presses used for sale (1,713)

Key data: 300 t

300 T Gantry Straightening Press – Gantry Press – 3,500 × 2,000 mm Table, 1,000 mm Open Height The machine shown here has already been built and delivered on behalf of a customer. We can manufacture this machine for you at very short notice – gladly taking individual options into account. It is a hydraulic gantry press with a pressing force of 300 t for straightening, assembly and machining processes on large-format components. Base price: 142.000 € net Options (on request): The options listed are based on completed customer projects and enable the machine to be specifically adapted to the respective application. The basic machine represents a functional basic design – in practice, in most cases it is expanded with additional equipment and configured accordingly for the specific project. Table top with T-slots according to DIN 650 75 mm table top Servo hydraulic ...

Key data: 300 t

300 T Gantry Straightening Press – Gantry Press – 3,000 × 2,000 mm Table, 1,000 mm Open Height The machine shown here has already been built and delivered on behalf of a customer. We can manufacture this machine for you at very short notice – gladly taking individual options into account. It is a hydraulic gantry press with a pressing force of 300 t for straightening, assembly and machining processes on large-format components. Base price: 102.000 € net Options (on request): The options listed are based on completed customer projects and enable the machine to be specifically adapted to the respective application. The basic machine represents a functional basic design – in practice, in most cases it is expanded with additional equipment and configured accordingly for the specific project. Table top with T-slots according to DIN 650 75 mm table top Servo hydraulic ...

BECKER & VAN HÜLLEN deep drawing press was built in Germany by Becker & van Hüllen Niederrheinische Maschinenfabrik GmbH & Co. KG. The machine has been continuously maintained and upgraded throughout its service life. In 2022, a major upgrade was carried out, which included replacing the seals, upgrading the control system, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The BECKER & VAN HUELLEN 650T is used in industries specialising in stamping, production of automotive parts, tanks and other parts that require high press force and multi-stage forming. Its main purpose is deep drawing. The machining process is performed with a high press force of up to 650 tonnes. The two-stage design allows successive forming stages to be carried out in a single work cycle, thus enabling the manufacture of parts with even the most complex shapes. The m ...

LASCO TSP 160 S forging press was built in Germany by Langenstein & Schemann A.G. (Lasco Umformtechnik GmbH). The machine has been continuously maintained and upgraded throughout its service life. In 2019, a major upgrade was carried out, which included replacing the seals, upgrading the control system, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The LASCO TSP 160 S is an extremely versatile hydraulic press designed for the production of extremely precise, repeatable and yet complex parts. It is ideal for forges and industrial plants that require high press forces and high repeatability of the manufactured parts. Its main purpose is die forging, metal stamping and metal forming, especially hot forming of steel or aluminium workpieces. It also enables punching, calibration of forgings, trimming and blanking of workpieces after the forgin ...

DIEFFENBACHER PO 500A hydraulic press was built in 1978 in Germany by J. Dieffenbacher GmbH & Co. The machine has been regularly maintained and upgraded throughout its service life. In 2017, a major upgrade was carried out, which included replacing the electrical cabinet, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The seals and electrical system were also replaced. The DIEFFENBACHER PO 500A is the perfect choice for even the most demanding metal forming operations. It enables the execution of such operations as die stamping, punching, calibration of forgings and hot and cold bending. All these machining processes are performed with a high press force of up to 500 tonnes, which, combined with a highly dynamic slider, guarantees the best machining results. The machine is also characterised by a rigid body made of thick steel plates and a ...

TMP VORONEZH KA2536 crank press was built in 1979 in the USSR by the Voronezh Mechanical Press Plant (Воронежский механический завод). The offered machine is perfect for many industries, especially those which require high press force and high repeatability of produced parts. This is because it enables even the most demanding metal forming processes to be performed, i.e. stamping of structural components, forming of parts, hot and cold forging, deep drawing operations and the production of parts with a large surface area. All of these machining processes are performed with a high press force of 400 tonnes and can be carried out continuously, increasing production efficiency and reducing downtime to a minimum. The crank mechanism used ensures uniform force transfer, which translates into precise slider feed and repeatability of each cycle. This solution is part ...

ARISA S-2-400-260-FD mechanical press was built in 2000 in Spain by Arisa S.A. (now Nidec Press & Automation Co. (NP&A)). The machine on offer is an excellent choice for series production of components used in the broadly defined automotive or machinery industry. It enables precise punching and stamping of metal parts. All these machining processes are performed with a high press force of up to 400 tonnes, which, combined with a highly dynamic slider, guarantees the best machining results. The ARISA S-2-400-260-FD features a robust, stress-relieved gantry design with an open side wall. This design maintains high rigidity, stable parameters and repeatability during even the most intensive operations with high press force. It is distinguished by the use of two connecting rods, a flywheel drive and an eccentric pinion gear. This solution ensures even torque transmission and smooth and pr ...

