turbines used for sale (120)

50 Hz - 6MW

50 HZ - 5.5 MW

Machine Type: Steam Turbine Manufacturer: Siemens (formerly KK&K or Kühnle, Kopp & Kausch) Model No.: SST-060 Serial number: 4.345.107 Year of Make: 2016 Operating hours: 0 h Condition: new, has never been put into operation Power: 1,047 kW Live steam parameters: 29.0 bar (26.0-34.0 bar), 480 °C (430-500 °C) Evaporation parameters: -0.36 bar (max. 0.50 bar), 425 °C Generator: AvK, 400 V, 2,165 A, 50 Hz, 1,500 kVA, cos φ 0.80 Dimensions: approx. 5.0 m long x 2.8 m wide x 2.8 m high (turbo generator set without control cabinet and ancillary systems) Scope: turbine, gearbox, generator, oil generator, oil cooler, control cabinet

Steam Turbine Siemens SST-300 UK Power Generators is offering Brand New Steam Turbine Siemens SST-300 – in factory packing from the year 2021. This turbine has never been installed and available with all its equipment and accessories, below are the details of the main components. Along with it see at the end of this document the pictures as it is stored in warehouse securely, in good environment. SO2 Blower o Vendor: Howden o SAR Blower, specifically an SF11.2 Centrifugal Turbo Compressor. o Technical Data: Operates with an inlet pressure of 0.91 bara, continuous pressure at 57°C, and short-time temperature at 65°C. It is electrically driven, requiring 1989 kW of power, and runs at a speed of 4733 rpm. The blower was constructed in 2021. o Dimensions/Weight: The skid (including the blower and gearbox) has a footprint of 5m x 5m.  ...

Several original new and reconditioned turbochargers and cartridges for Caterpillar engines type 3300 / 3400 / 3500 / C 18 / C32 and older type's perfect machinery international bv the Netherlands info@perfectmachinery.nl Whatsapp +31 653549259 the Netherlands Whatsapp +34 682511830 Spain

Reconditioned turbocharger TD13L part number 49182-03661 fully reconditioned with new bearings and seals for Mitsubishi S 12 R more turbochargers en parts available Perfect Machinery international bv the Netherlands info@perfectmachinery.nl Whatsapp +31 653549259 the Netherlands Whatsapp +34 682511830 Spain

Centrax ROLLS ROYCE 5 MW CX 501 KB7 Gas Turbine-Generator Package YEAR 2011 HOURS 42 000 Equipment List: Turbine/Alternator Housing and its complete contents including: • 1 Allison 501 KB7S DLE Gas Turbine - • 1 Alternator • 1 Epicyclic Gearbox • 1 Acoustic Enclosure • 1 Alternator Control Cabinet and Software • 1 Turbine Control Cabinet and Software • 1 Auxiliary Distribution Cabinet and Software • 1 Lubrication Unit including Oil Cooler • 1 Fuel Supply Circuit in Acoustic Enclosure • 1 Electro-Hydraulic Starting System- • 1 Compressor Cleaning System • 1 DC Power Supply • Battery Charger • Fire Protection and Gas Detection Circuit • Fan acoustic enclosure • Air cooler fan List of components: • Control/command panel and room and its complete contents • Filtration assembly and combustion air ducts • Filtration assembly, silencers and box vent ...

Type: Epicacyclic (Planetary) Model: APE 43 Reduction Ratio: 2.247:1 Rated power: 860 kW Power in service: 3355 kW Input speed: 14210 rpm Output speed: 1500 rpm Type: Planetary Epicenclic Reducer Brand: APE Allen Gears (UK) Reduction Ratio: 2.247:1 Input Speed: 14,210 RPM Output Speed: 1500 RPM Rated power: 860 kW (service: 3355 kW) Total weight: 1000 kg

APE gearbox (Dualbox) geabox Type: Planetary Epicenclic Reducer Brand: APE Allen Gears (UK) Reduction Ratio: 2.247:1 Input Speed: 14,210 RPM Output Speed: 1500 RPM Rated power: 860 kW (service: 3355 kW) Type: Epicacyclic (Planetary) Model: APE 43 Reduction Ratio: 2.247:1 Rated power: 860 kW Power in service: 3355 kW Input speed: 14210 rpm Output speed: 1500 rpm

