machines and plants for process engineering used for sale (7,510)

Refrigeration plant with 70 kW complete with compressor, condenser, in-house cooling tower, plate heat exchanger for glycol cooling and control cabinet. Refrigerant: Ammonia, Additional title: Refrigerant: Ammonia, Cooling capacity: 70 kW, Design to: -8 °C, Design tc: 27 °C, Power: 15 kW, Operation / Control: Control cabinet with hardware control, Features: Compressor, condenser, plate heat exchanger, glycol cooler, in-house cooling tower, control cabinet

horizontal tubular heat exchanger, Additional title: for CIP or hotwater, Media flow: 500 hl/h, Working pressure orifice baffle: 10 bar, Working pressure piping: 8 bar, Working temperature piping: 200 °C, Length: 1,05 m, Width: 0,6 m, Height: 1,1 m, Weight: 300 kg

Sewage sludge tank made of stainless steel, with insulation, agitator and side tapping., Additional title: Stainless steel tank with insulation, Capacity: 100000 l, Operating temperature: 80 °C, Material: Stainless steel, Position: Standing on concrete foundation, Base construction: Cylindrical tank with flat bottom, Features: Insulation with stainless steel cladding, feed pump (volume flow 12m3/h); agitator, ladder with back protection, tank top railing,

Decanter centrifuge for thickening municipal, industrial and biological sludge, Additional title: Sludge dewatering system, Capacity: 15 m3/h, Weight: 640 kg, Position: To be mounted on the customers substructure, Features: Operating platform

Decanter centrifuge for thickening municipal, industrial and biological sludge, Additional title: Sludge dewatering system, Throughput capacity: 15 m³/h, Weight: 545 kg, Position: To be mounted on the customers substructure, Features: Operating platform

Station for preparing flocculation aids.

Additional title: Sludge tank, Capacity: 70 m3, Material: Stainless steel, Position: Vertical, Features: Outlet pump 2,2 kW, (flow rate 19m3/h); Agitator

Additional title: Tank 2, Capacity: 50 m3, Material: Stainless steel, Position: Vertical, Features: Agitator

Additional title: Tank 3, Capacity: 100 m3, Material: Stainless steel, Position: Vertical, Features: Agitator

Additional title: Tank 1, Capacity: 150 m3, Material: Stainless steel, Position: Vertical

Bioreactor with pH, oxygen and temperature measurement. Membrane aerators are also included., Additional title: Vertical stainless steel tank with membrane ventilators and pump system, Capacity: 240 m³, Material: Stainless steel, Position: vertical, Features: Membrane aerators; pH measurement; oxygen measurement; temperature measurement; pump station inlet

Additional title: vertical stainless steel tank, Capacity: 100 m3, Material: Stainless steel, Position: Vertical

Additional title: vertical stainless steel tank, Capacity: 100 m3, Material: Stainless steel, Position: Vertical

Two-stage plate heat exchanger. First stage - Heating: hot water / product Product inlet approx 61-62°C, outlet approx 72°C, flow rate 600 hl/h; Hot water inlet approx 72,5°C, flow rate 750 hl/h Second stage - Regeneration: product / product Product inlet approx. 0-4°C, product outlet approx. 61-62°C, flow rate 600 hl/h; Product inlet approx. 72°C, product outlet approx. 11-14°C, flow rate 600 hl/h, Additional title: Product, Capacity: 600 hl/h, Hot water: 750 hl/h, Operating pressure: 21 bar, Operating temperature: 100 °C, Length: 2,15 m, Width: 0,95 m, Height: 2,15 m, Weight: 5000 kg, Material: EPDM HT / NBR / 1.4439

Water degassing module. Suitable for integration into existing control systems., Additional title: cold degassing, Capacity: 50 hl/h, Residual oxygen content: 0,03 mg/l, Column volume approx.: 300 l, Operating temperature: 95 °C, Operation / Control: PLC / visualization by customer, Material: Stainless steel 1.4301, Base construction: Height-adjustable feet, Features: Two-chamber column; water pump; panel

