boring mills and machining centers used for sale (3,232)

bore capacity in steel (diameter): 30 mmthroat: 275 mmbore stroke: 100 mmtaper MK: 4 MKtable-size: 420 x 340 mmfeeds: nein mm/Uturning speeds: 80 - 2000 U/mintotal power requirement: 0,9 / 1,45 KWweight of the machine ca.: 0,22 tdimensions: 0,85 x 0.6 x 1,9 mPillar drill with:- Variable spindle speed- Digital speed display- Digital depth display- Forward/reverse rotationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 32 mmthroat: 300 mmbore stroke: 140 mmtaper MK: 3 MKtable-size: 380 x 360 mmfeeds: über Handrad turning speeds: 85 - 1100 U/mintotal power requirement: 1,3 KWweight of the machine ca.: 0,27 tdimensions: 0,95 x 0,6 x 1,92 mPillar drill with:- Feed via handwheel- Spindle speeds via belt driveThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 32 mmthroat: 325 mmbore stroke: 170 mmtaper MK: 4 MKtable-size: 570 x 480 mmfeeds: 0,1 - 0,16 - 0,25 mm/Uturning speeds: 60 - 1600 U/mintotal power requirement: 2,9 KWweight of the machine ca.: 0,65 tdimensions: 1,2 x 0,8 x 2,15 mPillar drilling machine with:- Feed- Variable spindle speed- Coolant pump- Machine lightThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Nominal drilling depth 750 mm Full drilling in steel approx. 30 mm Spindle speed max. 5700 min-1 Clamping table 1280 x 420 mm Transverse Sliding Table Coolant tank Miscellaneous Accessories

Control Mitsubishi 64S Travel Distances X/Y/Z 600 x 400 x 460 mm Table size 700 x 410 mm Table load 250 kg Spindle speed 12,000 min-1 Tool magazine for 24 Wkz. BT 40 IKZ 20 bar Suction Chip conveyor

The machine is in good technical condition, after prior agreement it is possible to test it. Matrix NEXUS 2- control system Pallets 2x YES. Chip conveyor Yes ATC- YES High pressure 70 Bar Spindle 10 125 hours •Total machine start-up 32 348 hours Pallet 630 × 630 mm Number of pallets 2 Max. workpiece size Ø 1050 × 1300 mm Max. pallet load 1500 kg X travel 1050 mm Y travel 900 mm Z travel 980 mm 4th axis Yes (NC rotary table) Spindle taper BT50 / CAT50 Spindle speed 8000 rpm (standard) Optional speed 10,000 rpm Spindle power approx. 37 kW Tool magazine 40–120 positions Control system Mazatrol Matrix Nexus 2 Production type Production series machining Typical applications Cabinets, cast iron, steel, automotive Machine weight approx. 20–22 t Automatic pallet change Yes

The machine is in good technical condition, after prior agreement it is possible to test it. 0 Baumuller ball screws, spindle diameter 60 mm, SK 40, power 5.5kw/11 kW, torque 100Nm. Rotary tool changer 12. 3 axes and 4th axis only control board without 4th axis table..

The machine is in good technical condition, after prior agreement it is possible to test it. CONTROL SYSTEM Control language - completely in Czech 3D simulation - yes Programming type - Dialogue and NC TABLE Table dimensions - 1,270 x 610 mm T-slots - 5 x 18 mm Max. table load - 1,350 kg Distance between the spindle face and the table - 150 - 760 mm TRAVELS X-axis - 1,070 mm Y-axis - 610 mm Z-axis - 610 mm SPINDLE Max. spindle speed - 12,000 rpm Spindle taper - SK40 TOOL MAGAZINE Number of tools - 24 Max. tool diameter - 80 mm Max. tool weight - 7 kg

: 40 mmthreading in St 60: M24 threading in GG 20: M30 Short spindle: MK 3 Center of spindle to wall or column: 293 mmspindle turning speed - stepless: 160 - 2250 U/minColumn diameter: 115 mmspindle stroke: 120 mmMachine table - usable table surface: 514 x 360 mmT-Slots Amount - Width - Distance: 2 x 14 x 224 mmDistance spindle-table min.: 117/701 mmfeed: 0,10 + 0,20 mm/UMotor output: 1,45 / 1,9 kWheight of the machine: ca. 1840 mmweight of the machine ca.: 285 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mmy-travel: 400 mmz-travel: 330 mmtotal power requirement: kWweight of the machine ca.: 2100 kgdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 85 mmx-travel: 400 mmy-travel: 250 mmz-travel: 140 mmw-axis: 450 mmtable surface area: 600 x 380 mmtable load: 300 kgspeeds: 30 - 2500 U/minadjustment speed: 0,02 - 0,08 mm/mintool taper: SK 30 Control: Elesta CNC 211 total power requirement: 9,2 kWweight of the machine ca.: 3,5 tdimensions of the machine ca.: 2750 x 1700 x 2700 mm- CNC Control Elesta 211- with misc. tool holdersThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

BAZ Johnford FMC 850 for sale The machine is built in 1999 and can be viewed under chipboard. Enclosed is a type picture of the machine! Available in mid-June!

bore capacity in steel (diameter): 40 mmarm length: 1050 mmworkpiece height max.: - mmturning speeds: 15 - 2800 U/minfeed range: 0,075 - 0,45 mm/mindimensions: 2450 x 1300 x 2300 mmWeight: 1500 kgControl: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 400 mmy-travel: 400 mmz-travel: 375 mmtotal power requirement: kWweight of the machine ca.: 7150 kgdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1270 mmy-travel: 660 mmz-travel: 610 mmtotal power requirement: kWweight of the machine ca.: 8680 kgdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 630 mmy-travel: 500 mmz-travel: 500 mmcontrol: Heidenhain TNC 430 spindle speed:: 10000 U/minpower capacity - milling spindle: 13/9 kWfeed: 30 m/minrapid traverse: 30 m/minno. of workpieces in the magazine: 24 Stücktool taper: SK 40 table surface area: 800 x 500 mmtable load: 0,5 tOverall size: 1,9 x 3,3 x 2,6 mmweight of the machine ca.: 4500 kgUsed vertical machining centre in good condition.- external eletronic hand wheel- coolant system- servo tool magazinThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 25462 Technical data: - Drilling capacity in ST 37 to 32 mm - Drill spindle holder with tightening thread M 12 / MK 3 - Drilling spindle speeds 120 to 1600 rpm - Drilling unit height-adjustable by hand crank - Larger distance table / boring spindle 650 mm - Drilling spindle stroke with fine feed by handwheel 130 mm - Drilling spindle projection 205 mm - Drill milling unit can be rotated 360° - Coordinate table with 3 T-slots 730 x 210 mm - Table travel X-axis 250 mm / Y-axis 200 mm - Drive 400 V / 1.5 kW - Space requirement approx. W 1150 x H 1100 x D 1100 mm - Weight approx. 270 kg

Drilling capacity St 60/GG 22: 40/50 mm Thread cutting St 60/GG 22: M 36/M 45 Table clamping surface: 600 x 1800 mm Height adjustment of the boom: 450 mm small/large drilling radius: 305/1305 mm Spindle holder: SK 40 Quill stroke: 200 mm Spindle speeds infinitely variable: 15 - 2800 rpm Infinitely variable feeds: 5 - 2000 mm/min Spindle drive, frequency-controlled: 5.5 kW electr. Connection: 400 V, 14 kVA Weight: 3400 kg Space requirement: 3800 x 2000 x 2500 mm

Key data: 13 mm

Vario Speed 280 - 4500 rpm 380 V 16 A Length 0.70 m Width 0.57 m Height 2.05 m Steel table Vise Drill Chuck Röhm Supra 1-13 mm

CONTROLS  CNC controls OKUMA OSP-P300MA WORKING RANGE -CUBIC-  X-axis travel: 560 mm  Y-axis travel: 560 mm  Z-axis travel: 625 mmSPINDLE / HEAD  spindle revolutions (max): 15000 /minX/Z SLIDE  number of tool positions (total): 12   number of live positions: 12   - rotation speeds (max): 5000 /min  - drive power: 5.5 kWTOOL MAGAZINE  number of positions: 146 AUTOMATIC WORKLOAD EQUIPMENT  number of store positions: 2   Workpiece diameter max.: 600 mm  worpiece length max.: 900 mm  pallet length: 400 mm  pallet width: 400 mm  number of pallets: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzATTACHMENTS  chip conveyor: yes   coolant unit: yes   through spindle coolant attachment: yes   closed cabin: yes   European CE standards: yes

x-travel: 1016 mmy-travel: 610 mmz-travel: 760 mmtotal power requirement: ? kWweight of the machine ca.: 7,5 tdimensions of the machine ca.: 3 x 2,5 x 3,2 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1016 mmy-travel: 610 mmz-travel: 760 mmtotal power requirement: ? kWweight of the machine ca.: 7,5 tdimensions of the machine ca.: 4 x 3 x 3,2 mTable clamping surface 1,270 x 590 mmmax. table load 1,350 kgfeed rate 15,000 mm/minrapid traverse 20 m/minTool holder ISO 4024-position tool changerChip conveyorIKZPreparation for IR - measuring probe ( Renishaw )SELCA controlThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Witzig & Frank TriFlex 5XYear of manuf. : 2018 Control : Fanuc 30i-B ____________Description:In General:Year of construction:2018Control system:FanucProcessing stations:5 piecesLoading station:1 pieceTravelling range:X-axis:450 mmY-axis:500 mmZ-axis:450 mmRapid traverse X/Y/Z:50 m/minTurret:Number of stations:8Speed:13,300 rpmTorque:58 NmTool holder:HSK 63 CWorkpiece/device:Dimensions max.:350 x 350 x 350 mmMax. permissible mass:250 kgMedia supply line:6 piecesNC swivelling rotary table:A-axis:+/- 150°B-axis:360°Max. load:250 kgTable diameter:320 mmEquipment:Loading/unloading:Fanuc Robot M20i-AChip removal:2x chip conveyorsCoolant supply:IKZ system, 20 barPosition measuring systems:Direct in all axes

Auerbach AX TBE 200.1Year of manuf. : 2013 ____________Description:In general:Drilling-ø (max.):3,5 mmDrilling depth (max.):200 mmDeep drilling module:Technology:DrillingspindleSpeed (max.):10.000 rpmPower:3,5 kWTaper:HSK-A40Equipment/Accessory:Chipmanagement:Chip trayCoolingmanagement:Internal cooling unit with Filter and High-pressure, 140 barWorkpiececlamping:Collet chuck, SMW Autoblok KSZ-MB-040-Z140Oilmistseparation:Electrostatic extraction, LTA AC 500Further Accessory:Misc. Single lip driller

Soraluce SLP-6000Year of manuf. : 2017 Control : Heidenhain TNC 640 Speed : 5000 rpmMovement X/Y/Z : 4500/1800/1300 mm____________Description:In General:Year of manufacture:2017Control system:Heidenhain TNC 640Travel range X/Y/Z:4,500/1,800/1,300 mmSpindle speed:5,000 rpmTool holder:SK 50Milling head (spindle):Technology:Diagonal head with gear spindleIndex:0.001°Speed:5,000 rpmTool holder:SK 50Max. power:43 kWMax. torque:1,045 NmCoolant supply:Coolant + blast airWorking table:Clamping surface:6,000 x 1,100 mmT-slots:6 x 22H12, spacing 140 mmTool magazin:Technology:Chain magazineNumber of stations:40Tool changer:Double gripper (horizontal/vertical)Max. tool diameter:125 (250) mmMax. tool length:400 mmEquipment:Position measurement systems:Direct scalesChip removal:Chip conveyorCoolant supply:Internal coolant system with filter, 20 barWorkpiece measurement:Funk M&H probeSet-up oper ...