Alternator Brush – Type BEJSN1100 Manufacturer: Brush Electrical Machines Ltd – Loughborough, UK Type: Synchronous Alternator (AC Generator) Exciter: Brushless Exciter, Model XL163.82A Key features: Apparent power: 3125 kVA Voltage: 5,536 V Current: 325 A Frequency: 50 Hz Speed: 1500 rpm Power Factor: 0.8 Connection: Star Phase sequence: W-V-U (counterclockwise rotation view on the drive side) Weight: 7750 kg Cooling: Not specified on plate (to be confirmed) Additional technical details: Insulation class: F (reinforcement), H (rotor) Ambient temperature: 40°C Max. altitude: 430 m Year of manufacture: 1980 Bearing lubrication: Pressure: 1.07 bar Flow rate: 22.5 L/min

800kW CAPSTONE C800S Containerised set with MATTEI Compressor. Make and model: Capstone C800S Capacity: 4 x 200kW Year: 2019 Fuel: Landfill Gas Hours and status: Bay A: 2,527h - Powerhead broke in June 2023. (This is a backup bay with no head recovery). Bay B: 25,113h - Ready to operate - New Powerhead installed in April 2022 at 12,142h. Bay C: 16,590h - Powerhead ok, replaced in December 2022 at 10,294h - Stopped because of an electrical problem on the control board March 2023. Bay D: 19,093h - Powerhead broke down in March 2024. General information: Stopped in March 2024, stored since. Ready to be shipped. MATTEI Compressor in 10 foot container Make and model: MATTEI G135K7-50-25 Fuel: Landfill Gas Hours: 18 329h (back up with another compressor) Available for sale from Gas Engine Exchange . Please check our complete range of equipment at gasengineexchange.com.  ...

Centrax 501 KB57 DLE Gas Turbine-Generator Package engine overhaul in 2017 at 24 000 hours 372 start service hours 23 000

TECHNICAL DETAILS Rated power: 2,125 kVA generator Manufacturer: Piller Type: NKT 2150-4 Voltage: 400/231 V Frequency: 50 Hz Power: 2,125 kVA Insulation class: F Protection class: IP23 Power factor: 0.8 Speed: 1,500 rpm Current consumption: 3967 A turbine Manufacturer: Dresser-Rand Model No.: KG2-SL3 Rated speed: 1,500 rpm Peak load power: 1,890 kW MACHINE DETAILS Voltage for generator connection: 380 V Transport weight: 10,000 kg Year of construction: 1990 Condition: ready for operation (used) Functionality: fully functional Operating hours: 2,343 h

Allison Detroit Diesel Turbine Allison Type 501 KB Year of manufacture 1980 alternator RATED 3860KW alternator DUTY 3355KW Alison turbine = 4380 HP --> heating oil INPUT RPM 14210 OUTPUT RPM 1500 Number of hours 600H of operation 10 KV cell (alternator output) Deutz diesel 160 HP (turbine launcher)

Capacity: 3,224 kW Volts: 400 HZ: 50 Condition: Very Good Scope of Supply: Complete Turbine Power Station with turbine and alternator, Control Panel, Condensor, Cooling Towers, Spilling Unit, Switchgear, Synchronisation panel, Transformer, Piping / wiring / pumps. Total cost for power plant components was around 3 million on the actual power plant components . Nominal Steam requirement to run the turbine is 17, 5 t/h at 29 barg & 350 °C. Available for sale from Gas Engine Exchange. Please check our full range of equipment at gasengineexchange.com.

