presses used for sale (1,824)

Schaal SEP 80 SZV 302 Automatic Punching Press Machine • 2001 • ID: 34126 Frame and guidance on this unit are built for repeatability: a rigid double-column O-frame in vibration-damping cast iron, with the ram carried in 6-point play-free roller guides. Power is transmitted by a flywheel drive with pneumatic clutch/brake combination. Year of manufacture is 2001. Control and protection - Unidor electronic control system giving repeatable stroke accuracy and fast setup; integrated tool safety device protecting dies from damage caused by misfeeds or incorrect part positioning, which reduces downtime and tooling costs. Key data - pressing force 800 kN (80 tons); 60 – 320 min⁻¹; ram stroke adjustable 8 – 80 mm; ram adjustment 80 mm; ram surface 700 × 500 mm; clamping plate 830 × 700 mm at 80 mm thickness; table opening 500 × 200 mm; strip feed clearance 120 ± 40 mm; drive po ...

Configuration 2 x BRUDERER BBV 202/120 DOUBLE strip feeder KOHLER leveling machine 100.180/2.500.2M, year of construction 1992 Unwinding reel / coil reel Soundproof cabin Conveyor belt for part removal Lifting and sorting device for containers Roller conveyors and stacking racks Technical documentation available Complete BRUDERER high-performance punching line consisting of a precision punching machine BSTA 50 EL, BRUDERER strip feeder BBV 202/120, KOHLER leveling machine, unwinding reel, soundproof cabin, and discharge and conveying equipment. The system is designed for the efficient processing of strip material in high-speed punching operations. Extensive technical documentation is available. Technical Specifications Stroke Power 500 kN (50T) Table area: 940 x 580 mm Tool length max. 950 mm Operating hours 49637 Strip width: Max. 202 mm Machine dimensions: 3100 x 2700 x 1800 m ...

pressure:063 tthroat:250 mmstroke:8 - 100 mmno. of strokes:56 / 84 /mindistance table/ram, max. stroke up, adjustment up:415 mmtable surface area:710 x 500 mmhole in the table:320 mmtable height over floor:800 mmpassage to the back:320 mmram surface:450 x 280 mmram adjustment:63 mmweight:4,1 tdimensions (W x D x H):1,35 x 2,0 x 2,6 moverload protection in ram:mechanical

pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:51,0 kWweight:33,0 tdimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary

pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:52,0 kWweight:33,0 tDimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary

pressure:400 tdistance between columns:3250 mmdistance table/ram, max. stroke up, adjustment up:1000 mmstroke:800 mmtable surface area:3250 x 1400 mmtable height over floor:1250 mmdie cushion capacity:170 tdie cushion stroke:200 mmdie cushion area:1800 x 1000 mmdistance between cutting impact cushioning:2610 mmside window:800 mmram surface:3250 x 1400 mmreturn capacity:51 tspeed down:300 mm/sspeed up:300 mm/sworking speed:16 - 33 mm/squantity of oil:2900 lpower requirement:100,0 kWweight:70,0 tDimensions (WxDxH):4,9 x 3,1 x 7,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic

pressure:400 tdistance between columns:1250 mmstroke:250 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:825 mmtable surface area:1000 x 900 mmcolumn travel -side:400 x 700 mmram surface:1000 x 900 mmram adjustment:100 mmcapacity of ejector in table:40 tejector stroke:160 mmpower capacity:270,0 kWweight:44,0 tDimensions (WxDxH):2,4 x 3,6 x 7,2 mheight over floor:6,4 m

pressure:125 tstroke:25 fix mmno. of strokes:70 - 700 /mindistance between columns:1150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:1150 x 1000 mmhole in the table:900 x 220 mmside window:650 mmram surface:990 x 850 mmram adjustment:60 mmmaterial width:250 mmmaterial thickness:2,5 mmpower requirement:46,5 kWweight:29,5 troll feed:mechanical, Schuler, WK 8-250

pressure:250 ttable length:4000 mmtable width:3000 mmControls:SIEMENS SIMATIC C7 PRESS DESIGN:. - frame design : 4 column :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):250 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - tool weight max.:100000 kg - number of T-slots:12 - distance between T-slots:375 mm - height above floor level:390 mmRAM:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - number of T-slots:12 - distance between T-slots:375 mm - stroke:2900 mm - tool weight max.:50000 kgRAM (HYDR. PRESS):. - number of main-cylinders:1 - approximation velocity max.:180 mm/s - working velocity max.:50 mm/s - restoring force of ram:95 toTOOL ASSEMBLY DIMENSIONS:. - distance table - ram max.:2750 mm - distance between columns (H-frame):4100 mm - Free passage ...

