsing gun, rotating viewing panel, AR flushing, IKZ 40 bar/600 1) Oil Mist Separator AFS BlowinSpecial equipmentPreparation aut ...

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm control: SlimLine Siemens Main spindle:: turning speed range - main spindle: max. 12.000 min/-1 power capacity - main spindel: 13 / 9 kW max. Torque: 83 / 57 Nm tool taper: SK 40 NC-Tilting round table:: table surface area: 630 x 500 mm max. table load: 200 kg Swivel range: B: -5 / +110 ° rotation range: C: 360 ° T-slots: 7x 14 x 63 mm tool magazin:: number of toolpositions: 30 pos. max. tool weight: 8,0 kg max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. workpiece length: 300 mm change-time tool to tool: 2,7 sec change-time chip to chip: 7,0 sec feeds:: rapid traverse: X/Y/Z: 30 m/min Feed force: 4,5 kN feed speeds: 1 - 30.000 mm/min total power requirement: 30 kVA weight of the machine ca.: 4,7 t dimensions of the machine ca.: 4,5 x 3,5 x 3,2 m Documents: Chip conveyor: Coolantsystem: high pressure coolan ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110° ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgPackage Mill / TurnPackage Mill / Turn NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C-axis direct drive, speed max.1,200 rpm Integrated balancing system Motorspindle 20-20,000 rpm power 35/25 kW (40/100% ED) tool taper HSK-A63 according D ...

GeneralUniversal machining centre; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal600 mmCross500 mmVertical500 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmSpindle speed 20.000 rpm, HSK-A63Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Chain-type tool magazine 60 pocketsTool magazine with 60 positions, chain type with double gripper (differently from standard)Pneumatic set up station for tool loadingPneumatic set up station  ...

GeneralCTX beta 1250 4A Two spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - counter spindle slide; Control: CELOS X with Siemens 840D SL Operate Headstock, leftClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range0-5000 rpmC-Axis Speed2000 rpmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWC-Axis Speed2000 rpmTorque (100% DC)280 NmSlide 1Longitudina ...

GeneralCTX beta 1250 4A Two spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - counter spindle slide; Control: CELOS X with Siemens 840D SL Operate Headstock, leftSpindle nose diameter170h5 mmClamping chuck Ø315 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range0-5000 rpmC-Axis Speed2000 rpmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1170 mmTransverse stroke270 mmY axis, vertical+/- 60 mmHeadstock, rightSpindle nose diameter170h5 mmClamping chuck Ø315 mmSpind ...

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm c-axis: 360 ° B-axis (table): -50 / + 110° mm turning speeds: 10.000 U/min spindle taper ISO: 40 DIN 69871 Control: Heidenhain TNC 620 total power requirement: 13 / 9 kW weight of the machine ca.: 4,5 t dimensions of the machine ca.: 6 x 3 x 3 m Options: - 30-pocket magazine with double gripper - Production package with Internal Coolant + chip conveyor - 360 L coolant tank - Blow-off air - Coolant gun - Electronic handwheel - HEIDENHAIN TS 649 infrared probe - Direct measurement system New motor spindle in 2022 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 356 mm turning length: 510 mm control: M 730 BM total power requirement: 40 kVA weight of the machine ca.: 6,6 t dimensions of the machine ca.: m CNC control: Mitsubishi 730 BM Main spindle: Speed: 5000 rpm Power: 15/11 kW (15% duty cycle / constant) Bar diameter: 65 mm Sub spindle: Speed: 6000 rpm Power: 11/7.5 kW (25% duty cycle / constant) Turret: 12 stations Tool spindle speed: 10000 rpm Power: 5.5/3.7 kW (5 minutes / constant) Y-axis travel: +/- 50 mm Equipment: Machine with gantry loader: Left-hand installation, 14-station storage, 20-pallet workpiece storage, Double gripper conveyor 3-jaw hydraulic KITAGAWA power chuck, 210 mm diameter High/low pressure chuck system for main and counter spindles MABEO high-pressure pump with 1.5 MPa filter unit Coolant gun Coolant sprayer on the chuck for main and counter spindles Coolant sprayer for the machine bed cladding Oil  ...

GeneralUniversal Milling Machine; Control: CELOS X with Siemens 840D SL Operate Technical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minClamping SystemHSK-A 63 Rapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgWorking area 1Longitudinal650 mmCross520 mmVertical475 mmDirect measuring systemDirect path measuring systemBenefit PackageBenefit Package consisting of: Swarf conveyor, with cleaned slot screen Internal coolant supply 40bar/600l Air blast through spindle centre Application Tuning Cycle 3D quickSET (pre selection, measuring probe)Spindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp  ...

GeneralVertical Machining Center; Control: Control SIEMENS SINUMERIK ONE CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D200 mm)Tropical PackageTropical Package Option includes: - Active cooling unit for electrical cabinet - Additional ventilator for control panel Recommended from 35°C to max. 45°C environmental temperatureSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS SINUMERIK ONE CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D200 mm)Tropical PackageTropical Package Option includes: - Active cooling unit for electrical cabinet - Additional ventilator for control panel Recommended from 35°C to max. 45°C environmental temperatureSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel
