lathes used for sale (3,003)

This Takamaz XW-130 Lathe was manufactured in Japan in 2013 and has been operative for 69000 hours, from which 40000 are cutting hours. This machine incorporates 2 turrets each with 8 positions. 20 pcs tool holders are included.

This 3s DOOSAN PUMA 600LM was manufactured in 2007. It features a 45° inclined cast-iron bed and prismatic guideways with Rulon 142 antifriction material. The spindle offers a speed range of 15 – 1,800 rpm and a maximum torque of 9,025 Nm. With a bar capacity of 152 mm and continuous C-axis rotation, consider the opportunity to buy this DOOSAN PUMA 600LM horizontal turning machine. Contact us for further details.

This 5-axis Index G 200 RATIO LINE was manufactured in 2003. It features a Y-axis travel of 120 mm, a main spindle diameter of D65, and a counter spindle diameter of D60. The machine is equipped with a turret that has 12 stations and driven tools on turret 1 and 2. If you are looking to get high-quality turning and milling capabilities, consider the Index G 200 RATIO LINE turn-mill centre we have for sale. Contact us for further details.

CONTROLS  CNC controls FANUC BASIC FUNCTIONS  number of spindles: 2   number of turrets: 2   live positions: yes   number of c-axes: 2   number of y-axes: 1   number of b-axes: 1 WORKING RANGE TURNING  bar diameter (max): 50 mmMAIN SPINDLE  spindle revolutions (max): 5000 /min  drive power: 11 kW  spindle bore diameter: 50 mm  c-axis: yes COUNTER SPINDLE  spindle revolutions (max): 5000 /min  drive power: 7.5 kW  c-axis: yes   Z-axis travel: 465 mmX/Z SLIDE  tool fixture: Turret   number of tool positions (total): 24   number of live positions: 24   - rotation speeds (max): 6000 /minELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / ...

Key data: 250 mm, 500 mm, 3800 1/min

The machine is in good condition and fully functional. It can currently be visited under power. Included is the hydraulic three-jaw chuck, furthermore it has a hydraulic tailstock which is movable. The machine does not have a chip conveyor, but it does have a chip tray.

- 3 bed way construction- Bed width 1100 mm- 3 x C-Type Steady rest on lower base with in feed- 2 x Fixed steady rest 300 - 800 mm with 5 ton- 2 x Chip conveyor- 4 Chuck 1000 mm- Barafuldi 4 way turret head

CNC controller: FS-31IA5 (MAPPS 3) Capacity Z-axis travel mm: 1.550 + 100 Turning length mm: 1.542 Max. turning diameter mm: ø: 660 Swing over bed mm: ø: 730 Bar work capacity mm: 80 / 80 Turning diameter f. lower turret mm: 350 Distance between spindle centers mm: 1.862 Turn-mill spindle X-axis travel mm: 750 Y-axis travel mm: ±210 B-axis degree: ±120° (Index 1°) C-axis degree: 360º (0,001º) Speed spindle rpm: 12.000 Drive power kW: 18,5 / 11 (30min/cont) Tool magazine Magazine places: 100 Tool holder: CAPTO C6 Tool length max. mm: 400 Tool diameter max. mm: 140 Tool weight max kg: 8 Lower turret X-axis travel mm: 195 Z-axis travel mm: 1.525 Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Milling function: PROVIDED Main spindle Speed spindle rpm: 4.000 Drive power spindle kW: 22 / 18,5 (30min/cont) Spindle bore mm: 91 Counter spindle  ...

A vertical turning center is for sale: Working area swing diameter/turning diameter/turning height max.: 1350mm/1150mm/950mm, Faceplate diameter: 1000mm, Spindle speed: up to 800rpm, Tool changer: 12-position turret, Tool system: BMT, Control: FANUC 0i-TC, Installation dimensions L/W/H: approx. 4500mm/3600mm/4600mm, Machine weight: approx. 22000kg. Viewing possible by appointment.