Pressure:080 tthroat:380 mmstroke:8 - 112 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:472 mmtable surface area:840 x 610 mmtable height over floor:800 mmpassage to the back:520 mmram surface:650 x 400 mmram adjustment:70 mmpower capacity:7,5 kWweight:6,9 tDimensions (WxDxH):1,1 x 2,15 x 3,2 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:800 tdistance between columns:2900 mmstroke:350 mmControls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 toPRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mmRAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /minRAM (MECHAN. PRESS):. - ram adjustment:350 mmTOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):256 ...

pressure:250 tdistance between columns:930 mmstroke:200 mmDistance table/ram, stroke up:600 mmtable surface area:900 x 860 mmdie cushion capacity:100 tdie cushion stroke:50 mmdie cushion area:350 x 400 mmtable height over floor:950 mmside window:380 x 380 mmram surface:850 x 700 mmfeed down:400 mm/sfeed up:400 mm/sworking feed:30 mm/soil volume:350 lpower capacity:45,0 kWweight:11,5 tDimensions (WxDxH):2,0 x 1,2 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary

pressure:1000 ttable length:4000 mmtable width:1600 mmControls:SIEMENS S7-1500F PRESS DESIGN:. - frame design : Transfer press :. - Drive type : mechnical :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. - number of tables:2 PRESS FORCES:. - total force (nominal):1000 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):1600 mm - height above floor level:600 mm - autom. tool clamping device : yes :. RAM:. - stroke:400 mmRAM (MECHAN. PRESS):. - ram adjustment:300 mm - ram adjustment:100 mm - number of strokes min:8 /min - number of strokes max:50 /min - hydraulic overload protection : yes :. TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):900 mm - shut height (stroke down, adjustment up):766 mm - distance between columns (H-frame):4250 mm - Free passage between  ...

pressure:1000 tdistance between columns:3030 mmstroke:350 mmDistance table/ram, max. stroke up, adjustment up:1400 mmtable surface area:3000 x 2000 mmtable height over floor:430 mmside window:1450 x 1400 mmram surface:3000 x 2000 mmspeed down:300 mm/sspeed up:340 mm/sworking speed:18 - 44 mm/sreturn capacity:120 toil volume:4400 lwidth with platform:4950 mmpower capacity:2 x 90,0 + 10,0 kWweight:87,0 tDimensions (WxDxH):4,35 x 3,65 x 7,55 mheight over floor:6,05 mheight beneath floor:1,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:200 tdistance between columns:1650 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1200 mmtable surface area:1600 x 1250 mmdie cushion capacity:80 tdie cushion stroke:300 mmdie cushion area:1300 x 900 mmtable height over floor:800 mmram surface:1600 x 1250 mmoil volume:ca. 2000 lpower capacity:43,0 kWweight:25,0 tDimensions (WxDxH):2,9 x 2,3 x 5,8 mheight beneath floor:0,85 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20

pressure:350 tdistance between columns:1350 mmstroke:900 mmdistance table/ram, max. stroke up, adjustment up:1300 mmtable surface area:1300 x 1000 mmpressure of drawing cushion in table:100 tstroke of drawing cushion in table:380 mmdie cushion area:350 x 285 mmcapacity of ejector in ram:25 tejector stroke in ram:200 mmtable height over floor:750 mmram surface:1300 x 1000 mmspeed down:500 mm/sspeed up:160 - 470 mm/sworking speed:16 - 44 mm/sdrawing speed:57 - 160 mm/sreturn capacity:32 toil volume:1700 lpower requirement:91,0 kWDimensions (WxDxH):3,75 x 2,8 x 7,2 mheight over floor:5,28 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:in TDC foundation pit:necessary

pressure at min. stroke:3 tthroat:150 mmstroke:- 39 mmdistance table/ram, max. stroke up, adjustment up:200 mmtable surface area:280 x 380 mmpressure at min. stroke:1,5 tno. of strokes with min. stroke:- 80 /minno. of strokes with max. stroke:- 50 /minhole in the table:45 mmtable height over floor:790 mmram surface:115 x 100 mmRequired air-pressure:4 barweight:0,2 tDimensions (WxDxH):0,5 x 0,9 x 1,4 m

pressure at min. stroke:3 tthroat:150 mmstroke:- 40 mmdistance table/ram, max. stroke up, adjustment up:200 mmtable surface area:280 x 250 mmpressure at max. stroke:1,5 tno. of strokes with min. stroke:- 80 /minno. of strokes with max. stroke:- 50 /minhole in the table:45 mmtable height over floor:810 mmram surface:115 x 100 mmRequired air-pressure:4 barweight:0,15 tDimensions (WxDxH):0,7 x 0,8 x 1,4 m