Radial duct fan for easy, direct installation in the sewer system. Housing made of galvanized sheet steel. Rated Voltage: 400V Frequency: 50Hz Phase(s): 3~ Power consumption: 1,246W Current: 2.25A Speed: 1,315 r.p.m. Volume flow: max. ; 3,168; m³/h Minimum pressure, static: 250Pa Max. conveying device temperature: max. 40°C Max. conveying device temperature at speed control: 40°C Sound pressure level in 3m: 57dB(A) Degree of protection, motor: IP44 Weight: 31 kg Rectangular channel connection, height at inlet & outlet: 300 x 600mm

TWO-COMPONENT DOSING AND MIXING SYSTEM Little used. Only in the development department, no series production. The new price of the system was over 20,000 euros plus VAT. Facility details: - Total power requirement: 3.0 kW - Basic housing G22 for 30/60 L container - Base frame with drip tray, protective frame, crane eyelet, motor mount, compressed air filter regulator, pressure gauge, quick couplings and control cabinet, mounted with fixed and swivel castors - 2x dosing pump drive 0.55 kW incl. frequency converter and pump carrier = 1x dosing pump KF0/4; 1x Dosing pump FP/S14-N19; 1x Tank VA 60L, Tank Agitator 0.18kW (A-Comp.) - Respiratory dryer - Recirculation - Hoses - Mixing head GP 23 static/D low dead space - 2009 model with separately pneumatically controlled fluid valves - Air purge valve autom. Handle with E-switch - 4 solenoid valves 5/2-way - Static mixer - I ...

Manufacturer: Kautex Model: KBS2-20/40-S90/22D Year of Manufacture: 1999 PLC control: Siemens S5 Grinder: Rapid 3545 Conveyor Material feeding system Piovan Dedusting system Piovan Automatic component gripper and scale Spare parts Control Voltage: - AC: 230 V - DC: 24 V Working Voltage (AC, 3-phase): - Drive I: 400 V - Drive II: 400 V - Heating: 400 V Frequency: 50 Hz Rated Current: - Drive I: 285 A - Heating: 70 A Maximum Fuse Rating: - Drive I: 315 A (time delay) - Heating: 100 A (fast acting) Find more here - / Contact us at -

Used disc batch centrifuge LWG-47. Technical data: - Capacity: 10000 L / h - Bowl speed: 6000 rpm - Motor power: 11 kW; 3+N, 50 Hz, 380 V - Overall dimensions: 1240x800x1835 mm - Weight gross: 1075 kg - Weight net: 875 kg

Used GEA Finnah model 2209.014 cheese production and packaging machine. New: 2000. Maximum capacity: 8x28x60 = 13,440 cph (28-30 staples/min) Capacity: 150 g (120 g, 200 g) Product: cream, homogenised cheese Filling: aseptic Voltage 230/360 V 50 Hz Pressure 8 bar

General SKU390X1027 MakeTenez / Schmidt LocationBarneveld TypeSigmawig ST12-PF-03882 Pressure Working pressure25 Bar Vacuum possiblecheck Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 Information No.10V000139 Year of construction2010 Floorspace0,34 x 0,45 m Total height0,78 m Weight100 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld,  ...

General SKU390X1030 MakeTenez / Schmidt LocationBarneveld CEcheck TypeSigmawig ST12-PF-03882 Pressure Working pressure25 Bar Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 Information No.12V002703 Year of construction2012 Floorspace0,34 x 0,45 m Total height0,78 m Weight100 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlan ...

General SKU390X1043 MakeTenez / Schmidt LocationBarneveld TypeSigmawig ST12-PF-03882 Pressure Working pressure25 Bar Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 Information No.12V002703 Year of construction2012 Floorspace0,34 x 0,45 m Total height0,78 m Weight100 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Pleas ...