A twin spindle turning center in T2Y2 version is offered. Working area turning diameter/turning length/bar capacity max.: 320mm/810mm/65mm, Speed main and counter spindle: up to 5000rpm, Tool turret: 2x16 stations, Control: MSX-701-III, Installation dimensions L/W/H: approx. 3950mm/2200mm/2350mm, Machine weight: approx. 8300kg. Viewing possible by appointment.

A slant bed lathe from Samsung Machine Tools is offered. Turning length: 2140mm, Bed: 45° slant bed, SMW-Autoblok steady rest: Centering range 30-245mm, Travels X/Y/Z: 335mm/2250mm/+/-60mm 120mm stroke, Spindle nose: A2-11, Chuck: 450mm, Speed: max. 2500rpm, Tool turret: 12 stations BMT75, Power driven tools: 11/7.5kW Torque 70Nm, Control: Fanuc 0i-TD/Manual Guide i MGI, Two-stage cooling system: 10bar supply pressure/30bar high pressure pump Brinkmann, Accessories: hinged belt chip conveyor, tool setter, oil skimmer, extensive holder package incl. 2 axial and 2 radial driven tools, transformer, Installation dimensions L/W/H: approx. 6500mm/2300mm/2450mm, Machine weight: approx. 14500kg, Viewing possible by appointment.

A CNC cycle lathe is offered. Working area turning diameter/center distance/chuck size: 700mm/1500mm/315mm, Speed range: 40-1800rpm, Tool holder: Parat quick change system, Control: FANUC-Alpha, Installation area L/W/H: approx. 3400mm/1700mm/1800mm, Machine weight: approx. 3200kg. Viewing possible by appointment.

Main spindle: max. bar capacity: 65mm, draw tube bore: 75mm, collet holder diameter: 160mm, centering chuck diameter: 175mm, spindle nose: 140mm, max. speed: 5000/min, nominal torque (S1): 150Nm, nominal power (S1): 22kW. Counter spindle: draw tube bore: 45mm, centering chuck diameter: 175mm, spindle nose: 140mm, max. speed: 5000/min, nominal torque (S1): 100Nm, nominal power (S1): 16.8kW. W2 axis counter spindle: travel: 690mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X1 axis: travel: 165mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Z1 axis: travel: 220mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X2 axis: travel: 165mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Z2 axis: travel: 150mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1) ...

This 3s Biglia B1200M horizontal turning machine was manufactured in 2022. It features a maximum turning length of 620 mm and a maximum turning diameter of 360 mm, providing robust capabilities for various turning applications. With a spindle speed of 4,500 rpm and a bar capacity of 70 mm, consider the opportunity to buy this Biglia B1200M horizontal turning machine. Contact us for further details.

This 4-axis Mazak QUICK TURN COMPACT 200 MSY L was manufactured in 2018. It features a maximum swing of 695 mm and a machining diameter of 380 mm. Equipped with a Mazatrol SmoothG CNC control system, it ensures precision and efficiency. The main spindle supports up to 5000 rpm, while the second spindle reaches 6000 rpm. A great opportunity to buy this Mazak QUICK TURN COMPACT 200 MSY L lathe. Contact us for further details.

This 3-axis Mazak Quick Turn 200MA L was manufactured in 2023. It features a MAZATROL SmoothC control unit, a maximum machining diameter of Ø360 mm, and a bar capacity of Ø65 mm. The spindle operates at 5,000 rpm with a chuck size of 8 inches. Ideal for precision turning, it has a 12-station drum turret and rapid feedrates of 30,000/33,000 mm/min. Consider the opportunity to buy this Mazak Quick Turn 200MA L horizontal turning machine. Contact us for more information.