Technical data: X-axis 2,000 mm Y-axis 2,500 mm Z-axis 1,250 mm W-axis 800 mm Spindle power 37 kW Spindle speed 1.6 – 1,500 rpm. Tool holder SK 50 Control CNC HEIDENHAIN TNC415 Table dimensions 1,800 x 1,600 mm max. table load 8 to B-axis 360° Weight approx. 30,000 kg Motor fan new Simodrive modules new 2024 November SK 50 Cone Reground 2024 New cover X axis in 2024 Y scale 2023 overtaken by Heidenhain

A CNC vertical machining center Spinner is available. Travel X/Y/Z: 650mm/450mm/460mm, table dimensions X/Y: 710mm/450mm, max. table load: 500kg, speed: 8000rpm, tool holder: SK40, tool positions: 24, rapid traverse: 24m/min, feed: 10m/min, positioning accuracy: +/-0.01mm, repeatability: +/-0.005mm. Machine dimensions X/Y/Z: approx. 2400mm/2100mm/2600mm, weight: approx. 9500kg, control: Fanuc. Without vise and dividing head. The spindle was recently renewed and the hydraulic pump is currently being renewed. The rotary table is leaking oil. Documentation available. An on-site inspection is possible.

control: OSP P200 M Number of axles: 4 St.x-travel: 1000 mmy-travel: 1000 mmz-travel: 900 mmb-axis: 0.001 °size of pallet: 630 x 630 mmtool piece magazine with: 200 milling spindle: SK50 spindle turning speed - stepless: 12000 U/minchip conveyor: kWmisc. accessories: weight of the machine ca.: 30 tdimensions of the machine ca.: 10 x 4 x 3.5 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Mikron HSM 800 – High Speed Machining CenterYear 2007 | Heidenhain iTNC 530 | 24,000 rpm | 3-pallet changerHigh-precision CNC machining center from Mikron / GF AgieCharmilles, designed for demanding HSC applications such as mold & die, graphite and electrode machining, as well as flexible production.Travels: X 800 mm / Y 600 mm / Z 500 mm with pallet size 800 x 600 mm. Equipped with a 3-pallet changer for efficient automated operation.The machine features a high-speed spindle up to 24,000 rpm with HSK-A63 interface and a 50-position tool magazine.Well equipped with high-pressure through-spindle coolant (18–70 bar) including band filter system, chip conveyor, minimum quantity lubrication, oil mist extraction, rotating viewing window and probing system (M&H).Additional features include APS (Advanced Process System) and ITC (Intelligent Thermal Control) for maximum process stabi ...

Mikron HSM 400 is a high-precision, high-speed machining center STEP TEC spindle, type HVC140-SB-10-15/42-3F-HSK-E40Spindle hours: 26897 hManufacturer: Step-Tec AG (Switzerland)Spindle type: HVC140-SB-10-15/42-3F-HSK-E40Tool interface: HSK-E40Maximum spindle speed: 42,000 rpmPower: 13 kW (40% duty cycle), 10 kW (100% duty cycle)Torque: 4.25 Nm (40% duty cycle), 3.2 Nm (100% duty cycle)Lubrication: oil-air lubrication systemAxis Drives and DynamicsDrive system: AC servo motors with ball screw drivesFeed rate (X/Y/Z): 0 – 40 m/minAcceleration (X/Y/Z): 1 g (10 m/s²)Rotary Axis PerformanceB-axis speed: up to 54,000 °/minC-axis speed: up to 90,000 °/minTool SystemTool interface: HSK-E40Tool magazine capacities: 18 / 36 / 68 tools depending on configurationTool change time: approx. 10 secondsChip-to-chip time: approx. 12.5 secondsPallet and Clamping SystemErowa UPC pallet system: 320 ×  ...
