grinding machines used for sale (2,377)

grinding length:1500 mmgrinding width:700 mmworkpiece height:580 mmtable load capacity:2380 kptable speed -stepless-:5 - 35 m/mingrinding wheel dia. x width:500 x 100 x 203 mmgrinding wheel motor:18 kWspeeds::stufenlos elektronisch total power requirement:35 kWweight of the machine ca.:12 tdimensions of the machine ca.:5,3 x 2,9 x 3,8 (3,18) msurface grinding machine,paper-filter,DRO 3 axis,automatic infeed,el.handwheel,full cabin

Power supply: 0.75 kVA 230 V 50 Hz, Filling capacity work container: 42 l, Suitable for abrasives 2 - 40 mm room diagonal, Suitable for workpieces from 2 mm in any dimension

Speed: 2800 rpmConnection: 3 kWOperating voltage: 220/380 VBelt width: 75 mm

Grinding is accurate and rapid, easy operation with no skill to grind. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life. Bearing shaft and locking unit. The machine is set up with the function of adjusting a point (central point) size, which can effectively coordinate with the material of drill hole and the rotation speed. It can control the quality precision and prolong the service life of the drill bit. Standard with CBN grinding wheel for the HSS material, Optional SDC grinding wheel for the carbide material. Grinding Range:Φ3-Φ13, Point Angle:100°~135°, Power:AC220V, Motor:120W, Speed:4400rpm, Dimension:32x18x19 cm, Weight:9kg, Standard Equipment:Grinding wheel:CBN (for HSS)×1, Eleven collets:Φ3,Φ4,Φ5,Φ6,Φ7,Φ8,� ...

:FS-NC-50AHR | FS-NC-60AHR | FS-NC-70AHR grinding length:1020/1520/2020 mmgrinding width:500 | 600 | 700 mmDistance spindle center to table:600 (Option 800, 1000) mmtable surface area:500x1000/500x1500/500x2000 | 600x1000/600x1500/600x2000 | 700x1000/700x1500/700x2000 mmtable load capacity:800/1000/1000 | 1200/1400/1400 | 1500/1700/1700 kgtable speed -stepless-:5-25 m/minAuto. cross feed increment:0,5~20 mm/minrapid traverse cross:900 mm/minautom. vertical feed:0,001~0,999 (Option) mmgrinding wheel speeds:1450 U/mindimensions of grinding wheel:405x50x127 mmspindle drive:7,5 (Opt. 11) kWweight of the machine ca.:6000/7200/8400 | 6300/7500/8700 | 6600 /7800 /9000 kgmachine width/height:4600x2300 | 4600x2450 | 4600x2550 mmmachine length:4600/4800/6000 mm

:FS-C 80150/100150AHD | FS-C 80200/100200AHD | FS-C 800300/100300AHD | FS-C 800400/100400AHD grinding length:1500 | 2000 | 3000 | 4000 mmgrinding width:800/1000 mmdistance spindle nose and table:800 [Option: 1000] | 800 [Option: 1000] | 800 [Option: 1000] | 700 [Option: 900] mmmax. table load:800x1500 (2000kg)/1000x1500 (2400kg) | 800x2000 (2650kg)/1000x2000 (3200kg) | 800x3000 (3950kg)/1000x3000 (4800kg) | 800x4000 (5000kg)/1000x4000 (5500kg) kgtable-size:800/1000x1500|800/1000x2000 | 800/1000x3000 | 800/1000x4000 mmtable speeds:3?25 m/mintable guideways:V- und Flachführung automatic cross feed adjustable:0.5?20 mm/Hubrapid traverse cross:900 mm/mincross feed on handwheel:5 (Umdrehung) / 0.02 (Grad) mmrapid traverse vertical:240 mm/minautom. vertical feed:0.001 ~ 0,1 mmspindle speed:1450 1/mindimensions of grinding wheel:406 x 50.8 x 127 mmspindle drive:7,5 (11 Opt.) kWdrive motor fo ...