Pressure:063 tthroat:250 mmstroke:8 - 100 mmno. of strokes:120 /mindistance table/ram, max. stroke up, adjustment up:415 mmtable surface area:700 x 500 mmhole in the table:250 mmtable height over floor:800 mmpassage to the back:320 mmram surface:450 x 280 mmram adjustment:63 mmweight:4,5 tDimensions (WxDxH):1,6 x 2,0 x 2,8 moverload protection in ram:mechanical

pressure:65 tdistance between columns:930 mmstroke:1100 mmdistance table/ram, stroke up:2400 mmtable surface area:1340x700 / 930x1085 mmhole in the table:320x260 / 600x410 mmtable height over floor:850 mmside window:700 mmram surface:990 x 930 mmpower requirement:15,0 kWweight:8,0 tDimensions (WxDxH):2,8 x 2,6 x 5,2 mblank holder / ejector in ram:hydraulic side shifting device:hydraulic

Pressure:500 tdistance between columns:1550 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:900 mmtable surface area:1200 x 1300 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:150 mmdie cushion area:950 x 950 mmtable height over floor:1245 mmside window:1250 mmram surface:1200 x 1300 mmspeed down:750 mm/sspeed up:780 mm/sworking speed:105 mm/soil volume:4000 lpower requirement:263,0 kWweight:45,0 tDimensions (WxDxH):3,3 x 3,3 x 6,1 mheight over floor:6,1 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

Pressure:315 tdistance between columns:1350 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1000 mmtable surface area:1200 x 1300 mmtable height over floor:1245 mmside window:1250 mmram surface:1200 x 1300 mmspeed down:750 mm/sspeed up:680 mm/sworking speed:180 mm/soil volume:2000 lpower requirement:150,0 kWweight:35,0 tDimensions (WxDxH):3,3 x 3,3 x 5,5 mheight over floor:5,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch

pressure:200 tthroat:360 mmstroke:560 mmdistance table/ram, max. stroke up, adjustment up:780 mmtable surface area:740 x 720 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:200 mmdie cushion area:530 x 530 mmtable height over floor:920 mmram surface:560 x 560 mmslide drill hole x depth:70 mmpower requirement:35,0 kWweight:10,0 tdimensions:1,3 x 2,0 x 3,4 m

pressure:160 tdistance between columns:1340 mmstroke:300 mmDistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1300 x 900 mmtable height over floor:930 mmside window:600 mmram surface:1300 x 900 mmspeed down:367 mm/sspeed up:390 mm/sworking speed:58 mm/spower requirement:30,0 kWweight:15,0 tDimensions (WxDxH):2,5 x 2,2 x 4,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:063 tstroke:70 fix mmno. of strokes:15 - 60 /mindistance between columns:1340 mmwidth between oil collecting pans:1180 mmdistance table/ram, max. stroke up, adjustment up:328 mmtable surface area:1260 x 700 mmhole in the table:1000 x 100 mmtable height over floor:1000 mmcolumn travel -side:470 mmram surface:1300 x 650 mmram adjustment:100 mmpower requirement:27,5 kWweight:13,7 tDimensions (WxDxH):3,4 x 2,1 x 3,4 mclutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

Pressure:063 tthroat:250 mmstroke:10 - 100 mmno. of strokes:120 /mindistance table/ram, max. stroke up, adjustment up:380 mmtable surface area:700 x 500 mmhole in the table:180 x 140 mmtable height over floor:700 mmram surface:360 x 275 mmram adjustment:60 mmpower requirement:5,5 kWweight:3,8 tDimensions (WxDxH):1,9 x 1,7 x 2,4 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical

pressure:150 tthroat:400 mmstroke:30 - 150 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1000 x 750 mmhole in the table:320 x 200 mmtable height over floor:800 mmram surface:800 x 600 mmram adjustment:85 mmweight:10,0 tDimensions (WxDxH):1,4 x 2,2 x 3,1 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic
