other wood working machines used for sale (1,508)

Workpiece sizes: Length 180 - 2500 mm, width 150 - 800 mm, thickness 12 - 40 mmFixed side at the left, motorised width adjustment of the right side Working height/ transport height: 920 mmWorkpiecetransport with belts, infeed belts can lift upVariable feed speedEach side has got 5 glue injectors and 8 dowel inserters (Type 34)Doweldiameter: 8 mm, dowellength 30 mm, dowelprojection 7-14 mm, dowelcenters min. 32 mm, max. 736 mmEach side with dowel hopper feed with shaker and separatorsControll mirrorGlue pump 1:1 Glue injection controlls type ELC

X=3700mm Y=1440mm, Z=150mmMoving speed: X: 80 m/min, Y: 80 m/min, Z: 20 m/min8 supports with vacuum cups, pneumatic clamping8 fences at the rear8 fences in front2 left fences and 2 right fences6 rails for panel loading with pneumatic liftingPositioning the vacuum cups using a laser1 connection for templatesVacuum pump with flow rate 100 m3/hConfiguration V25,H8X/6Y, N1 X-Y 90?, F1-HSK63-15KW,F1-HSK63-9KW, C axis, W14 rearMain motor 15 kW, 1250-24000 rpm, air-cooled, 360? C-axis, C-axis interpolation axis, HSK 63 mountingC axis extension for flex-5 aggregateMain motor 9 kW, 1250-24000 rpm, air cooled, HSK 63 mountingTool changer operating in X direction with 14 positions, rear mounted2 x 4 vertical X drilling pins, 2 x 3 vertical Y drilling pins14 horizontal drilling spindles90? groove saw X-Y directionPC 85 power control software with:Woodwop: workshop-oriented programming systemImport 2 ...

Working width 180 - 3200 mm, electronic setting Sieb & MeyerFixed side at the leftChain transport, 80 mm wideInfeed for panels of about 1 m.Top pressure by driven beltsMax. workpiece thickness: 80 mmFeedspeed 7 - 35 m/min, motor 2,2 kWPop-up dogs every 1m10Equipment left / right:1 st postFront: 1+1 Jump scorer, motor 1,5 kW, 100 Hz, joined to 1+1 Hogger, motor 3 / 4,4 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 Hz2nd postFront: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzRear: 1+1 Fixed milling, tilting, motor 2,2/3,3 kW, 50/100 Hz3th postFront: 1+0 Jump milling, tilting, motor 2,2/3,3 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzAll units with horizontal/vertical adjustment and Siko read-outOutfeed chain approx. 80 cm lengthSound and safety enclosures

Right-hand versionWorkpiece dimensions: max. length 3000 mm, min. 250 mm, max. thickness 100 mm, min. 30 mm, width 200 mmOverhead cutting saw, 3 kW, 3000 rpm, manual horizontal movement over 120 mm, 400 mm blade, cutting height 100 mm1 vertical shaft, 340 mm long, 40 mm diameter, 7.5 kW, 3100 rpm, suction port with 150 mm diameter (x2), max. tool diameter: 320 mmCarriage with pneumatic clamping1100 x 500 mm tableStop, positioning from -45? to 45?Motorized carriage with electronic control 2-32 m/min

Machine designed for machining solid wood doors with frame and raised panelsWorkpiece dimensions Length 150 - 3000 mm Width 40 - 300 mm Thickness 20 - 60 mm Material: hard woods/soft woods Machine equiped with 2 working areas, including - 3 NC-axes X, Y, Z- telephone modem- 1 sawing unit- 1 horizontal boring unit- distance horizontal drill above table (Z):max. 40 mm- fixed workpiece table- central lubrication- CE package- max. workpiece length 2.400 mm KOCH Numeric with 3 NC-axes Positioning control with PC Pentium CPU Operating system Windows XP Professional: english 15? Touchpanel VGA + Touchscreen by means of LVDS connection USB-connection on PC and on Touchpanel Seriel and parallel interface on the PC Hard disk 2,5? Input of machine commands and motor control through the Touchpanel PS2 connection for external keyboard Office PC software Stretched machine bas for max. workpiece width ...