turning diameter: 820 mmturning length: 4500 mmcontrol: Siemens Si 840 D sl total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mNew purchase price in the year 2022 EUR 1.2 millionTime recording from Feb. 2025Operating hours = 16085 hMain spindle = 616 hMilling spindle = 369 hCNC control Siemens Sinumerik Si 840D slMax. center distance 4500 mmWorking height 1375 mmX-axis travel -15…+725 mmY-axis travel -245…+4756 mmSwing diameter over cross slide 780 mmSwing diameter over bed 820 mmC-axis, smallest increment +/-0.001°Main spindle A15 with BVG, 3135 N,/2000 rpmSpindle head DIN 55026 Form A 15Max. speed 3000 rpmMax. torque 3135 NmDrilling/milling unitMilling power (40/100% duty cycle) 36.5/29.8 kWTorque up to 1110 rpm (40/100% duty cycle) 328/261 NmMax. spindle speed 5000 rpmSwivel range (B-axis) -105…+95°Vertical travel (Y-axis) -250…+250°SR ...

CNC Swiss Automatic Lathe TRAUB TNL 32 9P With control TX 8 i - p Year of Make: 2016 Spindle bore: 32 mm MAIN SPINDLE Speed range: Max. 6400 rpm C Axis SUB-SPINDLE Speed range: Max. 6000 rpm C Axis TOOL TURRET TOP: Speed range: Max. 12000 rpm 10 speed turret ( All driven ) TOOL TURRET ABOVE: Speed range: Max. 12000 rpm 9 speed turret ( All driven ) REAR UNIT Number of stations: 8 Of which powered: 3 ( T 12 , 13 and 14 ) Speed T12 + T 14 ( 12000 rpm ) Speed T 13 : ( 4000 rpm ) With the following accessories: Full protection cab with interior lighting Various powered tools Various tool holders IEMCA Boss 338 Bar Feeder - HD KSS Pump 20 bar Chip conveyor Operating Instructions

I'm selling a Mazak Multiplex 6200 lathe-mill. It's in very good condition, still powered up. Inspections are available by appointment. The machine is highly efficient, with two spindles, two independent heads, and a milling capability (C-axis). It's equipped with a partition wall that automatically closes from the control panel. When the wall is closed, the machine can operate as two independent lathes. It can also operate as a standard lathe with a retractable handle. I can send videos and more detailed photos of the machine. Transportation and training are available. I also have other machines for sale. Technical Specifications 640 Control (Windows) Milling Two spindles Two independent tool heads Mazatrol 640T Control Year of Manufacture: 2000 Spindle speed: 0-5000 rpm Milling speed: 0-4500 rpm Turning diameter: 320 mm Turning length: 440 mm Number of tools: 2 x 1 ...

CNC lathe DMG MORI NLX 2000 SY/500 With DMG MORI M730 UM MAPPS CELOS CONTROLLER Year of Make: 2016 Max. workpiece diameter: 366 mm Max. workpiece length: 510 mm Travel in X: 260 mm Travel in Z: 590 mm Travel in Y: +- 50 mm Spindle bore: 65 mm Main spindle speed range: 4000 rpm Speed range sub-spindle: 6000 rpm Speed range of driven tools : 10000 rpm With the following accessories: Workroom door with interior lighting 20-fold turret with 20 driven stations C Axis , Y Axis Touch Probe ( Marposs ) Sub-spindle, parts catcher Tool presetter manual ( HS ) Collet Chuck Hydraulic with Foot Pedal (HS) Collet Chuck Hydraulic with Foot Pedal (GS) Bar Feeder LNS Move S2 30 tool holders Various powered tools Direct displacement measuring system X, Y, Z axis Signal lamp 4 colours Chip conveyor Coolant Setup Operating Instructions