Machine Group: Single Column Eccentric Press 25 to Make: Colombo Agostino Type CA.25.V Year of Make: 1988 Control: conventional

DIEFFENBACHER PO-F 1250 A hydraulic press was built in Germany in 1981 by J. Dieffenbacher GmbH & Co. The machine was regularly maintained and upgraded throughout its service life. In 2016, a major upgrade was carried out, which included replacing the electrical cabinet, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The piston seals were also replaced and measuring scales were added for precise position measurement of the slider, top ejector and lower die cushion. The DIEFFENBACHER PO-F 1250 A is an extremely versatile hydraulic press for demanding metal forming applications. Its main purpose is die stamping of steel components, calibration of forgings, dogging, hot and cold forging, cold forming and other operations that require very high press forces. All these machining processes are performed with a high press force of up to 1250 tonn ...

A completely renewed and overhauled Oevermann press is available. Press force: 150t, reach: 400mm, stroke: 400mm, installation height: 600mm, table dimensions X/Y: 1200mm/710mm, drive power: 37kW, weight: approx. 9500kg. The following areas have been renewed and overhauled: hydraulics, components, tank, lines and safety devices. The control system has been completely newly installed. Documentation available. An on-site inspection is possible.

A hydraulic transfer molding press Lauffer is available. Press force: 125t, power: 15kW, hydraulic oil volume: 300l, machine dimensions X/Y/Z: approx. 2200mm/1400mm/3000mm, weight: approx. 6500kg. An on-site inspection is possible.

Pressure total: 1200 ton Ram stroke: 600 mm Slide adjustment: 500 mm Shut height (stroke down, adjustment up): 1250 mm Free frontal opening L-R: 3550 mm Table surface area : 3500 x 2700 mm Slide area: 3500 x 2700 mm Die cushion capacity in table: 240 ton Die cushion stroke: 250 mm Ejector in ram: 95 ton Ejector stroke in ram: 150 Number of strokes: 10 - 16 s.p.m. Height over floor approx.: 9000 mm Weight of machine approx.: 280 ton

Pressure total: 2500 ton Stroke: 1700 mm Daylight: 2200 mm Free frontal opening L-R: 5100 mm Table surface area : 5000 x 2500 mm Slide area: 5000 x 2500 mm Die cushion capacity in table: 650 ton Die cushion stroke: 0 - 200 mm Die cushion pad area: 4260 x 2150 mm Max. die size: 5000 x 2500 x 1600 mm Ejector in ram: 65 ton Ejector stroke in ram: 200 mm Approach speed: 380 mm / sec Working speed: 200 mm / sec Return speed: 300 mm / sec Die weight at the ram max.: 30 ton Die Weight total: 60 ton Oil volume: 6000 l Required power: 2 x 230 kW Height over floor approx.: 9700 mm Weight of machine approx.: 533 ton

Manufacturer Erfurt Pressen Machine type Leinhaas Technology Country of origin Germany (BRD) Machine data Parameter Value Unit / Notes Max. press force 4500 kN Stroke rate (continuous) min. 15 strokes/min Max. stroke rate (tool designed for) 75 strokes/min Ram stroke 3 – 200 mm Ram adjustment 120 mm Installation height (min.) 600 mm Max. installation height 670 mm Dimensions of press table Press table length 2000 mm Press table width 1250 mm T-slots (press table) DIN 650 – 28 H12 Number of T-slots (table) 11 pcs Distance between T-slots 150 mm Dimensions of press ram Slide length 2000 mm Slide width 1200 mm T-slots (slide) DIN 650 – 22 H12 Number of T-slots (slide) 13 pcs Distance between T-slots 150 mm Press frame opening Side opening 900 mm Front opening 2200 mm Tool clamping Tool clamping height (upper tool) 80 mm Tool clampin ...

Pressure total: 1000 ton Stroke: 170 mm Shut height (stroke down, adjustment up): 490 mm Slide adjustment: 16 mm Max. stroke rate: 32 s.p.m. Table surface area : 800x800 mm Ram surface: 825x860 mm Free frontal opening L-R: 900 mm Upper ejector stroke: 16 mm Upper ejector capacity: 10 ton Lower ejector stroke: 80 mm Lower ejector capacity: 32 ton Dimensions L x W x H: 2950x1950x4090 mm Machine weight: 26 kg Main drive: 33,5 kW

Pressure total: 1000 ton Stroke: 170 mm Shut height (stroke down, adjustment up): 490 mm Slide adjustment: 16 mm Max. stroke rate: 32 s.p.m. Table surface area : 800x800 mm Ram surface: 825x860 mm Free frontal opening L-R: 900 mm Upper ejector stroke: 16 mm Upper ejector capacity: 10 ton Lower ejector stroke: 80 mm Lower ejector capacity: 32 ton Dimensions L x W x H: 2950x1950x4090 mm Machine weight: 26 kg Main drive: 33,5 kW