Model: Avon 1533-56L Year of Manufacture: 1992 Type: Aeroderivative Gas Turbine Rated power: Approximately 16,347 kW (22,225.73 hp) to 17,007 kW (23,123.08 hp) DIRECTINDUSTRY Thermal Efficiency: Up to 44% Dimensions: Length: Approx. 3,200 mm Diameter: approx. 907 mm Weight: Approximately 1,310 kg

INDUSTRIAL GAS TURBINE Brand: Rolls-Royce Model: 501-KB5s-DLE Maximum pressure: 1,205 PSI Condition: Pre-owned / Overhauled : Industrial Equipment Operational Period: 1999 - 2011 Total Running Hours: 39,500 hours Documentation: I am reviewing the documents and will send you the key details shortly

Centrax ROLLS ROYCE 5 MW CX 501 KB7 Gas Turbine-Generator Package YEAR 2011 HOURS 40 000 Equipment List: Turbine/Alternator Housing and its complete contents including: • 1 Allison 501 KB7S DLE Gas Turbine - • 1 Alternator • 1 Epicyclic Gearbox • 1 Acoustic Enclosure • 1 Alternator Control Cabinet and Software • 1 Turbine Control Cabinet and Software • 1 Auxiliary Distribution Cabinet and Software • 1 Lubrication Unit including Oil Cooler • 1 Fuel Supply Circuit in Acoustic Enclosure • 1 Electro-Hydraulic Starting System- • 1 Compressor Cleaning System • 1 DC Power Supply • Battery Charger • Fire Protection and Gas Detection Circuit • Fan acoustic enclosure • Air cooler fan List of components: • Control/command panel and room and its complete contents • Filtration assembly and combustion air ducts • Filtration assembly, silencers and box ventilat ...

Discover an exceptional opportunity to acquire a new and unused Siemens Steam Turbine, perfectly suited for high-efficiency power generation: - Voltage: 11kV - Frequency: 50Hz - Speed: 1500rpm - Blower: Howden SO2, powered by a Siemens motor with a robust 2200kW capacity. - Condenser: High-efficiency Shell and Tube type for superior heat exchange. - Condensate Extraction: Sigma pump ensuring effective condensate management. - Vacuum Pump: Invatech water ring vacuum pump for optimal system performance. - Steam Generator: Clayton E-1204-SH, known for its reliability and efficiency in steam production. - Deaerator and Blowdown Tanks: Depression models to safeguard system integrity. - Boiler Feed Pumps: Hammelmann, designed for consistent and reliable water supply to the boiler. - Boiler Booster Pumps: Flowserve, enhancing the system's pressure cap ...

Centrax Gas Turbine-Generator Package - (USED) 50Hz Fuel Description Bio Gas Only Unit type M2000 KB5S Running hours 126701 Starts 2950 Megawatt hours 349558.0 mwhr Turbine speed 14580 RPM inspection report available

Mitsubishi Heavy Industries Ltd Type - SC1F ( Single Cylinder Single Flow ), Condensing Steam Turbine Power : 205.440MW HP Steam : 85 ata, 538 C LP Steam : 5.5 ata 193 C Steam Turbine Generator Model : MB-H Power - 241, 680 KVA Voltage - 16.5KV, 50 Hz

Kawasaki M7A-03D 7.2MW Natural Gas Turbine Complete CHP Generating Set Completely self-contained Kawasaki M7A-03D 7.2MW Gas Turbine and Generator package with Heat Recovery (Thermic Fluid Heater and HRSG Hot Water Generator) in acoustic enclosure. Runs parallel with grid. Island operation mode. Make and Model: Kawasaki TD80A Capacity: 7200kW Hrs: 10,000 V: 11,000 HZ: 50 Year: 2010 Fuel: Natural Gas Scope of supply: Gas Turbine GPB 80, M7A-03 DLE Single Gas Fuel, single shaft with DLE Combustor, reduction gear box, coupling with guard, Diaphragm Type, Generator (TD80A, 2011) Heat Recovery System - Thermic Fluid Heater, HRSG Hot Water Generator Acoustic Canopy with Lighting Control and Instrumentation Exhaust collector and/or diffuser, Gas Fuel system, Lube oil system, Inlet ducting, Inlet filtration system, Inlet silencer, Combustion system, Protection system ...