Key data: 350 mm, 700 mm

DMG Mori NLX2500SY/700 Manufactured on 2013 and put into operation on 2014. ZAchse: 700mm, Y-axis 100mm, turning diameter approx. 350mm. Spindle passage 70mm. Operation hours 5353 hours only as new C Axis Y axis B axis 3 Powered Wkz Collets feeder extra included Measuring arm Fully equipped See pictures Immediately available

turning diameter: 305 mmturning length: 870 mmcontrol: FANUC 31i B5-NT-SmartX spindle turning speed range: 6000 + 6000 U/minturret head: 24 12 angetriebenDimensions (L/W/H): 3200 x 2500 x 2700 mmweight of the machine ca.: 16 tY- & B- axesMisc. accessoriesmore details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 180 mmturning length: 140 mmcontrol: FANUC 21TB bar capacity: 30 mmspindle turning speed range: -6300 U/minTop turret tool hodler:: 8 Stationen weight of the machine ca.: 0.8 tdimensions of the machine ca.: 2.2 x 1.1 x 1.7 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: / mmturning length: / mmswing diameter over bed slide: / mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: / mmturning length: / mmworkpiece length: / mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offered is a vertical turning center: travels X/Y: 390mm/750mm, rapid traverse X/Y: 20m/min, swing diameter max.: 800mm, turning diameter max.: 730mm, turning height max.: 750mm, chuck diameter: 500mm, speed range: up to approx. 2000rpm, spindle nose: A2-11, torque max.: approx. 2300Nm, tool turret: 12 positions, tool holder: BMT75, CNC control: FANUC Series 18-iT, space requirement X/Y/Z: approx. 2100mm/3250mm/3350mm, machine weight: approx. 9500kg. Inspection possible by arrangement.

Turning length: 4000mm, turning diameter over bed: 680mm, turning diameter over short cross slide: 480mm, turning diameter over long cross slide: 420mm, turning diameter in the gap: 880mm, swing diameter in the gap: 960mm, travel cross slide: 480mm, top slide: 230mm, tailstock quill: 280mm, center height over flat bed: 335mm, center height over prism top edge: 313mm, bed width: 560mm, diameter of tailstock quill: 125mm, Morse taper of center: no. 6. With upper support, steady rests, operating manual, digital readout and measuring system, Multifix tool holder. Machine is currently partially overhauled. An on-site inspection is possible.

Offered is a production turning center TAKAMAZ X-20 with sub-spindle: travels X/Y: 400mm/160mm, turning diameter max.: 250mm, turning length max.: approx. 400mm, chuck size main spindle: 200mm, chuck size sub-spindle: 160mm, speed range: 40-3500rpm, CNC control: FANUC 21-TB, space requirement X/Y/Z: approx. 2400mm/1700mm/1700mm, machine weight: approx. 4200kg. Inspection possible by arrangement.

For sale is a compact CNC lathe DAEWOO PUMA 160: travels Y/X: approx. 400mm/200mm, rapid traverse: approx. 20-24m/min, turning diameter max.: 200mm, turning length max.: approx. 200mm, swing diameter over bed: approx. 350mm, chuck diameter: 160mm, speed range: 40-5000rpm, spindle nose: A2-5, spindle bore: approx. 50mm, bar capacity approx. 42-45mm, CNC control: FANUC 21-i, space requirement X/Y/Z: approx. 1850mm/1450mm/1650mm, machine weight: approx. 2500kg. Inspection possible by arrangement.

Technical data: working area: turning diameter max.: 300mm, travel X/Y: max. 200mm/350mm, chuck diameter: 125mm, distance between centers: approx. 300mm, speed range: 40-5000rpm, spindle nose: A2-4, tool holder: VDI16, CNC control: FANUC Series 18i-TB, installation dimensions X/Y/Z: approx. 1800mm/1300mm/1700mm, machine weight: approx. 2200kg. Inspection is possible by arrangement.

Technical data: travel X/Y: 350mm/200mm, turning diameter max.: 300mm, swing diameter max.: approx. 400mm, clamping system: type E185, speed range: 40-6000rpm, tool holder: VDI30, 8-station turret, installation dimensions X/Y/Z: approx. 2200mm/1600mm/1750mm, machine weight: approx. 3500kg. Inspection possible by arrangement.