Pressure total: 1200 ton Ram stroke: 600 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1600 mm Free frontal opening L-R: 4550 mm Table surface area : 4500 x 2700 mm Slide area: 4500 x 2700 mm Die cushion capacity in table: 225 ton Die cushion stroke: 200 mm Number of strokes: 9 s.p.m. Height over floor approx.: 9000 mm Weight of machine approx.: 344 ton

pressure: 200 tnominal power: 2000 kNstroke length max.: 1700 mmworking feed: 50 mm/secweight of tools max.: 50000 kgvoltage: 400 Vtable-size: 4.800 x 2.400 mmtotal power requirement: 99 kWweight of the machine ca.: 113 tdimensions of the machine ca.: mpassage width: mmstroke: mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 135 tchamfer lenght: 3050 mmdistance between columns: 2550 mmstroke: 400 mmquantity of oil: 300 lControl: Cybelec Visitouch total power requirement: 15 kWweight of the machine ca.: 10.700 Kgrange L-W-H: 4200x2200x3200 mmEquipment:- Controlled axes: Y1, Y2, X, R, Z1, Z2- SICK” light barrier in front of the machine- Side safety guards- Protective grille behind the machine- foot switch- incl. toolsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 100 t

Durendus DCD-100 – Hydraulic single-column press 10–100 t – 800 × 600 mm For sale is a hydraulic single-column press (C-frame) from the manufacturer Durendus with an adjustable press force from 10 to 100 t. The machine is designed for demanding forming, deep-drawing and assembly processes and has an integrated thermoforming pad and a modern Siemens control system. Thanks to high travel speeds and precise control, it is suitable for both series production and flexible individual applications. Technical data + information: Hydraulic Single Column Press – DCD-100 General information - Manufacturer: Durendus - Model: DCD-100 - Type: C-frame / single-column press - Press force: 10–100 t (adjustable) - Total weight: approx. 6,500 kg - Overall dimensions: approx. 1,850 × 1,845 × 3,520 mm - Table height above floor: 1,000 mm Workspace - Max. distance table ...

pressure: 125 tchamfer lenght: 3550 mmdistance between columns: 3050 mmcolumn arm: 300 mmstroke of ram: 240 mmquantity of oil: 200 lcontrol: CYBELEC Cybtouch 15 range L-W-H: 4500x2200x3000 mmEquipment/accessories:- manual crowning- 3 x manual stop fingers- die displacement- pneum. upper tool clamping- foot switchThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- Cybelec 2D Controll system- 4 Axis controlled Y1 / y2 / X / Delta-R- 1 set universal tooling- Fiessler laser safe - Sheet support arms front side

pressure: 63 tstroke rate in continuous stroke: 90 minforce: 2200 NmTorque: 12500 Nmno. of strokes: 56 / 90 Hub/minLabour performance: 5,5 kWsheet thickness - max.: 6,3 / 3,2 mmcutting surface: 1600 mm²distance between columns: 320 mmthroat: 315 mmmin. ram stroke: 8 mmmax. ram stroke: 120 mmram adjustment: 70 mmram surface: 400 x 500 mmtool hole in ram: 40 mmtool shank hole (depth x diameter): 92 mmT-slots: 2 Stktotal power requirement: 6 kWweight of the machine ca.: 5,5 tRated force: 630 kN (63 tons)Maximum sheet thickness: 3.2 mmRam stroke: 8–120 mmStroke rate: 56 / 90 strokes per minuteShut height (table to ram): 560 mmRam adjustment: 70 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 tstroke: 500 mmtotal power requirement: 20,5 kWweight of the machine ca.: 7,5 tRated force: 160 Mp (˜ 1600 kN / 160 tons)Operating pressure: 144 kp/cm²Speed:Downward: 200 mm/sUpward: 250 mm/sRam stroke: 500 mmThroat depth: 360 mmMax. distance (table to ram): 800 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Press height 140 mm Press force 70 kN (7 t) Hydropneumatic actuator Compressed air connection 7 bar Air consumption per work stroke 35 l Length 1,100 mm, depth 950 mm, height 1,230 mm Weight 550 kg

pressure: 150 tstroke: mmdistance between table / ram: 660 mmtable surface area: 1500 x 610 mmtable height over floor: mmdiameter of seal: 150 mmrange L-W-H: 1,7 x 1,5 x 2,3 mweight of the machine ca.: tC-frame press- hole in table Ø 120 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- Optional T1 bending support holders- Optional T2 bending support holders- Motorized Crowning over controlled- Lazer safe CE-Safety- Hydraulic tool clamping