grinding diameter:250 mmgrinding length:2710 mmmax. module: min. module: total power requirement:45 kWweight of the machine ca.:15 tspace required L x W X H:7,1 x 4,7 x2,7 mmax. wheel dia.:450 mmSpindle drives Arena SiemensFor Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm

internal diameter:250 mmswing diameter:455 mmworkpiece length - max.:1200 mmtable rotating:-4/+8 °table speeds:0-4000 mm/minmax. workpiece weight:80 kgworkhead - center taper:5 MKRotation speed of workhead :0 - 400 1/minworkhead motor:4 kw3-jaw chuck:250 (selbstschließend) mmgrinding motor:4 kWcoolant pump:2,2 kWWeight approx.:2,4 tmachine dimensions:3200 x 2100 mmCNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mmclamping chuck:250 (selbstschließend), 1 Satz harte Backen, 1 Satz weiche Backen, 1 Satz Innen mmfrequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:RPM 28.000, diam. 60 mm. Min. diam. cap. 25 mm. x Bohrung 50 mm, Max. diam. cap. 100 mm. x Bohrung 115 mm . internal grinding spindle:RPM 10.000, diam ...

internal diameter:300 mmswing diameter:300/350 mmworkpiece length - max.:2300 mmtable rotating:-2/+6 °table speeds:0-4000 mm/minmax. workpiece weight:400 (fliegend, 150mm von der Spindelnase) kgworkhead - center taper:6 MKRotation speed of workhead :0 - 400 1/minworkhead motor:4 kw3-jaw chuck:250 (selbstschließend) mmgrinding motor:11 kWcoolant pump:2,2 kWCNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mmclamping chuck:350 (selbst zentrierend) mmfrequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:auf Anfrage internal grinding spindle:auf Anfrage fixed steady rests:10-100 mm, 100-170 mm PERFORMANCE AND PRECISION DEGREE Robbi grinding machines are according to the international precision normes ISO 2433.The t ...

internal diameter:300 mmgrinding depth:260 mmswing diameter:500 mmspindle nose:A2-5 workhead motor:1,8 kwmax. workpiece weight:50 kgwork piece spindle speed:0-1000 U/minworkpiece length - max.:300 mmgrinding wheel speeds:20.000 1/mingrinding wheel motor:3,75 kWrapid speed:8 m/minpositioning accuracy:X/Y/Z: 0,001 mmrepeating accuracy:X/Y/Z: 0,001 mm:3350x2250x1950 mmWeight approx.:5 tCNC controller:FANUC CNC-Steuerung 0i T Scales:Heidenhain in der X-Achse mit 0,005mm Auflösung servo spindle motor:für Werkstückantrieb 3 jaw chuck Ø:hydr. 200 mmcoolant system:140 l:in deutscher Sprache spindle:Eingebaute elektrische Schleifspindel 40.000 U/min mit Zubehör ; Minimale Drehzahl: 30.000 U/min. Magnetic and paper filter :Kühlmittelsystem mit Magnetabscheider & Papierfilter 60/min, 200L

Grinding is accurate and rapid, easy operation with no skill to grind. With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life. Bearing shaft and locking unit. The machine is set up with the function of adjusting a point (central point) size, which can effectively coordinate with the material of drill hole and the rotation speed. It can control the quality precision and prolong the service life of the drill bit. Standard with CBN grinding wheel for the HSS material. Grinding Range:Φ12-Φ26, Point Angle:95°~135°, Power:220V, Motor:250W, Speed:4400rpm, Standard Equipment:Grinding wheel:CBN (for HSS)×1, Fourteen collets:Φ13,Φ14,Φ15,Φ16,Φ17,Φ18,Φ19,Φ20,Φ21,Φ22,Φ23,Φ24,Φ 25,Φ26 Machine condition: unchecked. Approx. T ...