Ansaldo Condensing Steam Turbine Power: 9000 kW RPM: 7500 / 1500 Steam pressure: 40bara Steam temperature: 420 ºC Back Pressure: 0,08bar Number of extractions: 2 Number of stages: 8

BVI / ThyssenKrupp Condensing steam turbine MARC6-C03 2005 power generator with 135,000 operating hours, without steam condenser and AC generator. Inlet pressure 89 bar, outlet pressure 0.11 bar, 21,000 KWel x 1,500 rpm, Steam turbine BVI / ThyssenKrupp MARC6-C03 Manufacturer: BVI / ThyssenKrupp Model No.: MARC6-C03 Type: Steam Condensation Serial number: P-900078 Power [KW]: 23,545 Pressure Input [bar]: 89 Temperature Input [°C]: 520 Pressure output [bar]: 0.11 Year of Make: 2005 Hours: 135,000 Weight [kg]: 58,000 Dimensions LxWxH [cm]: 510x400x340

220 MW SGT-600 GT Complete Power Plant Duel Fuel Gas Turbine Power Plant Gensets 220.5 Megawatts in total 6 units available, 24.5 Mw each Speed 1,500 rpm, Generator Output 11 kV, Frequency 50 Hz Average running hours 70.000 hours Gas Turbine Power Plant operated predominately on natural gas with standby diesel fuel. Can be converted to alternative fuels as heavy fuel oil . Depends on the demand and needs of the customer. Phase I (5 units, commissioned on 2007) Phase II (4 units commissioned on 2012) Routine preventive maintenance was done for all units under OEM supervision, Emission ISO Standard at 15% O₂ Original Dry Low NOX ( DLE ) Combustion Chambers Inertial Filtration and Single Stage F9

Solar Gas turbine Taurus 65 SOLONOX The turbine and gear box is from 2022 and it only has 2000 running hours. The package is from year 2011. The condition is excellent and is ready to start working, in addition it included Solonox mode and fire extinction module. All the maintenance has been done by Turbomach official service. The equipment is already dismounted on our warehouse and ready to be load. It is available all the systems except the exhaust system that is optional. It is possible to have a visit and a inspection of the turbine. Also is available a boroscope of the turbine. YOM:2022 Power: 6300kWe Fuel: Natural Gas Working Hours: 2300 h Voltage: 6300V

SGT – 800 Gas Turbine Generator Set, 45,3 MW, with integral Local Equipment Room: Unit(s) to be supplied are unused, with zero running hours, never installed. Gas Turbine Package: Original year of assembly: 2022-2023 SGT 800 Gas Turbine Core Engine Original assembly location: Europe Never installed AC Generator: Original assembly location: SIEMENS Electrical Machines Original year of assembly: 2022-23 Package and core engine serial numbers will be confirmed upon placement of order The units` supporting documentation is available for review at any time with prior notice Scope of Supply: Driven unit AC Generator 11 kV 3 phase 50 / 60 Hz 4 pole 0.8 power factor Cylindrical pole brushless type Filter ventilated Class F insulation with class F total temperature rise Generator bearing temperature instrumentation Lubricating oil piping from gas turbine to driven unit  ...

82MW ISO rated combined cycle power plant. The plant’s main equipment is composed of a Rolls Royce Trent 60 DLE Gas Turbine (also known as the SGT-A65), a Nooter/Eriksen HRSG, and a Siemens SST-300 Steam Turbine. These are below; 1. Rolls Royce USA, manufactured Trent 60 (SGT-A65) Gas Turbine Generator Set; · Manufactured in 2016, delivered in August 2017. Never used. · 65.9 MW(e) ISO · 43.8% Gross efficiency / 8,228 kJ/kWh Heat Rate · DLE Dry Low Emissions with ≤ 25 ppmvd at 15% O2 on fuel gas · Cold start to full power in under 10minutes · 50Hz, but easily convertible to 60Hz · Engine still preserved in original shipping container · An aero derivative gas turbine 2. HRSG is licensed by Nooter Eriksen USA; 3. Siemens Steam Turbine Generator SST-300 C2S/C160; · Manufactured in 2016 · Output 15.75MW ISO · Speed 7059 RPM · Adm ...

Pratt & Whitney gas turbine generator Model : FT8 Twin pac Power output : 48 MW Voltage : 11 KV Frequency : 50 Hz

GE Model : LM6000PA Power Output : 42 MWe ISO condition Voltage : 11KV Frequency : 50Hz Total 2 nos.
