gluespreader machines used for sale (593)

Clever HIT S-20 installation kit complete for stationary machine with joint milling (This is a Vorfür unit) Net worth: 11 KW Air heater max. temp.: 650°C at 20 m/min feed List price: € 12.890 our price: € 5.950 Installation/retrofit: € 2.950

Gluing stand VHS with motor hydraulics for gluing all frame constructions with dowel connection – tine connection – 45° miter connection. The motor-hydraulic gluing stands VHS are available in the following sizes: Maximum grouting range 2,500 x 1,800 mm 2,500 x 2,100 mm 3,000 x 1,800 mm 3,000 x 2,100 mm 3,500 x 2,100 mm Three vertical press cylinders with a stroke range of 120 mm and a pressing force of 2 tons each. Two horizontal press cylinders with a stroke range of 120 mm and a pressing force of 2 tons each (optionally, the gluing stands can of course be supplied with more press cylinders). Drive power 0.75 to 1.25 kW.

Code: 0005 Brand: OMMA / OTHER BRANDS 2300 Model: 2300 Nr 2 rubber-coated rollers Technical data Length mm 2300 Diameter mm 230 Rifling 3,4 x 1 cm / 9 x 1" (inch) Overall dimensions of wooden crate for 2 rollers: mm 3000 x 900 x 550 h Weight kg 800

TABLE mm 2600 x 530 ROLLS min. ÷ max. mm 0.4 ÷ 3 STRIP FABRIC MAX MM 5 max. workpiece height min. ÷ max. mm 12 ÷ 50 min length or width processable plate mm 190/65 Speed m/min 7

Key data: 6 , 60 , 4000

Control system MEGA 120 & NESTING GROUPS SCM Group Joining unit with Dia-Leitz tools Glue basin station with quick-change pool Cross-cut unit with swivel function up to 15° Soft and postforming plates can also be known. Flush milling unit with radius milling Solid wood edges 6 x 60 mm Spraying device in front of joining unit Corner rounding unit Edge Brick Blade Unit Surface drawing blade unit Spraying device in front of babble unit Swabing unit Feed speed 10 m/min Machine length 4450 m

1 Quickmelt incl. evaluation device level. Interchangeable heads used, good condition 16 pcs. Interchangeable heads FK 11/13 devices, exchangeable at the top below.

Interchangeable heads used, good condition 16 pcs. Interchangeable heads FK 11/13 devices, exchangeable at the top below. 1 Quickmelt incl. evaluation device level.

SCM edge bander model BASIC 1 : - useful thickness of the panel from 8 to 40 mm - feed speed 8 mt/min - overall dimensions approx. 1.7 x 0.7 x h = 1.3 mt Operating groups: - gluing with hot melt glue tank - loader and shearing for roll material - Header kW 0,6 - Trimmers kW 0,5+0,5

Overview of equipment: - Workpiece support scissor design with roller support, 1000 mm extendable - Infeed ruler automatically adjustable - Fixed stop side left - Inlet interlock pneumatically controlled - Upper pressure via driven composite V-belt - Height adjustment electric - Workpiece transport device via transport chain with rubber support - Release agent spray unit top/bottom - Joint milling unit 2 x 3 kW - Gluing part A20 with 2 rollers, consisting of workpiece preheating, Quickmelt application unit with quick clamping system, 2-roll magazine, pressure zone C (auto-adjustable, with 1 pre-press roll and 6 repress rollers) - Cross-cut unit HL84 0.8 kW, with autom. Adjustment chamfer/straight as well as pneum. Adjustment flush/protrusion caps - Pre-milling unit 1.5 kW, pneum. Adjustment of bündi/protrusion milling machines - Mould milling unit FK11 with autom. Adjustme ...

technical details: - Number of goats: 6 pieces - Number of press beams: 6 pieces - Number of clamping wrenches: 4 pieces - Number of screeds (2,500 mm): 8 pieces - Number of wooden inserts: 6 pieces (1 x divided) Metrics: - Trestle height: 1,000 mm - Trestle width: 1,450 mm (1,410 mm) - Clamping height: 360 mm, minus the screed thickness of 140 mm = 220 mm! - Clamping area: 2,500 x 1,120 mm - Length of the screeds: 2,500 mm (Subject to changes and errors regarding technical data and prices!) In accordance with our terms and conditions, we would like to point out once again that cheques and bills of exchange cannot be accepted.

Edge banding machine Brandt Optimat KDF 1600 GC YOC 2009 Edge thickness 0.4 - 12 mm Plate thickness 8 - 60 mm Feed 12 m/min Inlet ruler adjustable Pneumatic package Automation package Quickmelt Premelting Unit Joining milling unit 2 x 2.2 kW Cross-cut unit chamfer / Straight 2 x 0.35 kW Milling unit 2 x 0.55 kW Mould milling unit 2 x 0.35 kW (2 units) Drawing blade unit with quick-change heads Surface drawing blade for glue joint Schwabbelaggregat 2 x 0,18 kW Electronics control Connection value 11.5 kW Machine length approx. 6600 mm Weight 2900 kg

Overview of the assembly: - Release agent spray unit top & bottom - Joining milling unit 2 x 4 kW - Glued part with workpiece preheating, 2 rolls, pressure zone C and QA34 application unit for PU with quick clamping system - autom. Adjustment pressure zone - Preparation for Lasertec activation unit - Hl84 cross-cut unit 0.8 KW - pneum. Adjustment pre-milling unit - Pre-milling unit Bf10 1.5 kW - Mould milling unit Fk11 Manual - Autom. Adjustment of chamfer to radius milling machines - Rolling side probe FK - Pneumatic adjustment FA11 for lateral displacement from the working area - Multi-drawing blade MN 21 autom. for a maximum of 5 different profiles. - Finishing unit (glue joint drawing blade and swabbing ridge) - Detergent spray unit top & bottom - powerControl PC22 Workpiece and edge parameters: - Workpiece width without edge min: - For workpiece thickness  ...