General SKU390X1048 MakeTenez / Schmidt LocationBarneveld CEcheck TypeSigmawig ST12-PF-03882 Pressure Working pressure25 Bar Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 Information No.10V000138 Year of construction2010 Floorspace0,34 x 0,45 m Total height0,78 m Weight100 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlan ...

General SKU390X1056 MakeTenez/ Schmidt LocationBarneveld CEcheck TypeSigmawig ST12-PF-03882 Pressure Working pressure25 Bar Vacuum possiblecheck Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 (316L) Information No.17V007270 Year of construction2017 Floorspace0,335x0,45 m Total height0,79 m Weight100 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine  ...

General SKU390X997 LocationBarneveld CEcheck MakeTenez / Schmidt Pressure Working pressure25 Bar Vacuum possiblecheck Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 Information TypeSigmawig ST12-PF-03882 No.12V002702 Floorspace0,34 x 0,45 m Total height0,78 m Weight250 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. P ...

General SKU390X1026 MakeTenez / Schmidt LocationBarneveld CEcheck TypeSigmawig ST12-PF-03882 Pressure Working pressure25 Bar Main Features MaterialStainless steel Surface16.5 m2 Size length580 mm Sizes width230 mm Specified Features - Plate heat exchanger Plate heat exchangerscheck Heating surface16,5 m² Capacity5,52 Ltr. Plate sizes230 x 580 mm Connectionscheck DN50/DN40 Max. temperature0 / 250°C Capacity35 m³/h MaterialStainless steel 1.4404 (316L) Information No.12V002704 Year of construction2012 Floorspace0,34 x 0,45 m Total height0,78 m Weight100 kgPlate heat exchangersApi SchmidtHeat exchangers > Plate heat exchangersBrand > Api Schmidt What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Ne ...

General SKU419X1299 MakeMorton Loedige LocationBarneveld TypeFM300D Main Features MaterialStainless steel Volume300 Ltr. Motor11.5 KW Specified Features - Powder turbo mixer Powder turbo mixercheck T-armscheck Capacity300 l Useful capacity250 l Trough sizes600 x1000 mm InletDia 100 mm Inspection hatch320 x 510 mm Outlet160 x 130 mm With adjustable packing glandscheck Motor7,5 kW(400 V, 1450 rpm) With variable speed drivecheck Speed mixing shaft150 rpm With lump breakercheck Motor4 kW(400 V, 2890 rpm) Speed lumpbreaker2890 rpm MaterialStainless steel 1.4552, Stainless steel 1.4301 (304) Information No.M23919 Year of construction1992 Mounted on framecheck With switchcheck With switchgearcheck Floorspace1,5 x2,2 m Total height1,8 m Weight900 kg Extra Specifications- through insulatedNew arrivalsPowder turbo mixersMortonNew arrivalsMixers > Powder turbo mi ...

General SKU251W326 MakeFlottweg LocationBarneveld CEcheck TypeZ53-4/454 Main Features MaterialStainless steel Capacity70000 Ltr./Hr. Motor55 KW Specified Features - Decanter Decantercheck 2-Phase decantercheck Screw diameterDia. 330 mm Screw lengthCa. 1900 mm Inletcheck dia. 65 mm Liquid outletcheck Solids outletcheck Motor55+5,5 kW, 400 volt Max. rotor speed3100 rpm MaterialStainless steel 1.4463 Information No.007.214.05 Year of construction2001 Mounted on framecheck Mounted on foundation platecheck With switchgearcheck (as is) Floorspace1,70x3,90 m Total height1,10 m Weight6800 kg Extra SpecificationsDrum dia. Inside 529 mm : max work temperature 100°C max drum speed 3100 rpm max sediment: 1,5 g/cm3 capacity: 35-70m3/h Technical specs Extra informationDrum inside Dia. 529 mm, drum length 1750 mm, max work temperature 100°C, DecantersFlottwegCentrifu ...