Drum crusher with hydraulic pusherKnife drum width: 800 mmMouth 800 x 1200 mmMotor: 18,5 kWextraction connection diameter 200 mm

Single sided postforming line, capable of doing L - and U profiles, with or without insert.Workpiece thickness: 16 to 60 mm.Min. workpiece width: 150 mm.Workpiece overhang: 70 mm.Max. laminate overhang: 105 mm.Feed speed 3 - 18 m/min.Fence side at the leftEquipment:Squaring and shaping part:1 x Postforming squaring unit, 2 motors each 1kW, 1st motor removing the laminate, 2nd motor trimming the overhaning laminate1 x scoring, motor 1 kW, top position1 x milling unit for the laminate when doing U profiles 1 x laminate support Postforming part1 x blow cleaning nozzle 6 x glue nozzle for the glue application 2 x glue roller9 x IR heating, each 2,2 kW2 x Hot air blower, each 10 kW1 x Basic postforming pressure zone for L-profiles, using rollers1 x Basic postforming pressure zone for U-profiles, using rollers1 x VF postforming pressure zone for special profiles, using pressure pathsFinishing  ...

Semi-automatic

Max working width: 1300mmMax working thickness: 140mmMax. machining width: 1300mmMotorized feed rollers2 brushing units

Fixed side at the leftPanel thickness min/max: 16/45 mmMin. panel width: 150 mmLateral panel support for panel width up to 900 mmMin/max. panel length: 700 / 3100 mmMax. laminate overhang: 110 mmMax. laminate thickness: 0,8 mmRadius min/max: 6 / 22 mm (depends the laminate)Feedspeed max. 18 m/minTop pressure by beltEquipment:Infeed fence, adjustable, defines the panel overhang2 x trimming unit 0,4 kW, HSK 25 toolholder1 x PVAc glue application5 x glue nozzle, adjustable1 x hot air blower3 x IR heating on top (55 cm length), 3 x bottom (90 cm length)Postforming zone 1,8 m. lengthVarious pre-installed profiling sets 1 x top trimmer 0,4 kW

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Workpiece thickness: 8 - 90 mm, electronically adjustableFeed rate: 18-32 m/min frequency controlledEdge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mmEquipment:Inlet guide automatically adjustable via the control, extension 500 mmJoint milling unit: 2 x 3.0 KWworkpiece preheatingGluing unit A34edging magazine for rollPressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the controlCutting unit WK14, straight, 2 motors 0.8 kWPre-milling unit: 2 x 1.5 KW, pneumatic adjustmentForm milling unit FF 12 automatic, 2 motors 0.4 kWradius/phase milling unit FF12 automatic 4 motors 0.4 KWuniversal milling aggregate controlled UF11, 4 kWProfile scrapers PN20Glue scrapersNozzles for detergent and anti-stickPolishing unitControl: Power Control PC22

Single sided edge bander with hot melt, fixed side at the right, pre-milling unitEdge thickness: 0,4 to 12 mmWorkpiece thickness: 8 - 60 mmFeedspeed 8-20 m/min (limited to 10 m/min using the contour trimming)Workpiece transport by chain, top pressures with rubber rollersSound enclosure over all trimming motorsEquipment:Adjustable fencePre-milling with 2 shapers, each 2,2 kWCoil and strip magazine Hot melt unit, Quickmelt type Pressure zone with1 driven and 2 non-driven pneum. Loaded rollersEnd trims, 2 x 0,35 kW motors, straight and chamfer 15?Top/bottom trimming, motors 2 x 0,35 kWRadius trimmmingContour trimming unit, leading and following edge, 2 x 0,35 kWRadius scraping unitGlue scrapersBuffing unitControlls PC 20+

Panel thickness: 8 - 50 mmThickness of the edges: 0,4- 3 mmFeed speed 8 - 11 m / minPU pressure rollersEquipment:Squaring unit, 2 motors 2,2 kWPanel edge heatingEdge magazine for coil and stripsHot melt application with rollerAirtec AT4510 unitThe Airtec aggregate is positioned so you can use Airtec or the standard glue potMotorized side pressure unitEnd trims, 2 motors, pneumatic positioning straight and with chamfertrimming unit above / belowContour trimming unitProfile scraping unitGlue scraping unitPolishing unitDetergent spray systemcentral lubrication