ID-Nr. 1-056-11-0400

Post IMA Height: 980 mm with Motor 4,4 kW Motor shaft 35 mm diameter Inner thread M16 left Outer thread 35x1,5 right Price: not reconditioned, from stock Other version available on request

Hebrock Edge gluing machine Edge glue Edge milling machine heating Capping

for bill of exchange order unit

• Workpiece thickness: 8 - 55 mm • Workpiece width min.: approx. 30 mm • Workpiece length min.: approx. 130 mm • Edge thickness: 0.4 - 1.0 mm • Roller separation max.: 0.8x60 mm • Inner radius: 25 mm • Heating time: max. 2 min • Temperatures: approx. 260 - 400°C • Diameter foil plate: 600 mm • Table depth min.: 465 mm • Table depth max.: 955 mm (extended) • Table length: 1400 mm • with edge cutter • Working height: approx. 230 mm • Weight: approx. 87 kg • Changeable location, as equipped with 2 wheels! Electrical connector: • 230V/ 50/60Hz Total connection: • 3.3 kW Heating: • 3.0 kW Dimensions (WxDxH): approx. 1700 x 1600 x 1100 mm Transport dimensions (HxWxD): approx. 1100 x 1400 x 750 mm (without pallet!) The machine has been completely reworked, cleaned and thoroughly tested in our company. (Changes a ...

- CE certification - Complete, original wood Her machine documents and operating instructions - Weight: 720 kg (basic machine), approx. 860 kg (machine with aggregates) Assembly: • Control panel (1888) SK 180 • Fully automatic edge feeding (1903) - Edge thickness striped goods 0.3 - 8 mm - Edge thickness rolled goods 0.3 - 3 mm - max edge height 51 mm • Adhesive application station (1906 M) - with hot melt adhesive cartridge - via sword nozzle with electro-pneumatic control - Temperature selector - Heating time approx. 5 min - Temperature approx. 190 - 240 degrees Celsius - Workpiece thickness 6 - 45 mm • Printing Unit (1912) • Cross-cut unit (1918) • Combino milling unit (1942 M) - for flushing, chamfering and radius milling • Pull blade unit (1929) - Edge thickness max. 3mm • Sandbar unit (1940) • 2 x suction connections 70 mm each • Compre ...

Edge gluing machine

PUR bag melter for processing from 2 to 3 kg PUR-DIN aluminium foil bags, Technical description: Hose connections, temperature controller PT100, 2 internal heating circuits, storage tank approx. 2.8 kg volume for bag change, 1 gear pump 7.3 cc drive via three-phase motor, glue stop shut-off direction, level monitoring for the Bag change with optical and acoustic signal, electronic Control with larsicht input (multilingual), weekly timer, digital inputs and outputs for integration to the mother machine, melting capacity adhesive-dependent, temperature reduction, Operating voltage 400 V Including - Hot glue hose length 3.5m i.D.10mm - Application head large glue outlet 5.6mm probe Pt100 - Homag cover plate QA65 with hose aging re - Switching amplifiers - Teflon probe S-506

20-09-510 Edge Banding Machine WOODLAND MACHINERY (new) Type GB/T10850 Engine power 0.18 kW Air Pressure 3-6 Bar Voltage 220 V 50 Hz Total Power 1.4 kW Heating Capacity 1.2 kW Edge width 8-50 mm Edge thickness 0.3-3 mm Feed speed 0-26 cm/s Vacuum workpiece Attraction Transport Dimensions Weight 300 kg

Type FZ-515 Thickness of panel 10-60 mm Edging thickness 0,4-3 mm Feeding speed 15 m/min Air pressure 0,8 MPa Total install power 6,5 kW Panel width ? 60mm Transport dimensions 3700x900x1700 mm Weight 1200 kg

Edge bander type STEFANI BRT UNIVER with trimming unit and automatic feeder for straight, curved and shaped panels . application of melaminic, Pvc, veneer edges, in rolls and strips Technical details: Max panel height mm 60 Edge thickness mm 0,4 - 1,5 Trimming unit 12000 rpm Automatic feeder Overall dimensions: mm 1350 x 1000 x 1150 h Weight kg 480

Automatic Edge Banding machine type OCMAC BS 21 . second hand composition : - glue pot - edge-trimming unit (2 motors) Kw 2 each one . rpm 12.000 with cabinet with HF converter Hp 5 volt. 380/50

AUTOMATIC EDGE BANDING machine type HOLZ-HER SPRINT 1411 work hours : 380 work meters : 32.000 CE mark : YES volt. 380/50 composition : 1. gluing unit with cartridge and comb nozzle 2. end trimming unit 3. edge trimming unit 4. tilting edge trimming unit 5. glue scraper

Complete with; push button magnetic starter and safety guards 220 Voltage

Edge gluing machine - see pictureNext:Edge gluing machine NEY-SENIOR SKM 100/3 gemaess Pictures

Edge glue machine HolzHer express 1437 Edge gluing, flush milling, caps flush milling with chamfer milling or RADIUS milling with sep. Aggregate Schwabelscheiben 2 mm and two units for chamfering or just milling milling ABS edge 2 additional units for RADIUS Hours of operation 1072.5 hours Masch. No. 721/9-203 L x W x H: 400 x 120 x 170 cm Weight approx. 900 kg Built in 1992 The machine is in good condition, ready to use. Subject to changes, errors, prior sale! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

Machine is still in < operation and fully functional solid up to 20mm rolls PVC to 3 mm caps flush milling RADIUS milling milling Schwabbleln chamfer