grinding height:-- mmgrinding width:220 mmgrinding wheel diameter:762 mmtotal power requirement:90 kWweight of the machine ca.:13 tgrinding spindle 1 drive::37 kWgrinding spindle 2 drive::37 kWGrinding machine for pre-grinding the connecting rodWith 2 replacement spindle motors

:Omicron 600 R | Omicron 1000 R grinding diameter:315 mmgrinding length:600|1000 mmcentre height:160 mmswing over bed:315 mmmax. workpiece weight:120 kggrinding wheel size:450x127xmin.20-max.50 mmperipheral speed:33 m/secgrinding spindle speed:600-1600 1/mingrinding head swivellable +/-:±180 °infeed each handwheel rotation/division line:2 (0,05)/0,01 (0,002) mmautomatic feeds:0,01/0,02/0,03/0,04 mm/minworkhead - spindle speed:0-600 1/minswiveling workpiece drive:±90 °workhead - center taper:4 MKtailstock quill adjustment:25 mmtailstock quill diameter:43 mmtaper in tailstock:4 MKtable speeds:0-5000 mm/minswivellable angle of table:600: +9°/-5° | 1000: +8°/-4 °table adjustment - longitudinal:max. 680 mm | 1080 mmtable cross movement -manual:13 mmgrinding wheel motor:4 kWworkhead motor:0,75 kWhydraulic motor:0,75 kWcoolant pump:0,18 kWmachine dimensions:2540x1350x1750 | 3750x1350x1 ...

:Omicron E 600 | Omicron E 1000 | Omicron E 1500 grinding diameter:355 / 455 mmgrinding length:630 | 1030 | 1530 mmcentre height:180 / 230 mmswing over bed:355 / 455 mmmax. workpiece weight:250 (300 opt.) kggrinding headstock:_________________________________________________ __grinding wheel size:450 (500 opt.) x127 x min.20-max.80 mmperipheral speed:33 m/secgrinding spindle speed:600-1600 (stufenlos) 1/mingrinding head swivellable +/-:±180 °infeed each handwheel rotation/division line:2 (0,05)/0,01 (0,002) mmautomatic feeds:0,01/0,02/0,03/0,04 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-600 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:5 MKtailstock quill adjustment:35 mmtailstock quill diameter:48 mmtaper in tailstock:5 MKtable:__________________________________________________ __table speeds:0-5000 mm/ ...

:Omicron RT6 600 | Omicron RT6 1000 grinding diameter:315 mmgrinding length:600|1000 mmcentre height:160 mmswing over bed:315 mmmax. workpiece weight:120 kggrinding headstock:_________________________________________________ __grinding wheel size:450 x127 x min.20-max.50 mmperipheral speed:33 m/secgrinding spindle speed:600-1600 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °automatic feeds:0,2-3000 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-600 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:4 MKtailstock quill adjustment:25 (opt. 50) mmtailstock quill diameter:43 (opt. 70) mmtaper in tailstock:4 MKtable:__________________________________________________ __table speeds:1-5000 mm/minswivellable angle of table:+9°/-5° | +8°/-4° °table adjustment  ...

:Omicron ET6 600 | Omicron ET6 1000 | Omicron ET6 1500 | Omicron ET6 2000 grinding diameter:355 / 455 mmgrinding length:630 | 1030 | 1530 | 2030 mmcentre height:180 / 230 mmswing over bed:355 / 455 mmmax. workpiece weight:250 (300 opt.) kggrinding headstock:. grinding wheel size:450 (opt. 500) mm x127 x min.20-max.80 mmgrinding spindle speed:600-1600 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °automatic feeds:0,2-3000 mm/minworkhead:. workhead - spindle speed:0-600 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:5 MKtailstock:. xxtailstock quill adjustment:35 (opt. 70) mmtailstock quill diameter:48 (opt. 70) mmtaper in tailstock:4 (opt. 5) MKtable:. table speeds:1-5000 mm/minswivellable angle of table:+9°/-5° | +8°/-4° | +7°/-3° | +6°/-2° °table adjustment - longitudinal:max. 780 |max.  ...