machine 1:Fixed side at the left, working width 220 mm to 2500 mmWorkpiece overhang max. 110 mmElectronic width adjustmentPanel thickness 8 - 90 mmTop pressure by beltsRolling chain with automatic lubrication, automatic pop-up dogs every 1000 mmFeed speed 10 - 40 m/minChain infeed taking 1,62 m. panels in front of the dogsPanel alignment at the infeedMiddle supportNC 30 controllsEquipment left and right:1+1 Jump universal shaper 6 kW1+1 Twin hogging unit, motors 6,6 kW (2 motors)1+1 Universal shaper 6 kW1+1 Jump universal shaper 6 kWpanel turning device HOMAG TD 31/30/13Year 1989machine 2:Fixed side at the left, working width 220 mm to 3000 mmWorkpiece overhang max. 110 mmElectronic width adjustmentPanel thickness 8 - 90 mmTop pressure by beltsRolling chain with automatic lubrication, automatic pop-up dogs every 1000 mmFeed speed 8 - 40 m/minChain infeed taking 1,62 m. panels in front of ...

Workpiece thickness: 8 - 50 mmEdge thickness: Coil edges 0.4 - 3 mmFeed speed 10 m/minEquipment:manual height adjustment.Joint milling unit, 2 motors Panel edge heatingGluing area Pressure zone 1 driven and 2 non-driven rollersEnd trims, 2 x 0,8 kW motors, straight and chamfer 15?Top and bottom trimmingProfile scraping unit for PVC edgingGlue scrapers

4-side squaring and edge banding lineMachine 1:Fixed side right, moving side leftRolling chain, feed 10 - 40 m/minControlls NC 21Panel thickness 8 - 60 mmMax. panel width 1500 mmEdges: coil 0,3 - 3 mm, strips 0,4 - 20 mmEntry fence for veneered panelsEquipment:1+1 Compact-twin hogger, 2 motors 6,6 kW1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application1+1 Free space for solid wood edges up to 2,54 m length1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm)1+1 Universal shaper 8,1 kW1+1 Universal shaper 8,1 kW1+1 Edge sander KS 101+1 Disc sander DS 401+1 Disc sander DS 40Angular transfer to the right, TWR 24/30/12/SPanel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mmMachine 2Machine II + infeed magazine TW 24Fixed side right, m ...

Motorised height-adjustmentSound enclosure over all trimming motorsEquipment:Coil and strip magazineHot melt unit Pressure zone End trims, chamfer and straight, automatic adjustmentTop/bottom rough trimmingTop/bottom fine trimming, tilting, Contour trimming unitScraping unitBuffing unitreturn conveyor Ligmatech ZHR 05

Excellent condition - Fully operational - Loading / Transport possible! motor 15 kW, shaft width 600 mm, shaft depth 800 mm, rotor

Material trolley steel/wood approx. 90x50 cm, 2 levels

Floor Pull Saw MAFELL Erika 85 Ec Year 2015, S/N 1114276

Suction lifter BOHLE, case

Pull-out ladder KRAUSE aluminium 3x8 steps

Column drilling machine MASCHINENMARKT DGS 80, S/N 13282Q0015, total machine height approx. 160h cm

Roller block BERNARDO KRS

Edgebander manufactured in 2008. This BIESSE Edge Stream B1 features a comprehensive set of tools including a PU-gluing machine, pre-milling unit, edge trimmer, and fine milling unit. It also includes rounding and edge scraper units, along with swaying brushes and an edge heater. If you are looking to get high-quality edging capabilities, consider the BIESSE Edge Stream B1 machine we have for sale. Contact us for further details.

Barberan machine manufactured in 2007. This Barberan PUR-33-L is a continuous wrapping line designed for applying PVC foil, CPL, paper, and veneer on various materials using hot-melt technology. It features a robust one-piece electro-welded steel frame, motorized rubber-coated feed wheels, and a slot die extrusion system for precise glue application. If you are looking to get high-quality wrapping capabilities, consider the Barberan PUR-33-L machine we have for sale. Contact us for further details.

Hocker Polytechnick MultiStar JP5 was manufactured in 2012. This used dust extraction system features a powerful 30 kW motor and a filter area of 121.3 m². It includes a Briketierpresse BrikStar c-3 18, designed for efficient operation. If you are looking to get high-quality dust extraction capabilities, consider the Hocker Polytechnick MultiStar JP5 machine we have for sale. Contact us for further details.

Dust extraction and filtration system manufactured in 2018. This Nawara RUBIN 2030 is designed for the extraction of dry dust and wood chips, making it suitable for woodworking and industrial dust collection. It features a stationary modular filter system and a warm air recovery system for continuous operation. If you are looking to get high-quality dust collection capabilities, consider the Nawara RUBIN 2030 machine we have for sale. Contact us for further details.