:Omicron PT6 1000 | Omicron PT6 1500 | Omicron PT6 2000 | Omicron PT6 3000 grinding diameter:595 / 695 mmgrinding length:1000 | 1600 | 2100 | 3000 mmcentre height:300 / 350 mmDistance between centres:1150 | 1750 | 2250 | 3150 mmswing over bed:595 / 695 mmmax. workpiece weight:1200 (1800 opt.) kggrinding headstock:_________________________________________________ __grinding wheel size:610 mm x 230 x min. 50-max.120 mmgrinding spindle speed:600-1250 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °grinding spindle movement:480 mmautomatic feeds:0,2-3000 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-300 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:6 MKtailstock:__________________________________________________ __tailstock quill adjustment:70 mmtailstock  ...

Inventory No.: 45702; for more details see photos of the nameplates;

:Omicron CNC 3206 | Omicron CNC 3210 grinding diameter:315 mmgrinding length:600|1000 mmcentre height:160 mmswing over bed:315 mmmax. workpiece weight:120 kggrinding headstock:_________________________________________________ __grinding wheel size:450 x127 x min.20-max.50 mmgrinding spindle speed:600-1600 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °automatic feeds:0,2-3000 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-600 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:4 MKtailstock:______________________________________________ __tailstock quill adjustment:50 mmtailstock quill diameter:70 mmtaper in tailstock:4 MKtable:__________________________________________________ __table speeds:1-5000 mm/minswivellable angle of table:+9°/-5° | +8°/-4° °ta ...

:Omicron CNC 3606 | Omicron CNC 3610 | Omicron CNC 3615 | Omicron CNC 3620 grinding diameter:355 / 455 mmgrinding length:630 | 1030 | 1530 | 2030 mmcentre height:180 / 230 mmswing over bed:355 / 455 mmmax. workpiece weight:250 (300 opt.) kggrinding headstock:_________________________________________________ __grinding wheel size:450 (opt. 500) mm x127 x min.20-max.80 mmgrinding spindle speed:600-1600 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °automatic feeds:0,2-3000 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-600 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:5 MKtailstock:__________________________________________________ __tailstock quill adjustment:70 mmtailstock quill diameter:70 mmtaper in tailstock:5 MKtable:________________________________ ...

:Omicron CNC 8030 | Omicron CNC 8040 | Omicron CNC 8050 | Omicron CNC 8060 grinding diameter:795/895/955 mmgrinding length:3000|4000|5000|6000 mmcentre height:400/450/500 mmDistance between centres:3000|4000|5000|6000 mmswing over bed:795/895/955 mmmax. workpiece weight:zw. Spitzen 4 tgrinding headstock:_________________________________________________ __grinding wheel size:760-1200mm x 305 x min. 50-max.120 mmgrinding spindle speed:600-1250 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °grinding spindle movement:480 mmautomatic feeds:0,2-3000 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-150 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:6 MKtailstock:__________________________________________________ __tailstock quill adjustment:120 mmtailstock quill d ...

:Omicron CNC 6010 | Omicron CNC 6015 | Omicron CNC 6020 | Omicron CNC 60300 grinding diameter:595/695 mmgrinding length:1000 |1600 |2100 |3000 mmcentre height:300/350 mmDistance between centres:1150 |1750 |2250 |3150 mmswing over bed:600/700 mmmax. workpiece weight:zw. Spitzen 1200 kggrinding headstock:_________________________________________________ __grinding wheel size:610mm x 230 x min. 50-max.120 mmgrinding spindle speed:600-1250 (stufenlos) 1/minfeed per revolution of handwheel:0,001/ 0,01 / 0,1 mmgrinding head swivellable +/-:±180 °grinding spindle movement:480 mmautomatic feeds:0,2-3000 mm/minworkhead:________________________________________________ __workhead - spindle speed:0-350 (stufenlos) 1/minswiveling workpiece drive:±90 °workhead - center taper:6 MKtailstock:__________________________________________________ __tailstock quill adjustment:70 mmtailstock quill diameter ...

:KSM 800 | KSM 1000 | KSM 1200 rotary table diameter:800 | 1000 | 1200 mmdistance spindle center to table:350 mmdimensions of grinding wheel:90x30x160x80x 8 pc. mmgrinding head - power requirement:22 kWgrinding spindle speed:850 (stepless) U/minvertical feed on handwheel:0,001/0,005/0,010 mm/Umtable load:1 ttable rotation speed:5-20 U/mintable movement - horizontal:420 | 520 | 620 mmweight of the machine ca.:9 | 9,5 | 10,2 ttotal power requirement:27 kWdimensions:3.350 x 2.250 x 2.800 mmLCD Touch Screen:with cycle support

x-travel:400 mmy-travel:250 mmworkpiece height:500 mmgrinding diameter:220 mmtable surface area:600 x 320 mmthroat:310 mmrange of angles:12 °grinding wheel stroke - vertical:110 mmstroke speeds:0 - 6 m/mingrinding spindle speed:bis 50000 U/minperipheral speed:max. 35 m/seccapacity:ca. 7 kVApower capacity:6 kWweight of the machine ca.:2 tdimensions of the machine ca.:3 x 3 x 3 mrotary table d = 300 mmfrequency changerTexte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht.Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt.Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt.Copyright © 2005-2024, Josef Weber. All rights reserved.

220 volts; 250 W; Drill diameter 13-26 mm.

Technical data of the ZS 201 machine Normal Grinding Spindle – Speed I • Speed: 9,150 min⁻¹ • Cutting speed: max. 45 m/s • Grinding pin diameter: max. 90 mm • Grinding pin guide for Ø centres: max. 130 mm Normal Grinding Spindle – Speed II • Speed: 18,300 min⁻¹ • Cutting speed: max. 45 m/s • Grinding pin diameter: max. 48 mm • Grinding pin guide for Ø centres: max. 88 mm Vise clamping range • Clamping range I: 5–105 mm, self-centering • Clamping range II: 95–160 mm, self-centering • Special clamping range: 160–225 mm, self-centering Workpiece dimensions • Workpiece length ZS 201/1200: 60–1200 mm • Workpiece length ZS 201/1500: 60–1500 mm • Workpiece length ZS 201/2000: 60–2000 mm Workpiece diameter • Above the clamping jaws: max. 450 mm • Above the tailstock tip: max. 325 mm • In the vice area: max. 285 mm • Max. workpiece  ...

Serial number: 125076Belt width: 150 mm

grinding diameter:600 mmgrinding length:3000 mmcentre height:315 mmworkpiece weight max.:3000 kgwork piece spindle speed:8 - 120 U/mingrinding wheel motor:25 kWgrinding wheel speed:45 m/secgrinding wheel width x diameter:750 x 80 mmtable speeds:30 - 4500 mm/minfeeds of grinding head:0 - 5 mm/mintable swivelabel +/-:7,5 °total power requirement:55 kVAweight of the machine ca.:18 tdimensions of the machine ca.:11,5 x 4 x 2,2 m- Internal grinding device- taper grinding up to 10,1° based on diameter- automatic grinding cycle- grinding wheels and flanges- dressing device- coolant attachment- dust exhauster, various steady rests

Max wheel diameter: 200 mm

grinding length:600 mmgrinding width:300 mmworkpiece height:450 mmtotal power requirement:8 kWweight of the machine ca.:2,2 tdimensions of the machine ca.:2,8 x 3,0 x 2,0 mgrinding spindle speed:1440 / 2905 U/minwith magnetic plate 600 x 200 mmautom. vertical feed coolant attachmentTexte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht.Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt.Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt.Copyright © 2005-2024, Josef Weber. All rights reserved.
